WARNING

The car's electrical system must be in igni-

tion position

when replacing bulbs.

Never touch the glass part of the bulbs
with your fingers. Grease from your fingers
is vaporised by the heat, coating the reflec-
tor and then causing damage.

If an error message remains after the bro-
ken bulb has been replaced then we rec-
ommend visiting an authorised Volvo
workshop.

Outside lighting such as headlamps and
rear lamps may temporarily have conden-
sation on the inside of the lens. This is nor-
mal, all exterior lighting is designed to
withstand this. Condensation is normally
vented out of the lamp housing when the
lamp has been switched on for a time.

Related information

•

Replacing the rear direction indicator bulb
(p. 609)

•

•

Changing brake light bulb (p. 610)

•

Replacing the rear fog lamp bulb (p. 611)

•

Bulb replacement (p. 608)

Exterior lamp positions

The exterior lighting of the car uses a number
of different lamps. An LED

type lamp must

be replaced by a workshop. An authorised
Volvo workshop is recommended.

Lamps, front

Daytime running lights/position lamps/
direction indicators (LED)
Main beam (LED)

Dipped beam (LED)

Front fog lamps/cornering lights

(LED)

Some cars have no bulbs.

LED (Light Emitting Diode)

LED (Light Emmitting Diode)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MAINTENANCE AND SERVICE

}}

609

Lamps, rear

Brake light - central, high-level (LED)

Fog lamp

Position lamps (LED)

Direction indicators

Brake lights

Reversing lamps (LED)

Related information

•

•

Lighting control (p. 138)

•

Replacing the rear direction

indicator bulb

Bulbs for rear direction indicators are located
behind the panel in the side of the cargo area.

1. Press in the panel hatch at the upper edge

to detach it.

2. Move the insulation aside to access the

supporting bridge.

3. Unscrew and remove the spring bolt anti-

clockwise, press the clips into the sides
and remove the supporting bridge. It is
easiest to allow the screw to remain in the
supporting bridge.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MAINTENANCE AND SERVICE

610

4. Undo the grey bulb holder by turning it

anticlockwise and pulling it out.

5. Remove the bulb by pressing it in and

turning anticlockwise.

6. Fit a new bulb by pressing it in and turning

it clockwise.

7. Attach the bulb holder by turning it clock-

wise.

8. Fit the supporting bridge with associated

spring bolt and make sure that the clips
align in the correct position. Tighten the
spring bolt until it stops, max. 2 Nm (1.5 ft
lbs).

9. Move back the insulation and then hook in

the panel and press it back into place.

Never touch the glass part of the bulbs
with your fingers. Grease from your fingers
is vaporised by the heat, coating the reflec-
tor and then causing damage.

Related information

•

•

Bulb replacement (p. 608)

•

Changing brake light bulb

Bulbs for brake lights are located behind the
panel in the side of the cargo area.

1. Press in the panel hatch at the upper edge

to detach it.

2. Move the insulation aside to access the

brake light bulb.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MAINTENANCE AND SERVICE

}}

611

3. Undo the black bulb holder by turning it

anticlockwise and pulling it out.

4. Remove the bulb by pressing it in and

turning anticlockwise.

5. Fit a new bulb by pressing it in and turning

it clockwise.

6. Attach the bulb holder by turning it clock-

wise.

7. Move back the insulation and then hook in

the panel and press it back into place.

Never touch the glass part of the bulbs
with your fingers. Grease from your fingers
is vaporised by the heat, coating the reflec-
tor and then causing damage.

Related information

•

•

Replacing the rear fog lamp bulb

The rear foglight is fitted in the rear bumper
on the driver's side.

The rear fog light is only fitted on the driver's side.

1. Loosen the foglight unit on the driver's

side by inserting a flat object, such as a
table knife or a screwdriver, on the bulb
kit's narrower short side of the keypad and
then prize the foglight unit out.

2. Unplug the connector.

3. Undo the bulb holder by turning it anti-

clockwise and pulling it out.

4. Remove the bulb by pressing it in and

turning anticlockwise.

5. Fit a new bulb by pressing it in and turning

it clockwise.

6. Attach the bulb holder by turning it clock-

wise.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MAINTENANCE AND SERVICE

612

7. Plug in the connector.

8. Insert the hook on the wide part of the

foglight unit in the rear bumper and rotate
the unit inwards so that the clips engage.

Related information

•

•

Bulb specifications

Specifications for replaceable bulbs.

Contact a workshop

if faults occur in lamps

other than bulbs. If a fault occurs in LED

lamps, the entire lamp unit usually must be
replaced.

Function

Type

Rear direction indicators

PY24W

Brake lights

H21W LL

Rear fog lamp

H21W LL

Watt

Related information

•

Bulb replacement (p. 608)

•

Cleaning the interior

Use cleaning agents and car care products
recommended by Volvo. Clean regularly, and
deal with stains straight away. Vacuuming is
important prior to using cleaning agents.

Cleaning the centre display (p. 613)

•

Certain items of coloured clothing (e.g.
dark jeans and suede garments) may
stain the upholstery. If this occurs, it is
important to clean and treat these
parts of the upholstery as soon as pos-
sible.

•

Never use strong solvents such as
washer fluid, pure petrol or white spirit
or concentrated alcohol to clean the
interior, since this may damage the
upholstery as well as other interior
materials.

•

Never spray the cleaning agent directly
onto components that have electrical
buttons and controls. Wipe them
instead using a moistened cloth con-
taining the cleaning agent.

•

Sharp objects and Velcro may damage
the fabric upholstery.

•

Only use cleaning agents on the type
of material for which they were
intended.

An authorised Volvo workshop is recommended.

LED (Light Emitting Diode)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MAINTENANCE AND SERVICE

}}

* Option/accessory.

613

Related information

•

•

Cleaning fabric upholstery and headlining
(p. 614)

•

Cleaning the seatbelts (p. 615)

•

Cleaning floor mats and inlay mats
(p. 615)

•

Cleaning leather upholstery

(p. 616)

•

Cleaning the leather steering wheel
(p. 617)

•

Cleaning interior plastic, metal and wood
parts (p. 617)

Cleaning the centre display

Dirt, stains and grease from fingers can affect
the centre display's performance and reada-
bility. Clean the screen frequently with a
microfibre cloth.

1. Turn off the centre display with a long

press on the home button.

2. Wipe the screen with the microfibre cloth

supplied or use another microfibre cloth of
equivalent quality. Wipe the screen with a
clean and dry microfibre cloth using small
circular movements. If necessary, lightly
moisten the microfibre cloth with clean
water.

3. Activate the display with a short press on

the home button.

The microfibre cloth used to clean the cen-
tre display must be free from sand and dirt.

When cleaning the centre display, only use
gentle pressure on the screen. Heavy pres-
sure can damage the screen.

Cleaning the interior (p. 612)

Do not spray any liquid or caustic chemi-
cals directly on the centre display. Do not
use window cleaning agent, other cleaning
agents, aerosol spray, solvents, alcohol,
ammonia or cleaning agent containing
abrasive.

Never use abrasive cloths, paper towels or
tissue paper, since they may scratch the
centre display.

Related information

•

•

Cleaning fabric upholstery and headlining
(p. 614)

•

Cleaning the seatbelts (p. 615)

•

Cleaning floor mats and inlay mats
(p. 615)

•

Cleaning leather upholstery

(p. 616)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MAINTENANCE AND SERVICE

* Option/accessory.

614

•

Cleaning the leather steering wheel
(p. 617)

•

Cleaning interior plastic, metal and wood
parts (p. 617)

Cleaning fabric upholstery and

headlining

It is recommended to use a fabric cleaning
agent when cleaning textile fabric. Clean if
necessary, and treat stains straight away.

Never scrape or rub a stain since this may
damage the upholstery.

Never use stain removing agent or strong
solvents, they could damage the uphols-
tery.

Cleaning fabric upholstery

1. Start by vacuum cleaning the upholstery.
2. Follow the instructions for the fabric

cleaning agent.

3. When cleaning fabric, a spray extraction

cleaner is recommended for suction of the
washing fluid and subsequent water rins-
ing.

Some coloured clothing (such as jeans and
suede garments) may stain the fabric
upholstery. Heavy stains such as oil may
be difficult to remove.

Always clean the entire upholstery, even
there are only individual stains. This is to
avoid water rings.

Do not remove the upholstery for cleaning.

Cleaning the headlining

1. Brush the headlining carefully using a soft

brush.

2. Follow the instructions for the fabric

cleaning agent.

3. Then use a soft and lint-free cloth to wipe

the headlining.
