Acura RL (1996-2004 year). Manual - part 141

2004 American Honda Motor Co., Inc.

99. Left Side of Glove Box

C528
(2-BLK)

TRUNK
OPENER
MAIN
SWITCH

2004 American Honda Motor Co., Inc.

100. Below Right Side of Dash

SERVICE
CHECK
CONNECTOR
(2-BLU)

ABS
INSPECTION
CONNECTOR
(6-ORN)
(‘96-‘97)

2004 American Honda Motor Co., Inc.

101. Behind Glove Box

RECIRCULATION
CONTROL
MOTOR

C807
(2-YEL) (’96-’98)
(4-YEL) (’99-’04)

FRONT
PASSENGER’S
AIRBAG
INFLATOR(S)

2004 American Honda Motor Co., Inc.

102. Behind Glove Box

EVAPORATOR
TEMPERATURE
SENSOR

AIR MIX
CONTROL
MOTOR

C526
(2-GRY)

BLOWER
POWER
TRANSISTOR
