LOADING AND STORAGE

Roof load

Load retaining eyelets

Loading - bag holder

The load carriers recommended for roof loads

The load retaining eyelets are used to fasten

The bag holders keep carrier bags in place and

are the ones developed by Volvo. This is in order

straps in order to anchor items in the cargo area.

prevent them from overturning and spreading

to avoid damage to the car and in order to

their contents around the cargo area. The holder

achieve the maximum possible safety during a

has a capacity of max. 3 kg.

journey.

Carefully follow the installation instructions sup-

plied with the carriers.

• Check periodically that the load carriers and

load are properly secured. Lash the load

securely with retaining straps.

• Distribute the load evenly over the load carri-

ers. Put the heaviest objects at the bottom.

• The size of the area exposed to the wind, and

therefore fuel consumption, increase with the

size of the load.

WARNING

Bag holder

• Drive gently. Avoid quick acceleration, heavy

Hard, sharp and/or heavy objects which pro-

braking and hard cornering.

trude may cause injury under violent braking.

Related information

WARNING

Always secure large and heavy objects with a

• Loading (p. 148)

seatbelt or cargo retaining straps.

The car's centre of gravity and driving charac-

• Loading - folding bag holder* (p. 151)

teristics are altered by roof loads.

For information about the maximum permitted

Related information

load on the roof, including load carriers and

• Loading (p. 148)

any space box, see Weights (p. 388).

Related information

• Loading (p. 148)

150

* Option/accessory.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOADING AND STORAGE

Loading - folding bag holder*

Folding up

12 V socket - cargo area

A folding bag holder in the floor keeps bags in

The electrical socket can be used for various

place and prevents them from overturning and

accessories designed for 12 Volts, e.g. display

spreading their contents in the cargo area, and

screens, music players and mobile phones.

can be opened up in three positions.

Lift the handle* on the upper floor and fold

up the floor.

Move the floor forwards to an appropriate

position and place it in the adjustment

Lower the cover to access the electrical socket.

Folding bag holder

groove.

• The socket also provides voltage when the

It can be set to two adjustment positions and one

3. In service position, the floor is moved all the

remote control key is not in the ignition

service position, as it is known, where it is fully

way forwards towards the rear seat back and

switch.

unfolded. There are also two floor combination

placed in the plastic support in the centre.

variants, one with adjustment positions in a tub

under the floor and one with adjustment posi-

Related information

IMPORTANT

tions in plastic rails. The raising below shows the

• Loading (p. 148)

Max. socket current is 10 A (120 W).

adjustment position in a tub under the floor.

• Loading - bag holder (p. 150)

The load on the central holder is max. 3 kg and

NOTE

max. 10 kg on the outer holder.

Remember that using the electrical socket

with the engine switched off involves the risk

of discharging the car's battery.

}}

* Option/accessory.

151

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOADING AND STORAGE

||

Cargo net*

Attaching

NOTE

A cargo net prevents cargo from being thrown

The compressor for emergency puncture

forward in the passenger compartment in the

NOTE

repair (p. 332) has been tested and approved

event of heavy braking.

by Volvo.

The easiest way to fit the safety net is via one

of the rear doors.

Related information

• Tunnel console - 12 V-sockets (p. 148)

WARNING

It is necessary to ensure that the upper secur-

ing points of the safety net are fitted correctly

and that the puller-straps are secured prop-

erly. Damaged nets must not be used.

The cargo net is fitted into four mounting points.

For safety reasons, the cargo net must always be

correctly fastened and secured. The mesh is

made of a strong nylon fabric and secured

behind the front seat backrests.

WARNING

Loads in the luggage compartment must be

anchored well, and also have a correctly fitted

safety net.

152

* Option/accessory.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOADING AND STORAGE

2. Depress the button in the anchoring strap's

Hat shelf

lock and thread the anchoring strap from

The hat shelf can be removed to provide addi-

below through the lock.

tional cargo space.

Tension the cargo net with the anchoring

Hat shelf removal

straps.

1. Hook the hooks into the roof mounting with

the anchoring strap locks turned towards

you.

Thread the cargo net's anchoring straps

through the eyes on the rear of the seat slide

Undo the hat shelf lifting eyes on both sides.

rails - it is easier if the backrests are straight-

ened and the seats are moved forward

Removal and storage

1. Release the tension in the cargo net by

Unhook the front edge of the hat shelf and

slightly.

pressing in the button on the anchoring

remove it.

Pay attention to make sure that you do not

strap's lock and feeding out the strap.

press the seat/backrest hard against the net

Related information

when the seat/backrest is moved back again

2. Unhook the hooks from the roof mountings.

• Loading (p. 148)

- only adjust until the seat/backrest makes

3. Fold up the cargo net and place it in the

• Loading - long load (p. 149)

contact with the net.

storage bag in the cargo area.

Related information

IMPORTANT

•

Loading (p. 148)

If a seat/backrest is pushed backwards hard

• Load retaining eyelets (p. 150)

into the safety net then the net and/or its

roof mounts may be damaged.

153

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Remote control key

tions (p. 160) for a description of its func-

Remote control key - losing

Amongst other things, the remote control key is

tions.

If you lose a remote control key (p. 156) then a

used for locking/unlocking and starting the

• Remote control key without PCC - with Key-

new one can be ordered at a workshop - an

engine.

less Drive* (p. 165) and keyless locking

authorised Volvo workshop is recommended.

(p. 167) and unlocking (p. 168).

The remaining remote control keys must be

There are three variants of key available -

• Remote control key with PCC - also has an

taken to the Volvo workshop. The code of the

Remote control key in basic version, Remote con-

information button and indicator lamps. Read

missing remote control key must be erased from

trol key without PCC* and Remote control key

more about these unique functions (p. 161).

the system as a theft prevention measure. The

with PCC*.

All remote control keys have a detachable key

current number of keys registered to the car can

blade (p. 163) made of metal. The visible section

be checked in the menu system MY CAR. For a

Basic^A

without

with

is available in two versions so that it is possible to

description of the menu system, see MY CAR

Functionality

PCC^A

PCC^B

distinguish between the remote control keys.

(p. 113).

Locking/

More remote control keys can be ordered - but

Related information

not variants other than the one supplied with the

unlocking and

•

Remote control key - functions (p. 160)

x

x

x

detachable key

car. Up to six keys can be programmed and used

•

Remote control key - range (p. 161)

for one single car.

blade

The car is supplied with two remote control keys.

Keyless lock-

x

x

ing/unlocking

WARNING

Keyless engine

x

x

If there are children in the car:

starting

Remember to switch off the supply to the

Information but-

power windows by removing the remote con-

ton and indica-

x

trol key if the driver leaves the car.

tor lamps

A 5-button key

B 6-button key

More information

• Remote Control Key Basic - is a key in the

basic version, see Remote control key - func-

156

* Option/accessory.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

||

Related information

Locking/unlocking - indicator

• Remote control key - functions (p. 160)

When the car is locked or unlocked using the

• Remote control key with PCC* - unique func-

remote control key (p. 156) the direction indica-

tions (p. 161)

tors confirm that locking/unlocking was correctly

performed.

• Locking - one flash and the door mirrors are

folded³ in.

• Unlocking - two flashes and the door mirrors

are folded³ out.

NOTE

Same LED as alarm indicator (p. 178).

Be aware of the risk of locking the remote

control key in the car.

NOTE

Cars that are not equipped with alarm also

When locking, indication is given only if all locks

have this indicator.

have been locked and all doors are closed. Indi-

cation is given when the last door has been

closed.

Related information

• Keyless drive* (p. 165)

Selecting the function

• Alarm indicator* (p. 178)

Different options for indicating locking/unlocking

with light can be set in the menu system MY

CAR. For a description of the menu system, see

MY CAR (p. 113).

Lock indicator

A flashing LED by the windscreen verifies that

the car is locked.

3 Only for cars with retractable power door mirrors.

158

* Option/accessory.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Remote control key - electronic

Message

Specification

Remote-controlled immobiliser with

immobiliser

tracking system*

Insert car

Error when reading the remote

The electronic immobiliser is a theft protection

Remote-controlled immobiliser with tracking sys-

key

control key during starting -

system that prevents the vehicle from being

tem⁴ makes it possible to track and locate the

Remove the key from the igni-

started (p. 270) by an unauthorised person.

car, and to remotely activate the immobiliser.

tion switch, press it in again and

Each remote control key (p. 156) has a unique

make a new start attempt.

Contact your nearest Volvo dealer for more infor-

code. The car can only be started with the correct

mation and assistance with activating the system.

Car key

Error reading the remote control

remote control key with the correct code.

not

key during starting - Try to start

Related information

The following error messages in the combined

found^A

again.

• Remote control key (p. 156)

instrument panel's information display are related

to the electronic immobiliser:

If the error persists: Insert the

• Remote control key - electronic immobiliser

remote control key into the igni-

(p. 159)

tion switch and try to start again.

Immobi-

Error in immobiliser system dur-

liser Try

ing starting. If the error persists:

to start

Contact a workshop - an author-

again

ised Volvo workshop is recom-

mended.

A Only applies to cars with keyless start and lock system.

Related information

• Remote-controlled immobiliser with tracking

system* (p. 159)

• Keyless drive* (p. 165)

4 Only certain markets and in combination with Volvo On Call*.

* Option/accessory.

159

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Remote control key - functions

Unlocking (p. 170) - Unlocks the doors

The remote control key has functions such as

and tailgate while the alarm is deactivated.

locking and unlocking the doors.

Press and hold to open all windows simultane-

ously. For more information, see Global opening

Functions

(p. 172).

The function can be changed from unlocking all

doors simultaneously, to unlocking the driver's

door only with one press of the button and, after

a further press of the button - within ten seconds

- unlocking the remaining doors.

The function can be changed in the menu system

Remote control key with PCC* (Personal Car

MY CAR. For a description of the menu system,

Communicator).

see MY CAR (p. 113).

Information button - see Remote control

key with PCC* - unique functions (p. 161)

Approach light duration (p. 102) - Used

for a description of its functionality.

to switch on the car's lighting at a distance.

Remote control key in basic version.

Tailgate (p. 172) - Unlocks and disarms

Function buttons

Locking

the alarm for the tailgate only.

Locking - Locks the doors and tailgate

Unlocking

while the alarm is activated, see Locking/unlock-

Panic function - Used to attract attention

ing - from the outside (p. 170).

in an emergency.

Approach light duration

Press and hold to close all windows simultane-

Press and hold the button for at least three sec-

Tailgate

ously. For more information, see Global opening

onds or press it twice within three seconds to

(p. 172).

activate the direction indicators and the horn.

Panic function

The function can be turned off with the same

WARNING

button once it has been active for at least five

If windows are closed using the remote con-

seconds. Otherwise the function switches off

trol key, check that nobody's hands are trap-

automatically after approx. three minutes.

ped.

Related information

• Remote control key (p. 156)

160

* Option/accessory.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Remote control key - range

Remote control key with PCC* -

Using the information button

Remote control key functions (in its basic ver-

unique functions

- Press the information button

sion) have a range of approx. 20 metres from

A remote control key with PCC* has enhanced

> All indicator lamps flash for approximately

the car.

functionality compared with a remote control key

7 seconds and the light travels around on

in basic version (p. 156) in the form of an infor-

the PCC. This indicates that information

If the car does not verify a button being pressed -

mation button and indicator lamps.

from the car has been read.

move closer and try again.

If any of the other buttons are pressed

during this time then the reading is inter-

NOTE

rupted.

The remote control key functions may be dis-

rupted by surrounding radio waves, buildings,

NOTE

topographical conditions, etc. The car can

always be locked/unlocked with the key blade

If none of the indicator lamps illuminates

(p. 164).

with repeated use of the information button

and in different locations (as well as after 7

If the remote control key is removed from the car

seconds and after the light has travelled

when the engine is running or key position I or II

around on the PCC), contact a workshop - an

(p. 80) is active, and all doors are closed, then a

authorised Volvo workshop is recommended.

warning message is shown in the information dis-

Remote control key with PCC.

play in the combined instrument panel and a

Information button

Indicator lamps display information in accordance

short audio reminder signal sounds at the same

with the following illustration:

time.

Indicator lamps

The message extinguishes when the remote con-

Using the information button enables access to

trol key is returned to the car, followed by a press

certain information from the car via the indicator

of the OK button, or when all doors are closed.

lamps.

Related information

• Remote control key (p. 156)

• Remote control key - functions (p. 160)

}}

* Option/accessory.

161

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

||

Remote control key with PCC* -

NOTE

range

If none of the indicator lamps illuminates

The range of a remote control key with PCC

with repeated use of the information button

(Personal Car Communicator) for unlocking the

and in different locations (as well as after 7

doors and tailgate is approx. 20 metres from the

seconds and after the light has travelled

car - the other functions are up to approx. 100

around on the PCC), contact a workshop - an

metres. If the car does not verify a button being

authorised Volvo workshop is recommended.

pressed - move closer and try again.

NOTE

Related information

The information button function may be dis-

• Keyless Drive* - range (p. 166)

rupted by surrounding radio waves, buildings,

• Remote control key - range (p. 161)

Green continuous light - the car is locked.

topographical conditions, etc.

Yellow continuous light - the car is unlocked.

Out of range

Red continuous light - the alarm has been

If the remote control key is too far away from the

triggered since the car was locked.

car for the information to be read then the status

Red light flashing alternately in both indicator

the car was last left in is shown, without the light

lamps - The alarm was triggered less than 5

travelling around on the remote control key.

minutes ago.

If several remote control keys are used for the

car then it is only the remote control key last

Related information

used for locking/unlocking that shows the cor-

• Remote control key with PCC* - range

rect status.

(p. 162)

162

* Option/accessory.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Detachable key blade

Detachable key blade - detaching/

Related information

The remote control key contains a detachable

attaching

•

Detachable key blade - unlocking doors

key blade of metal with which some functions

Detaching/attaching the detachable key blade

(p. 164)

can be activated and some operations carried

(p. 163) is carried out as follows:

•

Child safety locks - manual activation

out.

(p. 176)

Removing the key blade

The key blade's unique code is provided by

•

Passenger airbag - activating/deactivating*

authorised Volvo workshops, which are recom-

(p. 36)

mended when ordering new key blades.

Key blade functions

Using the remote control key's detachable key

blade:

• the left-hand front door can be unlocked

manually (p. 164) if central locking cannot

be activated with the remote control key.

• the rear doors' mechanical child safety locks

can be activated/deactivated (p. 176).

Slide the spring-loaded catch to the side.

• the right-hand front door and the rear doors

can be locked manually, e.g. in the event of

At the same time pull the key blade straight

power failure.

out backwards.

• the glovebox lock* can be unlocked.

Attaching the key blade

• the airbag for front passenger seat

Carefully refit the key blade into its location in the

(PACOS*) can be activated/deactivated.

remote control key (p. 156).

Related information

1. Hold the remote control key with the slot

• Manual locking of the door (p. 170)

pointed up and lower the key blade into its

slot.

• Locking/unlocking - glovebox (p. 172)

2. Lightly press the key blade. You should hear

• Passenger airbag - activating/deactivating*

a "click" when the key blade is locked in.

(p. 36)

* Option/accessory.

163

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Detachable key blade - unlocking

Remote control key/PCC - replacing

doors

the battery

The detachable key blade can be used if the

The battery⁵ in the remote control key may need

central locking cannot be activated with the

to be replaced.

remote control key - e.g. if the remote control

The battery for the remote control key should be

key's battery (p. 164) has been discharged.

replaced if:

The left-hand front door can be opened as fol-

• the information symbol is illuminated and the

lows:

display in the combined instrument panel

1. Unlock the left-hand front door with the key

shows Car key battery low See manual

blade in the door handle's lock cylinder. For

and/or

more information, see Keyless Drive* -

unlocking with the key blade (p. 168).

•

the locks repeatedly do not react to signals

from the remote control key within 20 metres

from the car.

NOTE

When the door has been unlocked using the

key blade and is opened, the alarm is trig-

gered.

Opening

2. Deactivate the alarm by inserting the remote

Slide the spring-loaded catch to the side.

control key in the ignition switch.

For cars with keyless start and lock system, see

At the same time pull the key blade

Keyless Drive* - unlocking with the key blade

straight out backwards.

(p. 168).

Insert a 3 mm slot screwdriver in the hole

Related information

behind the spring-loaded catch and gently

• Detachable key blade (p. 163)

prize the remote control key up.

• Remote control key (p. 156)

5 Remote control key with PCC has two batteries.

164

* Option/accessory.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Remote control key with PCC* with two

Keyless drive*

NOTE

batteries

Cars equipped with Keyless Drive have a star-

Turn the remote control key over with the but-

1. Carefully prize out the batteries.

ting and locking system that can be operated

tons facing up, this is to avoid the batteries

keylessly.

falling out when it is opened.

2. First install one new one with the (+) side up.

3. Position the white plastic tab in between and

With the keyless start and lock system the car

finally install a second new battery with the

can be started, locked and unlocked without the

IMPORTANT

(+) side down.

remote control key (p. 156) inserted in the igni-

Avoid touching new batteries and their con-

tion switch⁶. It is enough to have the remote con-

tact surfaces with your fingers as this may

Battery type

trol key with you in a pocket. The system makes it

Use batteries with designation CR2430, 3 V.

impair their function.

easier and more convenient to e.g. open the car

when your hands are full.

Assembly

Battery replacement

1. Press the remote control key together.

Both of the remote control keys included with the

car have keyless functionality. It is possible to

2. Hold the remote control key with the slot

NOTE

order more remote control keys.

pointed up and lower the key blade into its

Volvo recommends that the batteries to be

slot.

The car's electrical system can be set to three

used in the remote control key/PCC fulfil UN

different levels - key position 0, I and II (p. 81) -

3. Lightly press the key blade. You should hear

Manual of Test and Criteria, Part III, sub-

with the remote control key.

a "click" when the key blade is locked in.

section 38.3. Batteries fitted in the factory or

Related information

replaced by an authorised Volvo workshop

IMPORTANT

fulfil the above criteria.

• Keyless Drive* - range (p. 166)

Make sure that exhausted batteries are dis-

• Keyless Drive* - secure handling of the

posed of in a manner which is kind to the

remote control key (p. 166)

Closely study how the battery/batteries are

environment.

secured on the inside of the cover, with

• Keyless Drive* - interference to remote con-

regard to their (+) and (-) sides.

trol key function (p. 167)

Related information

Remote control key with one battery

• Remote control key (p. 156)

1. Carefully prize out the battery.

• Remote control key - functions (p. 160)

2. Install a new one with the (+) side down.

6 Does not apply to Remote Control Key Basic.

* Option/accessory.

165

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Keyless Drive* - range⁷

opened and then closed, then a warning mes-

Keyless Drive* - secure handling of

sage is shown in the information display in the

the remote control key

In order to unlock the doors or tailgate automati-

combined instrument panel and an audio

cally without pressing a button on the remote

It is important to handle all remote control keys

reminder signal sounds at the same time.

control key, a remote control key must be within

with great care.

approx. 1.5 metres from the car's door handle or

When the remote control key has been returned

tailgate.

to the car, the warning message goes off and the

If one of the remote control keys⁸ has been left

in the car then the keyless functions are deacti-

audible reminder ceases once either/or:

The person who wishes to lock or unlock a door

vated in case the car is e.g. locked with the other

must have the remote control key with him or her.

• a door has been opened and closed

remote control key that belongs to the car. This

It is not possible to lock or unlock a door if the

• the remote control key has been inserted in

prevents unauthorised entry.

remote control key is on the opposite side of the

the ignition switch

The next time the car is unlocked with the other

car.

• The OK button on the direction indicator

remote control key the forgotten remote control

stalk.

key is reactivated again.

Related information

IMPORTANT

• Keyless drive* (p. 165)

Avoid leaving the remote control key with

• Keyless Drive* - antenna location (p. 169)

PCC behind in the car. If someone breaks into

your car and takes the remote control key, it

will e.g. be possible to start the car by press-

ing the remote control key in the ignition

switch and then pressing the START/STOP

ENGINE button.

Related information

The red rings in the above figure indicate the

• Keyless drive* (p. 165)

range covered by the system's antennas.

If all remote control keys are removed from the

car when the engine is running or key position I

or II (p. 81) is active, and if a door has been

7 Does not apply to cars with keyless starting

8 Applies to remote control key with PCC (Personal Car Communicator).

166

* Option/accessory.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Keyless Drive* - interference to

Keyless Drive* - locking

NOTE

remote control key function

Cars equipped with keyless start and lock sys-

In cars with automatic gearbox selectors, the

Electromagnetic fields and screening can inter-

tem have a touch-sensitive area on the outside

gear selector must be set to the P position;

fere with the remote control key's keyless func-

handle of the doors and a rubberised button

otherwise the car can be neither locked nor

tions (p. 165).

next to the tailgate's rubberised pressure plate.

alarmed.

NOTE

NOTE

Do not place/store the remote control key

with keyless function near a mobile phone or

Be aware that the system may be activated in

metal object - no closer than 10-15 cm.

connection with car washing if the remote

control key is in range.

If interference is experienced nonetheless, use

the remote control key and the key blade like a

Related information

remote control key in basic version (p. 156).

• Keyless drive* (p. 165)

Related information

• Alarm indicator* (p. 178)

• Remote control key/PCC - replacing the bat-

tery (p. 164)

Lock the doors and the tailgate by grasping one

• Keyless Drive* - secure handling of the

of the door handles or pressing the smaller of the

remote control key (p. 166)

tailgate's two rubberised buttons - the lock indi-

• Keyless Drive* - range (p. 166)

cator (p. 158) in the windscreen confirms that

locking has been completed by starting to flash.

All doors and the tailgate must be closed before

the car can be locked - otherwise the car is not

locked.

* Option/accessory.

167

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Keyless Drive* - unlocking⁹

Keyless Drive* - unlocking with the

1. Press the key blade approx. 1 cm straight up

key blade

into the hole on the underside of the door

Unlocking takes place when a hand grasps a

handle/cover - do not prize.

door handle or the tailgate's rubberised pressure

If central locking cannot be activated with the

plate is actuated - open the door or tailgate as

remote control key, e.g. if the batteries are dis-

> The plastic cover loosens automatically by

normal.

charged, then the left-hand front door is

means of the torque when the blade is

unlocked with the remote control key's detacha-

pushed straight up and into the opening.

NOTE

ble key blade (p. 163).

2. Then insert the key blade in the lock cylinder

The door handles normally register a hand

and unlock the door.

that takes hold of the handle, but with thick

3. Refit the plastic cover after unlocking.

gloves on or after a very quick hand move-

ment a second attempt may be required, or

NOTE

with the glove taken off.

When the left-hand front door is unlocked

using the key blade and is opened, this trig-

Related information

gers the alarm (p. 177). It is switched off by

• Keyless drive* (p. 165)

inserting the remote control key in the ignition

• Keyless Drive* - locking (p. 167)

switch, see Alarm* - remote control key not

working (p. 179).

Hole for key blade - to loosen the cover.

Related information

To access the lock cylinder, the door handle's

• Keyless drive* (p. 165)

plastic cover must be removed - this is also done

• Detachable key blade - detaching/attaching

with the key blade:

(p. 163)

9 Does not apply to remote control keys with keyless starting.

168

* Option/accessory.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Keyless Drive* - lock settings

Keyless Drive* - antenna location

WARNING

Lock settings for cars equipped with keyless

Cars equipped with keyless start and lock sys-

People with pacemaker operations should not

start and lock system can be adapted by indicat-

tem have a number of built-in antennas posi-

come closer than 22 cm to the keyless sys-

ing in the menu system MY CAR which doors

tioned at different locations in the car.

tem's antennae with their pacemaker. This is

are to be unlocked.

to prevent interference between the pace-

maker and the keyless system.

For a description of the menu system, see MY

CAR (p. 113).

Related information

Related information

• Keyless drive* (p. 165)

• Keyless drive* (p. 165)

Rear bumper, centre

Door handle, left rear

Cargo area, central and furthest in under the

floor

Door handle, right rear

Centre console, under the rear section

Centre console, under the front section.

* Option/accessory.

169

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Locking/unlocking - from the

Manual locking of the door

NOTE

outside

In certain situations the car must be lockable

Remember that the alarm is triggered when

Locking/unlocking from the outside is carried

manually, e.g. in the event of power failure.

the door is opened after being unlocked with

out using the remote control key (p. 160). The

the key blade - the alarm is switched off when

The left-hand front door can be locked with its

remote control key can lock/unlock all doors, the

the remote control key is inserted into the

lock cylinder and the remote control key's

tailgate and the fuel filler flap. Different sequen-

ignition switch.

detachable key blade (p. 168).

ces for unlocking can be selected.

Other doors have no lock cylinders and instead

In order that the lock sequence can be activated,

WARNING

have a lock switch on the end of each door which

the driver's door must be closed - if any of the

must be depressed using the key blade - they are

other doors or the tailgate is open, then it/they

Be aware of the risk of being locked in the

then mechanically locked/blocked to prevent

is/are locked and the alarm is activated only

car when it is locked from the outside using

the remote control key - it is then not possible

them being opened from outside. The doors can

when it/they are closed. For cars equipped with

to open any of the doors from the inside with

still be opened from the inside.

keyless locking system* all doors and the tailgate

the door controls. For more information, see

must be closed, see Keyless Drive* - locking

Deadlocks* (p. 174).

(p. 167) and Keyless Drive* - unlocking (p. 168).

Automatic relocking

NOTE

If none of the doors or the tailgate is opened

Be aware of the risk of locking the remote

within two minutes of unlocking, all are locked

control key in the car.

again automatically. This function prevents the

car from being left unlocked unintentionally. For

cars with alarm, see Alarm* (p. 177).

If it is not possible to lock/unlock with the remote

control key, the battery may be discharged - lock

Related information

or unlock the left-hand front door with the

• Locking/unlocking - from the inside (p. 171)

detachable key blade (p. 163).

• Remote control key - functions (p. 160)

Manual locking of the door. Not to be mixed up with

child safety locks (p. 176).

- Remove the detachable key blade (p. 163)

from the remote control key. Insert the key

blade in the hole for lock reset and press the

key in until the key bottoms, approx. 12 mm.

170

* Option/accessory.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

The door can be opened from both the out-

Locking/unlocking - from the inside

A long press also opens all the side windows*

side and the inside.

Locking/unlocking can be performed using the

simultaneously (see also section Global opening

(p. 172)).

The door is blocked against opening from

driver's door button for central locking. All doors

the outside. To return to position A, the inner

and tailgate (p. 172) can be locked or unlocked

• Pull the door handle and open the door - the

door handle must be opened.

simultaneously.

door is unlocked and opened in one opera-

The doors can also be unlocked with the unlock

tion.

button on the remote control key (p. 156) or with

Locking

the central locking button on the driver's door.

•

Both front doors must be closed for the cen-

tral locking to be activated. Press the central

NOTE

locking button

- all doors are locked. If

• A door's lock reset only locks that partic-

any of the rear doors is open, it will lock

ular door - not all doors simultaneously.

when it is closed.

• A manually locked rear door with acti-

A long press also closes all the side windows

vated manual child safety locks (p. 176)

simultaneously (see also section Global opening

cannot be opened from either the outside

(p. 172)).

or the inside. A rear door that is locked in

this way can only be unlocked with the

Automatic locking

Central locking

remote control key or central locking but-

The doors and tailgate are locked automatically

ton.

of the button to lock -

when the car starts to move.

• Press one side

the other side

to unlock.

The function can be activated/deactivated in the

Related information

menu system MY CAR. For a description of the

Lamp in lock button

• Remote control key/PCC - replacing the bat-

menu system, see MY CAR (p. 113).

When the lamp in the central locking button for

tery (p. 164)

the driver's door is illuminated it means that all

Related information

doors are locked.

• Locking/unlocking - from the outside

(p. 170)

Unlocking

• Alarm* (p. 177)

A door can be unlocked from the inside in two

different ways:

• Press the central locking button

* Option/accessory.

171

-------------------------------------------------------------------------------------------------------------------------------------------------------------

LOCKS AND ALARM

Global opening

Locking/unlocking - glovebox

Locking/unlocking - tailgate

The global opening function opens or closes all

The glovebox (p. 147) can only be locked/

The tailgate can be opened, locked and

side windows simultaneously and can be used

unlocked using the detachable key blade from

unlocked in a number of different ways.

for example to quickly air the car during hot

the remote control key (p. 156).

Manual opening

weather.

For information on the key blade, see Detachable

key blade - detaching/attaching (p. 163).

Rubber plate with electrical contact.

Central locking button

The tailgate is held closed by an electrical lock.

A long press on the

symbol in the central

To open:

Locking the glovebox:

locking button or on the remote control key

1. Push down gently on the wider of the two

opens all side windows simultaneously. The

Insert the key blade in the glovebox lock cyl-

rubberised pressure plates under the outer

inder.

same procedure on the

button closes all

handle - the lock is released.

side windows simultaneously.

Turn the key blade 90 degrees clockwise.

2. Lift the outside handle in order to fully open

The keyhole is horizontal in the locked posi-

the tailgate.

Related information

tion.

• Locking/unlocking - from the inside (p. 171)

Pull out the key blade.

• Power windows (p. 104)

• Unlock by carrying this out in reverse order.

Related information

• Remote control key - functions (p. 160)

172

Content      ..     5      6      7      8     ..
