Acura RL (1996-2004 year). Manual - part 143

2004 American Honda Motor Co., Inc.

107. Behind Right Kick Panel

A
(26-GRY)

PASSENGER’S
MULTIPLEX
CONTROL
UNIT

B
(22-GRY)

2004 American Honda Motor Co., Inc.

108. Behind Right Kick Panel

C444
(22-GRN)

C446
(20-GRY)
(’96-’03)
(22-GRY)
(’04)

C441
(24-BLU)

C442
(22-GRY)

2004 American Honda Motor Co., Inc.

109. Behind Right Side of Glove Box

BLOWER
MOTOR
HIGH RELAY

BLOWER
MOTOR
RELAY

2004 American Honda Motor Co., Inc.

110. Above Right Kick Panel (Left Similar)

C605
(2-YEL)
(‘96-‘98)

C412 (LEFT)
C445 (RIGHT)
(42-GRY)
