It is important that only one touch-sensi-
tive surface is activated at a time. Gripping
the handle while touching the lock surface
risks giving double commands. This means
that the requested activity (locking/unlock-
ing) will not be executed, or will be execu-
ted with a delay.

Boot lid handle

The boot lid handle has a rubberised pressure
plate that is only used for unlocking.

Keyless locking and unlocking

Be aware that the system may be activated
in connection with car washing if the
remote control key is in range.

Related information

•

(p. 270)

•

Keyless

unlocking of boot lid (p. 271)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

270

Keyless locking and unlocking

With keyless locking and unlocking, it is suffi-
cient to touch the door handle's touch-sensi-
tive surface to lock or unlock the car.

One of the car's remote control keys must
be within range for locking and unlocking
to work.

Touch-sensitive recess for locking

Touch-sensitive surface for unlocking

Be aware that the system may be activated
in connection with car washing if the
remote control key is in range.

Keyless locking

All side doors must be closed to be able to
lock the car. The boot lid, on the other hand,
can be open when locking the car with a side
door handle.

–

Touch the marked surface towards the
rear on the outside of a door handle after
the door has been closed. Or press the

button on the underside of the boot

lid before it closes.
> The lock indicator on the instrument

panel starts to flash to indicate the car
is locked.

To close all side windows and the sunroof

simultaneously - place a finger against the
touch-sensitive recess on the outside of the
door handle and hold it there until all side win-
dows and the sunroof have been closed.

Locking when the boot lid is open

If the car has been locked and the boot lid is
still open, make sure that the remote control
key is not left in the cargo area when the boot
lid is closed.

Settings for Keyless entry

If the key is detected inside the car, the
boot lid will not lock when it is closed.

Keyless unlocking

–

Grasp a door handle or gently press the
rubberised pressure plate beneath the
boot lid handle to unlock the car.
> The lock indicator on the instrument

panel stops flashing to indicate that the
car is unlocked.

Rubberised pressure plate on the boot lid can only be

used for unlocking.

Automatic relocking

If none of the doors or the boot lid is opened
within 2 minutes of unlocking, they are locked
automatically. This function prevents the car
from being left unlocked unintentionally.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

* Option/accessory.

271

Related information

•

(p. 271)

•

Keyless

unlocking of boot lid (p. 271)

•

Keyless locking and unlocking

Settings for Keyless entry

It is possible to select different sequences for
Keyless entry.

To change setting:

1. Tap on

Settings

in the centre display's

top view.

2. Tap on

My Car

Locking

Keyless

Unlock

3. Select option:

•

All Doors

- unlocks all doors simultane-

ously.

•

Single Door

- unlocks selected door.

Related information

•

(p. 270)

•

Keyless

unlocking of boot lid

With keyless locking and unlocking, it is suffi-
cient to press lightly on the rubberized pres-
sure plate on the boot lid handle to unlock.

Operating the boot lid with foot move-
ment

One of the car's remote control keys must
be within range behind the car for unlock-
ing to work.

The boot lid is held closed by an electrical
lock.

To open:

1. Press gently on the rubberised pressure

plate beneath the boot lid handle.
> The lock is released.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

272

2. Lift by the outside handle in order to open

the boot lid.

IMPORTANT

•

Minimal force is required to release the
boot lid's lock - just gently press the
rubberised panel.

•

Do not place the lift force on the rubber
panel when opening the boot lid - lift the
handle. Using too much force may dam-
age the electrical contacts on the rubber
panel.

It is also possible to open the boot lid hands-
free with a kicking motion under the rear
bumper, see separate section.

WARNING

Do not drive with an open boot lid! Toxic

exhaust fumes could be drawn into the car

through the cargo area.

Related information

•

(p. 277)

•

•

Antenna locations for the start and

lock systems

An antenna for the keyless starting system
and antennas for the keyless locking system

are built into the car.

Antenna locations:

Under the cup holder in the front section
of the tunnel console
In the upper front section of the left-hand
rear door

In the upper front section of the right-hand
rear door

In the cargo area

WARNING

People with pacemaker operations should

not come closer than 22 cm (9 inches) to

the keyless system's antennas with their

pacemaker. This is to prevent interference

between the pacemaker and the keyless

system.

Related information

•

•

Settings for remotely controlled and inside
unlocking (p. 243)

Only in cars equipped with keyless locking and unlocking

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

* Option/accessory.

273

Locking and unlocking from inside

the car

The doors and boot lid can be locked and
unlocked from inside using the central lock-
ing controls in the front doors.

Central locking

Locking and unlocking button with indicator lamp in

the front door.

Unlocking using a button in the front
door

–

Press the

button to unlock all side

doors and the boot lid.

Alternative unlocking method

Opening handle for alternative unlocking in the side
door

–

Pull the opening handle on one of the side
doors and release.
> Depending on the settings in the

remote control key, either all doors will
be unlocked or only the selected door
will be unlocked and opened.

To change this setting, tap on

Settings

My Car

Locking

Remote and

Interior Unlock

in the centre display's

top view.

Locking using a button in the front
door

–

Press the

button - both front doors

must be closed.
> All doors and the boot lid are locked.

Locking using a button in the rear
door

Locking button with indicator lamp in the rear door.

The rear door lock buttons lock their respec-
tive rear door.

Unlocking the rear door

–

Pull the opening handle.
> The rear door is unlocked and opened

The figure is schematic - parts may vary depending on car model.

Provided that the child lock is not activated.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

274

Related information

•

•

Unlocking the boot lid from the inside of
the car (p. 274)

•

Activating and deactivating child safety
locks (p. 274)

Unlocking the boot lid from the

inside of the car

The boot lid can be unlocked from inside by
pressing the button on the instrument panel.

–

Brief press on the

button on the

instrument panel.
> The boot lid can be unlocked and

opened from the outside by grasping
the rubberised pressure plate.

With the power operated boot lid option

–

Long press on the

button on the

instrument panel.
> The boot lid opens.

Related information

•

Locking and unlocking from inside the car
(p. 273)

Activating and deactivating child

safety locks

The child safety lock prevents the rear doors
from being opened from inside.

The child lock can be either manual or electri-
cal

Manual child lock

Manual child lock. Not to be confused with manual

door locks.

–

Use the remote control key's detachable
key blade to turn the knob.

The door is blocked against opening from
the inside.
The door can be opened from both the
outside and the inside.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

275

Locking and unlocking from inside the car
(p. 273)

•

A door's knob control only blocks that
particular door - not both rear doors
simultaneously.

•

Cars with an electric child safety lock
do not have a manual child lock.

Electric child lock

The electric child lock can be activated and
deactivated in all ignition positions above

Activation and deactivation can be performed
up to 2 minutes after switching off the car,
provided that no door is opened.

Activation and deactivation button.

•

Lamp lit – the lock is activated.

•

Lamp not lit - the lock is deactivated.

When the child lock is activated, the following
is possible, the rear:

•

windows are only opened with the but-
tons in the driver's door.

•

doors cannot be opened from inside.

If the child lock is activated when the car is
switched off, it will remain activated the next
time the car is started.

Symbols and messages

Symbol Message

Specification

Rear child
lock

Acti-

vated

The child lock is
activated.

Rear child
lock

Deacti-

vated

The child lock is
deactivated.

Related information

•

•

Detachable key blade (p. 251)

Automatic locking when driving

The doors and boot lid are locked automati-
cally when the car starts to move.

To change this setting:

1. Tap on

Settings

in the centre display's

top view.

2. Press

My Car

Locking

3. Select

Auto Lock Doors While Driving

to deactivate or activate this function.

Related information

•

Locking and unlocking from inside the car
(p. 273)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

276

Closing and locking boot lid with

button

The buttons on the underside of the boot lid
can close and lock the car automatically.

Location of button/buttons on the underside of the

boot lid.

IMPORTANT

During manual boot lid operation, open or
close it slowly. Do not use force to open/
close it if there is resistance. It may be
damaged and stop working correctly.

Closing

–

Press the

button on the underside of

the boot lid.
> The boot lid closes automatically and

remains unlocked.

•

The button is active 24 hours after the
hatch has been left open. Thereafter, it
must be closed manually.

•

If the flap has been open for more than
30 minutes, it will close at a slow
speed.

Locking

1. Press the

button on the underside of

the boot lid.

2. Close the hatch manually.

> The boot lid and the doors are locked

Closing and locking

–

Press the

button on the underside of

the boot lid.
> The boot lid is closed automatically and

the car is locked

Operating the boot lid with foot move-
ment

•

One of the car's remote control keys
must be within range for locking and
unlocking to work.

•

When using keyless

locking or closing,

three signals will sound if the key is not
detected sufficiently close to the tail-
gate.

Applies to cars with power operated boot lid.

Applies to cars with the keyless locking/unlocking option.

Applies to cars with keyless locking/unlocking and power operated boot lid.

All doors must be closed for locking the car.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

* Option/accessory.

277

Cancel closing

•

Press the button on the instrument panel.

•

Press the remote control key's button.

•

Press the closing button on the underside
of the boot lid

•

Press the rubberised pressure plate
beneath the outside handle.

•

Using a kicking motion

The movement of the boot lid is stopped, and
it returns to fully open. The boot lid can then
be operated manually.

Pinch protection

If something with sufficient resistance pre-
vents the boot lid from closing then the pinch
protection is activated.

•

The movement is stopped, the boot lid
returns to fully open and a long signal
sounds.

WARNING

Pay attention to the risk of crushing when

closing.
Check that there is nobody near the boot

lid before starting to close it as a crush

injury may have severe consequences.
Always operate the boot lid with caution.

Related information

•

(p. 277)

•

Operating the boot lid with foot

movement

A function which allows the boot lid to open
and close by moving a foot under the rear
bumper makes life easier when your hands
are full.

If the car is equipped with keyless locking and
unlocking

then you can open the boot lid with

a foot movement.

The function with both opening and closing of
the boot lid is also available when the car is
equipped with power operated boot lid

The foot-operated boot lid function is avail-
able in two versions:

•

Only opening with foot movement.

•

Both opening and closing with foot
movement.

Note that the function for closing with foot
movement requires power operated boot
lid

Applies to cars with power operated boot lid.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

278

The sensor is positioned to the left of centre in the

bumper.

One of the car's remote control keys must be
within range behind the car, approx. 1 metre (3
feet), for opening and closing to be possible.
This also applies to an already unlocked car in
order to avoid accidental opening e.g. in a car
wash.

Opening and closing with foot
movement

Kicking motion within the detector's activation area.

–

Make

one

forward kicking motion under

the left part of the rear bumper. Then take
a step back. The bumper must not be
touched.
> A short acoustic signal sounds when

opening and closing is activated - the
boot lid is opened/closed.

If several kicking motions take place without
an approved remote control key being located
behind the car, opening or closing will not be
possible until after a certain delay.

Do not leave your foot positioned under the
car during the kicking motion. This could
cause activation to fail.

Cancel closing with a foot movement

–

Make

one

forward kicking motion while

closing is in progress in order to stop the
movement of the boot lid.
> The movement of the boot lid is stop-

ped and it returns to fully open. The
boot lid can then be operated manually.

The remote control key does not have to be in
the vicinity of the car to cancel closing.

There is a risk of reduced function, or no
function, if the rear bumper is loaded with
large amounts of ice, snow, dirt or similar.
For this reason, make sure you keep it
clean.

Pay attention to the possibility that the sys-
tem may be activated in a car wash or sim-
ilar if the remote key is within range.

Related information

•

•

Activating and deactivating private locking
(p. 279)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

279

Private locking

The boot lid and rear seat backrest can be
locked with the private locking function when
the car is taken in for service, left at a hotel or
similar. The function prevents the boot lid
from being opened and locks the rear seat
backrest in upright position.

The private locking function
button is located in the cen-
tre display function view.
Depending on the current
status of the lock,

Private

Locking Unlocked

Private Locking Locked

shown.

Related information

•

Activating and deactivating private

locking

Private locking is activated with a function
button in the centre display and an optional
PIN code.

The car needs to be in ignition mode

as a

minimum for the private locking function to
be activated.

Private locking has two codes:

•

A security code is created the first time
the function is used.

•

A new PIN code is selected every time the
function is activated.

Enter the security code before using
for the first time

A security code needs to be selected during
the first time the function is used. It can then
be used to deactivate private locking if the
selected PIN code has been forgotten or lost.
The security code acts as a PUK code for all
subsequent PIN codes set for the private lock-
ing function.

Save the security code in a safe place.

To create a security code:

1. Press the button for private locking in the

function view.

> A pop-up window is shown.

2. Enter the preferred security code and

press

Confirm

> The security code is saved. The private

locking function is now ready for activa-
tion.

Activate private locking
