S150 Bobcat Loader 11 Operation & Maintenance Manual DRIVING AND STEERING THE LOADER Available Controls Configurations The loader has three configurations available: • Standard Controls - Two Steering Levers control • Advanced Control System (ACS) (Option or Field • Selectable Joystick Controls (SJC) (Option) - (‘H’ Pattern) Left and right joysticks control left and Operation (Standard and ACS) Figure 19 The steering levers (1) [Figure 19] are on the left and Move the levers smoothly. Avoid sudden starting and Figure 20 The steering levers control forward and reverse travel and Forward Travel - Push both levers forward. Reverse Travel - Pull both levers backward. Normal Turning - Move one lever farther forward than Fast Turning - Push one lever forward and pull the other WARNING AVOID INJURY OR DEATH When operating the machine: Keep the seat belt fastened snugly. • The seat bar must be lowered. • Keep your feet on the pedal controls or footrests W-2261-0799 P-45122 1 PI-1849A Standard and ACS RIGHT TURN LEFT TURN RIGHT FAST TURN LEFT FAST TURN REVERSE FORWARD |
