It is important that only one pressure-sensi-
tive surface is activated at a time. If the han-
dle is grasped at the same time as the lock
area is pressed, there is a risk that double
commands may be sent. This may cause the
requested action (locking/unlocking) to be
delayed or not performed at all.

Trunk lid

The trunk lid handle has a rubberized pressure
plate that can only be used for unlocking.

Keyless locking and unlocking* (p. 253)

Please be aware that the system could be
activated in a car wash if the remote key is
within range.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

253

Related information

•

•

Keyless trunk lid unlock* (p. 255)

Keyless locking and unlocking*

The vehicle can be locked or unlocked from out-
side using the door or trunk lid handles if the
vehicle is equipped with keyless locking/unlock-
ing (Passive Entry)*.

One of the vehicle's remote keys must be
within range for locking and unlocking to be
possible.

Pressure-sensitive indentation for locking

Pressure-sensitive surface for unlocking

Rubberized pressure plate on the trunk lid used only for
unlocking.

Please be aware that the system could be
activated in a car wash if the remote key is
within range.

KEY, LOCKS AND ALARM

* Option/accessory.

254

Keyless locking

All of the doors have to be closed before the
vehicle can be locked. However, the trunk lid can
be open when a door handle is used for locking.

–

To lock, touch the marked area on the out-
side of one of the door handles after the
door is closed or press the button on the
lower edge of the trunk lid

before it is

closed.
> The lock indicator light in the windshield

will flash to confirm that the vehicle is
locked.

To close all door windows at the same time -
place your finger on the pressure-sensitive
indentation on the outside of the door handle and
hold it there until the side windows have closed.

Locking when the trunk lid is open

Keyless unlock settings* (p. 254)

If the vehicle is locked and the trunk lid is still
open, make sure that the remote key is not
left in the trunk when the trunk lid is closed
and the entire vehicle is locked.

If the key is detected in the vehicle, the trunk
lid will not lock when it is closed.

Keyless unlocking

–

To unlock, grasp a door handle or press the
rubberized pressure plate on the underside
of the trunk lid handle.
> The lock indicator light in the windshield

will go out to confirm that the vehicle is
unlocked. Open the doors or trunk lid as
usual.

Automatic relocking

If none of the doors or trunk lid are opened within
two minutes after being unlocked, they will auto-
matically relock. This function reduces the risk of
inadvertently leaving the vehicle unlocked.

Related information

•

•

Keyless trunk lid unlock* (p. 255)

•

Keyless locking and unlocking* (p. 253)

Keyless unlock settings*

Several different sequences are available for
keyless unlocking.

1. Tap

Settings

in the center display's Top

view.

2. Tap

My Car

Locking

Keyless Unlock

3. Select alternative:

•

All Doors

- unlocks all doors at the same time.

•

Single Door

- unlocks the selected door.

Related information

•

•

Applies to vehicles with power trunk lid.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

255

Keyless trunk lid unlock*

The trunk lid can be opened using the remote
key. The key only needs to be within range, e.g.
in a pocket or bag.

The trunk lid is held closed by an electronic lock-
ing mechanism.

To open the tailgate:

1. Lightly press the rubberized pressure plate

on the underside of the trunk lid handle.
> The lock will disengage.

Opening and closing the trunk lid with foot
movement* (p. 263)

One of the vehicle's remote keys must be
within range behind the vehicle for unlocking
to be possible.

2. Lift the outer handle to fully open the trunk

lid.

CAUTION

•

Only light pressure on the rubberized pres-
sure plate is necessary to release the
trunk lid's locking mechanism.

•

Use the handle to lift the trunk lid and do
not apply force to the rubberized pressure
plate. Too much force can damage the
pressure plate's electrical connections.

Hands-free opening of the trunk lid is also possi-
ble using a foot movement under the rear
bumper; see the separate section.

WARNING

Do not drive with the trunk lid open. Toxic

exhaust fumes can be sucked into the vehicle

through the trunk.

Related information

•

•

•

Antenna locations for the start and

lock system

The vehicle is equipped with a keyless start and
lock system

that uses a number of integrated

antennas positioned throughout the vehicle.

Location of the antennas.

Under the cup holder in the front section of
the tunnel console
In the upper front section of the left-side rear
door

In the upper front section of the right-side
rear door

In the trunk

KEY, LOCKS AND ALARM

* Option/accessory.

256

WARNING

Individuals with an implanted pacemaker

should not allow the pacemaker to come

closer than 22 cm (9 in.) to the Keyless sys-

tem antennas. The aim of this is to prevent

disturbances between the pacemaker and the

Keyless system.

Related information

•

•

Settings for remote and inside door unlock
(p. 241)

Locking and unlocking from inside

the vehicle

The doors and trunk lid can be locked and
unlocked from inside the vehicle using the cen-
tral lock buttons in the front doors. The lock but-
tons in the rear doors* can be used to lock/
unlock that particular door.

Central locking

Button with indicator light for locking and unlocking in
front door.

Unlocking using the front door buttons

–

Press the

button to unlock all side doors

and the trunk lid.

Alternative unlocking method

Alternative unlocking method using side door opening
handle

–

Pull either of the side door inside opening
handles and release.
> Depending on the remote key settings,

either all doors will be unlocked or just the
selected door will be unlocked and
opened.

To change this setting, tap

Settings

My Car

Locking

Remote and

Interior Unlock

in the Top view of the

center display.

The keyless lock system only applies to vehicles equipped with keyless locking and unlocking (Passive Entry*).

Only in vehicles equipped with keyless locking and unlocking (Passive Entry*).

The illustration is generic - details may vary according to vehicle model.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

257

Locking using the front door buttons

–

Press the

button (both front doors must

be closed).
> All doors and the trunk lid will lock.

Locking using the rear door button*

Button with indicator light for locking/unlocking in rear
door.

The lock buttons in the rear doors only lock/
unlock that particular door.

Unlocking the rear door

1. Pull the opening handle to unlock the rear

door.

2. Pull the opening handle again to open the

rear door

Related information

•

•

Unlocking the trunk lid from inside the vehi-
cle (p. 257)

•

Activating and deactivating child safety locks
(p. 259)

•

Opening the trunk lid from inside the trunk
(p. 258)

Unlocking the trunk lid from inside

the vehicle

The trunk lid can be unlocked from the inside
using a button on the dashboard.

Press the

button on the dashboard.

> The trunk lid will unlock and can be

opened from the outside by pressing the
rubberized pressure plate on the handle.

2. With the optional power trunk lid* -

Press and hold the

button on the dash-

board.
> The trunk lid will open.

Provided the child safety lock is not activated.

KEY, LOCKS AND ALARM

258

Related information

•

Locking and unlocking from inside the vehi-
cle (p. 256)

Opening the trunk lid from inside
the trunk

The vehicle is equipped with a fluorescent han-
dle on the inside of the trunk lid that can be
used in an emergency to open the trunk lid from
the inside.

1. Pull the handle downward to release the

trunk lid.
> The trunk lid will open.

2. After use, the handle must be pushed back

to its original position before the trunk lid can
be closed.

Locking and unlocking from inside the vehi-
cle (p. 256)

The handle is not intended to be used to
secure the trunk lid, e.g. when transporting
long objects.

WARNING

•

Lock the doors and trunk lid when the
vehicle is parked and keep the remote
keys out of reach of children. Unsuper-
vised children could lock themselves in
the trunk and be injured.

•

On hot days, the temperature in the trunk
and inside the vehicle could rise very
quickly. Exposure to these high tempera-
tures, even for a short time, could lead to
heat-related injury or fatality. Small chil-
dren are particularly at risk.

Related information

•

•

Unlocking the trunk lid from inside the vehi-
cle (p. 257)

US models.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

259

Activating and deactivating child

safety locks

Child safety locks help prevent children from
opening the rear doors from inside the vehicle.
There is an electric safety lock* and a manual
safety lock.

Activating and deactivating electric
child safety locks*

The electric child safety lock can be activated
and deactivated in any ignition mode higher than
0. The lock can be activated and deactivated up
to 2 minutes after the ignition is turned off if no
door has been opened.

Button for electric activation and deactivation.

1. Turn on the ignition and select any ignition

mode higher than 0.

2. Press the button on the driver's door control

panel.
> The message

Rear child lock

Activated

will be shown in the instrument panel and
the indicator light will illuminate to show
that the child safety locks are activated.

When the electric child safety locks are activated:

•

the rear windows can only be opened using
the driver's door control panel

•

the rear doors cannot be opened from the
inside.

The buttons on the right-side rear door will also
be deactivated.

To deactivate the child safety locks:

–

Press the button on the driver's door control
panel.
> The message

Rear child lock

Deactivated

will be shown in the instru-

ment panel and the indicator light will go
out to show that the child safety locks are
deactivated.

When the ignition is switched off, the current set-
ting will be saved. If the child safety locks were
activated when the ignition was switched off, they
will remain activated the next time the ignition is
started.

Symbol

Message

Meaning

Rear child
lock

Acti-

vated

The child safety
locks are acti-
vated.

Rear child
lock

Deacti-

vated

The child safety
locks are deacti-
vated.

Activating and deactivating manual
child safety locks

Manual child safety lock (this is not the manual door
lock).

–

Use the detachable key blade in the remote
key to turn the control.

The door cannot be opened from the inside.

The door can be opened from both the out-
side and the inside.

KEY, LOCKS AND ALARM

* Option/accessory.

260

Locking and unlocking from inside the vehi-
cle (p. 256)

•

The door's knob control only locks that
specific door, not both rear doors simulta-
neously.

•

There are no manual child safety locks on
models equipped with electronic child
safety locks.

Related information

•

•

Detachable key blade (p. 248)

Automatic locking when driving

The doors and trunk lid will automatically lock
when the vehicle begins to move.

Related information

•

Locking and unlocking from inside the vehi-
cle (p. 256)

Opening and closing the power

trunk lid*

The trunk lid can be opened and closed auto-
matically with the optional power trunk release.

Opening

To open the power trunk lid, do one of the follow-
ing:

–

Press and hold the

button on the

remote key until the trunk lid begins to open.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

261

–

Press and hold the

button on the dash-

board until the trunk lid begins to open.

–

Press lightly on the trunk lid's outside handle.

–

Move your foot in a kicking motion* under the
rear bumper.

Closing

To close

the power trunk lid, do one of the fol-

lowing:

–

Press the

button on the lower edge of

the trunk lid to close.

> The trunk lid will close automatically – the

trunk lid will remain unlocked.

•

The button remains active 24 hours after
the tailgate was opened. After this time,
the tailgate must be closed manually.

•

If the tailgate has been open for more than
30 minutes, it will automatically close
slowly.

Vehicles equipped with keyless locking and unlocking (Passive Entry*) have a button for closing and a button for closing and locking.

KEY, LOCKS AND ALARM

* Option/accessory.

262

–

Press and hold the

button on the

remote key.
> The trunk lid closes automatically and an

audible signal sounds - the trunk lid will
remain unlocked.

–

Press and hold the

button on the dash-

board.
> The trunk lid closes automatically and an

audible signal sounds - the trunk lid will
remain unlocked.

–

Move your foot in a kicking motion* under
the rear bumper.
> The trunk lid closes automatically and an

audible signal sounds - the trunk lid will
remain unlocked.

Closing and locking

–

Press the

button on the lower edge of

the trunk lid to close and simultaneously lock
both the trunk lid and doors (all doors must
be closed in order to lock).
> The trunk lid closes automatically – the

trunk lid and doors lock, and the alarm* is
armed.

Opening and closing the trunk lid with foot
movement* (p. 263)

•

One of the vehicle's remote keys must be
within range for locking and unlocking to
be possible.

•

When the keyless locking or closing* func-
tions are used, three audible signals will
sound if the key is not detected close
enough to the tailgate.

CAUTION

When operating the trunk lid manually, open
and close it slowly. If you encounter resis-
tance, do not use force. This could lead to
damage and loss of function.

Interrupting closing

Interrupt closing by doing one of the following:

•

Press the button on the dashboard.

•

Press the button on the remote key.

•

Press the close button on the underside of
the trunk lid.

•

Press the rubberized pressure plate on the
underside of the tailgate's outer handle.

•

Using a foot movement*.

The trunk lid will stop closing and return to its
fully open position. The trunk lid can then be
opened or closed manually.

Pinch protection

If anything obstructs the tailgate with enough
force to prevent it from closing, pinch protection
will be activated.

•

When closing - the trunk lid will stop and
then return to its fully open position. A long
audible signal will sound.

WARNING

Be aware of the risk of serious injury when

operating the trunk lid. Before closing, make

sure that no one is in the path of the tailgate

who could be injured by its movement.
Always operate the trunk lid with caution.

Vehicles equipped with keyless locking and unlocking (Passive Entry*) have a button for closing and a button for closing and locking.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

263

Related information

•

•

Opening and closing the trunk lid

with foot movement*

To make it easier to operate the trunk lid when
your hands are full, it can be opened and closed
by moving your foot in a forward kicking motion
under the rear bumper.

The sensor is located to the left of center under the rear
bumper.

One of the vehicle's remote keys must be within
range behind the vehicle (approx. 1 meter (3
feet)) for opening and closing to be possible. This
applies even if the vehicle is unlocked in order to
prevent the trunk lid from inadvertently opening
e.g. at a car wash.

Foot movement operation

Kicking motion within the sensor's activation area.

–

Make one slow forward kicking motion with
your foot under the left section of the rear
bumper. Take a step back. Do not touch the
bumper.
> A brief audible signal will sound when

opening or closing is activated - the trunk
lid will open/close.

If the trunk lid is open, it will always
close

when the foot motion sensor is

activated.

If several opening attempts have been made
without the remote key in range behind the vehi-
cle, foot movement operation will not be available
for a short period of time.

Applies to vehicles with power trunk lid*.

KEY, LOCKS AND ALARM

* Option/accessory.

264

Do not keep your foot under the vehicle in a kick-
ing motion. This may prevent activation.

Interrupting foot movement operation
–

Make one slow forward kicking motion while
the trunk lid is opening/closing to stop its
movement.
> The trunk lid will stop closing and return

to its fully open position. The trunk lid can
then be opened or closed manually.

The remote key does not need to be within range
of the vehicle to interrupt closing.

There is a risk of reduced or lost function if
there are large amounts of snow, ice, dirt, etc.
on the rear bumper. Make sure to keep the
bumper clean.

Please note that the system could be inadver-
tently activated in a car wash or similar if the
remote key is within range.

Related information

•

Opening and closing the power trunk lid*
(p. 260)

•

•

Activating and deactivating private locking
(p. 264)

Private Locking

The trunk lid and rear seat backrests can be
locked using the private locking function, e.g.
when the vehicle is left at a workshop or with a
valet. This function prevents the trunk lid from
being opened and locks the rear seat backrests
in the upright position.

The function button for private
locking is located in the center
display's Function view.
Depending on the current sta-
tus of the lock,

Private

Locking Unlocked

Private

Locking Locked

will be dis-

played.

Related information

•

Activating and deactivating private

locking

Private locking is activated using the function
button in the center display and a PIN code.

For the valet lock function to be activated the
car must be in at least ignition mode I.

Entering security code before initial use

The first time the function is used, a security
code must be selected. This code can then be
used to deactivate private locking if the selected
PIN code has been lost or forgotten. The security
code functions as a PUK (security) code for all
PIN codes used for private locking.

Save the security code in a safe place.

To create a security code:

1. Tap the button for private locking in Function

view.

> A pop-up window will appear.

KEY, LOCKS AND ALARM

* Option/accessory.

265

2. Enter your security code.

> The security code is saved. The private

locking function is now ready for activa-
tion.

If the system has been reset, the above proce-
dure will need to be repeated.

Activating private locking

The rear seat must be in the upright position
when private locking is activated in order for
the seats to lock. Seats in the folded-down
position will not lock.

1. Tap the button for private locking in Function

view.

> A pop-up window will appear.

2. Enter the code you would like to use to

unlock the trunk lid and rear seats and tap

Confirm

> The trunk lid and rear seats will lock. A

green indicator light will illuminate next to
the button in Function view to confirm
locked status.

Deactivating private locking

1. Tap the button for private locking in Function

view.

> A pop-up window will appear.

2. Enter the code used for locking and tap

Confirm

> The trunk lid and rear seats will unlock.

The green indicator light next to the but-
ton in Function view will go out to confirm
unlocked status.

If you have forgotten or lost your PIN code or
if the PIN code has been entered incorrectly
more than three times, the security code can
be used to deactivate private locking.

If private locking is activated and the vehicle
is unlocked using Volvo On Call* or the Volvo
On Call* app, private locking will be deacti-
vated automatically.

Related information

•

Private Locking (p. 264)

KEY, LOCKS AND ALARM

266

Alarm

The alarm emits sound and light signals if any-
one without a valid remote key attempts to break
into the vehicle or interferes with the start battery
or alarm siren.

When armed, the alarm will be triggered if:

•

the hood, trunk lid or any door is opened.

•

a battery cable is disconnected.

•

the alarm siren is disconnected.

Alarm signals

The following occurs if the alarm is triggered:

•

A siren will sound for 30 seconds or until the
alarm is turned off.

•

All turn signals will flash for 5 minutes or
until the alarm is turned off.

If the reason the alarm was triggered is not recti-
fied, the alarm cycle will repeat up to 10 times

Alarm indicator

A red indicator light on the dashboard shows the
status of the alarm:

•

Indicator off - the alarm is disarmed.

•

Indicator flashes once every two seconds -
the alarm is armed.

•

The indicator flashes quickly after the alarm
has been disabled for up to 30 seconds or
until the ignition is put in I mode – the alarm
has been triggered.

In the event of alarm system failure

If a problem is detected in the alarm
system, a symbol and the message

Alarm system failure

Service

required

will appear in the instrument

panel. Contact a workshop - an authorized Volvo
workshop is recommended.
