Limitations of Cross Traffic Alert

•

Messages for Cross Traffic Alert

•

•

•

Activating or deactivating Cross

Traffic Alert

The driver can select to switch off the

warn-

ing

in the Cross Traffic Alert (CTA) function –

the

auto brake

subfunction cannot be

switched off, however, and continues to be
active.

Activate or deactivate the
function using this button in
the centre display's function
view.

•

GREEN button indication – the function is
activated.

•

GREY button indication – warning signal
and indication on display for the function
is deactivated.

The function is activated automatically each
time the engine is started.

Related information

•

Cross Traffic Alert

(p. 358)

•

Limitations of Cross Traffic Alert

Limitations of Cross Traffic Alert

The Cross Traffic Alert (CTA) function with

auto-brake

may have limited functionality in

certain situations. Brake intervention is active
at speeds below 15 km/h.

WARNING

The

auto-brake

subfunction can only

detect and brake for other vehicles that are

moving –

not

for stationary obstacles, a

cyclist or a pedestrian, for example.

CTA has a certain limitation – the CTA sensors
cannot "see" through other parked vehicles or
obstructions, for example.

Here are some examples of situations where
CTA’s "field of vision" may be already limited
and approaching vehicles cannot therefore be
detected until they are very close:

Cross traffic alert when the car is reversing.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

* Option/accessory.

360

The car is parked deep inside a parking slot.

In an angled parking slot CTA may be completely

“blind” on one side.

Blind CTA sector.

Sector in which CTA can detect/“see”.

However, as your car slowly reverses, the
angle it makes with the obstructing vehicle/

object changes and the blind sector rapidly
decreases.

Examples of further limitations

•

The

auto-brake

subfunction only detects

moving vehicles and therefore

cannot

"see" and brake for stationary obstacles, a
cyclist or a pedestrian, for example.

•

Dirt, ice and snow covering the sensors
may reduce the functions and deactivate
alerts.

•

CTA is automatically deactivated if a
trailer, bicycle rack or similar is connected
to the car's electrical system.

•

For good performance of CTA, there
should be no bicycle rack, luggage carrier
or similar mounted on the car's towbar.

Limitations for camera and radar unit
(p. 333)

This function uses the car's camera and
radar units, which have certain general lim-
itations.

Related information

•

Cross Traffic Alert

(p. 358)

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

* Option/accessory.

361

Messages for Cross Traffic Alert

A number of messages regarding Cross
Traffic Alert (CTA) can be shown in the driver
display. Here are some examples.

Message

Specification

Blind spot sensor

Service required

The system does not function as it should. A workshop should be contacted

Blind spot system off

Trailer attached

BLIS

and CTA have been deactivated as a trailer has been connected to the car's electrical system.

An authorised Volvo workshop is recommended.

Blind Spot Information System

A text message can be cleared by briefly
pressing the

button, located in the centre

of the steering wheel's right-hand keypad.

If a message persists, contact a workshop

Related information

•

•

•

Limitations of Cross Traffic Alert

Cross traffic alert when the car is reversing.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

* Option/accessory.

362

Road Sign Information

The Road Sign Information function (RSI

)

can help the driver to observe speed-related
road signs and certain prohibition signs.

Examples of readable signs

RSI can provide information about such things
as current speed, when a motorway or road is
starting/ending, when overtaking is prohibited
or when the direction of travel is one-way.

If the car passes a speed limit sign, it will be
shown on the driver's display and the head-up
display

Driving support systems (p. 276)

In certain markets, the Road Sign Informa-
tion function

is only available in combina-

tion with Sensus Navigation

WARNING

•

The function is supplementary driver
support intended to facilitate driving
and make it safer – it cannot handle all
situations in all traffic, weather and
road conditions.

•

Related information

•

•

Activating or deactivating road sign infor-
mation

(p. 363)

•

Display mode for road sign information

(p. 363)

•

Road Sign Information and Sensus
Navigation

(p. 366)

•

Warning for speed limitation and speed
camera from road sign information

(p. 366)

•

Road Sign Information

Road signs are market-dependent - illustrations in these instructions only show a few examples.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

}}

* Option/accessory.

363

Activating or deactivating road

sign information

The Road Sign Information function (RSI

) is

optional – the driver can choose to activate or
deactivate this function.

Activate or deactivate the
function using this button in
the centre display's function
view.

•

GREEN button indication – the function is
activated.

•

GREY button indication – the function is
deactivated.

Road Sign Information is activated automati-
cally each time the engine is started.

•

If the automatic speed limiter function
is activated, road sign information is
shown in the driver display even if the
Road Sign Information function is not
activated.

•

To remove road sign information from
the driver display, you must deactivate

both

the automatic speed limiter and

Road Sign Information.

•

When the automatic speed limiter
function is activated but Road Sign
Information is deactivated, no warn-
ings are given from Road Sign Infor-
mation. Road Sign Information must
also be activated in order to receive
warnings.

Related information

•

Automatic speed limiter (p. 289)

•

•

Display mode for road sign

information

The Road Sign Information function (RSI

)

shows road signs in different ways depend-
ing on the sign and the situation.

Example

of detected speed information.

When the function detects a road sign with an
imposed speed limit, the driver display shows
the sign as a symbol combined with a col-
oured indication on the speedometer.

If the car is fitted with Sensus Navigation

speed-related information is also obtained
from map data, which means that the driver
display can show or change information on
the speed limit without having passed a
speed-related sign.

RSI: Road Sign Information.

Road Sign Information

Road signs are market-dependent - the illustrations in these instructions only show examples.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

* Option/accessory.

364

An additional

sign, such as

"no overtaking", may be
shown together with the
speed limit symbol.

If the driver enters a road
marked with a no-entry sign
at the roadside, the symbol
for this sign

flashes on and

off on the driver display as a
warning.

If the car is equipped with Sensus Navigation

information from map data is used to deter-
mine whether the car is being driven in the
wrong direction.

The driver can also get an acoustic warning
when driving towards a road marked with a
no-entry sign if the

Road Sign Audio

Warning

function is activated.

Speed limit or end of motorway

When the function detects an "indirect speed
limit sign" stating the end of the current speed
limit – e.g. at the end of a motorway – a sym-
bol appears with the corresponding road sign
in the driver's display.

If the car is equipped with Sensus Navigation

direct speed limit signs are normally displayed

– indirect speed limit signs are only displayed
if map data has no information on the speed
limit for the road section in question.

Example of indirect speed limit sign

End of all restrictions.

End of motorway.

The driver display symbol extinguishes after
10-30 seconds and remains so until the next
speed related sign is passed.

Changed speed limit

When passing a direct speed limit sign when a
speed limit changes, a symbol with the corres-
ponding road sign appears in the driver's dis-
play.

Example of direct speed limit
sign

The driver display symbol extinguishes after
about 5 minutes until the next speed-related
sign is passed.

If the car is fitted with Sensus Navigation

speed limit signs are shown in the driver dis-
play when map data contains information on
the speed limit for the road section in ques-
tion, even if no direct sign has been passed. If
there is no information in map data, the sign
goes off after approx. 3 minutes after the last
passing of a speed limit sign.

Road signs are market-dependent - the illustrations in these instructions only show examples.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

* Option/accessory.

365

Additional signs

Examples of additional signs

Sometimes different speed limits are signed
for the same road - an additional sign then
indicates the circumstances under which the
different speeds apply. The road section may
be particularly susceptible to accidents in rain
and/or fog, for example.

An additional sign relating to rain is displayed
only if the windscreen wipers are in use.

If a trailer is connected to the car's electrical
system and you pass a speed sign with the
additional sign "trailer", the indicated speed
will appear on the driver display.

Some speed limits only apply
after a certain distance or at a
certain time of day. The driv-
er's attention is drawn to this
fact by means of a symbol for
an additional sign below the
speed symbol. The additional

symbol in the driver display will show either
“DIST” or “TIME”.

A symbol for additional sign
in the form of an empty frame
under the driver display's
speed symbol

means that

the function has detected an
additional sign with supple-
mentary information for the

current speed limit.

Sign for "School" and "Children at
play"

If a warning sign

for

"School" or "Children at play"
is included in the satellite
navigator's map data

, the

driver display shows a sign of
this type.

Related information

•

•

Road signs are market-dependent - the illustrations in these instructions only show examples.

Only in cars with Sensus Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

* Option/accessory.

366

Road Sign Information and Sensus

Navigation

If the car is equipped with Sensus Navigation

speed information is read from the navigation
unit in the following cases:

•

On detection of signs that indirectly indi-
cate a speed limit, such as motorway, dual
carriageway and city limit signs.

•

If a previously detected speed sign is
assumed not to apply any longer, but no
new sign has been detected.

In certain markets, the Road Sign Informa-
tion function

is only available in combina-

tion with Sensus Navigation

If a downloaded third-party app is used for
navigation then there is no support for
speed-related information.

Related information

•

Warning for speed limitation and

speed camera from road sign

information

Road sign information (RSI

) includes sub-

functions that can warn the driver if a speed
limit has been exceeded or in connection with
speed cameras.

Examples of information on speed camera and speed

limit in the driver display.

Speed Limit Warning

The speed warning is given
by the driver display sym-
bol

100

showing the applicable

maximum permitted speed
temporarily flashing when
this speed is exceeded.

A speed warning is always given if the speed
limit is exceeded in connection with speed
camera information.

Speed Limit Warning

warns the driver when

the applicable speed limit or a preselected
"top speed" is exceeded – this warning is
repeated once after approx. 30 seconds
within the same speed limit area unless the
driver reduces the speed.

Another warning is available only when the
driver has reduced the speed by at least
5 km/h (3 mph) and then exceeds the speed
limit again, or when the car reaches a new/
different speed limit area.

To get an acoustic warning if you exceed
the required speed, the

Speed Limit

Warning

function must be activated and

the

Road Sign Audio Warning

subfunc-

tion must be set to

. An acoustic warn-

ing is then given if the car's speed exceeds
the speed indicated by the Road Sign
Information function in the driver display.

Road Sign Information

100

Road signs are customised for each market – the one shown here is just an example.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

}}

* Option/accessory.

367

Warning for speed camera

A car equipped with road
sign information and Sensus
Navigation can provide infor-
mation on an upcoming
speed camera in the driver
display.

101

If the car exceeds a detected speed limit with
the

Speed Limit Warning

function activated,

a speed warning is given when the car
approaches a speed camera, provided that the
navigation map for the area in question con-
tains information on speed cameras.

An option is available to receive an acous-
tic warning for speed cameras independ-
ently of the car's speed and exceeded
speed limit, and even if the

Road Sign

Audio Warning

function is deactivated.

Related information

•

Activating or deactivating warnings from
road sign information

•

(p. 367)

•

Activating or deactivating

warnings from road sign

information

The subfunction

Speed Limit Warning

for

Road Sign Information (RSI

102

) is optional –

the driver can choose to activate or deacti-
vate this subfunction.

Activating speed warning

1. Select

Settings

My Car

IntelliSafe

Road Sign Information

in the centre

display's top view.

2. Select

Speed Limit Warning

> The function is activated and a speed

limit selector appears.

Adjust the limit for Speed Warning

The driver can select to receive a warning at a
higher speed than the signed speed.

Select limit for speed warning as follows:

1. Select

Settings

My Car

IntelliSafe

Road Sign Information

in the centre

display's top view.

2. Select

Speed Limit Warning

> The function is activated and a speed

limit selector appears.

3. Adjust the limit for Speed Warning by

pressing the up/down arrows on the
screen.

Note that the function does
not give any consideration to
selected limit adjustment
when the driver display
shows the speed camera
symbol.

Activating acoustic warning in
connection with speed warning.

Change setting for acoustic warning as fol-
lows:

1. Select

Settings

My Car

IntelliSafe

Road Sign Information

in the centre

display's top view.

2. Select/deselect

Road Sign Audio

Warning

to activate/switch off the acous-

tic warning.

With the

Road Sign Audio Warning

function

activated, the driver is also warned when driv-
ing towards one-way traffic/no-entry entrance.

Activate Speed camera warning

If the car is fitted with Sensus Navigation

and

map data contains information on speed cam-

101

Information on speed cameras on the navigation map is not available for all markets/areas.

102

Road Sign Information

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

* Option/accessory.

368

eras, the driver can opt to receive an audible
warning when approaching a speed camera.

Change setting for acoustic warning as fol-
lows:

1. Select

Settings

My Car

IntelliSafe

Road Sign Information

in the centre

display's top view.

2. Select/deselect

Speed Camera Audio

Warning

to activate/switch off the audi-

ble speed camera warning.

Related information

•

Warning for speed limitation and speed
camera from road sign information

•

(p. 366)

•

Limitations of Road Sign

Information

The Road Sign Information (RSI

103

) function

may have limitations in certain situations.

Examples of what can reduce the function are
as follows:

•

Faded signs

•

Signs positioned on bends

•

Rotated or damaged signs

•

Signs positioned high above the roadway

•

Fully/partially obscured or poorly posi-
tioned signs

•

Signs completely or partly covered with
frost, snow and/or dirt

•

Digital road maps

104

are out-of-date, inac-

curate or have no speed information

105

In certain markets, the Road Sign Informa-
tion function

is only available in combina-

tion with Sensus Navigation

The RSI function may interpret some types
of bicycle rack, connected to the electrical
socket for trailers, as a connected trailer. In
such cases, the driver display may show
incorrect speed information.

This function uses the car's camera and
radar units, which have certain general lim-
itations.

Related information

•

Limitations for camera and radar unit
(p. 333)

•

103

Road Sign Information

104

In cars equipped with Sensus Navigation

105

Map data with speed information does not exist for all areas.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

}}

* Option/accessory.

369

Driver Alert Control

The Driver Alert Control (DAC) function is
intended to help make the driver aware that
he or she is starting to drive less consistently,
e.g. if the driver becomes distracted or starts
to fall asleep.

The objective for DAC is to detect slowly dete-
riorating driving ability and it is primarily
intended for major roads. The function is not
intended for city traffic.

The function is activated when speed exceeds
65 km/h (40 mph) and remains active as long
as the speed is over 60 km/h (37 mph).

DAC reads the position of the car in the lane.

A camera detects the edge markings painted
on the carriageway and compares the align-
ment of the road with the driver’s steering
wheel movements.

The car is being driven erratically in the lane.

If driving behaviour becomes
noticeably inconsistent, the
driver is alerted by this sym-
bol in the driver display, com-
bined with an acoustic signal
and the text message

Time

to take a break

If the car is equipped with Sensus Navigation

and has the function

Rest Stop Guidance

activated, suggestions for an appropriate
place for a break are also displayed.

The warning is repeated after a time if driving
behaviour has not improved.

WARNING

Driver Alert Control should not be used to

extend a period of driving. The driver

should instead plan for breaks at regular

intervals and make sure they are well

rested.

WARNING

An alarm from Driver Alert Control should

be taken very seriously, as a sleepy driver is

often not aware of his/her own condition.
If the alarm sounds or you feel fatigued:

•

Stop the car safely as soon as possible
and rest.

Studies have shown that it is just as dan-

gerous to drive while tired as it is to drive

under the influence of alcohol or other

stimulants.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

* Option/accessory.

370

WARNING

•

The function is supplementary driver
support intended to facilitate driving
and make it safer – it cannot handle all
situations in all traffic, weather and
road conditions.

•

Related information

•

Driving support systems (p. 276)

•

Activating or deactivating Driver Alert
Control (p. 370)

•

Select rest stop guidance in the event of a
warning from Driver Alert Control (p. 370)

•

Limitations of Driver Alert Control
(p. 371)

Activating or deactivating Driver

Alert Control

The Driver Alert Control (DAC) function can
be activated or deactivated.

1. Tap on

Settings

in the centre display's

top view.

2. Select

My Car

IntelliSafe

Driver

Alert Control

3. Select or deselect

Alertness Warning

activate or deactivate the function.

Related information

•

Driver Alert Control (p. 369)

•

Limitations of Driver Alert Control
(p. 371)

Select rest stop guidance in the

event of a warning from Driver

Alert Control

In cars equipped with Sensus Navigation

the driver can activate a guide that can auto-
matically suggest an appropriate rest area
when Driver Alert Control (DAC) issues a
warning.

It is possible to select whether the

Rest Stop

Guidance

function should be activated or

deactivated.

1. Tap on

Settings

in the centre display's

top view.

2. Select

My Car

IntelliSafe

Driver

Alert Control

3. Select or deselect

Rest Stop Guidance

to activate or deactivate the function.

Related information

•

Driver Alert Control (p. 369)

•

Limitations of Driver Alert Control
(p. 371)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

}}

* Option/accessory.

371

Limitations of Driver Alert Control

The Driver Alert Control (DAC) function may
have limitations in certain situations.

In some cases the system may issue a warn-
ing despite driving ability not deteriorating, for
example:

•

in strong side winds

•

on rutted road surfaces.

WARNING

In some cases, driving behaviour is not

affected despite driver fatigue – e.g. when

using the Pilot Assist

function – resulting

in the driver not getting a warning from

DAC.
It is therefore important to always stop and

take a break at the slightest feeling of fati-

gue, regardless of whether the function has

given a warning.

Driver Alert Control (p. 369)

This function uses the car's camera and
radar units, which have certain general lim-
itations.

Related information

•

•

Limitations for camera and radar unit
(p. 333)

Lane assistance

The function of the Lane Keeping Aid
(LKA

106

) is to help the driver to reduce the

risk of the car accidentally leaving its own
lane on motorways and similar major routes.

Lane Keeping Aid steers the car back into its
lane and/or alerts the driver with vibrations in
the steering wheel.

Lane Keeping Aid is active within the speed
range 65–200 km/h (40–125 mph) on roads
with clearly visible side lines.

On narrow roads the function may be unavail-
able, in which case it goes into standby mode.
The function becomes available again when
the road is wide enough.

A camera reads the side lines of the road/lane.

Lane assistance steers the car back into its lane.

Lane assistance warns with steering wheel vibra-

tions.

106

Lane Keeping Aid

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DRIVER SUPPORT

372

Depending on settings, lane assistance acts in
accordance with the following:

•

Assist

activated: When the car is

approaching a lane line, the function will
actively steer the car back into its lane by
applying a slight torque to the steering
wheel.

•

Warning

activated: If the car is about to

cross a lane line, the driver is warned by
means of vibrations in the steering wheel.

There is also an option where both steering
assistance and warning are activated simulta-
neously.
