Lotus Service Notes
Section PN Refrigerant Circuit Expansion valve High pressure vapour line Receiver- drier Condenser Evaporator Low pressure vapour line Compressor
p115 Heater Circuit Heater matrix Heater Thermostat return rail housing
Header Coolant outlet tank housing Air bleed screws Outlet from head
Re-circulation pump Pipe runs through LH sill
p116 |
