Technical specifications for media (p. 499)

•

Audio settings for media

Changing the audio settings for music and other
playback.

1. Press

Settings

in top view.

2. Tap on

Sound

and select settings:

•

Tone

— personal settings for bass, treble,

equaliser, etc.

•

Balance

- balance between right/left

loudspeakers and balance between front/
rear loudspeakers.

•

System Volumes

– adjusts volume in

the various systems of the car. For exam-
ple,

Voice Control

Park Assist

and

Phone Ringtone

Sound experience

Recreating the acoustics from Gothenburg Concert Hall.

With the

Sound Experience

app, there are

more audio playback options, e.g. playback with
concert hall feel. The settings replace any
choices made for audio settings.

Related information

•

Audio settings (p. 481)

•

AUDIO AND MEDIA

* Option/accessory.

494

No images are shown once the car reaches a
certain speed but the sound will be heard the
whole time. The picture returns once more when
the car is almost or completely stationary.

The TV is controlled from the centre display. Sev-
eral functions can also be controlled from the
right keypad on the steering wheel or with voice
recognition.

Related information

•

Using the TV

* (p. 494)

Using the TV

Start the TV

1. Open the app

from the app view.

2. Select a channel.

Change or search for TV channels

The TV automatically searches for the channels
with best reception.

Change the list of visible channels

1. Press

Library

2. Select playback from

TV-channels

Favourites

3. Select the desired channel.

Change channel from selected list
–

Press on

under the centre dis-

play or on the steering wheel keypad.
> The highlight moves up or down one

place in the selected playlist

You can also change stations from the centre
display.

Favourites

A TV channel can be saved as a favourite:

–

Tap on

in order to add/remove a chan-

nel to/from the favourites list.

TV guide

A programme guide is available with information
about TV programmes for up to 48 hours.

–

Tap on

Guide

to show information about TV

programmes.

If the car is moved within the country, e.g.
from city to city, it is not certain that

Favourites

are available since the frequency

may have changed.

Change the format of the TV picture

Tapping on

Picture format

enables you to

choose which format the TV picture should be
shown in.

Auto

- The TV picture is shown in the image

format being transmitted.

Auto fill

- The TV picture is maximised with-

out cropping.

Settings for TV

The option to make certain settings is available,
both in the top view or when TV-viewing takes
place in full screen mode.

Applies to certain markets.

AUDIO AND MEDIA

* Option/accessory.

495

With the video player in full screen mode, or by
opening the top view and pressing

Settings

Media

, the following can be adjusted:

•

Subtitle Language

•

Audio Language

Voice recognition control of radio and media
(p. 125)

The system only supports TV broadcasts in
the countries that broadcast in MPEG-2 or
MPEG-4 format and follow the DVB-T/T2
standard. The system does not support ana-
logue broadcasts.

Related information

•

* (p. 494)

•

•

Navigating in the centre display's views
(p. 40)

•

•

License agreement for audio and media
(p. 515)

Apple CarPlay

Apple CarPlay gives you the option to listen to
music, make phone calls, get directions, send/
receive messages and use Siri, all while you stay
focused on your driving. Apple CarPlay works
with selected Apple devices.

If the car is not already equipped with
Apple CarPlay then it is possible to install it after-
wards. Contact a Volvo dealer to install
Apple CarPlay.

Information about which apps are supported and
which phones are compatible is available on
Apple's website: www.apple.com/ios/carplay/.
Using apps that are not compatible with
Apple CarPlay may sometimes mean that the
connection between an iPhone and the car is
broken. Please note that Volvo is not responsible
for the content in Apple CarPlay.

When using map navigation via Apple CarPlay
there is no guidance in the driver display or head-
up display, but only in the centre display.

The Apple CarPlay apps can be controlled via the
centre display, mobile phone or with the steering
wheel's right-hand keypad (applies to certain
functions). The apps can also be voice-controlled
using Siri. A long press on the steering wheel
button

starts voice control using Siri and a

short press activates the car's own voice control.
If Siri breaks off too early, hold the steering wheel
button

depressed.

By using Apple CarPlay you acknowledge
the following: Apple CarPlay is a service
provided by Apple Inc. under its terms and
conditions. Volvo Cars is thus not
responsible for Apple CarPlay or its
features/applications. When using Apple
CarPlay, certain information from your car
(including its position) is transferred to your
iPhone. In relation to Volvo Cars, you are
fully responsible for your and any others
person’s use of Apple CarPlay.

Related information

•

•

•

Using Apple CarPlay

* (p. 496)

AUDIO AND MEDIA

* Option/accessory.

496

Using Apple CarPlay

To use Apple CarPlay, Siri voice control must be
activated in your phone. The phone must also
have an Internet connection via Wi-Fi or the
mobile network.

Connect an iPhone and start
Apple CarPlay

Apple CarPlay can only be used if Bluetooth
is deactivated. A phone or media player con-
nected to the car via Bluetooth will therefore
not be available when Apple CarPlay is active.
An alternative Internet source must be used
to connect to the Internet for the car's apps.
Use Wi-Fi or the car's built-in modem

1. Connect an iPhone to the USB port. In the

cases where there are two USB ports, the
one with the white frame around the port
must be used.

2. Read the information in the pop-up message

and then tap on

3. Tap on

Apple CarPlay

in the app view.

4. Read the terms and conditions and then tap

to connect.

> The subview with Apple CarPlay is opened

and compatible apps are shown.

5. Tap on the desired app.

> The app starts.

Starting Apple CarPlay

Apple CarPlay is started according to the follow-
ing after an iPhone has been connected.

1. Connect an iPhone to the USB port. In the

cases where there are two USB ports, the
one with the white frame around the port
must be used.
> If the setting for automatic start is

selected - the subview with
Apple CarPlay is opened and compatible
apps are shown.

2. If the subview with Apple CarPlay is not

opened, tap on

Apple CarPlay

in the app

view.
> The subview with Apple CarPlay is opened

and compatible apps are shown.

3. Tap on the desired app.

> The app starts.

Apple CarPlay runs in the background if another
app is started in the same subview. To show
Apple CarPlay in the subview again - tap on the
Apple CarPlay icon in the app view.

Switch the connection between
Apple CarPlay and iPod

Apple CarPlay to iPod

1. Press

Settings

in top view.

2. Continue to

Communication

Apple

CarPlay

3. Untick the box for the Apple device that shall

no longer start Apple CarPlay automatically
when the USB cable is connected.

4. Disconnect and connect the Apple device to

the USB port.

5. Open the app

iPod

from the app view.

iPod to Apple CarPlay

1. Tap on

Apple CarPlay

in the app view.

2. Read the information in the pop-up message

and then tap on

3. Disconnect and connect the Apple device to

the USB port.
> The subview with Apple CarPlay is opened

and compatible apps are shown.

Related information

•

•

Connecting a device via USB port (p. 492)

•

•

Settings for Apple CarPlay

* (p. 497)

•

Resetting settings in the settings menu
(p. 179)

AUDIO AND MEDIA

}}

* Option/accessory.

497

Settings for Apple CarPlay

Settings for Apple device connected with Apple
CarPlay.

Automatic start

1. Press

Settings

in top view.

2. Continue to

Communication

Apple

CarPlay

and select setting:

•

Tick the box - Apple CarPlay starts auto-
matically when the USB cable is con-
nected.

•

Untick the box - Apple CarPlay does not
start automatically when the USB cable is
connected.

A maximum of 20 Apple devices can be stored in
the list. When the list is full and a new device is
connected the oldest one is deleted.

A factory reset is required in order to delete the
list; see the section "Resetting settings in the
settings menu".

System volumes

1. Press

Settings

in top view.

2. Tap on

Sound

System Volumes

and

make the settings for the following:

•

Voice Control

•

Navi Voice Guidance

•

Phone Ringtone

Related information

•

Apple CarPlay

* (p. 495)

•

Android Auto

Android Auto gives you the option to listen to
music, make phone calls, get directions and use
car-adapted apps from an Android device.
Android Auto works with selected Android devi-
ces.

Information about which apps are supported and
which phones are compatible is available on the
website: www.android.com/auto/. For third-party
apps, see Google Play. Please note that Volvo is
not responsible for the content in Android Auto.

Android Auto is started from the app view. After
Android Auto has been started once, the applica-
tion will be started automatically the next time the
device is connected. Automatic start can be
deactivated under settings.

AUDIO AND MEDIA

* Option/accessory.

498

When a phone is connected to Android Auto
it is possible to stream via Bluetooth to
another media player. Bluetooth is active
while Android Auto is being used.

When using map navigation via Android Auto
there is no guidance in the driver display or head-
up display, but only in the centre display.

Android Auto can be controlled via the centre
display using the steering wheel's right-hand key-
pad or voice control. A long press on the steering
wheel button

starts voice recognition control

and a short press deactivates.

By using Android Auto, you acknowledge
the following: Android Auto is a service
provided by Google Inc. under its terms and
conditions. Volvo Cars is not responsible for
Android Auto or its features or applications.
When you use Android Auto, your car
transfers certain information (including its
location) to your connected Android phone.
You are fully responsible for your and any
other person’s use of Android Auto.

Starting Android Auto

The first time an Android is connected

1. Connect the Android to the USB port. In the

cases where there are two USB ports, the
one with the white frame around the port
must be used.

2. Read the information in the pop-up message

and then tap on

3. Tap on

Android Auto

in the app view.

4. Read the terms and conditions and then tap

to connect.

> The subview with Android Auto is opened

and compatible apps are shown.

5. Tap on the desired app.

> The app starts.

Previously connected Android

1. Connect the phone to the USB port.

> If the setting for automatic start is

selected - the subview with Android Auto
is opened and compatible apps are
shown.

2. If the setting for automatic start is not

selected - open the

Android Auto

app from

the app view.
> The subview with Android Auto is opened

and compatible apps are shown.

3. Tap on the desired app.

> The app starts.

Android Auto runs in the background if another
app is started in the same subview. To show
Android Auto in the subview again - tap on the
Android Auto icon in the app view.

Related information

•

•

Connecting a device via USB port (p. 492)

•

•

Settings for Android Auto

* (p. 499)

•

Overview of the centre display (p. 33)

•

AUDIO AND MEDIA

}}

* Option/accessory.

499

Settings for Android Auto

Settings for a phone that has been connected
the first time with Android Auto.

Automatic start

1. Press

Settings

in top view.

2. Press

Communication

Android Auto

and select setting:

•

Tick the box - Android Auto starts auto-
matically when the USB cable is con-
nected.

•

Untick the box - Android Auto does not
start automatically when the USB cable is
connected.

A maximum of 20 Android devices can be stored
in the list. When the list is full and a new device is
connected the oldest one is deleted.

A factory reset is required in order to delete the
list; see the section "Resetting settings in the
settings menu".

System volumes

1. Press

Settings

in top view.

2. Tap on

Sound

System Volumes

and

make the settings for the following:

•

Voice Control

•

Navi Voice Guidance

•

Phone Ringtone

Related information

•

Android Auto

* (p. 497)

•

Resetting settings in the settings menu
(p. 179)

•

Overview of the centre display (p. 33)

Technical specifications for media

Compatible file formats, audio specifications
and USB.

Audio files

For-
mat

File extension

Codec

MP3

.mp3

MPEG1 Layer III,
MPEG2 Layer III,
MP3 Pro (mp3
compatible),
MP3 HD (mp3
compatible)

AAC

.m4a, .m4b, .aac AAC LC (MPEG-4

part III Audio),
HE-AAC (aacPlus
v1/v2)

WMA

.wma

WMA8/9,
WMA9/10 Pro

WAV

.wav

LPCM

FLAC

.flac

FLAC

Video files

Format

File extension

MP4

.mp4, m4v

MPEG-PS

.mpg, .mp2, .mpeg, .m1v

AUDIO AND MEDIA

500

Format

File extension

AVI

.avi

AVI (DivX)

.avi, divx

ASF

.asf, .wmv

MKV

.mkv

Subtitles

Format

File extension

SubViewer

.sub

SubRip

.srt

SSA

.ssa

DivX

DivX certified devices have been tested for high-
quality DivX (.divx, .avi) video playback. When you
see the DivX logo, you have the freedom to play
DivX films.

Profile

DivX Home Theater

Video codec

DivX, MPEG-4

Resolution

720x576

Bit rate

4.8Mbps

Frame rate

30 fps

File extension

.divx, .avi

Max file size

4 GB

Audio codec

MP3, AC3

Subtitles

XSUB

Special func-
tions

Multiple subtitles, multiple
audio, resume play

Reference

Meets all requirements of
the DivX Home Theater pro-
file. Visit divx.com for more
information and software
tools to convert your files
into DivX Home Theater
video.

Storage on USB device

In order for the system to read the USB device
correctly, the following specifications must be fol-
lowed. No folder structure will be shown in the
centre display during playback.

Max number

Files

15000

Folders

1000

Folder levels

Playlists

100

Items in a playlist

1000

Subfolders

No limit

Technical specification for USB
connector

•

Type A socket

•

Version 2.0

•

Voltage supply 5 V

•

Current supply max. 2.1 A

Related information

•

•

AUDIO AND MEDIA

501

Phone

A mobile phone equipped with Bluetooth can be
connected wirelessly to the car's built-in hands-
free system.

The audio and media system acts as a handsfree,
with the facility to remotely control a selection of
the mobile phone's functions. The mobile phone
can still be operated with its own keys if it is con-
nected to the car.

When a mobile phone has been paired with the
car and connected, it can be used make calls,
send/receive messages, stream media and used
as an Internet connection.

The phone is operated from the
centre display, but some opera-
tions are also available via voice
recognition and the app menu,
which are accessed from the
right-hand steering wheel key-
pad.

Overview

Microphone.

Mobile phone.

Phone operation from centre display.

Keypad for operating phone functions that
are shown in the driver display and voice rec-
ognition.
Driver display.

Related information

•

Connecting/disconnecting the phone
(p. 503)

•

•

Managing phone calls (p. 504)

•

Managing text messages (p. 505)

•

Settings for text messages (p. 507)

•

•

Voice recognition (p. 122)

•

•

Using the application menu in the driver dis-
play (p. 113)

•

AUDIO AND MEDIA

502

Connect phone

Connect a Bluetooth-activated phone to the car
to make calls, send/receive messages, stream
media and connect the car to the Internet.

It is possible to have two Bluetooth devices con-
nected at once, in which case one of them can
only be streaming media. The most recently con-
nected phone will automatically be connected to
make calls, send/receive messages, stream
media and provide an Internet connection. To
change the use of the phone, see section
"Bluetooth settings".

Connection is performed once per device. After
connection, the Bluetooth device no longer
needs to be visible/searchable but only needs to
have Bluetooth activated. To connect the car to
the Internet via a phone, tethering must be acti-
vated on the phone. A maximum of 20 connected
Bluetooth devices can be stored in the car.

There are two options for connecting. Either
search the phone from the car or search the car
from the phone.

Option 1 - search phone from car

1. Make the phone searchable/visible via

Bluetooth.

2. To connect the car to the Internet via the

phone’s Bluetooth, activate tethering (porta-
ble/personal hotspot) via Bluetooth on the
phone.

3. Open the subview for phone.

•

If there is no phone connected to the car,
tap on

Add phone

•

If there is a phone connected to the car,
tap on

Change

. In the pop-up win-

dow, tap on

Add phone

> Available Bluetooth devices are listed. The

list is updated as new devices are
detected.

4. Tap on the name of the phone to be con-

nected.

5. Check that the specified number code in the

car matches that in the phone. In which case,
choose to accept in both places.

6. On the phone, choose to accept or reject any

options for phone contacts and messages.

•

The message function must be activated
in certain phones.

•

Not all mobile phones are fully compati-
ble and may therefore not show contacts
and messages in the car.

Option 2 - search car from phone

1. Open the subview for phone.

•

If there is no phone connected to the car,
tap on

Add phone

Make car

discoverable

•

If there is a phone connected to the car,
tap on

Change

. In the pop-up win-

dow, tap on

Add phone

Make car

discoverable

2. Activate Bluetooth on the phone.

3. To connect the car to the Internet via the

phone’s Bluetooth, activate tethering (porta-
ble/personal hotspot) via Bluetooth on the
phone.

4. Search on the phone for Bluetooth devices.

> Available Bluetooth devices are listed.

5. Select the name of the car on the phone.

6. Check that the specified number code in the

car matches that in the external device. In
which case, choose to accept in both places.

7. On the phone, choose to accept or reject any

options for phone contacts and messages.

AUDIO AND MEDIA

}}

* Option/accessory.

503

•

The message function must be activated
in certain phones.

•

Not all mobile phones are fully compati-
ble and may therefore not show contacts
and messages in the car.

If the phone's operating system is updated
then the connection may be broken. In which
case, delete the phone from the car and then
connect again.

Compatible phones

Many phones on the market now have wireless
Bluetooth technology, but not all of them are fully
compatible with the car. For compatibility, see
support.volvocars.com.

Related information

•

Connecting/disconnecting the phone
(p. 503)

•

•

Managing phone calls (p. 504)

•

•

Managing text messages (p. 505)

•

Online car

* (p. 508)

Connecting/disconnecting the

phone

Connect, change or disconnect a connected
phone.

Connecting the phone automatically

It is only the two last connected phones that can
be connected automatically.

1. Activate Bluetooth in the phone before set-

ting the car in ignition position I.

To connect the car to the Internet at the
same time, tethering (portable/personal hot-
spot) in the phone must be activated.

2. Set the car in ignition position I or higher.

> The phone will connect.

Connect the phone manually

1. Activate Bluetooth on the phone.

To connect the car to the Internet at the
same time, tethering (portable/personal hot-
spot) in the phone must be activated.

2. Open the subview for phone.

> Connected phones are listed.

3. Tap on the name of the phone to be con-

nected.
> The phone will connect.

Disconnecting the phone

–

Deactivate Bluetooth on the phone.

When the phone is out of range of the car it is
automatically disconnected. If disconnection
occurs during an active call then the call can be
continued on the phone.

Changing phones

1. Open the subview for phone.

2. Press

Change

> Available Bluetooth devices are listed.

3. Tap on the phone to be connected.

Removing a phone

1. Open the subview for phone.

2. Press

Settings

Communication

Bluetooth Devices

> A list of connected Bluetooth devices is

displayed.

3. Tap on the phone to be removed.

4. Tap on

Remove device

and confirm your

selection.
> The phone is no longer connected with

the car.

Related information

•

•

•

•

Ignition positions (p. 413)

AUDIO AND MEDIA

* Option/accessory.

504

•

•

Online car

* (p. 508)

Managing phone calls

Call handling in the car for a Bluetooth-con-
nected phone.

Generic illustration.

Making phone calls

1. Open the subview for phone.

2. Select call from: call history, enter number

using the keypad or via the contact list. It is
possible to search or browse in the contact
list. Tap on

in the contact list in order to

add a contact under

Favourites

3. Tap on

Call

4. Tap on

End call

to end the call.

You can also make calls from the call log via the
app menu, which is accessed from the right-hand
steering wheel keypad

Making multi-party calls

During a call:

1. Press

Add call

2. Choose to make a call from the call log,

favourites or the contact list.

3. Tap on an entry/row in the call log, or tap on

alongside the contact in the contact list.

4. Tap on

Swap call

to switch between the

parties.

5. Tap on

End call

to end the active call.

Conference calls

During an active multi-party call:

1. Tap on

Join calls

to merge the active multi-

party call.

2. Tap on

End call

to end the call.

Incoming phone calls

Incoming phone calls are shown in the driver dis-
play and the centre display. Manage the call on
the right-hand steering wheel keypad or in the
centre display.

1. Tap on

Answer

Reject

2. Tap on

End call

to end the call.

Incoming phone call during an active call

1. Tap on

Answer

Reject

2. Tap on

End call

to end the call.

AUDIO AND MEDIA

}}

505

Private call

–

During the current call, press

Privacy

and

select setting:

•

Switch to mobile phone

- the hands-

free function is disconnected and the call
continues on your mobile phone.

•

Driver focused

- the microphone in the

roof on the passenger side is switched off
and the call continues with the car's
handsfree function.

Related information

•

Voice recognition control of the phone
(p. 124)

•

•

Using the application menu in the driver dis-
play (p. 113)

•

Using the keyboard in the centre display
(p. 49)

•

Managing text messages

Message handling in the car for a Bluetooth-
connected phone.

In some phones, the message function must be
activated. Not all mobile phones are compatible.
In such cases, they cannot display contacts and
messages in the car. For compatibility, see
support.volvocars.com.

Managing text messages in the centre
display

Text messages are only shown in the centre dis-
play if the setting is selected; see the section
"Settings for text messages".

Press

Messages

in the app

view to manage text messages
in the centre display.

Reading a text message in the centre display
–

Press

Read out

to get the message read

aloud.

Sending text messages in the centre display

1. It is not possible to reply to a message or

create a new message.

•

Reply to message — tap on the contact
whose message you wish to reply to, then
tap on

Answer

•

To create a new message – press

Create

new

and then

. Select a contact or enter

a number.

2. Compose the message.

3. Press

Send

Managing text messages in the driver
display

Text messages are only shown in the driver dis-
play if the setting is selected; see the section
"Settings for text messages".

Reading a new text message in the driver
display
–

To have the message read aloud – select

Read out

with the steering wheel keypad.

Dictating a reply in the driver display

After the text message is read aloud, a brief reply
can be created through dictation.

–

Press

Answer

with the steering wheel key-

pad. A dictation dialogue starts. For this func-
tion to work, the car must be connected to
the Internet.

AUDIO AND MEDIA

506

Message notification

For notification settings, see section "Settings for
text messages".

Related information

•

Settings for text messages (p. 507)

•

•

Voice recognition control of the phone
(p. 124)

•

•

Using the keyboard in the centre display
(p. 49)

•

Managing the phone book

Contact handling in the car for a Bluetooth-con-
nected phone.

Browse between the letters and

to find

a matching contact. Depending on existing
contacts in the phone book, only matching
letters are shown.

Search contacts

- tap on

to search for

a phone number of name in the contact list.

Favourites

- tap on

to add/remove a

contact to/from the favourites list.

Only contacts from an active Bluetooth-con-
nected phone are shown in the centre display.
Up to 3000 contacts can be shown.

Sorting

The contact list is sorted in alphabetical order
where special characters and numbers are sorted
under

. The sort order can be made by first or

last name, see the section "Settings for phone"
for more information.

Related information

•

Voice recognition control of the phone
(p. 124)

•

•

Using the application menu in the driver dis-
play (p. 113)

•

Using the keyboard in the centre display
(p. 49)

•

Settings for text messages (p. 507)

AUDIO AND MEDIA

* Option/accessory.

507

Settings for phone

Settings for connected phone.

Phone

1. Press

Settings

in top view.

2. Press

Communication

Phone

and

select settings:

•

Ringtones

- select ringtone. It is possible

to use a ringtone from the phone or the
car. Some phones are not fully compatible
and their ringtones may therefore not be
available for use in the car. For compatibil-
ity, see support.volvocars.com.

•

Sort order for contacts

- select sort

order of contact list.

For call notifications in the head-up display

see section "Head-up display".

Related information

•

•

•

•

•

Head-up display

* (p. 118)

Settings for text messages

Settings for text messages on connected phone.

Message

1. Press

Settings

in top view.

2. Press

Communication

Text Messages

and select settings:

•

Notification in centre display

- shows

message notifications in the centre dis-
play's status bar.

•

Notification in driver display

- shows

notifications in the driver display. When
notifications in the driver display are
active, it is possible to manage incoming
messages with the steering wheel's right-
hand keypad.

•

Text message tone

- select tone for

incoming text message.

Related information

•

•

Managing text messages (p. 505)

•

•

Bluetooth

settings

Settings for Bluetooth-connected devices.

Bluetooth

1. Press

Settings

in top view.

2. Press

Communication

Bluetooth

Devices

and select settings:

•

Add device

- starts the pairing of a new

device.

•

Previously paired devices

- lists con-

nected devices.

•

Remove device

- removes the connected

device.

•

Allowed services for this device

- sets

device usage options: calling, sending/
receiving messages, streaming media and as
Internet connection.

•

Internet connection

- connects the car to

the Internet via the device's Bluetooth con-
nection.

Related information

•

Online car

* (p. 508)

•

•

•

AUDIO AND MEDIA

* Option/accessory.

508

Online car

An online car provides the ability to use e.g.
Internet radio and music services via apps as
well as contact dealers in the car and download
software.

The car is connected via Bluetooth, Wi-Fi or with
the car's built-in modem

When the car is connected to the Internet, its
Internet connection (Wi-Fi hotspot) can be
shared to allow other devices to use the Internet
connection

Connection status is indicated by the symbol in
the centre display's status bar.

Related information

•

Book service and repair (p. 553)

•

Apps (p. 480)

•

•

System updates (p. 555)

•

Volvo ID (p. 23)

•

Symbols in the centre display's status bar
(p. 45)

•

Sharing Internet via Wi-Fi hotspot (p. 510)

Connecting the car

Connect the car to the phone via Bluetooth,
Wi-Fi or with the car's built-in modem

The mobile phone and network operator must
support tethering (sharing the Internet connec-
tion) and the plan must include data.

Data is transferred when using the internet
(data traffic), which can have a cost.

Activation of data roaming can result in fur-
ther charges.

Contact your network operator about the cost
for data traffic.

When using Apple CarPlay, it is only possible
to connect the car to the Internet using Wi-Fi
or car modem
