Volvo V60 Plug-in Hybrid (2015 year). Instruction - part 19

fied in the tyre pressure table, see Tyres -

•

Check the tyre pressure when the

tyres are cold. "Cold tyres" means that

the tyres are at the same temperature

as the outdoor temperature. The tyres

will heat up and the tyre pressures will

increase after driving for a few kilome-

tres.

•

Tyre pressures which are too low will

increase fuel consumption, reduce tyre

service life and impair the car's han-

dling. Driving with tyre pressures

which are too low may lead to the

tyres overheating and sustaining dam-

age. Tyre pressures affect ride com-

fort, road noise and steering.

•

Tyre pressure decreases over time,

this is a natural phenomenon. Tyre

pressure also varies depending on

ambient temperature.

Tyre pressure label

G021830

The tyre pressure label on the driver side's

door pillar (between frame and rear door)

shows the tyre pressures for the car's recom-

mended tyre dimensions. This is also speci-

approved tyre pressures (p. 408).

Related information

•

Tyres - speed ratings (p. 318)

•

•

Tyres - load index (p. 317)

•

Tyres - maintenance (p. 313)

•

Tyres - tread wear indicators (p. 315)

Wheel and wheel rim dimensions

Wheel and rim dimensions are designated in

accordance with the examples in the table

below.

The car has an approval for the complete

vehicle. This means that certain combinations

of wheel (wheel rim) and tyre are approved.
Wheels (rims) have a designation of dimen-

sions, for example: 7Jx16x50.

Rim width in inches

Rim flange profile

16 Rim diameter in inches

50 Off-set in mm (distance from wheel

centre to wheel contact surface

against the hub)

Related information

•

Tyres - approved tyre pressures (p. 408)

•

Only 17" wheel Thia

09 Wheels and tyres

317

Tyres - dimensions

The car's wheels (wheel rims) and tyres have

a certain dimension, see the examples in the

table below.

The car has an approval for the complete

vehicle. This means that certain combinations

of wheels (wheel rims) and tyres are

approved.
The dimensions are stated on all car tyres.

Example of designation:235/45R17 97W.

235 Tyre width (mm)

Ratio between tyre wall height and

tyre width (%)

Radial ply

Rim diameter in inches (")

Codes for the maximum permitted

tyre load, tyre load index (LI)

Speed rating for maximum permitted

speed, speed rating (SS). (In this

case 270 km/h.)

Related information

•

Tyres - speed ratings (p. 318)

•

Tyres - load index (p. 317)

•

Tyres - direction of rotation (p. 314)

•

Tyres - maintenance (p. 313)

•

Tyres - approved tyre pressures (p. 408)

•

Wheel and wheel rim dimensions (p. 316)

Tyres - load index

Load index indicates a tyre's ability to carry a

certain load.

Each tyre has a certain capacity to carry a

load, a load index (LI). The car's weight deter-

mines the load capacity required of the tyres.

Minimum permissible index is indicated in the

load index table.

Related information

•

Tyres - approved tyre pressures (p. 408)

•

•

Tyres - speed ratings (p. 318)

•

Tyres - maintenance (p. 313)

09 Wheels and tyres

318

Option/accessory, for more information, see Introduction.

Tyres - speed ratings

Each tyre can withstand a certain maximum

speed and therefore belongs to a particular

speed rating (SS - Speed Symbol).

Tyre speed class must at least correspond

with the car's top speed. Minimum speed rat-

ing is indicated in the speed rating table

below. The only exception to these regula-
tions is the winter tyre (p. 319)

, where a

lower speed rating may be used. If such a

tyre is chosen, the car must not be driven

faster than the speed rating of the tyre (for

example, class Q can be driven at a maxi-

mum of 160 km/h). Traffic regulations deter-

mine how fast a car can be driven, not the

speed rating of the tyres.

have the same or a higher load index

The maximum permitted speed is speci-

fied in the table.

160 km/h (used only on winter tyres)

190 km/h

210 km/h

240 km/h

270 km/h

300 km/h

WARNING

The car must be fitted with tyres which

(p. 317) (LI) and speed rating (SS) than

specified. If a tyre with too low a load

index or speed rating is used, it may over-

heat.

Related information

•

Tyres - load index (p. 317)

•

•

Tyres - direction of rotation (p. 314)

Wheel bolts

Wheel bolts are used to fasten the wheels at

the hubs and are available in different ver-

sions.

Wheel and wheel rim dimensions (p. 316)

The wheel bolts must be tightened to 140

Nm. Overtightening can damage the nuts

and the bolts.

Only use rims that are tested and approved

by Volvo and which are Volvo genuine acces-

sories. Check the torque with a torque

wrench.

Locking wheel bolts*
Locking wheel bolts* can be used on both

aluminium and steel rims.

Related information

•

Both metal-studded and studless tyres.

09 Wheels and tyres

}}

Option/accessory, for more information, see Introduction.

319

Winter tyres

Winter tyres are tyres that are adapted for

winter road conditions.

Winter tyres
Volvo recommends winter tyres with particu-

lar dimensions. Tyre dimensions are depend-

ent on engine variant. When driving on winter

tyres, the correct type of tyres must be fitted

to all four wheels.

Volvo recommends that you consult a

Volvo dealer about which wheel rim and

tyre types are most suitable.

Studded tyres
Studded winter tyres should be run in gently

for 500-1000 km so the studs settle properly

into the tyres. This gives the tyre, and espe-

cially the studs, a longer service life.

Changing wheels - removing wheels

The legal provisions for the use of studded

tyres vary from country to country.

Tread depth
Road conditions with ice, slush and low tem-

peratures place considerably higher demands

on tyres than summer conditions. Volvo

therefore recommends not to drive on winter

tyres that have a tread depth of less than

4 mm.

Using snow chains
Snow chains may only be used on the front

wheels (also applies to all-wheel drive cars).

Never drive faster than 50 km/h with snow

chains. Avoid driving on bare ground as this

wears out both the snow chains and tyres.

WARNING

Use Volvo genuine snow chains or equiva-

lent chains designed for the car model,

and tyre and rim dimensions. In the event

of uncertainty Volvo recommends that you

consult an authorised Volvo workshop.

The wrong snow chains may cause serious

damage to your car and lead to an acci-

dent.

Related information

•

(p. 319)

Changing wheels - removing wheels

The car's wheels can be changed for e.g. win-

ter wheels/winter tyres.

Spare wheel*
The following instructions only apply if a

spare wheel has been purchased as an

accessory for the car. If the car is not equip-

ped with a spare wheel - see information

about Emergency puncture repair (TMK)

(p. 330).
The spare wheel (Temporary spare) is only

intended for use temporarily and must be

replaced by an ordinary wheel as soon as

possible. The car's handling may be altered

by the use of the spare wheel. The spare

wheel is smaller than the normal wheel. The

car's ground clearance is affected accord-

ingly. Pay attention to high kerbs and do not

machine wash the car. If the spare wheel is

fitted on the front axle, you cannot use snow

chains at the same time. On all-wheel drive

cars the drive on the rear axle can be discon-

nected. The spare wheel must not be

repaired.
The correct tyre pressure for the spare wheel

is stated in the tyre pressure table (p. 408).

09 Wheels and tyres

320

Option/accessory, for more information, see Introduction.

selected, see Raising the car (p. 348).

•

Never drive faster than 80 km/h with a

spare wheel on the car.

•

The car must never be driven fitted

with more than one "Temporary

Spare" wheel.

The spare wheel is supplied in a bag which

must be secured on the cargo area floor

using straps.

Cars with four load retaining eyelets.

Turn the handle on the spare wheel bag out

towards you. Attach the sewn-in tensioning

strap hooks in the front load retaining eyelets.

Attach the long strap into one of the front

load retaining eyelets, run the strap diagonally

over the spare wheel and through the upper

handle. Tighten the short tensioning strap

onto the long one. Attach the rear load retain-

ing eyelet and tighten.

Before changing a wheel
1. Loosen the straps, lift out the spare wheel

from the cargo area and remove it from

the spare wheel bag.

2. To access the towing eye, open the hatch

on the left-hand side of the cargo area.

3. Take out the jack*, tool to remove the

plastic caps on the wheel bolts and the

wheel wrench* (located in a bag on the

cargo area floor). If another jack is

Tool for removing the plastic caps on the wheel

bolts.

WARNING

Check that the jack is not damaged, that

the threads are thoroughly lubricated and

that it is free from dirt.

•

If the car is not equipped with the

accessory spare wheel then the jack

need not be stored in the car.

•

Volvo recommends only using the jack*

that belongs to the car model in ques-

09 Wheels and tyres

}}

Option/accessory, for more information, see Introduction.

321

tion, which is indicated on the jack's

label.

•

The decal also indicates the jack's

maximum lift capacity at a specified lift-

ing height.

4. Set up the warning triangle (p. 323) if a

The car's regular jack is designed only for

use occasionally and for a short time, such

as when changing a wheel with a punc-

tured tyre, switching between summer

tyres and winter tyres, etc. Only the jack

belonging to the specific model is to be

used to jack up the car. If the car is to be

jacked up more often, or for a longer time

than is required just to change a wheel,

use of a garage jack is recommended. In

this instance, follow the instructions for

use that come with the equipment.

wheel is replaced in a trafficked location.

The car and jack* must be on a firm hori-

zontal surface.

Removing
1. Apply the parking brake (p. 278) and

engage reverse gear, or position P if the

car has an automatic gearbox.

2. Place chocks in front of and behind the

wheels which will remain on the ground to

prevent them from rolling. Use heavy

wooden blocks or large stones for exam-

ple.

3. Screw together the towing eye with the

wheel wrench* until the stop position in

accordance with the following figure.

The towing eye must be screwed into all

threads in the wheel bolt wrench.

4. Remove the plastic caps from the wheel

bolts with the intended tool.

5. Loosen the wheel bolts ½-1 turn anti-

clockwise with the wheel wrench.

WARNING

Never position anything between the

ground and the jack, nor between the jack

and the car's jacking point.

6. There are two jacking points on each side

of the car. There is a recess in the plastic

cover at each point. Crank the foot of the

jack down so it is pressed squarely on the

ground.

Changing wheels - fitting (p. 322)

The ground must be firm, smooth and

level.

7. Lift the car so that the wheel is free.

Remove the wheel bolts and lift off the

wheel.

09 Wheels and tyres

322

Option/accessory, for more information, see Introduction.

WARNING

Never crawl under the car when it is raised

on the jack.
Passengers must leave the car when it is

raised on the jack. If a wheel must be

changed in a trafficked environment, pas-

sengers must stand in a safe place.

Related information

•

•

Jack* (p. 324)

•

Warning triangle (p. 323)

•

Wheel bolts (p. 318)

Changing wheels - fitting

It is important that the procedure for fitting

the wheel is carried out correctly.

Installation
1. Clean the contact surfaces between

wheel and hub.

2. Put on the wheel. Tighten the wheel bolts

thoroughly.

3. Lower the car so that the wheels cannot

rotate.

4. Tighten the wheel bolts crosswise. It is

important that the wheel bolts are tight-

ened properly. Tighten to 140 Nm. Check

the torque with a torque wrench.

The white arrow must point toward the front of

the car.

5. Screw apart the towing eye and the wheel

bolt wrench. Place the wheel bolt wrench

and the jack in their respective compart-

ments in the bag. Tighten the bag's cen-

tre strap firmly and use the other strap to

secure the bag in the rear load retaining

eyelet on the left-hand side of the cargo

area. Position the bag so it is not pinched

when the tailgate is closed. The white

arrow on the bag must point toward the

front of the car.

09 Wheels and tyres

Option/accessory, for more information, see Introduction.

323

Changing wheels - removing wheels

•

After a tyre has been inflated, always

refit the dust cap in order to avoid

damage to the valve from gravel, dirt,

etc.

•

Only use plastic dust caps. Metal dust

caps can rust and become difficult to

unscrew.

WARNING

The bag should be secured so that the

white arrow (see the inset figure) points

forward in the car.

Related information

•

(p. 319)

•

Jack* (p. 324)

•

Warning triangle (p. 323)

•

Wheel bolts (p. 318)

Warning triangle

The warning triangle is used to warn other

road users of a stationary vehicle.

Storage and folding up

Lift the floor hatch and take out the warn-

ing triangle.
Take the warning triangle from the case,

fold out and assemble the two loose

sides.
Fold out the warning triangle's support

legs.

Follow the regulations for the use of a warn-

ing triangle. Position the warning triangle in a

suitable place with regard to traffic.
Ensure the warning triangle and its case are

properly secured in the cargo area after use.

hatch cannot be opened, see Privacy lock-

If the car has been locked with privacy

locking then the boot lid/tailgate and floor

ing* (p. 168).

09 Wheels and tyres

324

Option/accessory, for more information, see Introduction.

Tools

Amongst other things, the car contains towing

eye, jack* and wheel bolt wrench*.

The car's towing eye and emergency punc-

ture repair kit are located behind the hatch on

the left-hand side of the cargo area. There is

also space for the sleeve for the lockable

wheel bolts. Jack* and wheel bolt wrench* are

located in a bag on the cargo area floor.
If the car is not equipped with the accessory

spare wheel then the jack need not be stored

in the car.

WARNING

When the towing eye and emergency

puncture repair kit are stored in the foam

block, they must always be strapped in

with the tensioning strap.

Related information

•

Emergency puncture repair (p. 330)

•

Towing eye (p. 310)

•

Changing wheels - removing wheels

(p. 319)

•

Wheel bolts (p. 318)

•

Jack* (p. 324)

Jack*

A jack is used to raise the car, e.g. when

changing the tyres.

The original jack should only be used for

changing to the spare wheel. The jack's

thread must always be well greased.

Tools - returning into place

The white arrow must point toward the front of

the car.

After use, crank the jack together and screw

apart the towing eye and wheel bolt wrench.

Place the wheel bolt wrench and the jack in

their respective compartments in the bag.

Tighten the bag's centre strap firmly and use

the other strap to secure the bag in the rear

load retaining eyelet on the left-hand side of

the cargo area. Position the bag so it is not

pinched when the tailgate is closed. The

white arrow on the bag must point toward the

09 Wheels and tyres

Option/accessory, for more information, see Introduction.

325

front of the car. Refit the towing eye in the

foam block on the left-hand side of the cargo

area.

WARNING

The bag should be secured so that the

white arrow (see the inset figure) points

forward in the car.

Warning triangle (p. 323)

If the floor hatch in the cargo area floor is

not closed then privacy locking does not

work.

Related information

•

•

Emergency puncture repair (p. 330)

First aid kit*

The first aid box contains first aid equipment.

A case with first aid equipment is located

under the floor in the cargo area.

hatch cannot be opened, see Privacy lock-

If the car has been locked with privacy

locking then the boot lid/tailgate and floor

ing* (p. 168).

Tyre pressure monitoring*

Tyre pressure monitoring warns the driver

when the pressure is too low in one or more

of the car's tyres. For certain markets the tyre

pressure monitoring is standard in accord-

ance with legal requirements.

The system does not replace normal tyre

maintenance.

Related information

•

Tyre pressure monitoring system (TPMS)*

- general (p. 326)

•

Tyre pressure monitoring (TPMS)* - adjust

(recalibration) (p. 327)

•

Tyre pressure monitoring (TPMS)* - recti-

fying low tyre pressure (p. 330)

•

Tyre pressure monitoring (TPMS)* - acti-

vate/deactivate (p. 328)

•

Tyre pressure monitoring (TPMS)* - rec-

ommendations (p. 329)

•

Tyre pressure monitoring (TPMS)* - drive-

able punctured tyres* (p. 329)

Standard in certain markets.

09 Wheels and tyres

326

Option/accessory, for more information, see Introduction.

Tyre pressure monitoring system
(TPMS)*

- general

Tyre pressure monitoring (TPMS) (Tyre

Pressure Monitoring System)* warns the

driver when the pressure is too low in one or

more of the car's tyres.

Tyre pressure monitoring uses sensors

located inside the air valve in each wheel.

When the car is driven at about 30 km/h the

system detects the tyre pressure. If the pres-
sure is too low then a warning lamp

illumi-

nates in the combined instrument panel and

one of the following messages is shown:

•

Tyre pressure low Check front right

tyre

•

Tyre pressure low Check front left

tyre

•

Tyre pressure low Check rear right

tyre

•

Tyre pressure low Check rear left tyre

•

Tyre needs air now Check front right

tyre

•

Tyre needs air now Check front left

tyre

•

Tyre needs air now Check rear right

tyre

•

Tyre needs air now Check rear left

tyre

•

Tyre pressure system Service

required

Both factory-fitted and optional wheels can

be equipped with TPMS sensors in the

valves.
If wheels without TPMS sensors are used or if

a sensor has failed then

Tyre pressure

system Service required

will be shown.

Always check the system after changing a

wheel in order to ensure that replacement

wheels work with the system.
For information on the correct tyre pressure,

see Tyres - air pressure (p. 315).
The system does not replace normal tyre

maintenance.

Tyre pressure monitoring (TPMS)* - adjust

If a fault occurs in the TPMS system the
warning lamp

in the combined instru-

ment panel will flash for approx. 1 minute

and then illuminate with a constant glow. A

message is also shown in the combined

instrument panel.

Related information

•

(recalibration) (p. 327)

•

Tyre pressure monitoring (TPMS)* - recti-

fying low tyre pressure (p. 330)

•

Tyre pressure monitoring (TPMS)* - acti-

vate/deactivate (p. 328)

•

Tyre pressure monitoring (TPMS)* - rec-

ommendations (p. 329)

•

Tyre pressure monitoring (TPMS)* - drive-

able punctured tyres* (p. 329)

Standard in certain markets.

09 Wheels and tyres

}}

Option/accessory, for more information, see Introduction.

327

Tyre pressure monitoring (TPMS)*

adjust (recalibration)

Tyre pressure monitoring (TPMS) (Tyre

Pressure Monitoring System)* warns the

driver when the pressure is too low in one or

more of the car's tyres.

TPMS can be adjusted in order to follow Vol-

vo's tyre pressure recommendations (p. 315),

such as when driving with a heavy load, for

example.

The car must be stationary when calibra-

tion is started.

Settings are made using the centre console's

controls, see MY CAR (p. 113).
1. Inflate the tyres to the desired pressure in

accordance with the tyre pressure label

on the driver's side door pillar (between

front and rear doors).

2. Start the engine.
3. Select the menu system MY CAR to open

the menus for tyre pressure.

4. Select

Calibrate tyre pressure

and

press OK.

5. Drive for at least 10 minutes at a speed of

at least 30 km/h.
> Calibration is performed automatically

following initialisation by the driver.

The system provides no confirmation

when the calibration is complete.

The new reference values apply until steps

1-5 are carried out again.

Related information

•

Tyres - air pressure (p. 315)

•

Tyre pressure monitoring system
(TPMS)*

- status

Tyre pressure monitoring (TPMS) (Tyre

Pressure Monitoring System)* warns the

driver when the pressure is too low in one or

more of the car's tyres.

System and tyre status
The current status of the system and the tyres

can be checked, see MY CAR (p. 113).
1. Select the menu system MY CAR to open

the menus for tyre monitoring.

2. Select

Tyre pressure

The status is colour-coded for each tyre in

accordance with the following:

•

All-green: the system is operating nor-

mally and the tyre pressure in all tyres is

slightly above the recommended level.

•

Yellow wheel: corresponding tyre's pres-

sure is too low.

•

Red wheel: corresponding tyre's pressure

is very low.

•

All wheels grey: the system is temporarily

unavailable. It may be necessary to drive

the car for a few minutes at a speed

above 30 km/h before the system

becomes active again.

•

All wheels grey and the message

Tyre

pressure system Service required

: an

Standard in certain markets.

09 Wheels and tyres

328

Option/accessory, for more information, see Introduction.

error has occurred in the system. Contact

a Volvo dealer or workshop.

Clearing warning messages
If a tyre pressure message has been shown

and the TPMS warning lamp has been illumi-

nated:
1. Check the tyre pressure on the indicated

tyre/tyres with a tyre pressure gauge.

2. Inflate the tyre/tyres to the correct pres-

sure in accordance with the tyre pressure

label on the driver's side door pillar

(between front and rear doors).

3. In some cases it may be necessary to

drive the car for a few minutes at a speed

above 30 km/h in order to clear the warn-

ing text. At which point, the TPMS warn-

ing lamp is extinguished as well.

•

The TPMS system uses a so-called

compensated pressure value, based

on both tyre temperature and ambient

temperature. This means that the tyre

pressure may differ slightly from the

recommended pressures listed on the

tyre pressure label on the driver's side

door pillar (between front and rear

doors). For this reason, it may be nec-

essary to inflate the tyres to a slightly

higher pressure in order to clear a low

tyre pressure message.

•

To avoid incorrect tyre pressure, the

pressure should be checked on cold

tyres. "Cold tyres" means the tyres are

the same temperature as the ambient

temperature (approx. 3 hours after the

car has been driven). After a few kilo-

metres of driving, the tyres warm up

and the pressure increases.

WARNING

•

Incorrect tyre pressure may lead to

tyre failure, which could result in the

driver losing control of the car.

•

The system cannot indicate sudden

tyre damage in advance.

Tyre pressure monitoring (TPMS)*

activate/deactivate

Tyre pressure monitoring (TPMS) (Tyre

Pressure Monitoring System)* warns the

driver when the pressure is too low in one or

more of the car's tyres.

The car must be stationary when the tyre

pressure monitoring is activated/deacti-

vated.

Settings are made using the centre console's

controls, see MY CAR (p. 113).
1. Start the engine.
2. Select the menu system MY CAR to open

the menus for tyre pressure.

3. Select

Tyre pressure

and press OK.

> An

is shown in the information dis-

play if the system is activated, the

option disappears if the system is
deactivated

Related information

•

Standard in certain markets.

Only in certain markets.

09 Wheels and tyres

}}

Option/accessory, for more information, see Introduction.

329

Tyre pressure monitoring (TPMS)*

recommendations

Tyre pressure monitoring (TPMS) (Tyre

Pressure Monitoring System)* warns the

driver when the pressure is too low in one or

more of the car's tyres.

•

Volvo recommends that TPMS sensors

are fitted to all wheels on the car, includ-

ing winter wheels.

•

Volvo recommends that sensors are not

moved between different wheels.

•

The spare wheel is not equipped a with

TPMS sensor.

•

If the spare wheel or a wheel without a

TPMS sensor is used, the error message

Tyre pressure system Service

required

will be shown in the combined

instrument panel.

•

If a wheel has been changed, or if the

TPMS sensor has been moved to another

wheel then the seal, nut and valve core

must be replaced.

•

When TPMS sensors are installed, the car

should be switched off for at least 15

minutes otherwise an error message will

be shown in the combined instrument

panel.

WARNING

When inflating a tyre equipped with TPMS,

hold the nozzle of the pump directly

against the valve to avoid damaging the

valve.

•

After a tyre has been inflated, always

refit the dust cap in order to avoid

damage to the valve from gravel, dirt,

etc.

•

Only use plastic dust caps. Metal dust

caps can rust and become difficult to

unscrew.

If you want to change the tyre dimension

then the TPMS system must be reconfig-

ured. For further information - contact a

Volvo dealer.

Related information

•

selected, the car is also equipped with TPMS

Tyre pressure monitoring (TPMS)*

driveable punctured tyres*

If SST (Self Supporting run flat Tires)* is

(p. 325).

This type of tyre has a specially reinforced

side wall that makes continued driving possi-

ble to a limited extent despite the tyre losing

all or some of its pressure. These tyres are fit-

ted on a special rim. (Normal tyres can also

be fitted to this rim.)
If an SST tyre loses tyre pressure then the

yellow TPMS lamp in the combined instru-

ment panel illuminates and a message is

shown in the information display. If this

occurs, reduce speed to max. 80 km/h. The

tyre must be replaced as soon as possible.
Drive carefully, in some cases it can be diffi-

cult to see which tyre is faulty. In order to

establish which tyre needs attention, check

all four tyres.

Standard in certain markets.

09 Wheels and tyres

330

Option/accessory, for more information, see Introduction.

WARNING

Only people with knowledge of SST tyres

should fit them.
SST tyres must only be fitted together with

TPMS.
After an error message about low tyre

pressure has been shown, do not drive

faster than 80 km/h.
Maximum mileage before tyre replacement

is 80 km.
Avoid hard driving such as sudden braking

or turning.
SST tyres must be replaced if they are

damaged or punctured.

Related information

•

Tyre pressure monitoring (TPMS)*

rectifying low tyre pressure

The tyre pressure monitoring system TPMS
(Tyre Pressure Monitoring System)

warns

the driver when the pressure is too low in one

or more of the car's tyres and indicates the

tyre to which it applies. The lamp illuminates

in yellow at the first indication, stop and

check the tyre pressure as soon as possible.

When the lamp illuminates in red you must

stop and rectify the tyre pressure immedi-

ately.

If a message for low tyre pressure is shown in

the display:
1. Check the tyre pressure on the tyre in

question.

2. Inflate the tyre(s) to the correct pressure.
3. Drive at least at 30 km/h for several

minutes and check that the message dis-

appears.

Related information

•

check and adjust the tyre pressure (p. 408).

Emergency puncture repair

Emergency puncture repair, where the emer-

gency puncture repair kit (TMK - Temporary

Mobility Kit) is used to seal a puncture and

The emergency puncture repair kit (p. 332)

consists of a compressor and a bottle of seal-

ant. The sealing works as a temporary repair.

The sealing fluid bottle must be replaced

before its expiration date and after use. The

sealing fluid effectively seals tyres punctured

in the tread.

The emergency puncture repair kit is only

intended for sealing tyres with a puncture

in the tread.

The emergency puncture repair kit has limited

capacity to seal tyres which have punctures

in the wall. Do not seal tyres with the emer-

gency puncture repair kit if they have larger

slits, cracks or similar damage. Connect the

compressor to one of the car's 12 V sockets.

Choose the socket that is nearest to the

punctured tyre.

Standard in certain markets.

Option only in certain markets.

09 Wheels and tyres

331

If the compressor is connected to one of

the two 12 V sockets, in the tunnel con-

sole, no other current consumer must be

connected to the other one.

Emergency puncture repair - operation

The compressor for temporary emergency

puncture repair has been tested and

approved by Volvo.

Related information

•

(p. 332)

•

Emergency puncture repair - rechecking

(p. 335)

•

Emergency puncture repair kit - overview

(p. 332)

•

Tools (p. 324)

Emergency puncture repair kit -

location

Emergency puncture repair kit (TMK -

Temporary Mobility Kit) is used to seal a

puncture and check and adjust the tyre pres-

sure (p. 408).

Location of the emergency puncture
repair kit

The emergency puncture repair kit is located

behind the hatch on the left-hand side of the

cargo area.
Set up the warning triangle (p. 323) if a tyre is

being sealed in a trafficked location.

The emergency puncture repair kit is only

intended for sealing tyres with a puncture

in the tread.

repair is connected to one of the two sock-

If the compressor for emergency puncture

ets (p. 150) in the tunnel console then no

other current consumer may be connected

to the other one.
