It is important that only one touch-sensi-
tive surface is activated at a time. Gripping
the handle while touching the lock surface
risks giving double commands. This means
that the requested activity (locking/unlock-
ing) will not be executed, or will be execu-
ted with a delay.

Tailgate handle

The tailgate handle has a rubberised pressure
plate that is only used for unlocking.

Keyless locking and unlocking

Be aware that the system may be activated
in connection with car washing if the
remote control key is in range.

Related information

•

(p. 274)

•

Keyless unlocking of the tailgate

(p. 275)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

274

Keyless locking and unlocking

With keyless locking and unlocking, it is suffi-
cient to touch the door handle's touch-sensi-
tive surface to lock or unlock the car.

One of the car's remote control keys must
be within range for locking and unlocking
to work.

Touch-sensitive recess for locking

Touch-sensitive surface for unlocking

Be aware that the system may be activated
in connection with car washing if the
remote control key is in range.

Keyless locking

All side doors must be closed to be able to
lock the car. The tailgate, on the other hand,
can be open when locking the car with a side
door handle.

–

Touch the marked surface towards the
rear on the outside of a door handle after
the door has been closed. Or press the

button on the underside of the tail-

gate before it closes.
> The lock indicator on the instrument

panel starts to flash to indicate the car
is locked.

To close all side windows and the panoramic
roof

simultaneously - place a finger against

the touch-sensitive recess on the outside of
the door handle and hold it there until all of the
side windows and the panoramic roof have
been closed.

Locking when the tailgate is open

If the car has been locked and the tailgate is
still open, make sure that the remote control
key is not left in the cargo area when the tail-
gate is closed.

Settings for Keyless entry

If the key is detected inside the car, the
tailgate will not lock when it is closed.

Keyless unlocking

–

Grasp a door handle or gently press the
rubberised pressure plate beneath the tail-
gate handle to unlock the car.
> The lock indicator on the instrument

panel stops flashing to indicate that the
car is unlocked.

Rubberised pressure plate on the tailgate can only be

used for unlocking.

Automatic relocking

If none of the doors or the tailgate is opened
within 2 minutes of unlocking, they are locked
automatically. This function prevents the car
from being left unlocked unintentionally.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

* Option/accessory.

275

Related information

•

(p. 275)

•

Keyless unlocking of the tailgate

(p. 275)

•

Keyless locking and unlocking

Settings for Keyless entry

It is possible to select different sequences for
Keyless entry.

To change setting:

1. Tap on

Settings

in the centre display's

top view.

2. Tap on

My Car

Locking

Keyless

Unlock

3. Select option:

•

All Doors

- unlocks all doors simultane-

ously.

•

Single Door

- unlocks selected door.

Related information

•

(p. 274)

•

Keyless unlocking of the tailgate

With keyless locking and unlocking, it is suffi-
cient to press lightly on the rubberized pres-
sure plate on the tailgate handle to unlock.

Keyless locking and unlocking

One of the car's remote control keys must
be within range behind the car for unlock-
ing to work.

The tailgate is held closed by an electrical lock.

To open:

1. Press gently on the rubberised pressure

plate beneath the tailgate handle.
> The lock is released.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

276

2. Lift by the outside handle in order to open

the tailgate.

IMPORTANT

•

Minimal force is required to release the
rear hatch lock - just gently press the
rubberised panel.

•

Do not place the lift force on the rubber
panel when opening the rear hatch - lift
the handle. Using too much force may
damage the electrical contacts on the
rubber panel.

It is also possible to unlock the tailgate hands-
free with a foot movement under the rear
bumper, see separate section.

WARNING

Do not drive with an open tailgate! Toxic

exhaust fumes could be drawn into the car

through the cargo area.

Related information

•

(p. 274)

•

Remote control key range (p. 248)

•

•

Operating the tailgate with foot move-
ment

(p. 282)

Antenna locations for the start and

lock systems

An antenna for the keyless starting system
and antennas for the keyless locking system

are built into the car.

Antenna locations:

Under the cup holder in the front section
of the tunnel console
In the upper front section of the left-hand
rear door

In the upper front section of the right-hand
rear door

In the cargo area

WARNING

People with pacemaker operations should

not come closer than 22 cm (9 inches) to

the keyless system's antennas with their

pacemaker. This is to prevent interference

between the pacemaker and the keyless

system.

Related information

•

Remote control key range (p. 248)

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

* Option/accessory.

277

Locking and unlocking from inside

the car

The doors and tailgate can be locked and
unlocked from inside using the central lock-
ing controls in the front doors.

Central locking

Locking and unlocking button with indicator lamp in

the front door.

Unlocking using a button in the front
door

–

Press the

button to unlock all side

doors and the tailgate.

Alternative unlocking method

Opening handle for alternative unlocking in the side
door

–

Pull the opening handle on one of the side
doors and release.
> Depending on the settings in the

remote control key, either all doors will
be unlocked or only the selected door
will be unlocked and opened.

To change this setting, tap on

Settings

My Car

Locking

Remote and

Interior Unlock

in the centre display's

top view.

Locking using a button in the front
door

–

Press the

button - both front doors

must be closed.
> All doors and the tailgate are locked.

Locking using a button in the rear
door

Locking button with indicator lamp in the rear door.

The rear door lock buttons lock their respec-
tive rear door.

Unlocking the rear door

–

Pull the opening handle.
> The rear door is unlocked and opened

Only in cars equipped with keyless locking and unlocking

The figure is schematic - parts may vary depending on car model.

Provided that the child lock is not activated.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

278

Related information

•

Settings for remotely controlled and inside
unlocking (p. 247)

•

Unlocking the tailgate from the inside of
the car (p. 278)

•

Activating and deactivating child safety
locks (p. 278)

Unlocking the tailgate from the

inside of the car

The tailgate can be unlocked from inside by
pressing the button on the instrument panel.

–

Brief press on the

button on the

instrument panel.
> The tailgate can be unlocked and

opened from the outside by grasping
the rubberised pressure plate.

With the power operated tailgate option

–

Long press on the

button on the

instrument panel.
> The tailgate is opened.

Related information

•

Locking and unlocking from inside the car
(p. 277)

Activating and deactivating child

safety locks

The child safety lock prevents the rear doors
from being opened from inside.

The child lock can be either manual or electri-
cal

Manual child lock

Manual child lock. Not to be confused with manual

door locks.

–

Use the remote control key's detachable
key blade to turn the knob.

The door is blocked against opening from
the inside.
The door can be opened from both the
outside and the inside.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

279

Locking and unlocking from inside the car
(p. 277)

•

A door's knob control only blocks that
particular door - not both rear doors
simultaneously.

•

Cars with an electric child safety lock
do not have a manual child lock.

Electric child lock

The electric child lock can be activated and
deactivated in all ignition positions above

Activation and deactivation can be performed
up to 2 minutes after switching off the car,
provided that no door is opened.

Activation and deactivation button.

•

Lamp lit – the lock is activated.

•

Lamp not lit - the lock is deactivated.

When the child lock is activated, the following
is possible, the rear:

•

windows are only opened with the but-
tons in the driver's door.

•

doors cannot be opened from inside.

If the child lock is activated when the car is
switched off, it will remain activated the next
time the car is started.

Symbols and messages

Symbol Message

Specification

Rear child
lock

Acti-

vated

The child lock is
activated.

Rear child
lock

Deacti-

vated

The child lock is
deactivated.

Related information

•

•

Detachable key blade (p. 255)

Automatic locking when driving

The doors and tailgate are locked automati-
cally when the car starts to move.

To change this setting:

1. Tap on

Settings

in the centre display's

top view.

2. Press

My Car

Locking

3. Select

Auto Lock Doors While Driving

to deactivate or activate this function.

Related information

•

Locking and unlocking from inside the car
(p. 277)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

280

Closing and locking tailgate with

button

The buttons on the underside of the tailgate
can close and lock the car automatically.

Location of the button/buttons on the underside of

the tailgate.

IMPORTANT

During manual tailgate operation, open or
close it slowly. Do not use force to open/
close it if there is resistance. It may be
damaged and stop working correctly.

Closing

–

Press the

button on the underside of

the tailgate.
> The tailgate closes automatically and

remains unlocked.

•

The button is active 24 hours after the
hatch has been left open. Thereafter, it
must be closed manually.

•

If the flap has been open for more than
30 minutes, it will close at a slow
speed.

Locking

1. Press the

button on the underside of

the tailgate.

2. Close the hatch manually.

> The tailgate and the doors are locked

Closing and locking

–

Press the

button on the underside of

the tailgate.
> The tailgate is closed automatically and

the car is locked
