5 - Fuse 5 on fuse holder C -SC5-

10 A

5)

5 A

6)

- Right headlight range control motor -V49-

5)

Left headlight range control motor -V48-

5)

Headlight range control adjuster -E102-

5)

Control unit for headlight range control -J431-

6)

Power output module for right headlight -J668-

6)

15

6 - Fuse 6 on fuse holder C -SC6-

5 A

- Power steering control unit -J500-

Data bus diagnostic interface -J533-

Selector lever sensors control unit -J587-

Mechatronic unit for dual clutch gearbox -J743-

15

7 - Fuse 7 on fuse holder C -SC7-

5 A

- Parking aid control unit -J446-

Automatic anti-dazzle interior mirror -Y7-

Garage door operating unit -E284-

Garage door operation control unit -J530-

Left washer jet heater element -Z20-

Right washer jet heater element -Z21-

Onboard supply control unit -J519-

Washer pump relay -J576-

Cabrio windbreak control unit -J531-

15

8 - Fuse 8 on fuse holder C -SC8-

5 A

10 A

2)

- Four-wheel drive control unit -J492-

15

9 - Fuse 9 on fuse holder C -SC9-

5 A

- Electronically controlled damping control unit -J250-

15

10 - Fuse 10 on fuse holder C -SC10-

5 A

- Airbag control unit -J234-

Seat occupied recognition control unit -J706-

7)

15

11 - Fuse 11 on fuse holder C -SC11-

10 A

1)4)

5 A

3)

- Air mass meter -G70-

3)4)

Structure-borne noise control unit -J869-

4)

Heater element for crankcase breather -N79-

1)4)

15

12 - Fuse 12 on fuse holder C -SC12-

10 A - Driver door control unit -J386-

Front passenger door control unit -J387-

30

13 - Fuse 13 on fuse holder C -SC13-

10 A - 16-pin connector, diagnostic connector -T16-

30

14 - Fuse 14 on fuse holder C -SC14-

5 A

- Rain and light detector sensor -G397-

12)

Selector lever sensors control unit -J587-

30

15 - Fuse 15 on fuse holder C -SC15-

5 A

15 A

13)

- Onboard supply control unit -J519-

Front interior light -W1-

Rain and light detector sensor -G397-

13)

30

16 - Fuse 16 on fuse holder C -SC16-

10 A - Climatronic control unit -J255-

30

17 - Fuse 17 on fuse holder C -SC17-

5 A

- Tyre pressure monitor control unit -J502-

7)

Tyre pressure monitor control unit 2 -J793-

30

18 - Vacant







19 - Vacant







20 - Vacant







 Audi TT

Fitting Locations

No.  801 / 1

Edition  04.2010

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
 permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
     with respect to the correctness of information in this document. Copyright by AUDI AG.

21 - Fuse 21 on fuse holder C -SC21-

10 A - Injectors -N....-

1)

15

22 - Fuse 22 on fuse holder C -SC22-

30 A - Cabrio windbreak control unit -J531-

9)

30

23 - Fuse 23 on fuse holder C -SC23-

20 A - Treble tone horn -H2-

Bass tone horn -H7-

30

24 - Fuse 24 on fuse holder C -SC24-

15 A - Mechatronic unit for dual clutch gearbox -J743-

30

25 - Fuse 25 on fuse holder C -SC25-

30 A

20 A

9)

- Heated rear window -Z1-

30

26 - Fuse 26 on fuse holder C -SC26-

30 A - Driver side window regulator motor -V147-

30

27 - Fuse 27 on fuse holder C -SC27-

30 A - Front passenger side window regulator motor -V148-

30

28 - Vacant







29 - Fuse 29 on fuse holder C -SC29-

15 A - Washer pump -V5-

15

30 - Fuse 30 on fuse holder C -SC30-

20 A - Cigarette lighter -U1-

10)

12-V plug socket -U5-

7)10)

15

31   Fuse 31 on fuse holder C -SC31-

40 A - Starter -B-

Terminal 50 voltage supply relay -J682-

15

32   Fuse 32 on fuse holder C -SC32-

5 A

- Steering column electronics control unit -J527-

30

33   Fuse 33 on fuse holder C -SC33-

5 A

- Control unit in dash panel insert -J285-

30

34   Fuse 34 on fuse holder C -SC34-

15 A

20 A

8)

- Navigation system with CD drive control unit -J401-

Radio -R-

Control unit with display for radio and navigation system -J503-

30

35   Fuse 35 on fuse holder C -SC35-

30 A - Digital sound package control unit -J525-

30

36   Fuse 36 on fuse holder C -SC36-

10 A - Engine control unit -J623-

Motronic current supply relay -J271-

Terminal 30 voltage supply relay -J317-

4)

30

37 - Fuse 37 on fuse holder C -SC37-

5 A

- Data bus diagnostic interface -J533-

30

38 - Fuse 38 on fuse holder C -SC38-

20 A - Relay for power sockets -J807-

11)

Cigarette lighter -U1-

11)

12-V plug socket -U5-

7)11)

30

39 - Vacant







40 - Vacant







41 - Vacant







42 - Vacant







43 - Vacant







44 - Vacant







45 - Vacant







46 - Vacant







 Audi TT

Fitting Locations

No.  801 / 1

Edition  04.2010

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
 permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
     with respect to the correctness of information in this document. Copyright by AUDI AG.

47 - Fuse 47 on fuse holder C -SC47-

5 A

- Satellite radio -R146-

7)

Telephone transmitter and receiver unit -R36-

Aerial amplifier for mobile telephone -R86-

TV tuner -R78-

Preparation for mobile telephone

30

48 - Fuse 48 on fuse holder C -SC48-

5 A

- Preparation for mobile telephone

15

49 - Vacant







Note

♦

1)

 for engine code BUB, CBRA only

♦

2)

 for engine code CDLB only

♦

3)

 engine code BWA, BPY, CDMA, CDLB only

♦

4)

 for engine code CBBB, CFGB only

♦

5)

 or manual headlight range control

♦

6)

 or automatic headlight range control

♦

7)

 for models with US equipment only

♦

8)

 for models with Japan equipment only

♦

9)

 Roadster

♦

10)

 up to May 2007

♦

11)

 from June 2007

♦

12)

 up to May 2009

♦

13)

 from June 2009

1.5

Location of fuses (SF) on fuse holder F

Torque settings
⇒ Electrical system, Repair Group 97, removing and installing fuse holders

 Audi TT

Fitting Locations

No.  801 / 1

Edition  04.2010

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
 permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
     with respect to the correctness of information in this document. Copyright by AUDI AG.

Fuse colours
40 A - orange
30 A - green
25 A - white
20 A - yellow
15 A - blue
10 A - red
7,5 A - brown
