KEY, LOCKS AND ALARM

* Option/accessory.

230

WARNING

Check that the battery is fitted correctly

with the correct polarity. If the remote con-

trol key shall not been used for a long time,

remove the battery to avoid battery leakage

and damage. Batteries with damage or

leaks may cause corrosive injury on contact

with the skin. Therefore, use protective

gloves when handling damaged batteries.

•

Keep batteries out of the reach of chil-
dren.

•

Do not leave batteries lying around
since they can be swallowed by chil-
dren or pets.

•

Batteries must not: be dismantled,
short-circuited or thrown into open
flames.

•

Do not charge non-rechargeable bat-
teries, this may cause an explosion.

Before use, the remote control key should

be checked to avoid causing damage. If

damage is discovered, e.g. if the battery

cover cannot be closed properly, then the

product should not be used. Keep defec-

tive products out of the reach of children.

IMPORTANT

Make sure that exhausted batteries are dis-
posed of in a manner which is kind to the
environment.

Related information

•

Locking and unlocking with the detacha-
ble key blade (p. 232)

•

Starting the car (p. 420)

•

Remote control key (p. 221)

Ordering more remote control keys

The car is supplied with two remote control
keys. A button-less key is supplied if the car
is equipped with keyless locking and unlock-
ing

*

. Additional keys can be ordered.

A total of twelve keys can be programmed and
used for one single car. If additional keys are
ordered, additional driver profiles are added -
one per new remote control key. This also
applies for the key tag.

Loss of a remote control key

If you lose a remote control key then a new
one can be ordered at a workshop - an author-
ised Volvo workshop is recommended. The
remaining remote control keys must be taken
to the workshop. The code of the missing key
must be erased from the system as a theft
prevention measure.

The current number of keys registered to the
car can be checked via driver profiles in the
centre display's top view, select

Settings

System

Driver Profiles

.

Related information

•

Remote control key (p. 221)

KEY, LOCKS AND ALARM

}}

* Option/accessory.

231

Detachable key blade

The remote control key contains a detachable
key blade of metal with which a number of
functions can be activated and some opera-
tions carried out.

The key blade's unique code is provided by
authorised Volvo workshops, which are rec-
ommended when ordering new key blades.

The key blade's application areas

Using the remote control key's detachable key
blade

•

the left-hand

7

 front door can be opened

manually if central locking cannot be acti-
vated with the remote control key

•

all doors are emergency-locked

•

the rear doors' mechanical child safety
locks can be activated and deactivated.

The button-less key

8

 does not have a detacha-

ble key blade. If necessary, use the detachable
key blade from the normal remote control key.

Detaching the key blade

 Hold the remote control key with the

front visible and the Volvo logo facing the
right way - slide the button at bottom
edge by the key ring to the right. Guide
the front side's shell a few millimetres
upwards.

 The shell will then come free and can

be lifted off the key.

 Detach the key blade by angling it up.

Return the key blade to its intended posi-
tion in the remote control key after use.

 Refit the shell by pressing it downward

until a clicking sound is heard.

 Then slide the shell back.

> A further click will indicate that the

shell is securely attached.

7

This applies whether the car is left-hand drive or right-hand drive.

8

Supplied with cars equipped with keyless locking/unlocking

*

.

||

KEY, LOCKS AND ALARM

232

Related information

•

Locking and unlocking with the detacha-
ble key blade (p. 232)

•

Remote control key (p. 221)

Locking and unlocking with the

detachable key blade

Amongst other things, the detachable key
blade can be used to unlock the car from the
outside - e.g. if the remote control key's bat-
tery has become discharged.

Unlocking

Pull out the front door handle on the left-
hand side

9

 to its end position so that the

lock cylinder become visible.

Insert the key in the lock cylinder.

Turn clockwise 45 degrees so that the key
blade is pointing straight back.

Turn the key back 45 degrees to its star-
ting position. Remove the key from the
lock cylinder and release the handle so
that the rear section of the handle is rest-
ing against the car again.

5. Pull out the handle.

> The door opens.

Locking will be performed in the same way,
but with an anticlockwise turn 45 degrees
instead of clockwise in step (3).

9

This applies whether the car is right-hand drive or left-hand drive.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

233

Switch off the alarm and start the car

*

NOTE

When the door is unlocked using the key
blade and is then opened, the alarm is trig-
gered.

The backup reader's location in the storage compart-

ment.

Deactivate the alarm as follows:

1. Place the remote control key on the key

symbol in the backup reader in the tunnel
console's storage compartment.

2. Press the start button.

> The alarm signal stops sounding and

the alarm is switched off.

Locking

It is also possible to lock the car with the
remote control key's detachable key blade e.g.
in the event of a loss of power or if the key's
battery has become discharged.

The left-hand front door can be locked with its
lock cylinder and the detachable key blade.

Other doors have no lock cylinders and
instead have a lock switch on the end of each
door which must be depressed using the key
blade - they are then mechanically locked/
blocked to prevent them being opened from
outside.

The doors can still be opened from the inside.

Manual locking of the door. Not to be mixed up with

the child safety locks.

–

Remove the detachable key blade from
the remote control key. Insert the key
blade in the hole for lock reset and press
the key in until it bottoms, approx. 12 mm
(0.5 inches).

The door can be opened from both the
outside and the inside.
The door is blocked against opening from
the outside. To return to position A, the
inner door handle must be opened.

The doors can also be unlocked with the
unlock button on the remote control key or
with the central locking button on the driver's
door.

NOTE

•

A door's lock reset only locks that par-
ticular door - not all doors simultane-
ously.

•

A manually locked rear door with acti-
vated manual or electric child safety
locks cannot be opened from either the
outside or the inside. A rear door that is
locked in this way can only be
unlocked with the remote control key,
central locking button or via Volvo On
Call

*

.

||

KEY, LOCKS AND ALARM

* Option/accessory.

234

Related information

•

Starting the car (p. 420)

•

Detachable key blade (p. 231)

•

Activating and deactivating alarms

*

(p. 263)

•

Replacing the battery in the remote con-
trol key (p. 226)

•

Remote control key (p. 221)

Immobiliser

The electronic immobiliser is a theft protec-
tion system that prevents an unauthorised
person from starting the car.

The car can only be started with the correct
remote control key.

The following error message in the driver dis-
play is related to the electronic immobiliser:

Symbol Message

Specification

Car key not
found

See
Owner's
manual

Error reading the
remote control
key during star-
ting - place the
key on the key
symbol in the
storage compart-
ment and try
again.

Related information

•

Remote control key (p. 221)

•

Ordering more remote control keys
(p. 230)

KEY, LOCKS AND ALARM

}}

* Option/accessory.

235

Type approval for the remote

control key system

Type approval for the car's remote key sys-
tem can be seen in the following tables.

For detailed information on type approval, go
to www.volvocars.com/intl/support.

Lock system keyless start (Passive
Start) and keyless locking/unlocking
(Passive Entry

*

)

CEM marking for the remote control key system. For

supplementary type approval numbers, see following

tables.

Country/Area

Type approval

Europe

Delphi Deutschland GmbH, 42367 Wuppertal hereby declares that
this CV1-134TRX conforms to the essential property requirements and
other relevant provisions contained in directive 2014/53/EU (RED).

The full text of the EU declaration of conformity can be found at
www.volvocars.com/intl/support

Jordan

TRC/LPD/2014/250

Serbia

P1614120100

Argentina

CNC ID: C-14771

||

KEY, LOCKS AND ALARM

236

Country/Area

Type approval

Brazil

MT-3245/2015

Indonesia

Nomor: 38301/SDPPI/2015

Malaysia

RAAT/37A/1215/S(15-5198)

Mexico

IFETEL: RLVDEVO15-0396

Russia

The United Arab Emi-
rates

ER37847/15

DA0062437/11

KEY, LOCKS AND ALARM

}}

237

Country/Area

Type approval

Namibia

TA-2016-02

South Africa

TA-2014-1868

||

KEY, LOCKS AND ALARM

238

Remote control key

Country/
Area

Type approval

Europe

Huf Hülsbeck & Fürst GmbH & Co. KG hereby declares that this type of radio
equipment HUF8423 conforms to directive 2014/53/EU.

The full text of the EU declaration of conformity can be found at
www.volvocars.com/intl/support

Wavelength: 433.92 MHz

Maximum radiated transmission power: 10 mW

Manufacturer: Huf Hülsbeck & Fürst GmbH & Co. KG, Steeger Str. 17, 42551
Velbert, Germany

Argentina

H-15532

Brazil

Anatel: 05568-16-06643

Modelo: HUF8423

Este equipomento opera em caráter secundário isto é não tem direito a proteção
contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode
causar interferência a sistemas operando em caráter primário.

KEY, LOCKS AND ALARM

}}

239

Country/
Area

Type approval

CU
(Customs
Union)

Belarus,
Kazakhstan,
Russia

Indonesia

[41005/SDPPI/2015]

[5149]

Jordan

TRC/LPD/2015/104

Morocco

AGREE PAR L'ANRT MAROC

Numéro d’agrément: MR 10668 ANRT 2015

Date d’agrément: 24/07/2015

Moldova

||

KEY, LOCKS AND ALARM

240

Country/
Area

Type approval

Mexico

IFETEL

Marca: HUF

Modelo (s): HUF8423

NOM-121-SCT1-2009

La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es
posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este
equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda
causar su operación no deseada.

Nigeria

Connection and use of this communication equipment is permitted by the
Nigerian Communications Commission

Oman

KEY, LOCKS AND ALARM

}}

241

Country/
Area

Type approval

Philippines

Serbia

Singapore

Complies with IMDA Standards

DA103787

South Africa

TA-2015-432

||

KEY, LOCKS AND ALARM

242

Country/
Area

Type approval

Taiwan

本產品符合低 率電波輻射性電機管理辦法



第十二條 第十四條等條文規定

 1.

經

型式認證合格之低 率射頻電機，非經許可，公司 商號或使用者均不得擅自變更

頻



率

大 率或變更原設計之特性及 能

 2.

低 率射頻電機之使用不得影響

飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時

方得繼續使用



前項合法通信，指依電信法規定作業之無線電通信



低 率射頻

電機須忍受合法通信或工業 科學及醫療用電波輻射性電機設備之干擾

The United
Arab Emi-
rates

KEY, LOCKS AND ALARM

}}

243

Key Tag

Country/
Area

Type approval

Europe

Huf Hülsbeck & Fürst GmbH & Co. KG hereby declares that this type of radio
equipment HUF8432 conforms to directive 2014/53/EU.

The full text of the EU declaration of conformity can be found at
www.volvocars.com/intl/support.

Wavelength: 433.92 MHz

Maximum radiated transmission power: 10 mW

Manufacturer: Huf Hülsbeck & Fürst GmbH & Co. KG, Steeger Str. 17, 42551
Velbert, Germany

Argentina

H-15029

Brazil

Anatel: 04362-16-06643

Modelo: HUF8432

Este equipo opera em caráter secundário isto é não tem direito a proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar
interferência a sistemas operando em caráter primário.

||

KEY, LOCKS AND ALARM

244

Country/
Area

Type approval

CU
(Customs
Union)

Belarus,
Kazakhstan,
Russia

Indonesia

[41006/SDPPI/2015]

[5149]

Jordan

TRC/LPD/2015/107

Morocco

AGREE PAR L'ANRT MAROC

Numéro d’agrément: MR 10667 ANRT 2015

Date d’agrément: 24/07/2015

Mexico

IFETEL

Marca: HUF

Modelo (s): HUF8432

NOM-121-SCT1-2009

IFT: RLVHUHU15-0972

La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es
posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este
equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda
causar su operación no deseada.

KEY, LOCKS AND ALARM

}}

245

Country/
Area

Type approval

Moldova

Nigeria

Connection and use of this communications equipment is permitted by the
Nigerian Communications Commission

Oman

Philippines

ESD-1511501C
