KEY, LOCKS AND ALARM

260

Detaching the key blade

 Hold the remote key with the front side

(with the Volvo logo) facing up and move
the button on the key ring section to the
right. Slide the front cover slightly upward.

 The cover will loosen and can be

removed from the key.

 Remove the key blade by pulling it up.

Put the key blade back into its designated
spot in the remote key after use.

 Replace the cover by pressing it down

until it clicks into place.

 Slide the cover back.

> An additional click indicates that the

cover is correctly in place.

Related information

•

Locking and unlocking with detachable
key blade (p. 260)

•

Remote key (p. 248)

Locking and unlocking with

detachable key blade

The detachable key blade can be used to
unlock the vehicle from the outside, e.g. if the
battery in the remote key is discharged.

Unlocking

Pull the front left-hand door handle to its
end position to access the lock cylinder.

Put the key in the lock cylinder.

Turn the key clockwise 45 degrees so that
the key blade is pointing straight rear-
ward.

Turn the key blade back 45 degrees to its
original position. Remove the key from the
lock cylinder and release the handle so
that it returns to its original position
against the vehicle.

5. Pull the door handle.

> The door will open.

KEY, LOCKS AND ALARM

* Option/accessory.

261

NOTE

When the door is unlocked using the
detachable key blade and then opened, the
alarm will be triggered. The alarm must be
deactivated manually; see separate sec-
tion.

Locking

The left-hand front door can be locked by
inserting the detachable key into the door's
lock cylinder.

The other doors have lock mechanisms in the
side of the door that must be pushed in using
the key blade. The door will then be locked
mechanically and cannot be opened from the
outside.

The doors can still be opened from inside.

Manual door lock. This is not the child lock.

1. Remove the detachable key blade from

the remote key.

2. Insert the key blade into the opening for

the lock mechanism.

3. Push in the key until it stops, about 12 mm

(0.5 inch).

The door can be opened from both the
outside and the inside.
The door cannot be opened from the out-
side. To return to position A, open the door
using the inside door handle.

NOTE

•

The door's lock controls only lock that
specific door, not all doors simultane-
ously.

•

A manually locked rear door with acti-
vated child lock cannot be opened
from either the outside or the inside.
The door can only be unlocked using
the buttons on the key, the central
locking button, the keyless locking sys-
tem

*

 or Volvo On Call.

Related information

•

Detachable key blade (p. 259)

•

Arming and disarming the alarm (p. 278)

•

Starting the vehicle (p. 424)

•

Replacing the remote key's battery
(p. 254)

•

Remote key (p. 248)

KEY, LOCKS AND ALARM

* Option/accessory.

262

Electronic immobilizer

The electronic immobilizer is a start inhibitor
that helps prevent the vehicle from being
started by an unauthorized person.

The vehicle can only be started with the right
remote key.

The following instrument panel error mes-
sages are related to the electronic immobil-
izer:

Symbol Message

Meaning

Vehicle key
not found

See
Owner's
manual

Remote key not
recognized dur-
ing start. Place
the remote key
on the key sym-
bol in the cup
holder and try to
start the vehicle
again.

Remote immobilizer with tracking
system

9

The vehicle is equipped with a system that
makes it possible to track and locate the vehi-
cle and to remotely activate the immobilizer to
prevent the vehicle from being started. Con-
tact your nearest Volvo retailer for more infor-
mation and assistance activating the system.

The following instrument panel error mes-
sages are related to the remote immobilizer
with tracking system:

Symbol Message

Meaning

Remotely
immobilised

Vehicle not
possible to
start

The remote
immobilizer with
tracking system
is activated. The
vehicle cannot
be started. Con-
tact Volvo On
Call Service
Center.

Related information

•

Remote key (p. 248)

•

Ordering additional remote keys (p. 258)

Start and lock system type

designations

The following information contains type des-
ignations for the start and lock system.

Alarm system

USA FCC ID: MAYDA 5823(3)

This device complies with part 15 of the FCC
rules. Operation is subject to the following
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired opera-
tion.

Canada IC: 4405A-DA 5823(3)

This device is subject to the following condi-
tions: (1) This device may not cause interfer-
ence, and (2) this device must accept any
interference, including interference that may
cause undesired operation of the device.

Remote keys (Passive Entry

*

/Passive

Start)

USA

Volvo Standard Key FCC ID: YGO-
HUF8423MS

Volvo Tag ID FCC ID: YGOHUF8432MS

9

Only certain markets and in combination with Volvo On Call.

KEY, LOCKS AND ALARM

* Option/accessory.

263

This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:

(1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.

CAUTION: Changes or modifications not
expressly approved by the party responsible
for compliance could void the user’s authority
to operate the equipment.

Canada

Volvo Standard Key IC: 4008C-HUF8423MS

Volvo Tag ID IC: 4008C-HUF8432MS

This device complies with part 15 of the FCC
Rules and Industry Canada license-exempt
RSS standard(s). Operation is subject to the
following two conditions:

(1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.

Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes :

(1) l'appareil ne doit pas produire de brouillage,
et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre
le fonctionnement.

Immobilizer and Passive Entry

*

/

Passive Start systems

USA-FCC ID: LTQVO3134

This device complies with part 15 of the FCC
rules. Operation is subject to the following
two conditions:

(1) This device may not cause harmful interfer-
ence, and

(2) this device must accept any interference
received, including interference that may
cause undesired operation.

Any changes or modification not expressly
approved by the party responsible for compli-
ance could void the user's authority to operate
this equipment.

Canada-IC:3659A-VO3134

This device complies with Industry Canada
license-exempt RSS standards. Operation is
subject to the following two conditions:

(1) This device may not cause harmful interfer-
ence, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.

Related information

•

Remote key (p. 248)

KEY, LOCKS AND ALARM

* Option/accessory.

264

Keyless and touch-sensitive

surfaces

*

With the keyless locking and unlocking func-
tion, the remote key only needs to be within
range, e.g. in a pocket or bag. The vehicle can
then be locked or unlocked by touching the
pressure-sensitive surface on the door han-
dle.

Pressure-sensitive surfaces

Door handle

There are indentations on the outside of the
outer door handles for locking, and pressure-
sensitive surfaces on the inside of the handles
for unlocking.

Pressure-sensitive indentation for locking

Pressure-sensitive surface for unlocking

NOTE

It is important that only one pressure-sen-
sitive surface is activated at a time. If the
handle is grasped at the same time as the
lock area is pressed, there is a risk that
double commands may be sent. This may
cause the requested action (locking/
unlocking) to be delayed or not performed
at all.

Tailgate handle

The tailgate handle has a rubberized pressure
plate that can only be used for unlocking.

NOTE

Please be aware that the system could be
activated in a car wash if the remote key is
within range.

Related information

•

Keyless locking and unlocking

*

 (p. 265)

•

Keyless tailgate unlock

*

 (p. 266)

KEY, LOCKS AND ALARM

}}

* Option/accessory.

265

Keyless locking and unlocking

*

With keyless locking and unlocking, touching
the pressure-sensitive indentation on the
door handle will lock or unlock the vehicle.

NOTE

One of the vehicle's remote keys must be
within range for locking and unlocking to
be possible.

Pressure-sensitive indentation for locking

Pressure-sensitive surface for unlocking

NOTE

Please be aware that the system could be
activated in a car wash if the remote key is
within range.

Keyless locking

All of the doors have to be closed before the
vehicle can be locked. However, the tailgate
can be open when a door handle is used for
locking.

–

Touch the marked area on the outside of
one of the door handles after the door is
closed. Or press the

 button on the

lower edge of the tailgate before it is
closed.
> The lock indicator light on the dash-

board will flash to confirm that the vehi-
cle is locked.

To close all door windows at the same time -
place your finger on the pressure-sensitive
indentation on the outside of the door handle
and hold it there until the side windows have
closed.

Locking when the tailgate is open

If the vehicle is locked and the tailgate is still
open, make sure that the remote key is not left
in the cargo compartment when the tailgate is
closed.

NOTE

If the key is detected in the vehicle, the tail-
gate will not lock when it is closed.

Keyless unlocking

–

To unlock, grasp a door handle or lightly
press the rubberized button on the under-
side of the tailgate handle.
> The lock indicator light on the dash-

board will stop flashing to confirm that
the vehicle is unlocked.

The rubberized button on the tailgate can only be

used for unlocking.

Automatic relocking

If none of the doors or tailgate are opened
within two minutes after being unlocked, they
will automatically relock. This function reduces
the risk of inadvertently leaving the vehicle
unlocked.

||

KEY, LOCKS AND ALARM

* Option/accessory.

266

Related information

•

Keyless unlock settings

*

 (p. 266)

•

Keyless tailgate unlock

*

 (p. 266)

•

Keyless and touch-sensitive surfaces

*

(p. 264)

Keyless unlock settings

*

Several different sequences are available for
keyless unlocking.

To change this setting:

1. Tap

Settings

 in the center display's Top

view.

2. Tap

My Car

Locking

Keyless

Unlock

.

3. Select alternative:

•

All Doors

 – unlocks all doors at the

same time.

•

Single Door

 – unlocks the selected

door.

Related information

•

Keyless locking and unlocking

*

 (p. 265)

•

Keyless and touch-sensitive surfaces

*

(p. 264)

Keyless tailgate unlock

*

With keyless locking and unlocking, the tail-
gate can be unlocked by lightly touching the
rubberized button on the tailgate handle.

NOTE

One of the vehicle's remote keys must be
within range behind the vehicle for unlock-
ing to be possible.

The tailgate is held closed by an electronic
locking mechanism.

To open:

1. Lightly press the rubberized pressure plate

on the underside of the tailgate handle.
> The lock will disengage.

KEY, LOCKS AND ALARM

* Option/accessory.

267

2. Lift the outer handle to open the tailgate.

CAUTION

•

Only light pressure on the rubberized
pressure plate is necessary to release
the tailgate's locking mechanism.

•

Use the handle to lift the tailgate and do
not apply force to the rubberized pres-
sure plate. Too much force can damage
the pressure plate's electrical connec-
tions.

Hands-free unlocking of the tailgate is also
possible using a foot movement under the rear
bumper; see the separate section.

WARNING

Do not drive with the tailgate open. Toxic

exhaust fumes can be sucked into the vehi-

cle through the cargo compartment.

Related information

•

Keyless locking and unlocking

*

 (p. 265)

•

Keyless and touch-sensitive surfaces

*

(p. 264)

•

Remote key range (p. 253)

•

Operating the tailgate with a foot move-
ment

*

 (p. 273)

Antenna locations for the start and

lock system

The antennas for the keyless start system and
keyless locking system

*

 are integrated in the

vehicle.

Location of the antennas:

Under the cup holder in the front section
of the tunnel console
In the upper front section of the left-side
rear door

10

In the upper front section of the right-side
rear door

10

In the center of the rear seat backrest

10

WARNING

Individuals with an implanted pacemaker

should not allow the pacemaker to come

closer than 22 cm (9 in.) to the Keyless

system antennas. The aim of this is to pre-

vent disturbances between the pacemaker

and the Keyless system.

Related information

•

Keyless and touch-sensitive surfaces

*

(p. 264)

•

Remote key range (p. 253)

10

Only in vehicles equipped with keyless locking and unlocking

*

.

KEY, LOCKS AND ALARM

* Option/accessory.

268

Locking and unlocking from inside

the vehicle

The doors and tailgate can be locked and
unlocked from inside the vehicle using the
central lock buttons in the front doors.

Central locking

Button with indicator light for locking and unlocking

in front door.

Unlocking using the front door buttons

–

Press the

 button to unlock all side

doors and the tailgate.

Alternative unlocking method

Alternative unlocking method using side door open-
ing handle

11

.

–

Pull either of the side door inside opening
handles and release.
> Depending on the remote key settings,

either all doors will be unlocked or just
the selected door will be unlocked and
opened.

To change this setting, tap

Settings

My Car

Locking

Remote and

Interior Unlock

 in the Top view of the

center display.

Locking using the front door buttons

–

Press the

 button (both front doors

must be closed).
> All doors and the tailgate will lock.

Locking using the rear door button

*

Button with indicator light for locking/unlocking in

rear door.

The lock buttons in the rear doors lock/unlock
that particular door.

Unlocking the rear door

1. Pull the opening handle to unlock the rear

door.

2. Pull the opening handle again to open the

rear door

12

.

11

The illustration is generic - details may vary according to vehicle model.

12

If the child lock is not activated.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

269

Related information

•

Settings for remote and inside door unlock
(p. 252)

•

Unlocking the tailgate from inside the
vehicle (p. 269)

•

Activating and deactivating child locks
(p. 269)

Unlocking the tailgate from inside

the vehicle

The tailgate can be unlocked from the inside
using the button on the dashboard.

–

Press the

 button on the dashboard.

> The tailgate will unlock and can be

opened from the outside by pressing
the rubberized button on the handle.

With the optional power tailgate

*

:

–

Press and hold the

 button on the

dashboard.
> The tailgate will open.

Related information

•

Locking and unlocking from inside the
vehicle (p. 268)

Activating and deactivating child

locks

The child locks help prevent the rear doors
from being able to be opened from the inside.

The child lock can be either manual or elec-
tric

*

.

Manual child lock

Manual child lock. This is not the manual door lock.

–

Use the detachable key blade in the
remote key to turn the control.

The door cannot be opened from the
inside.
The door can be opened from both the
outside and the inside.

||

KEY, LOCKS AND ALARM

* Option/accessory.

270

NOTE

•

The door's knob control only locks that
specific door, not both rear doors
simultaneously.

•

There are no manual child locks on
models equipped with electronic child
locks.

Electric child lock

*

The electric child lock can be activated and
deactivated in any ignition mode higher than

0

. The lock can be activated and deactivated

up to 2 minutes after the ignition is turned off
if no door has been opened.

Button for activation and deactivation.

•

Light on – lock is activated.

•

Light off – lock is deactivated.

When the child lock is activated, the rear:

•

windows can only be opened using the
buttons in the driver's door.

•

the rear doors cannot be opened from the
inside.

If the child lock is activated when the vehicle
is switched off, it will remain activated the
next time the vehicle is started.

Symbols and messages

Symbol Message

Meaning

Rear child
lock



Acti-

vated

The child lock is
activated.

Rear child
lock



Deacti-

vated

The child lock is
deactivated.

Related information

•

Locking and unlocking from inside the
vehicle (p. 268)

•

Detachable key blade (p. 259)

Automatic locking when driving

The doors and tailgate will automatically lock
when the vehicle begins to move.

Related information

•

Locking and unlocking from inside the
vehicle (p. 268)

KEY, LOCKS AND ALARM

}}

* Option/accessory.

271

Closing and locking the tailgate

using the buttons

*

The buttons on the underside of the tailgate
can be used to close and lock the vehicle
automatically.

Location of button(s) on underside of tailgate.

CAUTION

When operating the tailgate manually,
open and close it slowly. If you encounter
resistance, do not use force. This could
lead to damage and loss of function.

Closing

13

–

Press the

 button on the underside of

the tailgate.
> The tailgate will close automatically and

remain unlocked.

NOTE

•

The button remains active 24 hours
after the tailgate was opened. After this
time, the tailgate must be closed man-
ually.

•

If the tailgate has been open for more
than 30 minutes, it will automatically
close slowly.

Locking

14

1. Press the

 button on the underside of

the tailgate.

2. Close the trunk lid manually.

> The tailgate and doors will lock

15

.

Closing and locking

16

–

Press the

 button on the underside of

the tailgate.
> The tailgate closes automatically and

the vehicle locks

15

.

NOTE

•

One of the vehicle's remote keys must
be within range for locking and unlock-
ing to be possible.

•

When the keyless locking or closing

*

functions are used, three audible signals
will sound if the key is not detected
close enough to the tailgate.

13

Vehicles with power-operated trunk lid.

14

Vehicles equipped with keyless locking/unlocking.

15

All doors must be closed for the vehicle to lock.

16

Vehicles with keyless locking/unlocking and power-operated tailgate.

||

KEY, LOCKS AND ALARM

* Option/accessory.

272

Interrupting closing

•

Press the button on the dashboard.

•

Press the button on the remote key.

•

Press the close button on the underside of
the tailgate

13

.

•

Press the rubberized pressure plate on the
underside of the tailgate's outer handle.

•

Using a foot movement

*

.

Tailgate movement is interrupted and stops.
The tailgate can then be opened or closed
manually.

If the tailgate stops near the closed position, it
will open the next time it is activated.

Pinch protection

If anything obstructs the tailgate with enough
force to prevent it from opening or closing,
pinch protection will be activated.

•

When opening - the tailgate will stop
moving and an audible signal will sound.

•

When closing - the tailgate will stop, a
long audible signal will sound and the tail-
gate will return to the programmed maxi-
mum opening position.

WARNING

Be aware of the risk of injury when opening

and closing.
Before opening or closing, make sure that

no one is near the tailgate's range of

motion. Serious injury could occur.
Always operate the tailgate with caution.

Preloaded springs

Preloaded springs for the power tailgate.

WARNING

Do not attempt to open or access the pre-

loaded springs in the power tailgate struts.

They are preloaded with high pressure and

can cause injury if opened.

Related information

•

Setting maximum opening height for the
power tailgate

*

 (p. 273)

•

Operating the tailgate with a foot move-
ment

*

 (p. 273)

•

Remote key range (p. 253)

13

Vehicles with power-operated trunk lid.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

273

Setting maximum opening height

for the power tailgate

*

The tailgate can be set to stop opening at a
certain height, for example if the tailgate
needs to be opened in a garage with a low
ceiling.

Setting maximum opening height

1. Open the tailgate manually to the desired

opening height.

2. Press the

 button on the lower edge of

the tailgate and hold it for about
3 seconds.
> Two audio signals will sound to indicate

that the position has been stored.

NOTE

It is not possible to program an opening
position lower than half-open tailgate.

Resetting maximum opening position

1. Open the tailgate manually to the fully

open position.

2. Press the

 button on the lower edge of

the tailgate and hold it for about
3 seconds.
> Two audio signals will sound to indicate

that the stored position has been
erased.

NOTE

•

If the system has been working contin-
uously for a prolonged period of time, it
will be switched off to avoid overload.
It can be used again after approxi-
mately 2 minutes.

Operating the tailgate with a foot

movement

*

To make it easier to operate the tailgate when
your hands are full, it can be opened and
closed by moving your foot in a forward kick-
ing motion under the rear bumper.

The sensor is located to the left of center under the
rear bumper

17

.

One of the vehicle's remote keys must be
within range behind the vehicle, approx.
1 meter (3 feet), for opening and closing to be
possible. This applies even if the vehicle is
unlocked in order to prevent the trunk lid from
inadvertently opening e.g. at a car wash.

||

KEY, LOCKS AND ALARM

* Option/accessory.

274

Foot movement operation

Kicking motion within the sensor's activation area.

–

Make

one

 forward kicking motion with

your foot under the left section of the rear
bumper. Take a step back. Do not touch
the bumper.
> A brief audible signal will be heard

when opening or closing is activated -
the tailgate will open/close.

If several opening attempts have been made
without the remote key in range behind the
vehicle, foot movement operation will not be
available for a short period of time.

Do not keep your foot under the vehicle in a
kicking motion. This may prevent activation.

Interrupting opening or closing with a foot
movement

–

Make

one

 forward kicking motion while

the tailgate is opening or closing to stop
its movement.

The remote key does not need to be within
range of the vehicle to interrupt opening or
closing of the tailgate.

If the tailgate stops near the closed position, it
will open the next time it is activated.

NOTE

There is a risk of reduced or lost function if
there are large amounts of snow, ice, dirt,
etc. on the rear bumper. Make sure to keep
the bumper clean.

NOTE

Please note that the system could be inad-
vertently activated in a car wash or similar
if the remote key is within range.

Vehicle with skid plate accessory

*

If the vehicle is equipped with skid plate, the
sensor is located towards the left corner of the
bumper.

To activate opening and closing using a foot
movement on a vehicle with skid plate, make a
kicking motion from the side of the vehicle.
One of the vehicle's remote keys must be
within range (approx. 1 meter (3 feet)) for
opening and closing to be possible.

17

If the vehicle is equipped with skid plate

*

, the sensor is located towards the left corner of the bumper.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

275

Kicking motion within the sensor's activation area.

Related information

•

Keyless and touch-sensitive surfaces

*

(p. 264)

•

Remote key range (p. 253)

Private Locking

The tailgate and the glove compartment can
be locked using the private locking function
to prevent them from being opened, e.g.
when the vehicle is left at a workshop or with
a valet.

The function button for pri-
vate locking is located in the
center display's Function
view. Depending on the cur-
rent status of the lock,

Private Locking Unlocked

or

Private Locking Locked

will be displayed.

Related information

•

Activating and deactivating private locking
(p. 275)

Activating and deactivating private

locking

Private locking is activated using the function
button in the center display and a PIN code.

NOTE

For the valet lock function to be activated
the car must be in at least ignition mode

I

.

Two codes are used for private locking:

•

A security code, which is created the first
time the function is used.

•

A PIN code, which is changed each time
the function is activated.

Entering security code before initial
use

The first time the function is used, a security
code must be selected. This code can then be
used to deactivate private locking if the
selected PIN code has been forgotten or lost.
The security code functions as a PUK (secur-
ity) code for all PIN codes used for private
locking.

Save the security code in a safe place.
