Volkswagen Jetta Hybrid (2015 year). Instruction - part 5

Please first read and note the introductory information and heed the WARNINGS

Switches in the driver door

Key to

⇒

fig. 30

(1)

For the windows in the front doors.

(2)

For the windows in the rear doors.

(3)

Safety switch.

Opening or closing windows

Function

Action

Opening:

Press the

switch.

Closing:

Pull the

switch.

Stopping au-
tomatic
movement:

Press/pull the respective switch again.

The safety switch

(3)

deactivates the

power windows in the rear doors. The
yellow indicator light in the switch
comes on.

You can still use the power windows for several minutes after the ignition is switched off as long as the
driver or front passenger door has not been opened. When the vehicle key has been removed from
the ignition and the driver door has been opened, the power windows cannot be opened or closed.

A separate switch for controlling the passenger side window is located in the front passenger

door.

Power windows – features

Please first read and note the introductory information and heed the WARNINGS

One-touch opening and closing

The one-touch feature automatically opens/closes a power window all the way. The window switch
does not have to be held down/up.

For one-touch opening: Press the switch for the window down briefly as far as it goes.

For one-touch closing: Pull the switch for the window up briefly as far as it goes.

Stopping automatic movement: Pull/press the switch again.

Reactivating the one-touch feature

If the vehicle battery is disconnected or dead and the windows are not completely closed, the one-
touch feature will not work and must be reactivated:

  Switch on the ignition.
  Close all windows and doors.
  Pull the switch for the respective window up and hold it for at least 2 seconds in this position.
  Release the switch, pull up and hold again. The one-touch feature is now reactivated.

The one-touch feature can be reactivated for one or more windows at the same time.

Convenience closing

If your vehicle is equipped with the convenience closing feature, you can close the windows and the
power sunroof as follows:

From inside the vehicle: When the driver door is open, pull up and hold the switch for the driver

window until all windows and the sunroof close.

Manual locking from outside the vehicle: Lock the vehicle with the vehicle key bit in the driver door

and keep the key turned in the locking position to close all windows and the power sunroof

⇒ Manual-

ly unlocking and locking the driver door.

Vehicles with Keyless Access: Hold your finger on the lock sensor surface on the outside of the

door handle for a few seconds until the windows and power sunroof close

⇒ Unlocking or locking the

vehicle with Keyless Access.

WARNING

Improper use of power windows can result in serious personal injury.

Never let anyone get in the way of a power window when closing it.
When locking the vehicle from the outside, make sure that no one, especially children,

remains in the vehicle. The windows will not open in case of an emergency.

Always take the key with you when you leave the vehicle. You can still use the power win-

dows for several minutes after the ignition is switched off as long as the driver or front pas-
senger door has not been opened.

Always use the safety switch when children are in the back seat to disable the rear power

windows and keep them from being opened and closed.

If the power windows malfunction, the one-touch feature, as well as pinch protection may not

work properly. See an authorized Volkswagen dealer or authorized Volkswagen Service Facility right
away.

If convenience closing of the power windows from the outside requires removing the cover cap of

the lock cylinder on the driver door, the cover cap must be reinstalled after the vehicle is locked

⇒

Manually unlocking and locking the driver door.

Power window pinch protection

Please first read and note the introductory information and heed the WARNINGS

Pinch protection can help reduce the risk of pinching injuries when closing a power window

⇒

. If

one-touch window closing meets resistance or there is something in the way, the window will stop and
go down again.

  Check why the window did not close.
  Try one-touch window closing again.
  If the window meets resistance a second time, so that it stops and goes back down, one-touch

closing is deactivated for about 10 seconds.

If you pull the power window button up all the way and hold it during this 10 second interval, the

window will close without pinch protection

⇒

Closing the window without pinch protection

Try to close the window again within 10 seconds by holding the switch. Pinch protection is

turned off for a short distance in the window track!

If closing takes longer than about 10 seconds, pinch protection is turned on again. The window

stops again if there is resistance.

If the window still will not close, please see an authorized Volkswagen dealer or an authorized

Volkswagen Service Facility.

WARNING

Without pinch protection, power windows will close with enough force to cause serious per-
sonal injury.

Always be careful when closing power windows.
Always make sure that no one is in the way when overriding pinch protection to close

power windows!

Pinch protection cannot prevent fingers or other parts of the body from being pressed

against the window frame; injuries may result.

Pinch protection is also active during convenience closing of the windows and the power sunroof

⇒ Power windows – features.

Power sunroof

Introduction

In this section you’ll find information about:

Opening or closing the power sunroof

Power sunroof – convenience closing feature

Pinch protection for the power sunroof

Initializing the power sunroof

Depending on equipment, your vehicle may be equipped with a power sliding and tilting sunroof.

More information:

  Volkswagen Information System
  Power locking system
  Emergency closing and opening

WARNING

Improper use of the power sunroof can result in serious personal injury.

  Always make sure that no one is in the way of the power sunroof when it is closing.
  Always take the key with you when you leave the vehicle.
  Never leave children or disabled persons in the vehicle – particularly if they have access

to the vehicle key. Unsupervised use of the remote control vehicle key makes it possible to
lock the vehicle, start the engine, turn on the ignition and operate the sunroof.

You can still open or close the power sunroof for several minutes after you switch off the

ignition, as long as the driver or front passenger door has not been opened.

NOTICE

To help prevent damage, remove ice and snow from the sunroof before opening or tilting it

in winter weather.

Always close the sunroof before leaving the vehicle or if it begins raining. If the sunroof is

open or tilted, rain could enter the vehicle interior and cause extensive damage to the electrical
system. This could result in further vehicle damage.

Remove leaves and other objects from the sunroof guiderails regularly either by hand or using a

vacuum cleaner.

If the power sunroof malfunctions, pinch protection may not function properly. See an authorized

Volkswagen dealer or an authorized Volkswagen Service Facility.

Opening or closing the power sunroof

Fig. 31 In the headliner: Rotary switch for the power sunroof.

Please first read and note the introductory information and heed the WARNINGS

The rotary switch must be turned to its home position

⇒

fig. 31

(1)

to tilt the power sunroof.

Function

Switch

position

Action

⇒

fig. 31

To open sliding sunroof

fully:

(3)

Turn the switch past position

(2)

and

hold it there until the glass roof
moves to the desired position.

To open the sliding sun-

roof to the comfort posi-

tion:

(2)

Turn the switch to the desired posi-
tion.

To set an intermediate

position:

(1)

(2)

To close the sliding sun-

roof fully:

(1)

⇒

fig. 31

Function

Switch

position

Action

To tilt open the tilting

roof fully:

(4)

Push the rear part of the switch brief-
ly (arrow).

To stop the one-touch

feature:

(4)

(5)

Push or pull the switch again briefly.

To set an intermediate

position:

(4)

(5)

Pull or push the rear part of the

switch briefly until the desired posi-
tion is reached.

To close fully:

(5)

Pull the rear part of the switch briefly
(arrow).

You must switch on the ignition to operate the power sunroof. After switching off the ignition, you can
still open or close the power sunroof for several minutes as long as the driver or front passenger door
has not been opened.

Sliding headliner

The sliding headliner opens with the power sunroof and can be closed manually when the sunroof is
closed.

Power sunroof – convenience closing feature

Please first read and note the introductory information and heed the WARNINGS

Your vehicle may be equipped with the convenience closing feature.

Convenience closing

The convenience closing feature lets you close the power sunroof as follows:

Remove the cover cap from the concealed lock cylinder on the driver door (if necessary)

⇒ Manu-

ally unlocking and locking the driver door.

Turn the vehicle key bit in the lock of the driver door to the closing position and hold it there. The

windows and power sunroof close. Release the vehicle key to stop the process.

Vehicles with Keyless Access: Hold your finger on the lock sensor surface on the outside of the

door handle for a few seconds until the windows and the power sunroof close

⇒ Unlocking or locking

the vehicle with Keyless Access.

Convenience closing of the power sunroof from the outside leaves the rotary switch in the last

selected position. The switch must be newly positioned when starting to drive again.

If convenience closing of the power sunroof requires removing the cover cap of the lock cylinder

on the driver door, the cover cap must be reinstalled after the vehicle is locked

⇒ Manually unlocking

and locking the driver door.

Pinch protection for the power sunroof

Please first read and note the introductory information and heed the WARNINGS

Pinch protection can help reduce the risk of pinching injuries when closing the power sunroof

⇒

. If

the power sunroof closing meets resistance or there is something in the way, the power sunroof opens
again immediately.

  Check why the power sunroof did not close.
  Try to close the power sunroof again.
  If the power sunroof still cannot close, the power sunroof will stop where the resistance is located.

The power sunroof will close the next time without pinch protection.

Closing the power sunroof without pinch protection

If the power sunroof opens again but there is nothing in the way, turn the rotary switch to position

⇒

fig. 31

(1)

and pull down the rear part of the switch

⇒

fig. 31

(5)

until the power sunroof closes com-

pletely.

The power sunroof will now close without pinch protection!
If the power sunroof still will not close, please see an authorized Volkswagen dealer or an author-

ized Volkswagen Service Facility.

WARNING

Without pinch protection, the power sunroof will close with enough force to cause serious
personal injury.

Always be careful when closing the power sunroof.
Always make sure that no one is in the way when overriding the pinch protection to close

the power sunroof!

Pinch protection cannot prevent fingers or other parts of the body from being pressed

against the edge of the roof; injuries may result.

Pinch protection is also active during convenience closing of the windows and the power sunroof

⇒ Power sunroof – convenience closing feature.

If the power sunroof malfunctions, pinch protection may not function properly. See an authorized

Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

Initializing the power sunroof

Fig. 32 In the headliner: Sunroof rotary switch.

Please first read and note the introductory information and heed the WARNINGS

Initializing the sunroof

If the vehicle battery has been disconnected or is dead, the sunroof must be initialized.

The switch must be rotated to the “Closed” position

⇒

fig. 32

(1)

Pull the switch at the rear until the sunroof is fully closed.
The sunroof will now close without pinch protection!

  Release the switch.
  Pull and hold the switch at the rear. The sunroof will open and close on its own.
  When the sunroof is closed once again, release the switch.
  If the sunroof still will not close, contact an authorized Volkswagen dealer or an authorized

Volkswagen Service Facility.

WARNING

Careless or unsupervised use of the sunroof can cause serious injuries.

  Always make sure that no one is in the way of the power sunroof when it is closing.
  Always take all vehicle keys with you when leaving the vehicle.
  Never leave children or persons requiring assistance unattended in the vehicle, especially

if they have access to the vehicle key. Unsupervised use of the remote control vehicle key
can lock the vehicle, start the engine, switch on the ignition and operate the sunroof.

The sunroof can still be opened or closed for a short period after the ignition has been

switched off, as long as the driver or passenger door is not opened.

WARNING

Closing the sunroof without pinch protection can cause severe injuries.

Always be careful when closing the sunroof.
Always make sure that no one is in the way when overriding pinch protection to close the

sunroof.

Pinch protection does not prevent fingers or other body parts from being pressed against

the roof frame, thereby causing injury.

If the power sunroof malfunctions, pinch protection may not function properly. See an authorized

Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

HomeLink

Universal Transmitter

Introduction

In this section you’ll find information about:

Programming the HomeLink

Universal Transmitter

Operating the HomeLink

Universal Transmitter

The HomeLink

Universal Transmitter in your vehicle can be used to open/close an automatic garage

door or gate, activate a house alarm, or control a lighting system or other devices. Such devices
usually come with a hand-held remote control that sends a signal to a controller to operate the device.

These instructions will help you program the HomeLink

Universal Transmitter in your vehicle so that

you will not have to use the hand-held remote control that was supplied with the garage door opener
or other device, inside your vehicle.

Fixed code or rolling code

The garage door opener or other device may work with either a fixed or rolling code. For garage door
openers or other devices with rolling codes, the HomeLink

Universal Transmitter must be synchro-

nized after programming the device

⇒ Programming the HomeLink® Universal Transmitter.

Compatibility

Volkswagen recommends that you consult an authorized Volkswagen dealer or authorized
Volkswagen Service Facility about compatible devices before you buy a garage door opener or other
device that you want to control with the HomeLink

Universal Transmitter.

The HomeLink

Universal Transmitter can be programmed to the radio frequency codes of most

current hand-held remote controls.

Safety switches are mandatory for garage door openers.

A Declaration of Compliance with the United States FCC and Industry Canada regulations is found on
⇒ Declaration of Compliance, Telecommunications and Electronic Systems.

DANGER

20 mm button cells and other lithium batteries will cause serious personal injury and even
death within a short time if swallowed.

Always keep hand-held remote control devices with batteries, spare batteries, as well as

dead button cell and larger 20 mm batteries out of the reach of children.

Get medical attention immediately if you suspect that a battery has been swallowed.

WARNING

Improper use of the HomeLink

Universal Transmitter can cause serious or even fatal per-

sonal injury.

  Garage doors operate with enough force to cause serious personal injury.
  Never let anyone get in the way of a garage door when it is opening or closing.
  When programming the HomeLink

Universal Transmitter, you may be operating a garage

door or estate gate. Always make sure that people and objects are out of the way to help
prevent serious personal injury or property damage.

When operating the “training” button on a garage door opener with a rolling code, you will

need to stand on a ladder or step-stool. Always take extra precautions to prevent falls and
serious injury.

Never use the HomeLink

Universal Transmitter with any garage door opener that does

not have the safety stop-and-reverse feature, as required by federal safety standards. This
includes any garage door opener model manufactured before April 1, 1982.

A garage door opener that cannot detect an object, signaling the door to stop and reverse,

does not meet current federal safety standards. Using a garage door opener without these
features increases the risk of serious injury or death.

Follow the installation manual and the included safety information from the manufacturer

when using the remote-controlled garage door opener or electrical drive.

Programming the HomeLink

Universal Transmitter

Fig. 33 In the driver side sun visor: The remote control and buttons for the HomeLink Universal Transmitter.

Fig. 34 To program: Simultaneously press the buttons for the HomeLink Universal Transmitter and the remote
control.

Please first read and note the introductory information and heed the WARNINGS

Getting ready to program

Please read the product manufacturer's instructions before programming the garage door opener

or other device.

Safely park the vehicle within range of the device to be programmed.

Switch the ignition on, but do not start the engine.

The buttons 1 , 2 , and 3 on the keypad in the sun visor can operate up to 3 separate devices (for
example, a gate and garage door, house alarm or lighting system).

Please carry out each step only in the order specified:

For first time programming only: Press and hold the two outer
HomeLink buttons 1 and 3 at the same time for about 20 seconds,
releasing only when the HomeLink indicator light above button 2
begins to flash.
This step deletes any old settings. Do not perform this step when
programming the additional HomeLink buttons.

Position the hand-held transmitter for your remote control device 1-
3 inches (25-75 mm) away from the HomeLink keypad on the driver
side sun visor, keeping the HomeLink indicator light in view, as

shown

⇒

fig. 33

Please carry out each step only in the order specified:

Using both hands, simultaneously press and hold both the
HomeLink button you want to program (1, 2, or 3) and the hand-

held transmitter button, as shown

⇒

fig. 34

. Do not release the

buttons until the HomeLink indicator light flashes slowly and
then rapidly. When the indicator light flashes rapidly, release both
buttons. The rapid flashing indicates successful programming.

Press and hold the programmed HomeLink button and watch the
indicator light.
If the indicator light comes on and does not flash, programming is
complete and your garage door opener or other device should acti-
vate when the HomeLink button is pressed and released.
If the indicator light blinks rapidly for 2 seconds and then stays on,
proceed with the following programming instructions for a rolling
code device. A second person may make the following steps
quicker and easier. Please use a ladder or other device. Do not

stand on your vehicle to perform the next steps

⇒ in Operating

the HomeLink® Universal Transmitter.

At the garage door opener receiver (overhead unit) in the garage,
locate the “learn” or “training” button. The name and color of the
button may vary by manufacturer. This button is usually located
near the hanging antenna wire attachment point on the unit. If you
cannot locate the “training” button, refer to the garage door open-
er’s user manual.

Press and release the “training” button.
Once the button is pressed, you have 30 seconds to initiate
the next step.

Return to the vehicle. Firmly press and hold the programmed
HomeLink button for 2 seconds and release.

Repeat the “press/hold/release” sequence up to 3 times to com-
plete the programming process for that button.

Repeat the steps to program the other buttons for the HomeLink

Universal Transmitter on the sun

visor keypad to control other devices.

Deleting programming for all buttons

Be sure to delete programming on all buttons on the sun visor keypad before selling the vehicle or
turning it over to people you do not know.

Complete the programming preparation steps described above.

Press and hold buttons 1 and 3 at the same time, for about 20 seconds.

When the indicator light above button 2 begins to flash, immediately release buttons 1 and 3 .

This step deletes all old settings.

After programming

Test the garage door opener

Operating the HomeLink

Universal Transmitter

Please first read and note the introductory information and heed the WARNINGS

The vehicle must be in operating range of the garage or outer gate drives.

With ignition turned on or engine running, press the appropriate button on the sun visor

⇒

The range of the HomeLink

Universal Transmitter roughly corresponds to the range of the original

remote control of the device or the electrical drive. If the garage door or the electrical drive does not
work, this could be for one of the following reasons:

Malfunction

Possible cause

Possible remedy

Garage door or
electrical drive
does not work.

Distance or trans-
mission angle too
great.

Try different distances and
angles to the receiver.

Garage door or elec-
trical drive not com-
patible.

May not comply with legal re-
quirements and may have to
be replaced.

Incorrect program-
ming.

Reprogram the garage door
opener.

DANGER

20 mm button cells and other lithium batteries will cause serious personal injury and even
death within a short time if swallowed.

Always keep hand-held remote control devices with batteries, spare batteries, as well as

dead button cell and larger 20 mm batteries out of the reach of children.

Get medical attention immediately if you suspect that a battery has been swallowed.

WARNING

Improper use of the HomeLink

Universal Transmitter can cause serious or even fatal per-

sonal injury.

  Garage doors operate with enough force to cause serious personal injury.
  Never let anyone get in the way of a garage door when it is opening or closing.
  When programming the HomeLink

Universal Transmitter, you may be operating a garage

door or estate gate. Always make sure that people and objects are out of the way to help
prevent serious personal injury or property damage.

When operating the “training” button on a garage door opener with a rolling code, you will

need to stand on a ladder or step-stool. Always take extra precautions to prevent falls and
serious injury.

Never use the HomeLink

Universal Transmitter with any garage door opener that does

not have the safety stop-and-reverse feature, as required by federal safety standards. This
includes any garage door opener model manufactured before April 1, 1982.

A garage door opener that cannot detect an object, signaling the door to stop and reverse,

does not meet current federal safety standards. Using a garage door opener without these
features increases the risk of serious injury or death.

Follow the installation manual and the included safety information from the manufacturer

when using the remote-controlled garage door opener or electrical drive.

NOTICE

The wrong batteries can damage the hand-held remote control. Replace a dead battery with
one that has the same voltage, size, and specifications.

Please dispose of old batteries properly and in an environmentally responsible manner. Always

keep them out of the reach of children.

Certain batteries used in hand-held remote controls are classified as Perchlorate Material.

Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all legal
requirements regarding proper disposal. Authorized Volkswagen dealers and authorized Volkswagen
Service Facilities are familiar with the requirements, and we recommend that you have them perform
this service for you.

Adjusting the seating position

Introduction

In this section you’ll find information about:

Examples of improper seating positions

Proper seating position

Manual controls on the driver and front passenger seats

Electrical controls on the driver and front passenger seats

Adjusting the front and rear head restraints

Removing and reinstalling the head restraints

Adjusting the steering wheel position

Center armrest

Number of seats

The vehicle has a total of 5 seating positions: 2 in front and 3 in the rear. Each seating position has a
safety belt.

More information:

  Seat functions
  Safety belts
  Airbag system
  Child safety and child restraints

WARNING

Improper seating positions increase the risk of severe or fatal injuries in a crash or other
accidents, especially when the airbag deploys.

All occupants must sit properly and be properly restrained at all times.
Never let more people ride in the vehicle than there are seating positions with safety belts

available.

Always secure children in the vehicle with an approved and suitable restraint system ap-

propriate for their age, weight, and height

⇒ Child safety and child restraints, ⇒ Airbag sys-

tem.

Always keep your feet on the floor in front of the seat. Never rest them on the seat, in-

strument panel, out of the window, etc. The airbag system and safety belt will not be able to
protect you properly and can even increase the risk of injury in a crash.

Content .. 3 4 5 6 ..
