Navigating in the centre display's views
(p. 113)

•

•

Renaming a driver profile (p. 135)

•

Linking remote control key to driver profile
(p. 136)

Renaming a driver profile

It is possible to change the name of the dif-
ferent driver profiles used in the car.

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

System

Driver Profiles

3. Select

Edit Profile

> A menu opens, where the profile can be

edited.

4. Tap in the box

Profile Name

> A keyboard appears, and it is possible

to change the name. Tap on

close the keyboard.

5. Save the name change by pressing

Back

> The name has now been changed.

Selecting driver profile (p. 135)

A profile name cannot start with a space,
as the profile name will not then be saved.

Related information

•

•

Keyboard in centre display (p. 124)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

136

Protect driver profile

In some cases it is preferable not to save vari-
ous settings defined in the car to the active
driver profile. In this case, it is possible to
protect the driver profile.

Protecting a driver profile is only possible
when the car is stationary.

To protect a driver profile:

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

System

Driver Profiles

3. Select

Edit Profile

> A menu opens, where the profile can be

edited.

4. Select

Protect Profile

to protect the pro-

file.

5. Save your profile protection option by

pressing

Back

> When the profile is protected, settings

defined in the car will not be saved
automatically to the profile. Instead,
your changes must be saved manually
under

Settings

System

Driver

Profiles

Edit Profile

by pressing

Save current settings to the profile

When the profile is unprotected, on the
other hand, your settings will be saved
automatically to the profile.

Related information

•

Linking remote control key to

driver profile

It is possible to link your key to a driver pro-
file. The driver profile along with all of its set-
tings will then be automatically selected
every time the car is used with that specific
remote control key.

The first time the remote control key is used, it
is not linked to any specific driver profile.
When the car is started, the

Guest

profile will

automatically be activated.

A driver profile can be selected manually with-
out linking it to the key. When the car is
unlocked, the last active driver profile is acti-
vated. Once the key has been linked to a driver
profile, a driver profile does not need to be
selected when that specific key is used.

Linking a remote control key to a
driver profile

Connecting a remote control key to a driver
profile is only possible when the car is sta-
tionary.

First select the profile to be linked to the key,
if the profile to be linked is not already active.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

137

The active profile can then be linked to the
key.

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

System

Driver Profiles

3. Select the desired profile. The display

returns to the home view. The

Guest

pro-

file cannot be linked to a key.

4. Drag down the top view again and tap on

Settings

System

Driver Profiles

Edit Profile

5. Select

Connect key

to link the profile with

the key. It is not possible to link a driver
profile to a different key than the one cur-
rently being used in the car. If there are
multiple keys in the car, the message

More than one key is found, put the key
you want to connect on backup reader

will be displayed.

Backup reader's location in the tunnel console.

> When the message

Profile connected

to key

is shown, the key and the driver

profile are linked.

6. Press

> This key is now linked to the driver pro-

file and will remain linked as long as the

Connect key

box is not unticked.

Related information

•

Renaming a driver profile (p. 135)

•

•

Remote control key (p. 237)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

138

Resetting settings in the driver

profiles

Settings that have been saved to one or more
driver profiles can be reset if the car is sta-
tionary.

Factory reset

is only possible when the

car is stationary.

1. Press

Settings

in the top view.

2. Press

System

Factory reset

Reset

Personal Settings

3. Select one of the options

Reset for the

active profile

Reset for all profiles

Cancel

Related information

•

Resetting settings in the centre display
(p. 132)

•

Message in centre display

The centre display can show messages to
inform or assist the driver in the event of dif-
ferent events.

Example of a message in the centre display's top

view.

The centre display shows messages that are
of lower priority for the driver.

Most messages are shown above the centre
display's status bar. After a while, or when any
required action related to the message has
been taken, the message disappears from the
status bar. If a message needs to be saved, it
is positioned in the top view in the centre dis-
play.

Message composition may vary and they can
be shown together with graphics, symbols or
a button for activating/deactivating a function
linked to the message.

Pop-up messages

In some cases, a message is shown in the
form of a pop-up window. Pop-up messages
have higher priority than messages shown in
the status bar and require acknowledgement/
action before they disappear.

Related information

•

Managing messages in the centre display
(p. 139)

•

Handling a message saved from the cen-
tre display (p. 139)

•

Messages in the driver display (p. 103)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

}}

139

Managing messages in the centre

display

Messages in the centre display are handled in
centre display views.

Example of a message in the centre display's top

view.

Some messages in the centre display have a
button (or several buttons in pop-up mes-
sages) for e.g. activating/deactivating a func-
tion linked to the message.

Managing a new message

For messages with buttons:

–

Press the button to perform the action or
allow the message to close automatically
after a while.
> The message disappears from the sta-

tus bar.

For messages without buttons:

–

Close the message by tapping on it, or
allow the message to close automatically
after a while.
> The message disappears from the sta-

tus bar.

If a message needs to be saved, it is posi-
tioned in the top view in the centre display.

Related information

•

Message in centre display (p. 138)

•

Handling a message saved from the cen-
tre display (p. 139)

•

Messages in the driver display (p. 103)

Handling a message saved from

the centre display

Whether saved from the driver display or the
centre display, messages are managed in the
centre display.

Examples of saved messages and possible options in

the top view.

Messages that are shown in the centre display
that need to be saved are added in the top
view of the centre display.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

* Option/accessory.

140

Reading a saved message

1. Open the top view in the centre display.

> A list of saved messages is shown.

Messages with an arrow to the right
can be maximised.

2. Tap on a message to expand/minimise.

> More information on the message is

shown in the list and the image to the
left in the app shows information about
the message graphically.

Managing a saved message

Some messages have a button for e.g. activat-
ing/deactivating a function linked to the mes-
sage.

–

Press the button to perform the action.

Saved messages in the top view are deleted
automatically when the car is switched off.

Related information

•

Message in centre display (p. 138)

•

Managing messages in the centre display
(p. 139)

•

Messages in the driver display (p. 103)

Head-up display

The head-up display supplements the car's
driver display and projects information from
the driver display onto the windscreen. The
projected image can only be seen from the
driver position.

The head-up display shows warnings and
information relating to speed, cruise control
functions, navigation, etc. in the driver's field
of vision. Road Sign Information and incoming
phone calls can also be shown in the head up
display.

The driver's ability to see the information in
the head-up display is impaired by the fol-
lowing

•

use of polarising sunglasses

•

a driving position which means that
the driver is not sitting centred in the
seat

•

objects on the display unit's cover
glass

•

unfavourable light conditions.

IMPORTANT

The display unit from which the informa-
tion is projected is located in the instru-
ment panel. To avoid damage to the dis-
play unit's cover glass - do not store any
objects on the cover glass and make sure
that no objects fall down onto it.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

* Option/accessory.

141

Examples of what can be shown in the display.

Speed

Cruise control

Navigation

Road signs

A number of symbols can be shown temporar-
ily in the head-up display, e.g.:

If the warning symbol illuminates -
read the warning message in the
driver display.

If the information symbol illuminates
- read the message in the driver dis-
play.

The snowflake symbol illuminates in
the event of a risk of icy conditions.

Activating and deactivating the head-up
display

Certain visual defects may cause head-
aches and a feeling of stress during the use
of the head-up display.

City Safety in the head-up display

In the event of a collision warning, the infor-
mation in the head-up display is replaced by
the warning symbol for City Safety. This
graphic is illuminated even if the head-up dis-
play is switched off.

The warning symbol for City Safety flashes in order

to attract the driver's attention if there is a risk of col-

lision.

Related information

•

(p. 142)

•

Cleaning the head up display

(p. 637)

•

Head up display when replacing the wind-
screen

(p. 603)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

* Option/accessory.

142

Activating and deactivating the

head-up display

The head-up display can be activated and
deactivated when the car has been started.

Press the

Head-up Display

button in the centre display
function view. An indicator in
the button illuminates when
the function is activated.

Related information

•

Settings for head-up display

(p. 142)

•

Head-up display

(p. 140)

Settings for head-up display

Adjust the settings for the head-up display's
projection onto the windscreen.

Settings can be defined when the car has
been started and a projected image is shown
on the windscreen.

Selecting display options

Select which functions are to be shown in the
head-up display.

1. Tap on

Settings

in the centre display's

top view.

2. Press

My Car

Displays

Head-Up

Display Options

3. Select one or more functions:

•

Show Navigation

•

Show Road Sign Information

•

Show Driver Support

•

Show Phone

The setting is saved as a personal setting in
the driver profile.

Adjusting brightness and vertical
position

1. Press the

Head-up Display Adjustments

button in the centre display function view.

2. Adjust the brightness and vertical position

of the projected image in the driver's field
of vision using the steering wheel's right-
hand keypad.

Reducing the brightness

Increasing the brightness

Raising the position

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

}}

* Option/accessory.

143

Lowering the position

Confirm

The brightness of the graphics is automatically
adapted to their background light conditions.
The brightness is also affected by the adjust-
ment of the brightness in the car's other dis-
plays.

The height position can be stored in the mem-
ory function for the power

front seat using the

keypad in the driver's door.

Calibrate the horizontal position

The head-up display's horizontal position may
need to be calibrated if the windscreen or dis-
play unit is replaced. Calibration means that
the projected image is rotated clockwise or
anticlockwise.

1. Tap on

Settings

in the centre display's

top view.

2. Select

My Car

Displays

Head-Up

Display Options

Head-Up Display

Calibration

3. Calibrate the image's horizontal position

with the steering wheel's right keypad.

Rotate anticlockwise

Rotate clockwise

Confirm

Related information

•

Head-up display

(p. 140)

•

Activating and deactivating the head-up
display

(p. 142)

•

Storing position for seat, door mirrors and
head-up display

•

(p. 184)

Voice recognition

Voice control

allows you to control func-

tions in the car, e.g. climate system, radio or
a Bluetooth-connected phone with spoken
commands. In cars equipped with Sensus
Navigation

, the navigation system can also

be controlled with voice recognition.

What is voice control?

Voice control is an aid that can facilitate the
use of different commands in your car. In prin-
ciple, it works like a normal application in
which you enter information in a fixed
sequence in order to perform a task, but
instead of typing on a keyboard you use voice
commands. It may therefore be a good idea to
learn how, and in what order, a voice com-
mand should be spoken in order to achieve the
desired result.

The voice control system allows you to control
certain infotainment and climate functions
using voice commands. The system can
respond with speech and by showing informa-
tion in the driver display.

Applies to certain markets.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

* Option/accessory.

144

WARNING

The driver always holds overall responsibil-

ity for driving the vehicle in a safe manner

and complying with all applicable rules of

the road.

Voice control system microphone

System updating

The voice recognition system is continuously
improved. It is recommended to always have
the latest version installed.

Download updates from
support.volvocars.com.

Related information

•

Using voice recognition (p. 144)

•

Controlling a telephone with voice recog-
nition (p. 146)

•

Voice control of radio and media (p. 147)

•

Controlling climate control with voice rec-
ognition (p. 199)

•

Voice recognition (p. 143)

Using voice recognition

Start voice control

To give commands via the
voice control system, you
have a "dialogue" with the
system. Depress the steering
wheel button for voice recog-
nition

to activate the sys-

tem and initiate a dialogue

using voice commands. After you have
pressed the button, a beep tone can be heard
and the voice control symbol is shown in the
driver display.

This shows that the system has started to lis-
ten and you can start to say the commands.
As soon as you start to talk, the system is
trained to recognise and understand your
voice. This takes several seconds and is done
automatically, which means that you do not
need to start any voice training manually.

Remember the following:

•

Speak after the tone with a normal voice
at a normal tempo.

•

Do not speak while the system is replying
(the system cannot understand com-
mands during this time).

•

Avoid background noise in the passenger
compartment by having the doors, win-
dows and panoramic roof

closed.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

}}

145

In general, the system works by listening for a
basic command which is followed by more
detailed commands that specify what you
want the system to do.

To change the system audio volume, turn the
rotary volume knob when the voice speaks. It
is possible to use other buttons during voice
control. However, other sounds will be
silenced during dialogue with the system,
which means that it is not possible to execute
any functions linked with audio using the but-
tons.

Cancel voice control

Voice control can be cancelled in different
ways:

•

Tap briefly on

and say "

Cancel

•

Give a long press on the steering wheel
button for voice control

until you hear

two beeps. This stops voice recognition
even when the system is speaking.

Voice control is also cancelled if you do not
reply during a dialogue. The system will first
ask for a reply three times and if there is still
no response then voice control will be cancel-
led automatically.

To speed up communication and skip the
prompts from the system, press the steering

wheel button for voice control

. This can-

cels the system voice and you can say the next
command.

Example of voice recognition control

1. Press

2. Say "

Call [Forename]

[Surname]

[number category]

", e.g. "

Call Robin

Smith

Mobile

> The system dials the selected contact

from the phonebook. If the contact has
several phone numbers (e.g. home,
mobile, work), the right category must
be referred to.

Commands/phrases

The following commands can generally be
used, regardless of the situation:

•

Repeat

" - repeats the last voice instruc-

tion in the ongoing dialogue.

•

Cancel

" - discontinue the dialogue.

•

Help

" - starts a help dialogue. The sys-

tem replies with the commands available
in the current situation, a prompt or an
example.

Commands for specific functions such as
phone and radio are described in specific sec-
tions.

Digits

The number commands are stated differently
depending on the function to be controlled:

•

Phone numbers and postcodes

must be

spoken individually, number by number,
e.g. "zero, three, one, two, two, four, four,
three" (03122443).

•

House numbers

can be spoken individu-

ally or in groups, e.g. "two, two" or
"twenty-two" (22). For English and Dutch,
several groups can be said in sequence,
e.g. "twenty-two, twenty-two" (22 22).
For English, double or triple can be used,
e.g. "double zero" (00). Numbers can be
given within the range 0-2300.

•

Frequencies

can be spoken as "ninety

eight point eight" (98.8), "a hundred and
four point two" or "hundred four point
two" (104.2).

Applies to certain markets.

Note that this only stops the dialogue when the system is not speaking. To do that, give a long press on

until two beep tones are heard.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

* Option/accessory.

146

Speed and repetition mode

It is possible to adjust the speed if the system
is speaking too quickly.

Repetition mode can be enabled so that the
system repeats what you have said.

To change the speed or activate/deactivate
repetition mode:

1. Press

Settings

in the top view.

2. Press

System

Voice Control

and

select settings.

•

Repeat Voice Command

•

Speech Rate

Related information

•

•

Controlling a telephone with voice recog-
nition (p. 146)

•

Voice control of radio and media (p. 147)

•

Controlling climate control with voice rec-
ognition (p. 199)

•

Voice recognition (p. 143)

Controlling a telephone with voice

recognition

Call a contact, have messages read aloud or
dictate brief messages with voice control
commands to a Bluetooth connected tele-
phone.

To specify a contact in the phone book, the
voice recognition command must include con-
tact information that is entered in the phone
book. If a contact, e.g.

Robyn Smith

, has sev-

eral phone numbers then the number category
can also be stated, e.g.

Home

Mobile

Call Robin

Smith

Mobile

Press

and say one of the following com-

mands:

•

Call [contact]

" - dials the selected con-

tact from the phone book.

•

Call

[phone number]

" - dials the phone

number.

•

Recent calls

" - displays the call list.

•

Read message

" - message is read out. If

there are several messages - select which
message should be read out.

•

Message to [contact]

" – the user is

requested to say a brief message. The
message is then repeated aloud and the
user can choose to send

or revise the

message. For this function to work, the
car must be connected to the Internet.

Related information

•

•

Using voice recognition (p. 144)

•

Voice control of radio and media (p. 147)

•

Controlling climate control with voice rec-
ognition (p. 199)

•

Only certain phones can send messages via the car. For information on which phones are compatible, see support.volvocars.com.

•

Internet-connected car

(p. 527)

Applies to certain markets.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

DISPLAYS AND VOICE CONTROL

}}

* Option/accessory.

147

Voice control of radio and media

Commands for radio and media player device
control are shown below.

Tap on

and say one of the following com-

mands:

•

Media

" - starts a dialogue for media and

radio and shows examples of commands.

•

Play

[artist]

" - plays back music by the

selected artist.

•

Play

[song title]

" - plays back the

selected song.

•

Play

[song title]

from

[album]

" - plays

back the selected song from the selected
album.

•

Play

[TV channel name]

" - starts the

selected TV channel

•

Play

[radio station]

" - starts playing

back the selected radio channel.

•

Tune to [frequency]

" - starts the

selected radio frequency in the current fre-
quency band. If no radio source is active,
the FM band is started by default.

•

Tune to [frequency]

[wavelength]

" -

starts the selected radio frequency in the
selected frequency band.

•

Radio

" - starts FM radio.

•

Radio FM

" - starts FM radio.

•

DAB

" - starts DAB radio

•

" - starts playback from TV

•

" - starts playback from CD

•

USB

" - starts playback from USB.

•

iPod

" - starts playback from iPod.

•

Bluetooth

" - starts playback from a

Bluetooth-connected media source.

•

Similar music

" - plays back music simi-

lar to the music currently playing back
from USB devices.

Related information

•

Voice recognition (p. 143)

•

Using voice recognition (p. 144)

•

Controlling a telephone with voice recog-
nition (p. 146)

•

Controlling climate control with voice rec-
ognition (p. 199)

•
