SOUND, MEDIA AND INTERNET

}}

* Option/accessory.

537

Remove Wi-Fi network

Removing a network that is not to be used.

1. Press

Settings

 in the top view.

2. Continue to

Communication

Wi-Fi

Saved networks

.

3. Tap on

Forget

 alongside the network to

be removed.

4. Confirm the selection.

> The car will no longer connect to the

network in future.

Remove all networks

All networks can be removed simultaneously
by restoring factory settings. Please note that
all user data and system settings are reset to
original factory settings.

Related information

•

Internet-connected car

*

 (p. 531)

•

No or poor Internet connection (p. 536)

•

Resetting settings in the centre display
(p. 132)

•

Connect the car to the Internet via a
phone (Wi-Fi) (p. 533)

Wi-Fi technologies and security

Possible network types to connect to.

It is only possible to connect to the following
types of network:

•

Frequency — 2.4 or 5 GHz

15

.

•

Standards — 802.11 a/b/g/n.

•

Security type — WPA2-AES-CCMP.

The car’s Wi-Fi system is designed to handle
Wi-Fi devices inside the car.

If several devices operate on the frequency at
the same time then it may result in reduced
performance.

Related information

•

Internet-connected car

*

 (p. 531)

User terms and conditions and

data sharing

The first time certain services and apps are
started, a pop-up window with the headings

Terms and conditions

 and

Data sharing

may be shown.

The purpose is to inform about Volvo's user
terms and conditions and policy for data shar-
ing. By accepting data sharing, the user
accepts that certain information is sent from
the car. This is required so that certain servi-
ces and apps can have full functionality.

The data sharing function for online services
and apps is deactivated as default

16

. Data

sharing needs to be activated so that certain
online services and apps in the car can be
used. Data sharing can be set from the centre
display's settings menu or in connection with
the services or apps being started in the cen-
tre display.

Privacy and data sharing

With the software update made available
November 2017, privacy and data sharing set-
tings were introduced for online services and
downloaded apps. The settings can be found
under

Privacy and data

 in the settings menu

in the car's centre display.

15

Selection of frequency is not available on all markets.

16

Does not apply to Volvo On Call

*

.

||

SOUND, MEDIA AND INTERNET

538

There you can select the online services which
are allowed to share data. Data sharing for
downloaded apps can also be deactivated
there. Note that services and apps cannot be
used as intended if data sharing is deacti-
vated.

After a factory reset or e.g. a workshop visit or
software update, the data sharing settings
may have been reset to their default settings.
In which case, reactivate data sharing for
online services and for downloaded apps.

NOTE

Privacy and data sharing settings are
unique for every driver profile.

Related information

•

Activating and deactivating data sharing
(p. 538)

Activating and deactivating data

sharing

Data sharing for services and apps required
can be set in the centre display's settings
menu.

1. Press

Settings

 in the top view in the cen-

tre display.

2. Press

System

Privacy and data

.

3. Select activation or deactivation of data

sharing for individual services and all apps.

If data sharing has not been activated for an
online service or downloaded apps, this can be
done when they are started in the centre dis-
play. If this is the first time a service is started,
or e.g. after a factory reset or certain software
updates, Volvo's terms and conditions for
online services need to be approved. Note that
data sharing will then also be activated for
other services or apps for which sharing has
already been approved.

NOTE

After a visit to a Volvo workshop, you may
need to reactivate data sharing so that the
online services and apps shall work again.

Related information

•

User terms and conditions and data shar-
ing (p. 537)

Data sharing for services

If you have not activated data sharing for an
online service or for downloaded apps, you
can do this in connection with starting them
in your centre display. If this is the first time
you are starting a service, or e.g. after a fac-
tory reset or certain software updates, you
also need to approve Volvo's terms and con-
ditions for online services.

SOUND, MEDIA AND INTERNET

539

Activate data sharing when you start a
service

1. Select the function or service to be acti-

vated.
> If this is the first time you are using the

service, or e.g. after a factory reset or
certain software updates, you first need
to approve Volvo's terms and condi-
tions for online services in order to con-
tinue.

2. Select to approve data sharing for the

service or to cancel.

If you select to approve, data sharing is acti-
vated and you can start to use the service.

Activate data sharing when you start
an app

To approve data sharing for an app that needs
the function, start the app and tap on

Allow

 in

the pop-up window.

You can deactivate data sharing for services
and apps in the settings menu under

System

Privacy and data

Data Sharing

.

Storage space on hard disk

It is possible to view how much free space
there is on the car's hard disk.

Storage information for the car's hard disk,
including total capacity, available capacity and
how much space is used for installed apps can
be shown. The information is available under

Settings

System

System Information

Storage

.

Related information

•

Apps (p. 498)

SOUND, MEDIA AND INTERNET

540

License agreement for audio and

media

A license is an agreement for the right to
operate a certain activity or the right to use
someone else's entitlement according to the
terms and conditions in the agreement. The
following texts are Volvo's agreements with
manufacturers/developers.

Bowers & Wilkins

Bowers & Wilkins and B&W are trademarks
of the B&W Group Ltd. Nautilus is a trade-
mark of B&W Group Ltd. Kevlar is a registered
trademark of DuPont.

Dirac Unison

®

Dirac Unison co-optimises the loudspeakers in
frequency, time and space for the best possi-
ble bass integration and clarity. It enables a
faithful reproduction of the acoustic characte-
ristics of specific performance venues. Using
advanced algorithms, Dirac Unison controls all
loudspeakers digitally based on acoustic high-
precision measurements. Like a conductor of
an orchestra, it guarantees that the loudspeak-
ers perform in perfect unison.

DivX

®

DivX

®

, DivX Certified

®

 and associated logo-

types are trademarks belonging to DivX, LLC
and are used under licence.

This DivX Certified

®

 device can play back

DivX

®

 Home Theater video files up to 576p

(including .avi, .divx). Download free software
on www.divx.com to create, play back and
stream digital video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certified

®

 device must be registered in order

to play back purchased DivX Video-on-
Demand (VOD) films. Get the registration
code by locating the DivX VOD section in the
device's settings menu. Go to vod.divx.com
for more information on how to complete the
registration.

Patent numbers

Protected by one or more of the following US
patents. 7,295,673; 7,460,668; 7,515,710;
8,656,183; 8,731,369; RE45,052.

Gracenote

®

SOUND, MEDIA AND INTERNET

}}

541

Parts of the content are copyright

 of

Gracenote or its suppliers.

Gracenote,Gracenote logo and logotype,
"Powered by Gracenote" and Gracenote
MusicID are either registered trademarks or
trademarks of Gracenote, Inc. in the USA
and/or other countries.

Gracenote

®

 End User License Agreement

This program or device contains software from
Gracenote, Inc. of Emeryville, California, USA
("Gracenote"). The software from Gracenote
("Gracenote software") activates this program
to perform disc and/or file identification and
obtain music-related information, including
name, artist, track and title ("Gracenote data")
from online servers or embedded databases
(together called "Gracenote servers") and in
order to perform other actions. You may only
use Gracenote data in accordance with the
intended end-user functions for this program
or this device.

You agree to only use Gracenote data, Grace-
note software and Gracenote servers for your
own personal non-commercial use. You agree
not to assign, copy, transfer or transmit this
Gracenote software or any Gracenote data to
any third party. YOU AGREE NOT TO USE OR
EXPLOIT GRACENOTE DATA, GRACENOTE
SOFTWARE OR GRACENOTE SERVERS,
EXCEPT AS EXPRESSLY PERMITTED IN
THIS AGREEMENT.

You agree that your non-exclusive right to use
Gracenote data, Gracenote software and
Gracenote servers will be terminated if you
violate these restrictions. If your license is ter-
minated you agree to cease all use of Grace-
note data, Gracenote software and Gracenote
servers. Gracenote holds exclusive rights to all
Gracenote data, all Gracenote software and all
Gracenote servers, including all ownership
rights. Gracenote will under no circumstances
have any obligation to pay you for any informa-
tion you provide. You agree that Gracenote,
Inc. may enforce the company's rights under
this agreement against you directly in its own
name.

The Gracenote service uses a unique identifier
to track enquiries for statistical purposes. The
purpose of a randomly assigned numeric iden-
tifier is to enable the Gracenote service to
count enquiries without knowing anything
about who you are. Additional information is
available on the web page for Gracenote's pri-
vacy policy for the Gracenote service.

The Gracenote software and everything
included in Gracenote data are licensed to you
"as is". Gracenote provides no undertakings or
warranties, express or implied, as to the accu-
racy of the Gracenote data contained in the
Gracenote servers. Gracenote reserves the
right to delete data from the Gracenote serv-
ers or to change data categories for any rea-
son that Gracenote deems sufficient. No war-

ranty is provided that the Gracenote software
or Gracenote servers are fault-free or that the
Gracenote software or Gracenote servers will
operate without interruption. Gracenote has
no obligation to provide you with new,
improved or additional data types or catego-
ries that Gracenote may provide in the future,
and the company reserves the right to discon-
tinue its services at any time.

GRACENOTE DISCLAIMS ALL WARRAN-
TIES, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTA-
BILITY, FITNESS FOR A PARTICULAR PUR-
POSE, TITLE AND NON-INFRINGEMENT OF
INTELLECTUAL PROPERTY RIGHTS.
GRACENOTE DOES NOT GUARANTEE THE
RESULTS OBTAINED THROUGH YOUR USE
OF THE GRACENOTE SOFTWARE OR A
GRACENOTE SERVER. GRACENOTE WILL
IN NO EVENT BE LIABLE FOR ANY CONSE-
QUENTIAL DAMAGE OR FOR ANY LOST
PROFITS OR REVENUES.

 Gracenote, Inc. 2009

Sensus software

This software uses parts of sources from clib2
and Prex Embedded Real-time OS - Source
(Copyright (c) 1982, 1986, 1991, 1993, 1994),
and Quercus Robusta (Copyright (c) 1990,
1993), The Regents of the University of
California. All or some portions are derived

||

SOUND, MEDIA AND INTERNET

542

from material licensed to the University of
California by American Telephone and
Telegraph Co. or Unix System Laboratories,
Inc. and are reproduced herein with the
permission of UNIX System Laboratories, Inc.
Redistribution and use in source and binary
forms, with or without modification, are
permitted provided that the following
conditions are met: Redistributions of source
code must retain the above copyright notice,
this list of conditions and the following
disclaimer. Redistributions in binary form must
reproduce the above copyright notice, this list
of conditions and the following disclaimer in
the documentation and/or other materials
provided with the distribution. Neither the
name of the <ORGANIZATION> nor the
names of its contributors may be used to
endorse or promote products derived from
this software without specific prior written
permission. THIS SOFTWARE IS PROVIDED
BY THE COPYRIGHT HOLDERS AND
CONTRIBUTORS "AS IS" AND ANY
EXPRESS OR IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE DISCLAIMED.
IN NO EVENT SHALL THE COPYRIGHT
OWNER OR CONTRIBUTORS BE LIABLE
FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING,

BUT NOT LIMITED TO, PROCUREMENT OF
SUBSTITUTE GOODS OR SERVICES; LOSS
OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND
ON ANY THEORY OF LIABILITY, WHETHER
IN CONTRACT, STRICT LIABILITY, OR TORT
(INCLUDING NEGLIGENCE OR
OTHERWISE) ARISING IN ANY WAY OUT
OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE.

This software is based in part on the work of
the Independent JPEG Group.

This software uses parts of sources from
"libtess". The Original Code is: OpenGL
Sample Implementation, Version 1.2.1,
released January 26, 2000, developed by
Silicon Graphics, Inc. The Original Code is
Copyright (c) 1991-2000 Silicon Graphics,
Inc. Copyright in any portions created by third
parties is as indicated elsewhere herein. All
Rights Reserved. Copyright (C) [1991-2000]
Silicon Graphics, Inc. All Rights Reserved.
Permission is hereby granted, free of charge,
to any person obtaining a copy of this
software and associated documentation files
(the "Software"), to deal in the Software
without restriction, including without
limitation the rights to use, copy, modify,
merge, publish, distribute, sublicense, and/or
sell copies of the Software, and to permit
persons to whom the Software is furnished to

do so, subject to the following conditions: The
above copyright notice including the dates of
first publication and either this permission
notice or a reference to http://oss.sgi.com/
projects/FreeB/ shall be included in all copies
or substantial portions of the Software. THE
SOFTWARE IS PROVIDED "AS IS",
WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO THE WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE AND
NONINFRINGEMENT. IN NO EVENT SHALL
SILICON GRAPHICS, INC. BE LIABLE FOR
ANY CLAIM, DAMAGES OR OTHER
LIABILITY, WHETHER IN AN ACTION OF
CONTRACT, TORT OR OTHERWISE,
ARISING FROM, OUT OF OR IN
CONNECTION WITH THE SOFTWARE OR
THE USE OR OTHER DEALINGS IN THE
SOFTWARE. Except as contained in this
notice, the name of Silicon Graphics, Inc. shall
not be used in advertising or otherwise to
promote the sale, use or other dealings in this
Software without prior written authorization
from Silicon Graphics, Inc.

This software is based in parts on the work of
the FreeType Team.

This software uses parts of SSLeay Library:
Copyright (C) 1995-1998 Eric Young
(eay@cryptsoft.com). All rights reserved

SOUND, MEDIA AND INTERNET

}}

543

Linux software

This product contains software licensed under
GNU General Public License (GPL) or GNU
Lesser General Public License (LGPL), etc.

You have the right of acquisition, modification,
and distribution of the source code of the
GPL/LGPL software.

You may download Source Code from the
following website at no charge: http://
www.embedded-carmultimedia.jp/linux/oss/
download/TVM_8351_013

The website provides the Source Code "As Is"
and without warranty of any kind.

By downloading Source Code, you expressly
assume all risk and liability associated with
downloading and using the Source Code and
complying with the user agreements that
accompany each Source Code.

Please note that we cannot respond to any
inquiries regarding the source code.

camellia:1.2.0

Copyright (c) 2006, 2007

NTT (Nippon Telegraph and Telephone
Corporation). All rights reserved.

Redistribution and use in source and binary
forms, with or without modification, are
permitted provided that the following
conditions are met:

1. Redistributions of source code must retain

the above copyright notice, this list of
conditions and the following disclaimer as
the first lines of this file unmodified.

2. Redistributions in binary form must

reproduce the above copyright notice, this
list of conditions and the following
disclaimer in the documentation and/or
other materials provided with the
distribution.

THIS SOFTWARE IS PROVIDED BY NTT ``AS
IS'' AND ANY EXPRESS OR IMPLIED
WARRANTIES, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE ARE
DISCLAIMED. IN NO EVENT SHALL NTT BE
LIABLE FOR ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING,
BUT NOT LIMITED TO, PROCUREMENT OF
SUBSTITUTE GOODS OR SERVICES; LOSS
OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND
ON ANY THEORY OF LIABILITY, WHETHER
IN CONTRACT, STRICT LIABILITY, OR TORT
(INCLUDING NEGLIGENCE OR
OTHERWISE) ARISING IN ANY WAY OUT
OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE.

Unicode: 5.1.0

COPYRIGHT AND PERMISSION NOTICE

Copyright c 1991-2013 Unicode, Inc. All rights
reserved. Distributed under the Terms of Use
in http://www.unicode.org/copyright.html.

Permission is hereby granted, free of charge,
to any person obtaining a copy of the Unicode
data files and any associated documentation
(the "Data Files") or Unicode software and any
associated documentation (the "Software") to
deal in the Data Files or Software without
restriction, including without limitation the
rights to use, copy, modify, merge, publish,
distribute, and/or sell copies of the Data Files
or Software, and to permit persons to whom
the Data Files or Software are furnished to do
so, provided that (a) the above copyright
notice(s) and this permission notice appear
with all copies of the Data Files or Software,
(b) both the above copyright notice(s) and this
permission notice appear in associated
documentation, and (c) there is clear notice in
each modified Data File or in the Software as
well as in the documentation associated with
the Data File(s) or Software that the data or
software has been modified.

THE DATA FILES AND SOFTWARE ARE
PROVIDED "AS IS", WITHOUT WARRANTY
OF ANY KIND, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE
WARRANTIES OF MERCHANTABILITY,

VOLVO ON CALL

* Option/accessory.

552

Plan and schedule the charging of

your car using the Volvo On Call

*

app

You can use the Volvo On Call app to plan
and schedule the charging of your car.

You can schedule charging for the charging
stations you have saved in your app, which
may be practical if, for example, you need to
plan charging points along a travel itinerary or
when you are planning charging intervals for
your car at home or in your neighbourhood.

1. Via the

Home

 tab, select

Fuel range

 or

Battery charging

.

> In the view that appears you can see

saved charging stations under

Saved

locations

. If you have not saved a

charging station yet or want to add
new locations, e.g. charging stations
along a travel itinerary or in your neigh-
bourhood, you can select the option for

Add location

 (you can save up to eight

charging stations).

2. Select the location for which you want to

schedule charging.
> A view opens for the saved location.

3. Select a start time for the charging.

4. Select an end time for the charging.

5. Go back to the view for fuel.

> A charging icon appears by the saved

location for which you have scheduled
the charging. When the icon disappears
again the scheduling has been saved
and programmed.

WHEELS AND TYRES

554

Tyres

The function of the tyres is to carry load, pro-
vide grip on the road surface, dampen vibra-
tion and protect the wheel from wear.

The tyres greatly affect the car's driving cha-
racteristics. The type of tyre, dimensions, tyre
pressure and speed rating are important for
how the car performs.

The car is fitted with tyres according to the
tyre information sticker found on the driver's
side door pillar (between the front door and
the rear door).

WARNING

A damaged tyre may lead to loss of control

over the car.

Recommended tyres

On delivery, the car is equipped with Volvo
original tyres that have the VOL

1

 marking on

the side of the tyres. These tyres are carefully
adapted to the car. In the event of changing
tyres, it is therefore important that the new
tyres also have this marking in order for the
car's driving characteristics, comfort and fuel
consumption to be maintained.

New tyres

Tyres are perishable. After a few years they
begin to harden at the same time as the fric-
tion capacity/characteristics gradually deterio-
rate. For this reason, aim to get as fresh tyres
as possible when you replace them. This is
especially important with regard to winter
tyres. The last four digits in the sequence
mean the week and year of manufacture. This
is the tyre's DOT marking (Department of
Transportation), and this is stated with four
digits, for example 0717. The tyre is then man-
ufactured in week 07, year 2017.

Tyre age

All tyres older than 6 years old should be
checked by an expert even if they seem
undamaged. Tyres age and decompose, even
if they are hardly ever or never used. The func-

tion can therefore be affected. This applies to
all tyres that are stored for future use. Exam-
ples of external signs which indicate that the
tyre is unsuitable for use are cracks or disco-
louration.

Tyre economy

•

Maintain the correct tyre pressure.

•

Avoid fast starts, heavy braking and
squealing tyres.

•

Tyre wear increases with speed.

•

Correct wheel alignment is very important.

•

Unbalanced wheels worsen tyre economy
and travelling comfort.

•

The tyres must have the same direction of
rotation during their entire service life.

•

When you change tyres, the tyres with the
best tread must be fitted on the rear
wheels to reduce the risk of oversteer dur-
ing heavy braking.

•

If you drive over kerbstones or deep holes
you can damage the tyres and/or wheel
rims permanently.

Tyre rotation

The car has no mandatory tyre rotation. Driv-
ing style, tyre pressure, climate and road con-
dition affect how quickly the tyres age and

1

There may be deviations for certain tyre dimensions.

WHEELS AND TYRES

* Option/accessory.

555

wear. Correct tyre pressure results in more
even wear.

To avoid differences in tread depth and to pre-
vent wear patterns forming on the tyres, the
front and rear wheels should be switched with
each other. A suitable distance for the first
change is approx. 5000 km (approx.
3100 miles) and then at 10000 km (approx.
6200 miles) intervals.

Volvo recommends the an authorised Volvo
workshop is contacted for checking if you are
uncertain about tread depth. If significant dif-
ferences in wear (> 1 mm difference in tread
depth) between tyres have already occurred,
then the least worn tyres must always be fit-
ted on the rear. Understeer is normally easier
to correct than oversteer, and leads to the car
continuing forwards in a straight line rather
than having the rear end skidding to one side,
resulting in possible complete loss of control
over the car. This is why it is important for the
rear wheels never to lose grip before the front
wheels.

Storing wheels and tyres

When you store complete wheels (tyres fitted
on wheel rims) they should be hung up or
positioned lying on their sides on the floor.

Tyres not fitted on rims must be stored lying
on their sides or standing upright, but not
hung up.

IMPORTANT

Tyres should be stored in a cool, dry and
dark place, and should never be stored
close to solvents, petrol, oils, etc.

WARNING

•

Wheel rim size and tyre size for your
Volvo are specified to meet stringent
requirements for stability and driving
characteristics. Unapproved combina-
tions of wheel rim size and tyre size
may have a negative effect on the car's
stability and driving characteristics.

•

Any damage caused by the fitting of
unapproved combinations of wheel rim
size and tyre size is not covered by the
new car warranty. Volvo accepts no lia-
bility for death, personal injury or any
costs caused by such installations.

Related information

•

Checking tyre pressure (p. 558)

•

Tyres' rotation direction (p. 557)

•

Tread wear indicators on the tyres
(p. 558)

•

Tyre pressure monitoring system

*

(p. 560)

•

Emergency puncture repair kit (p. 574)

•

Dimension designation for tyre (p. 556)

•

Approved wheel and tyre sizes (p. 671)

•

Recommendations for loading (p. 589)

WHEELS AND TYRES

556

Dimension designation for tyre

Designations for tyre dimension, load index
and speed rating.

The car has an approval for the complete vehi-
cle with certain combinations of wheel rims
and tyres.

Designation of dimensions

All tyres have a dimension designation, such
as: 245/45 R18 100 W.

245 Tyre width (mm)

45

Ratio between tyre wall height and
tyre width (%)

R

Radial ply

18

Rim diameter in inches

100 Codes for the maximum permitted

tyre load, tyre load index (LI)

W

Speed rating for maximum permitted
speed, speed rating (SS). (In this
case 270 km/h (168 mph).)

Load index

Each tyre has a certain capacity to carry a
load, a load index (LI). The car's weight deter-
mines the load capacity required of the tyres.

Speed rating

Each tyre can withstand a certain maximum
speed. Tyre speed rating, SS (Speed Symbol),
must at least correspond with the car's top
speed. The table below shows the maximum
permitted speed for each speed rating (SS).
The only exception to these regulations is win-
ter tyres

2

, where a lower speed rating may be

used. If such a tyre is selected, the car must
not be driven more quickly than the tyre is
rated for. For example, cars with Q rating tyres
must be driven at speeds not exceeding
160 km/h (100 mph). The road conditions and
applicable road traffic rules determine how
quickly the car can be driven, not the speed
rating of the tyres.

NOTE

The maximum permitted speed is specified
in the table.

Q

160 km/h (100 mph) (used only on
winter tyres)

T

190 km/h (118 mph)

H

210 km/h (130 mph)

V

240 km/h (149 mph)

W 270 km/h (168 mph)

Y

300 km/h (186 mph)

WARNING

The lowest permitted tyre load index (LI)

and speed rating (SS) for the tyres for each

respective engine variant are shown in the

specifications, which can be found in the

printed owner's manual. If a tyre with too

low a load index or speed rating is used, it

may overheat and be damaged.

Related information

•

Tyres (p. 554)

•

Dimension designation for wheel rim
(p. 557)

•

Approved wheel and tyre sizes (p. 671)

•

Minimum permitted tyre load index and
speed rating for tyres (p. 672)

2

Both those with metal studs and those without.

WHEELS AND TYRES

557

Dimension designation for wheel

rim

Wheel and rim dimensions are designated in
accordance with the examples in the table
below.

The car has an approval for the complete vehi-
cle with certain combinations of wheel rims
and tyres.

All wheel rims have a dimension designation,
for example: 8Jx18x42.

8

Rim width in inches

J

Rim flange profile

18

Rim diameter in inches

42 Off-set in mm (distance from wheel

centre to wheel contact surface
against the hub)

Related information

•

Tyres (p. 554)

•

Dimension designation for tyre (p. 556)

•

Approved wheel and tyre sizes (p. 671)

Tyres' rotation direction

Tyres with a tread pattern which are designed
to only turn in one direction have the direc-
tion of rotation marked with an arrow.

The arrow shows the tyre's direction of rotation.

•

The tyre must always rotate in the same
direction throughout its lifespan.

•

Tyres should only be switched between
front and rear positions, never between
left and right-hand sides, or vice versa.

•

If the tyres are fitted incorrectly, the car's
braking characteristics and capacity to
force rain and slush out of the way are
adversely affected.

•

Tyres with the greatest tread depth should
always be fitted to the rear of the car (to
decrease the risk of skidding).

NOTE

Make sure that both pairs of wheels have
the same type and dimension, and also the
same make.

Related information

•

Tyres (p. 554)

WHEELS AND TYRES

558

Tread wear indicators on the tyres

Tread wear indicators show the status of the
tyre's tread depth.

A tread wear indicator is a narrow elevation
across the longitudinal grooves of the tyre's
tread pattern. On the side of the tyre are the
letters TWI (Tread Wear Indicator). When the
tyre's tread depth is down to 1.6 mm (1/16
inch), the tread will be level in height with the
tread wear indicators. Change to new tyres as
soon as possible. Remember that tyres with
little tread depth provide very poor grip in rain
and snow.

Related information

•

Tyres (p. 554)

Checking tyre pressure

Correct tyre pressure helps to improve driv-
ing stability, save fuel and extend the service
life of the tyres.

Tyre pressure decreases over time, this is a
natural phenomenon. Tyre pressure also varies
depending on ambient temperature. Driving
on tyres with tyre pressure that is too low
could result in the tyres overheating and being
damaged. Tyre pressure affects travelling
comfort, road noise and driving characteris-
tics.

Check the tyre pressures monthly. Use the
recommended tyre pressure for cold tyres in
order to maintain good tyre performance. Tyre
pressure that is too low or too high may cause
uneven wear on the tyres.

WARNING

•

Tyre pressure that is too low is the
most common cause of tyre failure and
may result in serious cracks in the tyre,
the tread loosening or the tyre explod-
ing, with unexpected loss of control of
the car and increased risk of personal
injury.

•

Tyres with pressure that is too low
reduce the load capacity of the car.

Cold tyres

The tyre pressure must be checked when the
tyres are cold. Tyres are considered cold when
they have the same temperature as the sur-
rounding air. This temperature is normally
reached when the car has been parked for at
least three hours.

After having driven approximately 1.6 km
(1 mile) these tyres are considered as warm. If
you have to drive further than this to inflate the
tyres, first check and record the tyre pressure
and inflate to a suitable tyre pressure when
you arrive at the pump.

When the outside temperature changes, the
tyre pressure also changes. A decrease in tem-
perature of 10 degrees causes the tyre pres-
sure to decrease 1 psi (7 kPa). Check the tyre
pressure regularly and adjust to the correct
pressure, which is specified on the car's tyre
information decal or certification label.

If you check the tyre pressure when the tyres
are warm then you must never release any air.
The tyres are warm due to driving and it is nor-
mal for the pressure to increase above the rec-
ommended pressure for cold tyres. A warm
tyre with tyre pressure equal to or below the
recommendation for cold tyres may have a
pressure that is far too low.

WHEELS AND TYRES

}}

* Option/accessory.

559

Related information

•

Adjusting tyre pressure (p. 559)

•

Recommended tyre pressure (p. 560)

•

Tyre pressure monitoring system

*

(p. 560)

•

Tyres (p. 554)

Adjusting tyre pressure

Tyre pressure decreases over time, this is a
natural phenomenon. The tyre pressure must
therefore sometimes be adjusted in order to
maintain the recommended tyre pressure.

Use the recommended tyre pressure for cold
tyres in order to maintain good tyre perform-
ance and even tread wear.

NOTE

To avoid incorrect tyre pressure, the pres-
sure should be checked on cold tyres.
"Cold tyres" means the tyres are the same
temperature as the ambient temperature
(approx. 3 hours after the car has been
driven). After a few kilometres of driving,
the tyres warm up and the pressure increa-
ses.

1. Remove the cap from the valve on one

tyre and then press the tyre pressure
gauge firmly down onto the valve.

2. Inflate the tyres to the correct pressure,

see the decal on the door pillar on the driv-
er's side showing the recommended pres-
sure for factory fitted tyres.

3. Refit the dust cap.

NOTE

•

After a tyre has been inflated, always
refit the dust cap in order to avoid dam-
age to the valve from gravel, dirt, etc.

•

Only use plastic dust caps. Metal dust
caps can rust and become difficult to
unscrew.

4. Check the tyres visually for any implanted

nails or other objects that could puncture
the tyre and cause leakage.

5. Check the sidewalls for any cavities, cuts,

bumps or other irregularities.

6. Repeat this for all tyres, including the

spare tyre

*

.

NOTE

If you have over-inflated, release air by
pressing in the metal pin in the centre of
the valve. Then check the pressure again
using the tyre pressure gauge.

Some spare tyres require a higher tyre
pressure than other tyres. Check in the tyre
pressure table or on the tyre pressure label.

||

WHEELS AND TYRES

* Option/accessory.

560

Related information

•

Recommended tyre pressure (p. 560)

•

Checking tyre pressure (p. 558)

•

Inflating tyres with the compressor from
the puncture repair kit (p. 578)

•

Approved tyre pressures (p. 673)

Recommended tyre pressure

The tyre pressure label on the driver's side
door pillar (between frame and rear door)
shows which pressures the tyres should have
at different loads and speed conditions.

The decal displays the designation for the fac-
tory-fitted tyres on the car, as well as load lim-
its and tyre pressure.

Improved fuel economy with ECO pressure

For a light load (max. 3 people) and a speed of
up to 160 km/h (100 mph), the ECO pres-
sures can be chosen for good fuel economy.
However, the lower comfort pressures are rec-
ommended instead if improved noise and trav-
elling comfort are desired.

Related information

•

Checking tyre pressure (p. 558)

•

Approved tyre pressures (p. 673)

Tyre pressure monitoring system

*

The tyre pressure monitoring system

3

, gives a

warning with an indicator symbol in the driver
display when the pressure in one or more of
the car's tyres is too low.

The symbol illuminates to indicate
low tyre pressure.

If there is a fault in the system the
tyre pressure warning symbol

flashes for approximately one minute and then
remains illuminated.

System description

The tyre pressure monitoring system meas-
ures differences in rotation speed between the
different wheels via the ABS system in order
to be able to determine whether they have the
correct tyre pressure. If the tyre pressure is too
low, the tyre's diameter is changed and, as a
result, so is its rotation speed. By comparing
the tyres with each other the system can
determine whether one or more tyres have
pressure that is too low.

WHEELS AND TYRES

}}

* Option/accessory.

561

General information on the tyre monitoring
system

In the information below, the tyre monitoring
system is referred to generically as TPMS.

Each tyre, including the spare tyre

*

, should be

checked once a month. When checking, the
tyre should be cold and have the air pressure
recommended by the car manufacturer speci-
fied on the tyre pressure label or in the tyre
pressure table. If the car has tyres of a differ-
ent size than that recommended by the manu-
facturer, find out what the correct air pressure
level is for these.

As an extra safety feature, the car is equipped
with a tyre pressure monitoring system
(TPMS), which shows when the air pressure in
one or more tyres is too low. When the indica-
tor symbol for low air pressure is lit, stop and
check the tyres as soon as possible and inflate
to the correct air pressure.

Driving with tyres that have tyre pressure that
is too low may cause the tyre to overheat,
which can cause a tyre failure. Low tyre pres-
sure also reduces fuel efficiency as well as tyre
service life, and can affect car handling and
stopping ability. Note that TPMS does not
replace regular tyre maintenance. It is the driv-
er's responsibility to maintain correct tyre
pressure, even if the limit for low tyre pressure

has not been reached so that the indicator
symbol illuminates.

The car is also equipped with a TPMS system
fault indicator, which indicates when the sys-
tem is not functioning correctly. The TPMS
system fault indicator is combined with the
indicator symbol for low tyre pressure. When
the system detects a fault, the symbol in the
driver display will flash for about one minute
and then remain illuminated. This procedure
will be repeated when the car is started until
the fault has been rectified. When the symbol
is illuminated, the system's ability to detect or
warn of low tyre pressure may be affected.

A TPMS system fault can occur for several
reasons, such as after changing to a spare
tyre, or changing tyres or wheels that prevent
TPMS from functioning correctly.

Always check the indicator symbol for TPMS
after changing one or more tyres in order to
ensure the new tyre or wheel is working cor-
rectly with TPMS.

Messages on the instrument panel

When the tyre pressure is too low, the indica-
tor symbol for low tyre pressure is illuminated
in the driver display and a message is shown.
Check the tyre pressure in the

Car Status

 app

in the centre display.

•

Tyre pressure low



Check Car Status

app in center display

•

Tyre pressure system



Temporarily

unavailable

•

Tyre pressure system



Service required

To bear in mind

•

Always save a new tyre pressure in the
system after changing a wheel or adjust-
ing tyre pressure.

•

If you change to tyres of a different size to
the ones fitted at the factory, the system
must be reset by storing a new tyre pres-
sure for these tyres to avoid false warn-
ings.

•

If a spare wheel

*

 is used, it is possible that

the tyre pressure monitoring system does
not work correctly due to the differences
between the wheels.

•

The system does not replace the need for
regular tyre inspection and maintenance.

•

It is not possible to switch off the tyre
pressure monitoring system.

3

Indirect Tyre Pressure Monitoring System (ITPMS)
