KEY, LOCKS AND ALARM

}}

* Option/accessory.

245

The remote keys can be linked to different
driver profiles to store personal settings in the
vehicle.

WARNING

The remote key contains a button cell bat-

tery. Keep new and used batteries out of

the reach of children. If batteries are swal-

lowed, they can cause serious injury.
If any damage is detected, e.g. if the bat-

tery cover cannot be closed properly, do

not use the product. Keep defective prod-

ucts out of the reach of children.

Remote key buttons

The remote key has four buttons, one on the left side

and three on the right.



Locking

 - Press once to lock the doors,

tailgate and fuel filler door and arm the
alarm.
Press and hold to close all windows.


Unlocking

 - Press once to unlock the

doors, tailgate and fuel filler door and dis-
arm the alarm.
Press and hold to open all windows at the
same time. This total airing function can
be used to e.g. quickly air out the vehicle
in hot weather.


Tailgate

 - Unlock and disarm the tailgate

only. On vehicles equipped with the power
tailgate

*

, press and hold to automatically

open the tailgate. Press and hold to close

an open tailgate (an audible warning sig-
nal will be given).


Panic alarm

 - Used to attract attention in

emergency situations. Press and hold the
button for at least 3 seconds or press
twice within 3 seconds to activate the
turn signals and horn. To deactivate, wait
at least 5 seconds and press the button
again. If no action is taken, the panic alarm
will deactivate automatically after 3
minutes.

WARNING

If anyone is left in the vehicle, make sure

that power to the power windows and pan-

oramic roof

*

 is cut off by always taking the

remote key with you when you leave the

vehicle.

||

KEY, LOCKS AND ALARM

* Option/accessory.

246

NOTE

Be aware of the risk of locking the remote
key in the vehicle.

•

If the remote key or key tag is left in
the vehicle, it will be deactivated when
the vehicle is locked and the alarm set
using another valid key. The key will be
reactivated when the vehicle is
unlocked.

•

If the remote key or Care Key is left in
the vehicle, it will be deactivated even
if the vehicle is locked using Volvo On
Call, and will be reactivated when the
vehicle is unlocked using Volvo On Call
or another valid key.

Button-less key (Key Tag)

*

The button-less key

4

 provided with the keyless

locking and unlocking function works in the
same way as the regular remote key for key-
less start, locking and unlocking. The key is
waterproof up to a depth of approx. 10 meters
(30 feet) for up to 60 minutes. It does not
have a detachable key blade and its battery
cannot be replaced.

Care Key - restricted remote key

A Care Key enables the vehicle owner to set a
maximum speed limit for the vehicle. This limit

is intended to promote safe use of the vehicle,
e.g. when it is loaned out.

Interference

Electromagnetic fields or obstructing objects
may interfere with the remote key's functions
for keyless start and keyless locking and
unlocking

*

.

NOTE

Avoid storing the remote key near metal
objects or electronic devices, e.g. cell
phones, tablets, laptops or chargers – pref-
erably no closer than 10-15 cm (4-6 in.).

If you experience interference, use the remote
key's detachable blade to unlock the vehicle
and then place the remote key in the backup
reader in the tunnel console cup holder to dis-
arm the alarm and start the vehicle.

NOTE

When the remote control key is placed in
the cup holder, make sure that no other
vehicle keys, metal objects or electronic
devices (e.g. cell phones, tablets, laptops
or chargers) are found in the cup holder.
Multiple vehicle keys close to each other in
the cup holder can disrupt their functional-
ity.

WARNING

California Proposition 65

Operating, servicing and maintaining a pas-

senger vehicle can expose you to chemi-

cals including engine exhaust, carbon mon-

oxide, phthalates, and lead, which are

known to the State of California to cause

cancer and birth defects or other reproduc-

tive harm. To minimize exposure, avoid

breathing exhaust, do not idle the engine

except as necessary, service your vehicle in

a well ventilated area and wear gloves or

wash your hands frequently when servicing

your vehicle. For more information go to

4

Also called sport key.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

247

Related information

•

Starting the vehicle (p. 396)

•

Locking and unlocking using the remote
key (p. 247)

•

Remote key range (p. 249)

•

Replacing the remote key's battery
(p. 250)

•

Detachable key blade (p. 255)

•

Care Key – restricted remote key (p. 254)

•

Electronic immobilizer (p. 258)

•

Linking a remote key to a driver profile
(p. 142)

Locking and unlocking using the

remote key

All doors, tailgate and fuel filler door can be
locked and unlocked simultaneously using
the buttons on the remote key.

Locking with remote key

The illustration is generic - details may vary accord-

ing to vehicle model.

–

Press the

 button on the remote key to

lock the vehicle.

To activate the locking sequence, the driver's
door must be closed

5

. If any of the other doors

or the tailgate are open, they will be locked
and the alarm will be armed once they are
closed.

NOTE

Be aware of the risk of locking the remote
key in the vehicle.

•

If the remote key or key tag is left in
the vehicle, it will be deactivated when
the vehicle is locked and the alarm set
using another valid key. The key will be
reactivated when the vehicle is
unlocked.

•

If the remote key or Care Key is left in
the vehicle, it will be deactivated even
if the vehicle is locked using Volvo On
Call, and will be reactivated when the
vehicle is unlocked using Volvo On Call
or another valid key.

Locking when the tailgate is open

NOTE

If the vehicle is locked and the tailgate is
still open, make sure that the remote key is
not left in the cargo compartment when
the tailgate is closed and the entire vehicle
is locked

6

.

5

If the vehicle is equipped with keyless locking/unlocking

*

, all side doors must be closed.

6

If the vehicle is equipped with keyless locking/unlocking and the key is detected inside the vehicle, the tailgate will not lock when it is closed.

*

||

KEY, LOCKS AND ALARM

248

Unlocking with remote key

–

Press the

 button on the remote key to

unlock the vehicle.

Automatic relocking

If none of the doors or tailgate are opened
within two minutes after being unlocked, they
will automatically relock. This function reduces
the risk of inadvertently leaving the vehicle
unlocked.

Remote key not working

NOTE

Move closer to the vehicle and try to
unlock it again.

If the remote key is not working to lock or
unlock the vehicle, its battery may be dis-
charged. Use the detachable key blade to
lock/unlock the driver's door instead.

Related information

•

Settings for remote and inside door unlock
(p. 248)

•

Unlocking the tailgate using the remote
key (p. 249)

•

Remote key (p. 244)

•

Replacing the remote key's battery
(p. 250)

•

Locking and unlocking with detachable
key blade (p. 256)

Settings for remote and inside

door unlock

Several different sequences are available for
remote unlocking.

To change this setting:

1. Tap

Settings

 in the center display's Top

view.

2. Tap

My Car

Locking

Remote and

Interior Unlock

.

3. Select alternative:

•

All Doors

 – unlocks all doors at the

same time.

•

Single Door

 – unlocks the driver's

door. Press the remote key unlock but-
ton twice to unlock all doors.

The settings made here also affect central
locking using the inside door handle.

Related information

•

Locking and unlocking using the remote
key (p. 247)

•

Locking and unlocking from inside the
vehicle (p. 264)

KEY, LOCKS AND ALARM

}}

* Option/accessory.

249

Unlocking the tailgate using the

remote key

The remote key can be used to unlock the
tailgate while keeping the rest of the vehicle
locked.

1. Press the

 button on the remote key.

> The tailgate will be unlocked but remain

closed.

The side doors remain locked and
armed. The lock and alarm indicator on
the dashboard will go out to indicate
that the vehicle is no longer fully
locked.

Press lightly on the rubberized pressure
plate under the tailgate handle to open
the tailgate. If the tailgate is not opened
within 2 minutes, it will be relocked and
the alarm armed.

2. With the optional power tailgate

*

 -

Hold and press (about 1.5 seconds) the

 button on the remote key

> The tailgate will unlock and open. How-

ever, the side doors will remain locked
and armed.

Related information

•

Locking and unlocking using the remote
key (p. 247)

Remote key range

In order to function correctly, the remote key
must be within a certain distance from the
vehicle.

Manual use

The remote key's functions for e.g. locking and
unlocking, which are activated by pressing
or

, have a range of approx. 20 meters

(65 feet) from the vehicle.

If the vehicle's locks do not react, move closer
and try again.

Keyless

*

 use

The shaded areas around the vehicle illustrate the

range of the system's antennas.

For keyless use, a remote key or the Key Tag
must be within the shaded areas shown in the
illustration, i.e. a semicircle with a radius of

||

KEY, LOCKS AND ALARM

* Option/accessory.

250

approx. 1.5 meter (5 feet) along the sides of
the vehicle or approx. 1 meter (3 feet) from the
tailgate.

NOTE

The functions of the remote control key
can be disrupted by ambient radio waves,
buildings, topographical conditions, etc.
The vehicle can always be locked/unlocked
using the key blade.

If the remote key is removed from the
vehicle

If the remote key is removed from
the vehicle while the engine is run-
ning, the warning message

Vehicle

key not found



Removed from

vehicle

 will be displayed in the instrument

panel and an audible signal will sound when
the last door is closed.

The message will disappear when the key is
returned to the vehicle and the

O

 button on

the right-side steering wheel keypad is
pressed or when the last door is closed again.

Related information

•

Remote key (p. 244)

•

Antenna locations for the start and lock
system (p. 263)

•

Keyless and touch-sensitive surfaces

*

(p. 260)

Replacing the remote key's battery

The battery in the remote key must be
replaced when it is discharged.

NOTE

All batteries have a limited service life and
must eventually be replaced (does not
apply for Key Tag). The battery's service life
varies depending on how often the
vehicle/key is used.

The remote key battery should be replaced if

•

the information symbol illuminates and the
message

Vehicle key bat. low

 is dis-

played in the instrument panel

•

the locks do not react after several
attempts to lock or unlock the vehicle
using the remote key within approx.
20 meter (65 feet) from the vehicle.

NOTE

Move closer to the vehicle and try to
unlock it again.

The battery in the smaller key without but-
tons

7

 (the Key Tag) cannot be replaced. A new

key can be ordered from an authorized Volvo
workshop.

CAUTION

An end-of-life Key Tag must be turned in to
an authorized Volvo workshop. The key
must be deleted from the vehicle because
it can still be used to start the vehicle via
backup start.

Opening the key and replacing the
battery

 Hold the remote key with the front side

(with the Volvo logo) facing up and move
the button on the key ring section to the
right. Slide the front cover slightly upward.

 The cover will loosen and can be

removed from the key.

KEY, LOCKS AND ALARM

}}

251

 Turn the key over, move the button to

the side and slide the rear cover slightly
upward.

 The cover will loosen and can be

removed from the key.

Use a screwdriver or similar object to turn
the battery cover counterclockwise so the
markers point to

OPEN

.

Remove the cover carefully by pressing
e.g. a fingernail into the indentation.

Pry the cover up.

The battery's positive side (

+

) faces

upward. Carefully pry out the battery as
shown in the illustration.

CAUTION

Avoid touching new batteries and their
contact surfaces with your fingers as this
will impair their function.

7

Included in vehicles equipped with keyless locking/unlocking

*

.

||

KEY, LOCKS AND ALARM

252

Insert a new battery with the positive side
(

+

) facing upward. Do not touch the con-

tact surfaces of the remote key battery.

 Place the edge of the battery down-

ward into the holder. Slide the battery for-
ward until it locks into place under the two
plastic catches.

 Press the battery downward until it

locks into place under the upper black
plastic catch.

NOTE

Use batteries with the designation
CR2032, 3 V.

NOTE

Volvo recommends that batteries used in
the remote control key satisfy UN Manual
of Test and Criteria, Part III, sub-section
38.3. The factory installed batteries and
batteries replaced by an authorized Volvo
workshop satisfy the above criterion.

Replace the battery cover and turn it
clockwise until it points to

CLOSE

.

 Put the rear cover back into position

and press it down until it clicks into place.

 Slide the cover back.

> A second click indicates that the cover

is correctly positioned and locked into
place.

KEY, LOCKS AND ALARM

253

 Turn the remote key over and press the

front cover down until it clicks into place.

 Slide the cover back.

> An additional click indicates that the

cover is correctly in place.

WARNING

Make sure the battery is positioned cor-

rectly with the right polarity. If the remote

key will not be used for a prolonged period

of time, remove the battery to avoid battery

leakage and damage. Wear protective

gloves when handling damaged batteries,

as batteries that are damaged or leaking

can cause corrosive damage in contact

with the skin.

•

Keep batteries out of the reach of chil-
dren.

•

Do not leave batteries lying out where
they could be swallowed by children or
pets.

•

Never disassemble, short-circuit or
place a battery into open fire.

•

Do not charge non-rechargeable bat-
teries, as this could cause an explosion.

Check the remote key for damage before

using it. If any damage is detected, e.g. if

the battery cover cannot be closed prop-

erly, do not use the product. Keep defec-

tive products out of the reach of children.

CAUTION

Be sure to dispose of end-of-life batteries
in a way that protects the environment.

WARNING

California Proposition 65

Operating, servicing and maintaining a pas-

senger vehicle can expose you to chemi-

cals including engine exhaust, carbon mon-

oxide, phthalates, and lead, which are

known to the State of California to cause

cancer and birth defects or other reproduc-

tive harm. To minimize exposure, avoid

breathing exhaust, do not idle the engine

except as necessary, service your vehicle in

a well ventilated area and wear gloves or

wash your hands frequently when servicing

your vehicle. For more information go to

Related information

•

Locking and unlocking with detachable
key blade (p. 256)

•

Starting the vehicle (p. 396)

•

Remote key (p. 244)

KEY, LOCKS AND ALARM

* Option/accessory.

254

Ordering additional remote keys

Two remote keys are provided with the vehi-
cle. One Key Tag is also included if the vehi-
cle is equipped with keyless locking/unlock-
ing

*

. Additional keys can be ordered.

A total of 12 keys can be programmed and
used for the same vehicle. An additional driver
profile will be added for each new remote key.
This also applies to the key tag.

Loss of a remote key

If you lose your remote key, you can order a
replacement from a workshop - an authorized
Volvo workshop is recommended. Bring the
other remaining remote keys to the workshop.
As an anti-theft measure, the code of the lost
remote key must be erased from the system.

The current number of keys registered for the
vehicle can be checked via driver profiles in
the center display's Top view. Select

Settings

System

Driver Profiles

.

NOTE

Volvo recommends that you order a new or
duplicate remote key from an authorized
Volvo workshop.

You can also obtain additional or duplicate
remote keys from certain independent
repair facilities and locksmiths that are
qualified to make remote keys. Each key
must be programmed to work with your
vehicle.

A list of independent repair facilities and/or
locksmiths known to Volvo that can cut
and code replacement keys can be found:

•

at volvocars.com

•

by calling Volvo Customer Care
1-800-458-1552.

Related information

•

Remote key (p. 244)

Care Key – restricted remote key

A Care Key enables the vehicle owner to set a
maximum speed limit for the vehicle. This
limit is intended to promote safe use of the
vehicle, e.g. when it is loaned out.

A maximum vehicle speed can be defined for a
Care Key. Otherwise, the Red Key functions in
the same way as a standard remote key.

This restriction is intended to help reduce the
risk of accidents and help the driver feel more
secure when handing over the vehicle to e.g. a
young driver, parking attendant or workshop.

Ordering a Care Key

One or more Care Key can be ordered from a
Volvo retailer. A total of twelve keys can be
programmed and used for the same vehicle.
Up to ten may be restricted keys, but at least
two must be standard remote keys.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

255

Care Key limitations

The key is linked to a specific Care Key driver
profile, and when it is active the key's settings
cannot be changed. It is also not possible to
switch to another driver profile, as this
requires a regular remote key.

The driver profile is activated when the vehicle
is unlocked using a Care Key without a regular
remote key nearby.

NOTE

If the vehicle changes owners, the vehicle
must be locked and then unlocked for a
new driver profile to be activated.

Setting options

The following limitations are available:

•

speed range: 50-180 km/h (30-112 mph)

•

Increments: 1 km/h (1 mph)

Symbol

Meaning

Speed limitation is active.

Related information

•

Care Key settings (p. 255)

•

Remote key (p. 244)

Care Key settings

Change maximum speed for a Care Key via
the center display.

1. Unlock the vehicle using a regular remote

key.

2. Tap

Settings

 in the center display's Top

view.

3. Tap

System

Driver Profiles

Care

Key

.

4. Adjust desired settings.

Related information

•

Care Key – restricted remote key (p. 254)

Detachable key blade

The remote key contains a detachable metal
key blade that can be used to activate a num-
ber of functions and preform certain actions.

A Volvo workshop can provide you with the
key blade's unique code, which is recom-
mended in case you need to order a new key
blade.

Using the detachable key blade

The detachable key blade can be used to

•

manually open the left-side front door if
central locking cannot be activated with
the remote key

•

emergency lock all doors

•

activate/deactivate the rear door mechani-
cal child locks.

The button-less key

8

 does not have a detacha-

ble key blade. If needed, use the standard
remote key's detachable key blade.

8

Included in vehicles equipped with keyless locking/unlocking

*

.

||

KEY, LOCKS AND ALARM

256

Detaching the key blade

 Hold the remote key with the front side

(with the Volvo logo) facing up and move
the button on the key ring section to the
right. Slide the front cover slightly upward.

 The cover will loosen and can be

removed from the key.

 Remove the key blade by pulling it up.

Put the key blade back into its designated
spot in the remote key after use.

 Replace the cover by pressing it down

until it clicks into place.

 Slide the cover back.

> An additional click indicates that the

cover is correctly in place.

Related information

•

Locking and unlocking with detachable
key blade (p. 256)

•

Remote key (p. 244)

Locking and unlocking with

detachable key blade

The detachable key blade can be used to
unlock the vehicle from the outside, e.g. if the
battery in the remote key is discharged.

Unlocking

Pull the front left-hand door handle to its
end position to access the lock cylinder.

Put the key in the lock cylinder.

Turn the key clockwise 45 degrees so that
the key blade is pointing straight rear-
ward.

Turn the key blade back 45 degrees to its
original position. Remove the key from the
lock cylinder and release the handle so
that it returns to its original position
against the vehicle.

5. Pull the door handle.

> The door will open.

KEY, LOCKS AND ALARM

* Option/accessory.

257

NOTE

When the door is unlocked using the
detachable key blade and then opened, the
alarm will be triggered. The alarm must be
deactivated manually; see separate sec-
tion.

Locking

The left-hand front door can be locked by
inserting the detachable key into the door's
lock cylinder.

The other doors have lock mechanisms in the
side of the door that must be pushed in using
the key blade. The door will then be locked
mechanically and cannot be opened from the
outside.

The doors can still be opened from inside.

Manual door lock. This is not the child lock.

1. Remove the detachable key blade from

the remote key.

2. Insert the key blade into the opening for

the lock mechanism.

3. Push in the key until it stops, about 12 mm

(0.5 inch).

The door can be opened from both the
outside and the inside.
The door cannot be opened from the out-
side. To return to position A, open the door
using the inside door handle.

NOTE

•

The door's lock controls only lock that
specific door, not all doors simultane-
ously.

•

A manually locked rear door with acti-
vated child lock cannot be opened
from either the outside or the inside.
The door can only be unlocked using
the buttons on the key, the central
locking button, the keyless locking sys-
tem

*

 or Volvo On Call.

Related information

•

Detachable key blade (p. 255)

•

Arming and disarming the alarm (p. 273)

•

Starting the vehicle (p. 396)

•

Replacing the remote key's battery
(p. 250)

•

Remote key (p. 244)

KEY, LOCKS AND ALARM

* Option/accessory.

258

Electronic immobilizer

The electronic immobilizer is a start inhibitor
that helps prevent the vehicle from being
started by an unauthorized person.

The vehicle can only be started with the right
remote key.

The following instrument panel error mes-
sages are related to the electronic immobil-
izer:

Symbol Message

Meaning

Vehicle key
not found

See
Owner's
manual

Remote key not
recognized dur-
ing start. Place
the remote key
on the key sym-
bol in the cup
holder and try to
start the vehicle
again.

Remote immobilizer with tracking
system

9

The vehicle is equipped with a system that
makes it possible to track and locate the vehi-
cle and to remotely activate the immobilizer to
prevent the vehicle from being started. Con-
tact your nearest Volvo retailer for more infor-
mation and assistance activating the system.

The following instrument panel error mes-
sages are related to the remote immobilizer
with tracking system:

Symbol Message

Meaning

Remotely
immobilised

Vehicle not
possible to
start

The remote
immobilizer with
tracking system
is activated. The
vehicle cannot
be started. Con-
tact Volvo On
Call Service
Center.

Related information

•

Remote key (p. 244)

•

Ordering additional remote keys (p. 254)

Start and lock system type

designations

The following information contains type des-
ignations for the start and lock system.

Alarm system

USA FCC ID: MAYDA 5823(3)

This device complies with part 15 of the FCC
rules. Operation is subject to the following
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired opera-
tion.

Canada IC: 4405A-DA 5823(3)

This device is subject to the following condi-
tions: (1) This device may not cause interfer-
ence, and (2) this device must accept any
interference, including interference that may
cause undesired operation of the device.

Remote keys (Passive Entry

*

/Passive

Start)

USA

Volvo Standard Key FCC ID: YGO-
HUF8423MS

Volvo Tag ID FCC ID: YGOHUF8432MS

9

Only certain markets and in combination with Volvo On Call.

KEY, LOCKS AND ALARM

* Option/accessory.

259

This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:

(1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.

CAUTION: Changes or modifications not
expressly approved by the party responsible
for compliance could void the user’s authority
to operate the equipment.

Canada

Volvo Standard Key IC: 4008C-HUF8423MS

Volvo Tag ID IC: 4008C-HUF8432MS

This device complies with part 15 of the FCC
Rules and Industry Canada license-exempt
RSS standard(s). Operation is subject to the
following two conditions:

(1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.

Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes :

(1) l'appareil ne doit pas produire de brouillage,
et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre
le fonctionnement.

Immobilizer and Passive Entry

*

/

Passive Start systems

USA-FCC ID: LTQVO3134

This device complies with part 15 of the FCC
rules. Operation is subject to the following
two conditions:

(1) This device may not cause harmful interfer-
ence, and

(2) this device must accept any interference
received, including interference that may
cause undesired operation.

Any changes or modification not expressly
approved by the party responsible for compli-
ance could void the user's authority to operate
this equipment.

Canada-IC:3659A-VO3134

This device complies with Industry Canada
license-exempt RSS standards. Operation is
subject to the following two conditions:

(1) This device may not cause harmful interfer-
ence, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.

Related information

•

Remote key (p. 244)

KEY, LOCKS AND ALARM

* Option/accessory.

260

Keyless and touch-sensitive

surfaces

*

With the keyless locking and unlocking func-
tion, the remote key only needs to be within
range, e.g. in a pocket or bag. The vehicle can
then be locked or unlocked by touching the
pressure-sensitive surface on the door han-
dle.

Pressure-sensitive surfaces

Door handle

There are indentations on the outside of the
outer door handles for locking, and pressure-
sensitive surfaces on the inside of the handles
for unlocking.

Pressure-sensitive indentation for locking

Pressure-sensitive surface for unlocking

NOTE

It is important that only one pressure-sen-
sitive surface is activated at a time. If the
handle is grasped at the same time as the
lock area is pressed, there is a risk that
double commands may be sent. This may
cause the requested action (locking/
unlocking) to be delayed or not performed
at all.

Tailgate handle

The tailgate handle has a rubberized pressure
plate that can only be used for unlocking.

NOTE

Please be aware that the system could be
activated in a car wash if the remote key is
within range.

Related information

•

Keyless locking and unlocking

*

 (p. 261)

•

Keyless tailgate unlock

*

 (p. 262)
