Volvo V60 (2019 year). Instruction - part 8

Changing settings in the center display's Top
view (p. 130)

Active Bending Lights are not available when
the headlight pattern is temporarily changed
from left-hand to right-hand traffic, or vice
versa.

Related information

•

•

Function view in the center display (p. 120)

•

Active Bending Lights* (p. 157)

Parking lights

The parking lights can be used to help other
road users see the vehicle if it is stopped or
parked. Use the lighting ring on the steering
wheel lever to turn on the parking lights.

Lighting ring in the parking light position.

Turn the lighting ring to the

position to

turn on the parking lights (the license plate light-
ing will also illuminate).

Canadian models: If the ignition is in the II posi-
tion, the daytime running lights will illuminate
instead of the front parking lights. With the light-
ing ring in this position, the parking lights will
remain on regardless of what position the ignition
is in.

US models: When

mode is selected, the

daytime running lights can be deactivated in the
center display. The parking lights will also be

deactivated. In weak daylight or dark conditions,
the parking lights and low beams will be illumi-
nated.

In dark conditions, the rear parking lights also
illuminate when the tailgate is opened to alert fol-
lowing traffic. This happens regardless of what
position the lighting ring or ignition is in.

Related information

•

•

LIGHTING

* Option/accessory.

153

Daytime running lights

The vehicle has sensors that detect ambient
lighting conditions. With the lighting ring in the

position, the daytime running lights will

always be activated when the ignition is in mode
II. In weak daylight or dark conditions, the head-
lights automatically switch to low beams.

Lighting ring in AUTO position.

With the steering wheel lever's lighting ring in the

position, the daytime running lights (DRL

)

will illuminate when the vehicle is driven in day-
light conditions. The headlights will switch auto-
matically from daytime running lights to low
beams in weak daylight or dark conditions. The
headlights will also switch to low beams if the
front fog lights* and/or rear fog light are acti-
vated.

US models: When

mode is selected, the

daytime running lights can be deactivated in the
center display. The parking lights will also be
deactivated. In weak daylight or dark conditions,
the parking lights and low beams will be illumi-
nated.

US models: With the lighting ring in the
or

position, the daytime running lights will

be off.

Canadian models: With the lighting ring in the

position, the daytime running

lights will be on.

Volvo recommends use of Daytime Running
Lights in the US. Its use is mandatory in Can-
ada.

WARNING

The system is an energy saving aid – it cannot

in all situations determine when the daylight is

too weak or not strong enough, e.g. when

there is fog or rain.
The driver is always responsible for driving the

vehicle with lighting that is safe for the traffic

conditions and as specified by applicable traf-

fic regulations.

Related information

•

•

•

Low beams (p. 154)

Daytime Running Lights

LIGHTING

* Option/accessory.

154

Low beams

When driving with the lighting ring in the
position, low beam will be automatically acti-
vated in weak daylight or dark conditions, when
the ignition is in the II position.

Lighting ring in AUTO position.

With the lighting ring in the

position, the

low beams will be automatically activated if:

•

the front fog lights* are activated

•

the rear fog light is activated

•

the rear and front fog lights are activated.

With the lighting ring in the

position, low

beams will always be on when the ignition is in
the II position.

Tunnel detection

The vehicle will detect if it enters a tunnel and
shift from daytime running lights to low beams.

Note that the left-hand steering wheel lever must
be in

position for tunnel detection to work.

Related information

•

•

Daytime running lights (p. 153)

•

Using high beam

High beam is operated via the left-hand steering
wheel lever. High beam is the vehicle's strongest
lighting and should be used when driving in dark
conditions, provided it does not blind other road
users, to improve visibility.

Steering wheel lever with lighting ring.

High beam flash

Move the steering wheel lever slightly back-
ward to the high beam flash mode. The high
beams will illuminate until the lever is
released.

LIGHTING

}}

* Option/accessory.

155

High beams

The high beams can be activated when the
lighting ring is in mode

Activate high beams by moving the steering
wheel lever forward. Deactivate by moving
the steering wheel lever backward.

When the high beams are activated, the
symbol will be illuminated in the instrument panel.

Related information

•

Active high beam (p. 155)

•

Active high beam

Active high beams is a function that uses cam-
era sensors in the upper edge of the windshield
to detect the headlights of approaching vehicles
or the taillights of the vehicle directly ahead.
When either of these is detected, the vehicle's
headlights will automatically switch from high
beams to low beams.

Active high beam is enabled by moving the lighting ring
on the steering wheel lever to

The function can also detect street lighting.
When the camera sensor no longer detects an
approaching vehicle or a vehicle ahead, the head-
lights will return to high beams.

This function can be used in dark conditions
when the vehicle's speed is approx. 20 km/h
(approx. 12 mph) or higher.

If active high beams are deactivated when the
high beams are on, the headlights will automati-
cally switch to low beams.

When active high beams are activated, a white

symbol will be displayed in the instrument

panel.

When high beams are on, the symbol will be blue.
For LED headlights, this applies even if the high
beams are partially dimmed, i.e. if the headlights
are illuminated with slightly more than low beams.

Vehicles with LED

headlights*

If the active high beams are equipped with the
auto on/off function

, the headlights will return to

high beams a second or so after the camera sen-
sor no longer detects the headlights of approach-
ing vehicles or the taillights of a vehicle ahead.

When the low beams are on.

LED (Light Emitting Diode)

Depends on the vehicle's equipment level.

LIGHTING

156

Limitations for active high beams

The camera sensor on which the function is
based has limitations.

If this symbol and the message

Active

High Beam

Temporarily

unavailable

is displayed in the instru-

ment panel, switching between high

and low beams must be done manually. The light-
ing ring on the steering wheel lever can remain in
the

position. The

symbol will go out

when the message is displayed.

The same applies if this symbol along
with the message

Windscreen

sensor

Sensor blocked, see

Owner's manual

is displayed.

Active high beams may be temporarily unavailable
in certain situations, e.g. heavy fog or rain. When
active high beams become available again, or the
windshield sensors are no longer blocked, the
message will disappear and the

symbol will

be displayed.

WARNING

Automatic high beam is an aid in using the

best possible light based on prevailing condi-

tions.
The driver is always responsible for manually

switching between high and low beam when

traffic situations or weather conditions require

this.

Related information

•

Camera limitations (p. 332)

•

Using high beam (p. 154)

•

Using turn signals

The vehicle's turn signals are controlled using
the left-side steering wheel lever. The turn sig-
nals flash three times or continuously, depend-
ing on how far up or down the lever is moved.

Turn signals.

Triple flash indicator

Move the steering wheel lever up or down to
the first position and release. The turn sig-
nals will flash three times. If the function is
deactivated via the center display, the signals
will flash once.

LIGHTING

* Option/accessory.

157

Hazard warning flashers (p. 160)

•

This automatic flashing sequence can be
interrupted by immediately moving the
lever in the opposite direction.

•

If the turn signal indicator flashes more
quickly than normal, refer to the message
in the instrument panel.

Continuous flashing sequence

Move the lever up or down as far as possible.

The lever will stop in its end position and can be
moved back manually or automatically by moving
the steering wheel.

Related information

•

•

Adjusting light functions via the center dis-
play (p. 151)

Active Bending Lights*

Active Bending Lights (ABL) are designed to
help provide maximum illumination in curves and
intersections. Depending on equipment level,
vehicles with LED

headlights* may be equipped

with Active Bending Lights.

Headlight pattern with function deactivated (left) and
activated (right).

Active Bending Lights follow the movement of
the steering wheel to help provide maximum illu-
mination in curves and intersections, helping to
improve visibility for the driver.

The function is automatically activated when the
engine is started. If a fault is detected in the sys-
tem, the

symbol will illuminate in the

instrument panel and a message will be dis-
played.

The function is only active in weak daylight or
dark conditions and only when the vehicle is mov-
ing and the low beams are on.

Deactivating/activating the function

The function is activated as the default factory
setting and can be activated and deactivated in
the center display's Function view:

Tap the

Active Bending

Lights

button.

Related information

•

Adjusting light functions via the center dis-
play (p. 151)

•

Front fog lights/cornering illumination*
(p. 158)

LED (Light Emitting Diode)

LIGHTING

* Option/accessory.

158

Front fog lights/cornering

illumination*

The front fog lights have a stronger beam than
low beam, making them particularly effective in
fog.

Front fog lights button.

The front fog lights can be turned on when the
ignition is in mode II and the lighting ring is in
position

Tap the button to activate or deactivate the func-
tion. The

symbol in the instrument panel

comes on when the front fog lights are on.

The front fog lights turn off automatically when
the ignition is switched off or when the lighting
ring is in position

Regulations concerning fog light use vary
from country to country.

Cornering illumination*

The front fog lamps can include the cornering
lights function, which temporarily illuminates the
area diagonally in front of the car in the direction
the steering wheel is turned on a sharp bend, or
in the direction shown by the direction indicators.

The function is activated in weak daylight or dark
conditions when the lighting ring is in

mode and the vehicle speed is less than

about 30 km/h (about 20 mph).

Both cornering illumination are also illuminated
as a complement to the taillights when reversing.

The function is activated as the default factory
setting and can be activated and deactivated
using the center display.

Related information

•

•

Active Bending Lights* (p. 157)

•

Rear fog light (p. 158)

•

•

Adjusting light functions via the center dis-
play (p. 151)

Rear fog light

The rear fog light is considerably brighter than
ordinary taillights and should only be used to
help other road users see the vehicle when visi-
bility is reduced by conditions such as fog,
snow, smoke or dust.

Rear fog light button.

The rear fog light consists of a light on the rear
of the vehicle on the driver's side.

The rear fog light can only be used when:

•

ignition mode II is active and the lighting ring
is in position

•

the lighting ring is in the

position and

the front fog lights are on.

Press the button for On/Off. The

symbol in

the instrument panel illuminates when the rear
fog light is on.

LIGHTING

* Option/accessory.

159

The rear fog light turns off automatically when:

•

the ignition is off or the lighting ring is in the

position.

•

the lighting ring is in the

position and

the front fog lights are turned off.

Regulations concerning rear fog light use vary
from country to country.

Related information

•

Front fog lights/cornering illumination*
(p. 158)

•

•

Emergency brake lights (p. 159)

Brake lights

The brake lights are automatically illuminated
when braking.

The brake lights illuminate when the brake pedal
is depressed. They also illuminate when the
brakes are automatically applied by one of the
driver support systems.

Related information

•

•

Brake functions (p. 412)

Emergency brake lights

The emergency brake lights are activated to
warn following vehicles of hard braking.

This function causes an additional taillight on
each side of the vehicle to illuminate.

The emergency brake lights are activated in the
event of hard braking or if the ABS system is
activated and the vehicle is traveling at a high
speed.

After the driver decelerates to a low speed and
then releases the brake, the brake lights resume
their normal brightness.

Related information

•

Brake lights (p. 159)

•

Brakes (p. 412)

•

Hazard warning flashers (p. 160)

LIGHTING

* Option/accessory.

160

Hazard warning flashers

Hazard warning flashers warn other road users
by all of the vehicle's turn signals being activated
at the same time. The function can be used to
warn about a traffic hazard.

Hazard warning flashers button.

Press the button to activate the hazard warning
flashers.

Emergency brake lights (p. 159)

Regulations concerning the use of hazard
warning flashers may vary from country to
country.

Related information

•

•

Using turn signals (p. 156)

Using home safe lighting

Some of the exterior lights remain on to illumi-
nate the area around the vehicle. This is called
home safe lighting.

To activate home safe lighting:

1. Switch off the ignition.

2. Push the left-side steering wheel lever

toward the dashboard and release.

3. Exit the vehicle and lock the doors.

When the function is activated, a symbol will be
shown in the instrument panel and the parking
lights, outer door handle lights* and the license
plate lights will be illuminated.

The length of time home safe lighting remains
illuminated can be set in the center display.

Related information

•

Adjusting light functions via the center dis-
play (p. 151)

•

Welcome Light (p. 160)

Welcome Light

Approach lighting is activated when the vehicle
is unlocked and can be used to provide light as
you walk toward the vehicle.

The function is activated when the remote key is
used for unlocking. The parking lights, outer door
handle lights*, license plate lights, interior ceiling
lights, footwell lighting and trunk/cargo compart-
ment lighting will be illuminated. If a door is
opened while the function is activated, the light-
ing in the outer door handle* and the interior
lighting will remain illuminated for a longer period
of time.

This function can be activated and deactivated in
the center display.

Related information

•

Adjusting light functions via the center dis-
play (p. 151)

•

Using home safe lighting (p. 160)

•

Remote key (p. 237)

LIGHTING

}}

* Option/accessory.

161

Interior Lighting

The interior is equipped with several different
types of lighting to improve the experience. This
includes reading lamps, glove box lighting and
ground lighting.

All lighting in the passenger compartment can be
turned on and off manually within 5 minutes
after:

•

the engine has been switched off and the
ignition is in mode 0.

•

the vehicle is unlocked but the engine has
not been started.

Front ceiling lighting

The controls in the ceiling console for the front reading
lights and courtesy lighting.

Reading light left side

Passenger compartment lighting

Courtesy lighting auto switch

Reading light right side

Reading lights

The reading lights on the right and left sides are
switched on and off by briefly pressing the but-
tons in the ceiling console. To adjust the bright-
ness, press and hold the button.

Passenger compartment lighting

Briefly press the button in the ceiling console to
switch on or off the footwell lighting and ceiling
lighting.

Courtesy lighting auto switch

Activate the auto switch by briefly pressing the
AUTO button in the ceiling console. With Auto
activated, the indicator light in the button and the
courtesy lighting come on and are turned off as
follows.

The courtesy lighting:

•

comes on when the vehicle is unlocked and
when the ignition is switched off

•

goes off when the engine is started and
when the vehicle is locked

•

comes on or goes off when a side door is
opened or closed

•

remains on for 2 minutes if any of the side
doors are open.

Rear roof lighting

Reading lights are located in the rear section of
the vehicle and can also be used as passenger
compartment lighting.

Reading lights over the rear seat.

In vehicles with panoramic roofs*, there are two lamp
units, one on each side of the ceiling.

LIGHTING

* Option/accessory.

162

Briefly press the button on the light to turn on or
off the reading lights. To adjust the brightness,
press and hold the button.

Glove compartment lighting

The glove compartment lighting comes on or
goes off when the glove compartment is opened
or closed.

Vanity mirror lighting*

The vanity mirror lighting comes on or goes off
when the cover over the mirror is opened or
closed.

Ground lighting*

The ground lighting comes on or goes off when a
door is opened or closed.

Cargo compartment lighting

The cargo compartment lighting comes on or
goes off when the cargo compartment is opened
or closed.

Ambient Lighting

The ambient lighting comes on when the doors
are opened and goes out when the vehicle is
locked. Ambient lighting brightness can be
adjusted in the center display and also fine-tuned
using the thumb wheel in the dashboard.

Mood lighting*

The vehicle is equipped with LEDs that provide
faint lighting in various colors. This lighting is on
when the engine is running. Mood lighting can be

adjusted in the center display and also fine-tuned
using the thumb wheel in the dashboard.

Lighting in the door storage
compartments

Lighting in the door storage compartments
comes on when the doors are opened and goes
out when the vehicle is locked. The brightness
can be adjusted using the thumb wheel in the
dashboard.

Lighting in the tunnel console's front
cup holder

The lighting in front console cup holders
switches on when the vehicle is unlocked and off
when the vehicle is locked. The brightness can
be adjusted using the thumb wheel in the dash-
board.

Related information

•

Adjusting interior lighting (p. 162)

•

•

Passenger compartment interior (p. 558)

•

Adjusting interior lighting

Illumination in the vehicle varies depending on
ignition mode. The interior lighting can be
adjusted with a thumb wheel in the dashboard
and certain light functions can also be adjusted
via the center display.

The thumb wheel on the dash-
board to the left of the steering
wheel can be used to adjust
the brightness of the display
lighting, instrument lights,
ambient lighting and mood
lighting*.

Adjust ambient decor lighting

1. Tap

Settings

in the Top view in the center

display.

2. Tap

My Car

Lights and Lighting

Interior Lighting

3. Choose from among the following settings:

•

Under

Ambient Light Intensity

, select

Off

Low

High

•

Under

Ambient Light Level

, select

Reduced

Full

Adjusting mood lighting*

The vehicle is equipped with several LEDs that
provide faint lighting in various colors. This light-
ing is on when the engine is running.

LIGHTING

163

Changing the brightness

1. Tap

Settings

in the Top view in the center

display.

2. Tap

My Car

Lights and Lighting

Interior Lighting

Interior Mood Lighting

3. Under

Interior Mood Light Intensity

, select

Off

Low

High

Changing the color of the light

1. Tap

Settings

in the Top view in the center

display.

2. Tap

My Car

Lights and Lighting

Interior Lighting

Interior Mood Lighting

3. Choose

By Temperature

By Color

change the color of the light.

By Temperature

is selected, the light will

change according to the temperature set for
the passenger compartment.

By Color

is selected, the subcategory

Theme Colors

can be used to make further

adjustments.

Related information

•

Interior Lighting (p. 161)

•

Adjusting light functions via the center dis-
play (p. 151)

•

Pinch protection for windows and sun cur-
tains (p. 166)

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

166

Windows, glass and mirrors

The vehicle is equipped with controls for win-
dows, glass and mirrors. Some of the windows
in the car are laminated.

Laminated glass

The windshield has laminated glass. Laminated
glass is also available as on option for some
other glass surfaces. Laminated glass is rein-
forced, which provides better protection against
break-ins and improved soundproofing in the
passenger compartment.

The panoramic roof* also has laminated glass.

The symbol shows the windows containing laminated
glass

Related information

•

•

Panoramic roof* (p. 172)

•

Power windows (p. 167)

•

Rearview/door mirrors (p. 169)

•

Head-up display* (p. 140)

•

Using the windshield wipers (p. 176)

•

Using the windshield and headlight washers
(p. 179)

•

Activating and deactivating the heated wind-
shield* (p. 221)

•

Activating and deactivating the heated rear
window and door mirrors (p. 222)

Pinch protection for windows and

sun curtains

All power windows and sun curtains* have a
pinch protection function that is triggered if any-
thing blocks them while they are opening or
closing.

If pinch protection is activated, movement will
stop and then retract automatically to approx.
50 mm (2 inches) from the point at which it was
blocked (or to full ventilation position).

It is still possible to override pinch protection
when closing is interrupted (e.g. due to ice) by
pressing and holding down the control in the
same direction.

If there is any problem with the pinch protection,
a rest procedure can be tested.

WARNING

If the starter battery is disconnected, the func-

tion for automatic opening and closing must

be reset to function correctly. A reset is

required in order for the pinch protection to

work.

Does not apply to windshield and panoramic roof*, which are always laminated and therefore do not have this symbol.

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

167

Related information

•

Reset procedure for pinch protection
(p. 167)

•

Operating the power windows (p. 168)

•

Panoramic roof* (p. 172)

Reset procedure for pinch

protection

If you experience any problems with the electri-
cal functions for the power windows, you can try
to perform a reset.

WARNING

If the starter battery is disconnected, the func-

tion for automatic opening and closing must

be reset to function correctly. A reset is

required in order for the pinch protection to

work.

If the problem persists or if it affects the panor-
amic roof or sunroof, contact a workshop

Resetting a power window

1. Start with the window in the closed position.

2. Then operate the window in manual mode

three times upward toward the closed posi-
tion.
> The system will be automatically initiated.

Related information

•

Pinch protection for windows and sun cur-
tains (p. 166)

•

Operating the power windows (p. 168)

Power windows

The power windows are operated using the con-
trol panels found in the doors. The driver's door
has controls for operating all windows and for
activating the child safety locks.

Driver's door control panel.

Electric child safety locks* that deactivate the
controls in the rear doors to prevent the
doors or windows from being opened from
the inside.
Rear window controls.

Front window controls.

The power windows have pinch protection. If
there is any problem with the pinch protection, a
rest procedure can be tested.

An authorized Volvo workshop is recommended.

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

168

WARNING

Children, other passengers or objects can be

trapped by the moving parts.

•

Always operate the windows with caution.

•

Do not allow children to play with the
operating controls.

•

Never leave a child alone in the vehicle.

•

Remember to always cut the current to
the power windows by setting the vehi-
cle's electrical system to ignition mode 0
and then taking the remote key with you
when leaving the vehicle.

•

Never stick objects or body parts out
through the windows, even if the vehicle
electrical system is completely turned off.

Related information

•

Operating the power windows (p. 168)

•

Pinch protection for windows and sun cur-
tains (p. 166)

•

Reset procedure for pinch protection
(p. 167)

Operating the power windows

All power windows can be operated using the
control panel in the driver's door. The control
panels in the other doors can be used to oper-
ate that particular door.

The power windows have pinch protection. If
there is any problem with the pinch protection, a
rest procedure can be tested.

WARNING

Children, other passengers or objects can be

trapped by the moving parts.

•

Always operate the windows with caution.

•

Do not allow children to play with the
operating controls.

•

Never leave a child alone in the vehicle.

•

Remember to always cut the current to
the power windows by setting the vehi-
cle's electrical system to ignition mode 0
and then taking the remote key with you
when leaving the vehicle.

•

Never stick objects or body parts out
through the windows, even if the vehicle
electrical system is completely turned off.

Operating the power windows.

Operating manually. Move one of the controls
slightly up or down. The power windows go
up or down while the control is held in posi-
tion.
Operating with automatic controls. Move one
of the controls up or down to its end position
and release it. The window moves automati-
cally to its fully closed/open position.

To use the power windows, the ignition must be
in at least mode I or II. After the ignition has
been switched off, the power windows can be
operated for several minutes or until a door is
opened. Only one control panel can be operated
at a time.

It can also be operated using keyless opening*
with the door handle.

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

169

WARNING

Make sure that no child or other passenger

comes into contact with the windows as they

are closing with keyless closing*.

One way to reduce the pulsating wind noise
heard when the rear windows are open is to
also open the front windows slightly.
