SOUND, MEDIA AND INTERNET

}}

* Option/accessory.

517

Using Android Auto

*

To use the

Android Auto

 app, the app must

be installed on your Android device and the
device must be connected to the car's USB
input.

NOTE

For installation of Android Auto to be pos-
sible, the car must be equipped with two
USB ports (USB hub)

*

. If the car only has

one USB port then it is not possible to use
Android Auto.

The first time an Android is connected

1. Connect your Android device to the USB

input with a white frame.

2. Read the information in the pop-up win-

dow and then tap on

OK

.

3. Tap on

Android Auto

 in the app view.

4. Read the terms and conditions and then

tap on

Accept

 to connect.

> The subview with Android Auto is

opened and compatible apps are
shown.

5. Tap on the desired app.

> The app starts.

Previously connected Android

1. Connect your device to the USB input

with a white frame.
>

If the setting for automatic start is
selected

 - the name of the device is

shown.

2. Tap on the device name – the tile with

Android Auto is opened and compatible
apps are shown.

3.

If the setting for automatic start is not
selected

 - open the

Android Auto

 app

from the app view.
> The subview with Android Auto is

opened and compatible apps are
shown.

4. Tap on the desired app.

> The app starts.

Android Auto runs in the background if
another app is started in the same subview. To
show Android Auto in the subview again - tap
on the Android Auto icon in the app view.

Related information

•

Android Auto

*

 (p. 516)

•

Settings for Android Auto

*

 (p. 517)

•

Connecting a device via USB port (p. 510)

•

Voice recognition (p. 143)

Settings for Android Auto

*

Settings for an Android device that has been
connected the first time with Android Auto.

Automatic start

1. Press

Settings

 in the top view.

2. Press

Communication

Android Auto

and select setting:

•

Tick the box - Android Auto starts auto-
matically when the USB cable is con-
nected.

•

Untick the box - Android Auto does not
start automatically when the USB cable
is connected.

A maximum of 20 Android devices can be
stored in the list. When the list is full and a
new device is connected the oldest one is
deleted.

A factory reset has to be executed in order to
clear the list.

System volumes

1. Press

Settings

 in the top view.

2. Tap on

Sound

System Volumes

 and

make the settings for the following:

•

Voice Control

•

Navi Voice Guidance

•

Phone Ringtone

||

SOUND, MEDIA AND INTERNET

* Option/accessory.

518

Related information

•

Android Auto

*

 (p. 516)

•

Using Android Auto

*

 (p. 517)

•

Resetting settings in the centre display
(p. 132)

Tips for using Android Auto

*

Here are some useful tips for using Android
Auto.

•

Ensure that your apps are updated.

•

When starting the car, wait until the cen-
tre display has started, connect the device
and then open Android Auto from the app
view.

•

In the event of problems with Android
Auto, disconnect your Android device from
the USB port and then reconnect via USB.
Otherwise, try closing the app on the
device and then restarting the app.

•

When a device is connected to Android
Auto it is still possible to playback media
via Bluetooth to another media player. The
Bluetooth function is on when Android
Auto is used.

•

If the icon for Android Auto is greyed out,
this means no device is connected. When
you connect your device the icon will be
illuminated. If the icon is not visible at all
then the car does not have support for
connecting a device for this purpose.

•

If the device is connected to the car via
Bluetooth, the connection will be interrup-
ted when Android Auto is used. Resume
the Internet connection in the car by shar-
ing the Internet via the Wi-Fi hotspot from
the device.

•

If the car is shared by a lot of people, such
as in a car pool, it is worth noting that a
maximum of 20 Android devices can be
stored simultaneously. When the list is full
and a new device is connected the oldest
one is deleted. A factory reset has to be
performed in order to clear the list.

Related information

•

Android Auto

*

 (p. 516)

•

Connect the car to the Internet via a
phone (Wi-Fi) (p. 529)

SOUND, MEDIA AND INTERNET

519

Phone

A phone with Bluetooth can be connected
wirelessly to the car's built-in hands-free sys-
tem.

The audio and media system acts as hands-
free, with the facility to remotely control a
selection of the phone's functions. The phone
can still be operated with its own keys even if
it is connected to the car.

When a phone has been connected online and
connected with the car, it can be used make
calls, send/receive messages, play back media
wirelessly and be used as an Internet connec-
tion.

The phone is operated from the centre display,
but also via voice recognition and the app
menu, which are accessed from the right-hand
steering wheel keypad.

Overview

Microphone.

Phone.

Phone operation from centre display.

Keypad for operating phone functions that
are shown in the driver display and voice
recognition.
Driver display.

Related information

•

Managing phone calls (p. 523)

•

Managing the phone book (p. 526)

•

Managing text messages (p. 524)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

•

Connecting a phone to the car via Blue-
tooth automatically (p. 521)

•

Connecting a phone to the car via Blue-
tooth manually (p. 522)

•

Disconnecting a Bluetooth-connected
phone (p. 522)

•

Switch between Bluetooth-connected
phones (p. 523)

•

Removing devices connected to Bluetooth
(p. 523)

•

Settings for phone (p. 526)

•

Voice recognition (p. 143)

•

Handling the application menu in the
driver display (p. 102)

•

Audio settings (p. 492)

•

Connect the car to the Internet via a Blue-
tooth-enabled phone (p. 528)

SOUND, MEDIA AND INTERNET

520

Connecting a phone to the car via

Bluetooth for the first time

Connect a phone with Bluetooth activated to
then be able to make calls from the car, send/
receive messages, play back media wirelessly
and connect the car to the Internet.

It is possible to have two Bluetooth devices
connected at once, in which case one of them
can only play back wirelessly. The most
recently connected phone will automatically
be connected to make calls, send/receive
messages, play back media and provide an
Internet connection. It is possible to change
what the phone is to be used for under

Bluetooth Devices

 via the settings menu in

the centre display's top view. Your mobile
phone needs to be equipped with Bluetooth
and support tethering.

After the device has been connected/regis-
tered a first time via Bluetooth, it no longer
needs to be visible/discoverable, but only have
Bluetooth activated. A maximum of 20 con-
nected Bluetooth devices can be stored in the
car.

There are two options for connecting. Either
search the phone from the car or search the
car from the phone.

Option 1 - search phone from car

1. Make the phone searchable/visible via

Bluetooth.

2. Open the phone tile in the centre display.

•

If there is no phone connected to the
car, tap on

Add phone

.

•

If there is a phone connected to the car,
tap on

Change

. In the pop-up win-

dow, tap on

Add phone

.

> Available Bluetooth devices are listed.

The list is updated as new devices are
detected.

3. Tap on the name of the phone to be con-

nected.

4. Check that the specified number code in

the car matches that in the phone. In
which case, choose to accept in both pla-
ces.

5. On the phone, choose to accept or reject

any options for phone contacts and mes-
sages.

NOTE

•

The message function must be acti-
vated in certain phones.

•

Not all mobile phones are fully compat-
ible and may therefore not show con-
tacts and messages in the car.

Option 2 - search car from phone

1. Open the phone tile in the centre display.

•

If there is no phone connected to the
car, tap on

Add phone

Make car

discoverable

.

•

If there is a phone connected to the car,
tap on

Change

. In the pop-up win-

dow, tap on

Add phone

Make car

discoverable

.

2. Activate Bluetooth on the phone.

3. Search on the phone for Bluetooth devi-

ces.
> Available Bluetooth devices are listed.

4. Select the name of the car on the phone.

5. A pop-up window for the connection is

shown in the car. Confirm the connection.

6. Check that the specified number code in

the car matches the one shown in the
external device. In which case, choose to
accept in both places.

7. On the phone, choose to accept or reject

any options for phone contacts and mes-
sages.

SOUND, MEDIA AND INTERNET

}}

* Option/accessory.

521

NOTE

•

The message function must be acti-
vated in certain phones.

•

Not all mobile phones are fully compat-
ible and may therefore not show con-
tacts and messages in the car.

NOTE

If the phone's operating system is updated
then the connection may be broken. In
which case, delete the phone from the car
and then connect again.

Compatible phones

Many phones on the market now have wire-
less Bluetooth technology, but not all of them
are fully compatible with the car.

For compatibility, see support.volvocars.com.

Related information

•

Phone (p. 519)

•

Connecting a phone to the car via Blue-
tooth automatically (p. 521)

•

Connecting a phone to the car via Blue-
tooth manually (p. 522)

•

Disconnecting a Bluetooth-connected
phone (p. 522)

•

Switch between Bluetooth-connected
phones (p. 523)

•

Removing devices connected to Bluetooth
(p. 523)

•

Settings for Bluetooth devices (p. 527)

•

Internet-connected car

*

 (p. 527)

•

Connect the car to the Internet via a Blue-
tooth-enabled phone (p. 528)

Connecting a phone to the car via

Bluetooth automatically

It is possible to connect a phone to the car
automatically via Bluetooth. The phone has to
have been connected to the car for the first
time.

It is only the two last connected phones that
can be connected automatically.

1. Activate Bluetooth in the phone before

setting the car in ignition position

I

.

2. Set the car in ignition position

I

 or higher.

> The phone will connect.

Related information

•

Phone (p. 519)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

•

Connecting a phone to the car via Blue-
tooth manually (p. 522)

•

Disconnecting a Bluetooth-connected
phone (p. 522)

•

Switch between Bluetooth-connected
phones (p. 523)

•

Removing devices connected to Bluetooth
(p. 523)

•

Settings for Bluetooth devices (p. 527)

•

Internet-connected car

*

 (p. 527)

SOUND, MEDIA AND INTERNET

* Option/accessory.

522

•

Connect the car to the Internet via a Blue-
tooth-enabled phone (p. 528)

•

Ignition positions (p. 434)

Connecting a phone to the car via

Bluetooth manually

It is possible to connect a phone to the car
manually via Bluetooth. The phone has to
have been connected to the car for the first
time.

1. Activate Bluetooth on the phone.

2. Open the subview for phone.

> Connected phones are listed.

3. Tap on the name of the phone to be con-

nected.
> The phone will connect.

Related information

•

Phone (p. 519)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

•

Connecting a phone to the car via Blue-
tooth automatically (p. 521)

•

Disconnecting a Bluetooth-connected
phone (p. 522)

•

Switch between Bluetooth-connected
phones (p. 523)

•

Removing devices connected to Bluetooth
(p. 523)

•

Settings for Bluetooth devices (p. 527)

•

Internet-connected car

*

 (p. 527)

•

Connect the car to the Internet via a Blue-
tooth-enabled phone (p. 528)

Disconnecting a Bluetooth-

connected phone

It is possible to disconnect a phone con-
nected to Bluetooth, and it will then no
longer be connected to the car.

•

When the phone is out of range of the car
it is automatically disconnected. If discon-
nection occurs during an active call, then
the call will be continued on the phone.

•

It is also possible to disconnect the phone
by manually deactivating Bluetooth.

Related information

•

Phone (p. 519)

•

Settings for phone (p. 526)

•

Switch between Bluetooth-connected
phones (p. 523)

•

Removing devices connected to Bluetooth
(p. 523)

•

Settings for Bluetooth devices (p. 527)

SOUND, MEDIA AND INTERNET

}}

523

Switch between Bluetooth-

connected phones

It is possible to switch between a number of
Bluetooth-connected phones.

1. Open the tile for the phone.

2. Tap on

Change

 or drag down the top

view and tap on

Settings

Communication

Bluetooth Devices

Add device

.

> Available Bluetooth devices are listed.

3. Tap on the phone to be connected.

Related information

•

Phone (p. 519)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

•

Settings for Bluetooth devices (p. 527)

•

Disconnecting a Bluetooth-connected
phone (p. 522)

•

Removing devices connected to Bluetooth
(p. 523)

Removing devices connected to

Bluetooth

It is possible to remove phones from the list
of registered Bluetooth devices, for example.

1. Press

Settings

 in the top view.

2. Press

Communication

Bluetooth

Devices

.

> Registered Bluetooth devices are listed.

3. Tap on the device to be removed.

4. Tap on

Remove device

 and confirm your

selection.
> The device is no longer registered to

the car.

Related information

•

Phone (p. 519)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

•

Disconnecting a Bluetooth-connected
phone (p. 522)

•

Switch between Bluetooth-connected
phones (p. 523)

•

Settings for Bluetooth devices (p. 527)

Managing phone calls

Call handling in the car for a Bluetooth-con-
nected phone.

Generic illustration.

Making phone calls

1. Open the subview for phone.

2. Select call from call history, enter number

using the keypad or via the contact list. It
is possible to search or browse in the con-
tact list. Tap on

 in the contact list in

order to add a contact under

Favourites

.

3. Press

 to make a call.

4. Tap on

 to end the call.

You can also make calls from the call log via
the app menu, which is accessed from the
right-hand steering wheel keypad

.

||

SOUND, MEDIA AND INTERNET

524

Making multi-party calls

During a call:

1. Press

Add call

.

2. Choose to make a call from the call log,

favourites or the contact list.

3. Tap on an entry/row in the call log, or tap

on

 alongside the contact in the con-

tact list.

4. Tap on

Swap call

 to switch between the

parties.

5. Tap on

 to end the active call.

Conference calls

During an active multi-party call:

1. Tap on

Join calls

 to merge the active

multi-party call.

2. Tap on

 to end the call.

Incoming phone calls

Incoming phone calls are shown in the driver
display and the centre display. Manage the
call on the right-hand steering wheel keypad
or in the centre display.

1. Tap on

Answer

/

Reject

.

2. Tap on

 to end the call.

Incoming phone call during an active call

1. Tap on

Answer

/

Reject

.

2. Tap on

 to end the call.

Private call

–

During the current call, press

Privacy

 and

select setting:

•

Switch to mobile phone

 - the hands-

free function is disconnected and the
call continues on your mobile phone.

•

Driver focused

 - the microphone in the

roof on the passenger side is switched
off and the call continues with the car's
handsfree function.

Related information

•

Phone (p. 519)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

•

Controlling a telephone with voice recog-
nition (p. 146)

•

Handling the application menu in the
driver display (p. 102)

•

Enter the characters, letters and words
manually in the centre display (p. 127)

•

Managing the phone book (p. 526)

•

Managing text messages (p. 524)

•

Audio settings (p. 492)

Managing text messages

10

Message handling in the car for a Bluetooth-
connected phone.

In some phones, the message function must
be activated. Not all phones are compatible. In
such cases, they cannot display contacts and
messages in the car.

For compatibility, see support.volvocars.com.

Managing text messages in the centre
display

Text messages are only shown in the centre
display if the setting is selected.

Press

Messages

 in the app

view to manage text mes-
sages in the centre display.

Reading text messages in the centre
display

Press the icon to get the message
read aloud.

SOUND, MEDIA AND INTERNET

* Option/accessory.

525

Sending text messages in the centre
display

11

1. You can reply to a message or create a

new message.

•

Reply to message - tap on the contact
whose message you wish to reply to,
then tap on

Answer

.

•

Create new message - tap on

Create

new

. Select a contact or enter a num-

ber.

2. Compose the message.

3. Press

Send

.

Managing text messages in the driver
display

Text messages are only shown in the driver
display if the setting is selected.

Reading a new text message in the driver
display

–

To have the message read aloud - select

Read out

 with the steering wheel keypad.

Dictating a reply in the driver display

After the text message has been read out, it is
possible to reply briefly with dictation if the car
is connected to the Internet.

–

Press

Answer

 with the steering wheel

keypad. A dictation dialogue starts.

Message notification

It is possible to activate and deactivate notifi-
cations in the text message settings.

Related information

•

Phone (p. 519)

•

Settings for text messages (p. 525)

•

Settings for phone (p. 526)

•

Internet-connected car

*

 (p. 527)

•

Controlling a telephone with voice recog-
nition (p. 146)

•

Enter the characters, letters and words
manually in the centre display (p. 127)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

•

User terms and conditions and data shar-
ing (p. 533)

Settings for text messages

Settings for text messages on connected
phone.

1. Press

Settings

 in the top view.

2. Press

Communication

Text Messages

and select settings:

•

Notification in centre display

 - shows

message notifications in the centre dis-
play's status bar.

•

Notification in driver display

 - dis-

plays notifications in the driver's display
and incoming messages can be man-
aged using the steering wheel's right-
hand keypad.

•

Text message tone

 - select tone for

incoming text messages.

Related information

•

Phone (p. 519)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

•

Managing text messages (p. 524)

•

Settings for phone (p. 526)

10

Valid in certain markets only. Contact a Volvo dealer for more information.

11

Only certain phones can send messages via the car.

SOUND, MEDIA AND INTERNET

* Option/accessory.

526

Managing the phone book

When a phone is connected to the car with
Bluetooth, contacts can be managed directly
in the centre display.

Up to 3000 contacts can be shown from the
phone selected in the centre display.

Browse between the letters and

 to

find a matching contact. Depending on
existing contacts in the phone book, only
matching letters are shown.

Search contacts

 - tap on

 to search

for a phone number of name in the contact
list.

Favourites

 - tap on

 to add/remove a

contact to/from the favourites list.

Sorting

The contact list is sorted in alphabetical order
where special characters and numbers are

sorted under

. It is possible to sort by first

name or surname, and this setting is adjusted
in the telephone setup.

Related information

•

Phone (p. 519)

•

Settings for phone (p. 526)

•

Controlling a telephone with voice recog-
nition (p. 146)

•

Enter the characters, letters and words
manually in the centre display (p. 127)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

Settings for phone

When the telephone is connected to the car,
the following settings can be made:

1. Press

Settings

 in the top view.

2. Press

Communication

Phone

 and

select settings:

•

Ringtones

 - selection of ring signal. It

is possible to use a ring signal from the
phone or the car. Some phones are not
fully compatible and their ring signals
may therefore not be available for use in
the car.

12

•

Sort Order

 - select sort order of con-

tact list.

Call notifications in head up display

*

1. Tap on

Settings

 in the centre display's

top view.

2. Press

My Car

Displays

Head-Up

Display Options

.

3. Select

Show Phone

.

Related information

•

Phone (p. 519)

•

Settings for text messages (p. 525)

•

Settings for Bluetooth devices (p. 527)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

SOUND, MEDIA AND INTERNET

}}

* Option/accessory.

527

•

Head-up display

*

 (p. 140)

•

Audio settings (p. 492)

Settings for Bluetooth devices

Settings for Bluetooth-connected devices.

1. Press

Settings

 in the top view.

2. Press

Communication

Bluetooth

Devices

 and select settings:

•

Add device

 - starts the pairing of a new

device.

•

Previously paired devices

 - lists regis-

tered/paired devices.

•

Remove device

 - removes the connected

device.

•

Allowed services for this device

 - sets

device usage options: calling, sending/
receiving messages, streaming media and
as Internet connection.

•

Internet connection

 - connects the car to

the Internet via the device's Bluetooth
connection.

Related information

•

Phone (p. 519)

•

Settings for phone (p. 526)

•

Internet-connected car

*

 (p. 527)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

Internet-connected car

*

When the car is connected to the Internet, it
is possible – for example – to use web radio
and music services via apps, download soft-
ware and contact your retailer from the car.

The car is connected via Bluetooth, Wi-Fi or
with the car's built-in modem

*

 (SIM card).

When the car is connected to the Internet, it is
possible to share the car's Internet connection
(Wi-Fi hotspot) so that other devices such as
tablets can access the Internet

13

.

The Internet status is indicated by a symbol in
the centre display's status bar.

12

For compatibility, see support.volvocars.com.

13

This does not apply in the case of connection with Wi-Fi.

||

SOUND, MEDIA AND INTERNET

* Option/accessory.

528

NOTE

Data is transferred when using the internet
(data traffic), which can have a cost.

Activation of data roaming can result in fur-
ther charges.

Contact your network operator about the
cost for data traffic.

NOTE

When using Apple CarPlay, it is only possi-
ble to connect the car to the Internet using
Wi-Fi or the car modem

*

.

NOTE

When using Android Auto, it is possible to
connect the car to the Internet using Wi-Fi,
Bluetooth or the car modem

*

.

Before connecting the car to the Internet,
search support information on terms and con-
ditions for services and privacy policy for cus-
tomers at www.volvocars.com.

Related information

•

Symbols in the centre display's status bar
(p. 122)

•

Connect the car to the Internet via a Blue-
tooth-enabled phone (p. 528)

•

Connect the car to the Internet via a
phone (Wi-Fi) (p. 529)

•

Connect the car to the Internet via car
modem (SIM card) (p. 530)

•

Apps (p. 494)

•

No or poor Internet connection (p. 532)

•

Sharing Internet access from the car via a
Wi-Fi hotspot (p. 531)

•

Remove Wi-Fi network (p. 533)

•

Wi-Fi technologies and security (p. 533)

•

Volvo ID (p. 28)

•

User terms and conditions and data shar-
ing (p. 533)

Connect the car to the Internet via

a Bluetooth-enabled phone

Create an Internet connection via Bluetooth
by sharing your phone's Internet access and
access several online services in the car.

1. To be able to connect the car to the Inter-

net via a Bluetooth-connected phone, the
phone has to have already been con-
nected to the car via Bluetooth for a first
time.

2. Make sure that your phone supports teth-

ering and that this function is activated.
On an iPhone, this function is known as
"tethering". On Android phones, this func-
tion may have different names but is fre-
quently known as "hotspot". For iPhones,
the menu page "tethering" must also be
open until the Internet connection has
been established.

3. If the phone has been connected via Blue-

tooth previously, press

Settings

 in the

centre display top view.

4. Press

Communication

Bluetooth

Devices

.

5. Tick the box for

Bluetooth Internet

connection

 under the heading

Internet

connection

.

SOUND, MEDIA AND INTERNET

* Option/accessory.

529

6. If another connection source has been

used, confirm the option to change con-
nection.
> Your car is now connected to the Inter-

net via the Bluetooth-connected phone.

NOTE

The telephone and network provider must
support tethering (Internet connection
sharing), and the subscription must include
data.

NOTE

When using Apple CarPlay, it is only possi-
ble to connect the car to the Internet using
Wi-Fi or the car modem

*

.

Related information

•

Internet-connected car

*

 (p. 527)

•

Connect the car to the Internet via car
modem (SIM card) (p. 530)

•

Connecting a phone to the car via Blue-
tooth for the first time (p. 520)

•

Connect the car to the Internet via a
phone (Wi-Fi) (p. 529)

•

Apple

®

 CarPlay

®

*

 (p. 512)

•

No or poor Internet connection (p. 532)

•

Settings for Bluetooth devices (p. 527)

Connect the car to the Internet via

a phone (Wi-Fi)

Create an Internet connection via Wi-Fi by
tethering your phone and access online servi-
ces in the car.

1. Make sure that your phone supports teth-

ering and that this function is activated.
On an iPhone, this function is known as
"tethering". On Android phones, this func-
tion may have different names but is fre-
quently known as "hotspot". For iPhones,
the menu page "tethering" must also be
open until the Internet connection has
been established.

2. Press

Settings

 in the top view.

3. Continue to

Communication

Wi-Fi

.

4. Activate/deactivate by ticking/unticking

the box for Wi-Fi.

5. If another connection source has been

used, confirm the option to change con-
nection.

6. Tap on the network name of the network

to be connected.

7. Enter the network password.

> The car connects to the network.

Note that certain phones switch off tethering
after the contact with the car has been discon-
nected, e.g. when leaving the car and until the
next time it is used. The tethering in the phone

therefore needs to be reactivated the next
time it is used.

When a phone is connected to the car, it is
saved for future use. To show a list of saved
networks or manually delete saved networks,
go to

Settings

Communication

Wi-Fi

Saved networks

.

NOTE

The telephone and network provider must
support tethering (Internet connection
sharing), and the subscription must include
data.

Technical and safety requirements for Wi-Fi
connection, are described in a separate sec-
tion.

Related information

•

Internet-connected car

*

 (p. 527)

•

Remove Wi-Fi network (p. 533)

•

No or poor Internet connection (p. 532)

•

Wi-Fi technologies and security (p. 533)

SOUND, MEDIA AND INTERNET

* Option/accessory.

530

Connect the car to the Internet via

car modem (SIM card)

It is possible to establish an Internet connec-
tion via the car modem and a personal SIM
card (P-SIM)

*

.

Cars equipped with Volvo On Call will use the
Internet connection with car modem for the
services.

1.

Fit a personal SIM card into the holder by
the floor on the passenger side.

Note that a

mini SIM

 is required to fit the

car's card reader.

2. Press

Settings

 in the top view.

3. Press

Communication

Car Modem

Internet

.

4. Activate/deactivate by ticking/unticking

the box for

Car modem Internet

.

5. If another connection source has been

used, confirm the option to change con-
nection.

6. Enter the SIM card's PIN code.

> The car connects to the network.

NOTE

Note that the SIM card used for Internet
connection via P-SIM cannot have the
same telephone number as the SIM card
that the phone uses. If this is disregarded,
it will not be possible to route calls cor-
rectly to the telephone. Therefore, use a
SIM card with a separate telephone num-
ber for the Internet connection, or a data
card that does not handle telephone calls
and is therefore unable to disrupt the func-
tion of the telephone.

Related information

•

Internet-connected car

*

 (p. 527)

•

No or poor Internet connection (p. 532)

•

Settings for car modem

*

 (p. 530)

Settings for car modem

*

The car is equipped with a modem that can
be used to connect the car to the Internet. It
is also possible to share the Internet connec-
tion via Wi-Fi.

1. Press

Settings

 in the top view.

2. Press

Communication

Car Modem

Internet

 and select settings:

•

Car modem Internet

 - select whether to

use the car modem as Internet connec-
tion.

•

Data usage

 - tap on

Reset

 resets the

counters for received and sent data vol-
ume.

•

Network
Select network operator

 - automatic or

manual selection of network operator.

Data roaming

 - if the box is ticked, the

car modem will attempt to connect to the
Internet when the car is abroad and out-
side its home network. Note that this may
result in heavy costs. Check your roaming
agreement for data traffic abroad with
your network provider in your home coun-
try.

•

SIM card PIN

SOUND, MEDIA AND INTERNET

}}

531

Change PIN

 - a maximum of 4 digits can

be entered.

Disable PIN

 - select whether the PIN

code shall be required for access to the
SIM card.

•

Send request code

 - used e.g. to top up

or check the balance on a prepaid card.
Functionality depends on the provider.

NOTE

Note that the SIM card used for Internet
connection via P-SIM cannot have the
same telephone number as the SIM card
that the phone uses. If this is disregarded,
it will not be possible to route calls cor-
rectly to the telephone. Therefore, use a
SIM card with a separate telephone num-
ber for the Internet connection, or a data
card that does not handle telephone calls
and is therefore unable to disrupt the func-
tion of the telephone.

Related information

•

Connect the car to the Internet via car
modem (SIM card) (p. 530)

•

No or poor Internet connection (p. 532)

Sharing Internet access from the

car via a Wi-Fi hotspot

When the car is online, its Internet connec-
tion can be shared to allow other devices to
use the Internet connection

14

.

The network operator (SIM card) must sup-
port tethering (sharing of the Internet connec-
tion).

1. Press

Settings

 in the top view.

2. Press

Communication

Car Wi-Fi

Hotspot

.

3. Tap on

Network name

 and name the

shared connection.

4. Tap on

Password

 and select a password

to be entered on connecting devices.

5. Tap on

Frequency band

 and select the

frequency on which the hotspot is to
transmit data. Note that selection of fre-
quency band is not available in all markets.

6. Activate/deactivate by ticking/unticking

the box for

Car Wi-Fi Hotspot

.

7. If Wi-Fi has been used as a connection

source, confirm the option to change con-
nection.
> It is now possible for external devices

to connect to the car's tethering (Wi-Fi
hotspot).

14

Does not apply when the car is online via Wi-Fi.

||

SOUND, MEDIA AND INTERNET

* Option/accessory.

532

NOTE

Activation of Wi-Fi-hotspot can result in
further charges from your network opera-
tor.

Contact your network operator about the
cost for data traffic.

Connection status is indicated by the symbol
in the centre display's status bar.

Press

Connected devices

 to see a list of the

currently connected devices.

Related information

•

Symbols in the centre display's status bar
(p. 122)

•

Internet-connected car

*

 (p. 527)

•

No or poor Internet connection (p. 532)

No or poor Internet connection

Factors that affect the Internet connection.

The amount of data transferred is dependent
on the services or apps in use in the car. For
example, streaming audio can require large
amounts of data which requires a good con-
nection and good signal strength.

Phone to car

The speed of the Internet connection may vary
depending on the location of the phone in the
car. Move the phone closer to the centre dis-
play in order to increase the signal strength.
Ensure that there is no source of interference
in between.

Phone to network operator

The speed of the mobile network varies
depending on the coverage in the present
location. Poor network coverage may occur,
for example in tunnels, in mountainous coun-
try, in deep valleys or indoors. The speed also
depends on the agreement you have with your
network.

NOTE

In the event of problems with data traffic,
contact your network operator.

Restarting the phone

If there are problems with the Internet con-
nection then it may help to restart the phone.

Related information

•

Internet-connected car

*

 (p. 527)

•

Wi-Fi technologies and security (p. 533)
