Volkswagen Jetta Hybrid (2015 year). Instruction - part 2

Menu structure – overview

Please first read and note the introductory information and heed the WARNINGS

The instrument cluster display is divided into 3 parts. The time (digital clock) is displayed in the top
part. The bottom part contains the odometer and the trip odometer (“trip”). You can select the following
displays for the middle part:

Multi-Function Indicator (MFI)
▪  Travel time
▪  Consumption --.- mpg (current fuel consumption)
▪  Av. consumption --.- mpg (average fuel consumption)
▪  Range -- mi
▪  Route -- mi
▪  Average speed --- mph
▪  --- mph (digital speed display)
▪  Oil temperature
▪  Speed warning --- mph
Energy Flow

Audio

⇒ Booklet

Radio or ⇒ Booklet Navigation system

Navigation

⇒ Booklet

Navigation system

Phone

⇒ Booklet

Mobile Phone Package

Assistants (if equipped)
▪  R. Traf. Alert
▪  Blind Spot
▪  AFS
Vehicle status
Settings
▪  Assistants

–  AFS
–  Blind Spot
–  Back

▪ Language
▪ MFI data

–  Travel time
–  Curr. consum. (current fuel consumption)
–  Av. consum. (average fuel consumption)
–  Route
–  Av. speed
–  Digit. speed (digital speed display)
–  Oil temp. (Oil temperature)
–  Speed warn. (speed warning)
–  Back

▪ Convenience

– ATA confirm
– Central locking

Auto unlock
Unlock doors

Back

– Window op. (window operation)

Off
All
Driver
Back

– Mirror adjust

Individually
Both mirrors
Back

– Factory setting
– Back

▪ Lights & Vision

–  Coming Home
–  Leaving Home
–  Footwell light
–  Conv. turn sig. (convenience turn signal)
–  Factory setting
–  Back

▪ Time

–  Set clock
–  24 hr. mode
–  Daylight save
–  Back

▪ Snow tires (winter tires)

–  On
–  + 5 mph
–  - 5 mph
–  Back

▪ Units

–  Temperature
–  Consump./dist.
–  Back

▪ Service

– Info
– Back

▪ Factory setting

Using the instrument cluster menus

Fig. 13 Right side of the multi-function steering wheel: Controls for the menus in the instrument cluster dis-
play.

Please first read and note the introductory information and heed the WARNINGS

The instrument cluster menus are controlled with buttons on the right side of the steering wheel
⇒

fig. 13

Accessing the instrument cluster menus

Switch on the ignition.

If a message or the vehicle icon is displayed, push the button (

⇒

fig. 13

) on the right side of the

multi-function steering wheel until a main menu appears in the instrument cluster display. For a list of
main menus, see

⇒ , Main menus.

Push buttons # or ∃ to move to another main menu, and push the arrow up and down buttons

and to navigate inside the current main menu.

Displaying a submenu

Press the button

⇒

fig. 13

to display submenu items. For instance, after scrolling to MFI data in

the Settings main menu, press the

button to display items available under the MFI data sub-

menu.

Selecting a setting

Use the arrow up and down buttons or on the multi-function steering wheel

⇒

fig. 13

to navigate

through the available options. The selected menu item is located between the 2 horizontal lines. There
may also be a triangle ( ) on the right. Push the button to select a setting.

Returning to the main menu

Press the # or ∃ buttons

⇒

fig. 13

or use the arrow up and down buttons or and select Back.

Main menus

Please first read and note the introductory information and heed the WARNINGS

Menu

Function

See

MFI

Multi-Function Indicator (MFI) in-
formation.

Energy

Flow

Shows the current energy flow to
the hybrid drive.

Audio

Station indicator in radio mode.
Track display in CD mode.
Track display in media mode.

⇒ Booklet

Radio or

⇒ Booklet

Navigation

system

Navigation

Information displays on the navi-
gation system (if equipped):
When destination guidance is ac-
tive, turn arrows and proximity
bars are shown. The illustration is
similar to the symbol display in the
navigation system.
If destination guidance is inactive,
driving direction (compass func-
tion) and the current street name
are displayed.

⇒ Booklet

Navigation

system

Phone

Information and settings of the
mobile phone package.

⇒ Booklet

Mobile

Phone Package

Assistants

Turn the Blind Spot monitor, Rear
Traffic Alert, and Adaptive Front
Lighting System (AFS) on and off
(if equipped).

Vehicle

status

Current warning and information
messages.
This menu item is only displayed
when warning or information mes-
sages are available. The number
of available messages is shown in
the display. Example: 1/1 or 2/2.

Menu

Function

See

Settings

Includes various submenus and
settings such as time, speed warn-
ing for winter tires, language, and
units.

MFI menu (Multi-Function Indicator)

Please first read and note the introductory information and heed the WARNINGS

Some MFI menus have 2 automatic memories: 1 – single trip memory and 2 – total trip memory.
The number of the trip memory is shown at the upper right of the display, if applicable.

The trip memories are in addition to the trip odometer, which is displayed in the bottom part of the
instrument cluster and controlled using the .

button on the right of the instrument panel

⇒

fig. 10

(4)

Press the button on the multi-function steering wheel

⇒

fig. 13

to toggle between the two memories.

Push and hold the button to manually reset a trip memory to zero.

Since

start

Single
trip
memory

The memory accumulates and stores information
about distance driven and fuel used from the time the
ignition was switched on until the time it was switched
off.
If the ignition stays off for 2 hours or more, stored
information is automatically deleted. If the trip is con-
tinued within 2 hours after the ignition was switched
off, the new values are added.

Long

term

Total
trip
memory

The memory displays and stores the accumulated
driving and fuel consumption data of any number of
single trips up to a total driving time of 99 hours and
59 minutes, and up to a total distance of 9,999 miles
(9,999 km). If one of the maximum values is exceed-
ed, then the memory is automatically cleared and
starts again from 0.

Possible MFI menu displays

The following displays can be accessed in the MFI menu if enabled under Settings > MFI data.
Displays that are not enabled will not appear.

Display

Function

Travel time

Driving time in hours (h) and minutes (min) corre-
sponding to trip memories 1 and 2 (toggle).

Consumption

--.- mpg

Current fuel consumption in miles per gallon
(l/100 km) while driving.
When units are set to miles, dashes appear instead of
a number when the engine is running and the vehicle
is standing still.
When units are set to kilometers, the display shows
liters consumed per hour when the engine is running
and the vehicle is standing still.

Consumption

--.- l/100 km

Av. consump-

tion

--.- mpg

Average fuel consumption in miles per gallon
(l/100 km) on trips per trip memories 1 and 2 (toggle)
is displayed once the vehicle has been driven about
330 feet (100 m). Until then, dashes appear instead
of a number. The value displayed is updated every
5 seconds.

Av. consump-

tion

--.- l/100 km

Range -- mi Estimated distance in miles (km) that the vehicle can

go with the fuel left in the tank the way you are cur-
rently driving. Takes account of the current fuel con-
sumption, among other things.

Range -- km

Route -- mi

Distance driven in miles (km) per trip memories 1 and
2 (toggle).

Route -- km

Average speed

-- mph

Average speed on trips per trip memories 1 and 2
(toggle). Displayed once the vehicle has been driven
about 300 feet (100 m). Until then, dashes may ap-
pear instead of a number. The value displayed is
updated every 5 seconds.

Average speed

-- km/h

-- mph

Digital display of the current vehicle speed.

-- km/h

Display

Function

Oil tempera-

ture ---°F

Current engine oil temperature.

Oil tempera-

ture ---°C

Speed warning

--- mph

When the set speed (from 20–155 mph or 30–
250 km/h) is exceeded, an acoustic warning sounds
and a visual message may also appear in the instru-
ment cluster display.

Speed warning

--- km/h

Switching between the displays

Use the arrow up and down buttons ( and ) on the multi-function steering wheel.

Storing speed for the speed warning

  Select the Speed warning display.
  Press the   button to save the current speed and to activate the warning.
  If the speed is not right, press buttons   or   on the multi-function steering wheel to set a differ-

ent speed within about 5 seconds. Then press the

button a second time or just wait a few seconds.

The speed is saved and the warning is activated.

To deactivate, toggle to Speed warning and press the button. The set speed is deleted.

Manually erasing trip memory 1 or 2

Select the trip memory to be erased.
Press the button for about 2 seconds.

Enabling and disabling displays

Use the Settings menu, submenu MFI data to enable displays you want to be available under the
MFI menu in the instrument cluster display. The units in which data is displayed can also be changed
⇒ Settings menu.

Settings menu

Please first read and note the introductory information and heed the WARNINGS

Settings menu Function

Assistants

Settings for the driver assistance systems

Settings menu Function

Language

Set the language for messages in the display and
navigation system.

MFI data

Select the features you want to have displayed in the
MFI menu in the instrument cluster display

Convenience

Convenience function settings

Lights & Vi-

sion

Vehicle lighting settings

Time

Set hours and minutes for the instrument cluster clock
and the Radio & Navigation System clock. The time
can be displayed in 12 or 24 hour format, and can
also be set to daylight savings time.

Snow tires

Set up a visual and acoustic speed warning. Use the
feature only when winter tires are installed that have
a speed rating less than top vehicle speed.

Units

Set the units in which temperature, fuel consumption,
and distances should be displayed (for example,
whether to show distance driven in miles or kilome-
ters).

Service

View the service reminder display

Factory set-

ting

Reset the functions in the Settings menu back to
the factory settings.

Volkswagen Car-Net: Connecting you and your
vehicle

Introduction

In this section you’ll find information about:

Volkswagen Car-Net service

Features

Application software (“apps”)

3-button module

Volkswagen Car-Net services are provided by Verizon Telematics, Inc. (VzT) and are available only on
select models. Automatic Crash Notification (ACN) may be engaged for up to 6 months without activat-
ing a trial or paid subscription; Manual Emergency Call service and all other Volkswagen Car-Net
services require a trial or paid subscription. Volkswagen Car-Net may collect location information. See
applicable Terms of Service and Privacy Policy available at www.vw.com/carnet for details.

Data Collection and Privacy

Vehicle location information is transmitted to Volkswagen and our Volkswagen Car-Net service provid-
er, Verizon Telematics, Inc. (VzT), anytime you press a Volkswagen Car-Net in-car button, when an
ACN event occurs or periodically in connection with the operation of Volkswagen Car-Net.

Unless Volkswagen Car-Net equipment is disabled in the vehicle, it is possible for Volkswagen and
VzT to determine the car’s location if required to do so by law, court order, subpoena or other legal
requirement. For more information, please contact the Volkswagen Car-Net Response Center at 1-
877-820-2290.

Calls may be monitored or recorded.

Volkswagen collects, processes, transmits, uses, and shares information about you and your vehicle
in accordance with the Volkswagen Car-Net Terms of Service and Privacy Policy. See the Volkswagen
Car-Net Terms of Service and Privacy Policy at (http://www.vw.com/carnet) for more details.

More information:

Declaration of Compliance

WARNING

Application software and Volkswagen Car-Net services that are unsuitable or improperly
used can cause accidents, serious personal injury and vehicle damage.

Volkswagen Car-Net services can be used only where adequate cellular and GPS signals

are available.

Volkswagen recommends using only services and application software that are provided

by Volkswagen or Verizon Telematics, Inc. (VzT) specifically for your vehicle.

  Protect the mobile device and its application software from misuse.
  Never modify application software and Volkswagen Car-Net services.
  Always read and heed the operating instructions for the mobile device.

WARNING

Driver distraction causes accidents, collisions and serious personal injury! Using application
software and Volkswagen Car-Net services while driving can distract the driver from traffic.

Always drive attentively and responsibly.

Volkswagen Car-Net service

Please first read and note the introductory information and heed the WARNINGS

Your vehicle has equipment to enable Volkswagen Car-Net, a suite of connected vehicle services that
makes driving and owning a Volkswagen vehicle more convenient. Volkswagen Car-Net allows you to
seamlessly connect your car and your life by offering the following services:

  Safe & Secure – Receive support and assistance in the moment of need.
  Family Guardian – Keep track of family members driving your vehicle.
  Remote Vehicle Access – Interact with your vehicle through your Volkswagen Car-Net iPhone

Android

app, computer or a Volkswagen Car-Net Customer Specialist (text and data rates apply).

Diagnostics & Maintenance – Manage your vehicle health with diagnostic checks and service

scheduling.

You can access Volkswagen Car-Net services via your Volkswagen Car-Net iPhone

or Android

app

(text and data rates apply) and the Volkswagen Car-Net website (http://www.vw.com/carnet). If you
have a question or would like to subscribe, please either press the • button in your vehicle or contact
the Volkswagen Car-Net Response Center at 1-877-820-2290. For more information or to log on to
your Volkswagen Car-Net account, visit http://www.vw.com/carnet.

Note: Please review the Volkswagen Car-Net Terms of Service and Privacy Policy at
http://www.vw.com/carnet.

Subscription required

Automatic Crash Notification (ACN) may be engaged for up to 6 months, starting from the date of new
vehicle sale, without activating a trial or paid subscription.

The Manual Emergency Call service and all other Volkswagen Car-Net features require a trial or paid
subscription. To begin your trial or paid subscription, authentication and activation are required. For
more information, please visit the website (http://www.vw.com/carnet), press the • button in the 3-
button module in your vehicle or contact the Volkswagen Car-Net Response Center at 1-877-820-
2290.

The LED light in the 3-button module will be green during the trial period and whenever you have an
active subscription. The LED light will go off if the trial period is over and the customer has not sub-
scribed to the Volkswagen Car-Net services. The LED light will be red only during a VW Car-Net

hardware malfunction or fault

⇒ 3-button module.

Once a trial or paid Volkswagen Car-Net subscription has been activated, please advise all who
use the vehicle that different kinds of data can be sent and received automatically by the vehi-
cle, including speed, location and more.

WARNING

Vehicle health reports do not replace the information provided by the vehicle warning and
indicator lights. Failure to heed warning lights and instrument cluster text messages can
cause the vehicle to break down in traffic and result in a collision and serious personal injury.

  Never ignore warning lights or text WARNINGS.
  Always stop the vehicle as soon as it is safe to do so.
  Park the vehicle at a safe distance from moving traffic and where no part of the hot cata-

lytic converter and exhaust system can come into contact with flammable materials under the
vehicle, such as dry grass, brush, spilled fuel, etc.

A broken down vehicle presents a high accident risk for itself and others. Switch on

emergency flashers and set up a warning triangle to warn oncoming traffic.

Before opening the engine hood, always switch off the engine and let the engine cool

down.

Always be very careful when working in the engine compartment, which is a potentially

dangerous area in any motor vehicle and can cause serious personal injury.

NOTICE

Failure to heed warning lights or text WARNINGS can result in vehicle damage.

Volkswagen collects, processes, transmits, uses and shares information about you and your

vehicle in accordance with the Volkswagen Car-Net Terms of Service and Privacy Policy. See the
Volkswagen Car-Net Terms of Service and Privacy Policy at http://www.vw.com/carnet for more de-
tails.

Volkswagen Car-Net services use a system based on a wireless communication network. If all

technical and other conditions are met and Volkswagen Car-Net still does not work properly, please try
using the service again later.

Features

Please first read and note the introductory information and heed the WARNINGS

The following listed features are available after Volkswagen Car-Net registration either through the 3-

button module

⇒ 3-button module, a mobile device ⇒ Application software (“apps”), the Volkswagen

Car-Net website (http://www.vw.com/carnet) or by contacting the Volkswagen Car-Net Response
Center at 1-877-820-2290. They are divided into 4 categories: Safe & Secure, Family Guardian, Re-
mote Vehicle Access and Diagnostics & Maintenance Services. Always refer to the Volkswagen Car-
Net website for the most up-to-date information regarding Volkswagen Car-Net services.

Safe & Secure:

Feature

Description

Safe & Secure:

Feature

Description

Automatic Crash
Notification (ACN)

Automatic Crash Notification is initiated in the event
of airbag deployment or rollover. When the feature is
activated the Volkswagen Car-Net Response Center
is notified of your location and contacts your vehicle
to determine the risk of injury and to dispatch help.
Help is dispatched even if the Volkswagen Car-Net
Response Center does not connect to the vehicle's
occupants. Automatic Crash Notification may be
engaged for up to 6 months without activating a trial
or paid subscription.

Manual Emergency
Call

In the case of an emergency, press the

•

button in

the 3-button module: The Volkswagen Car-Net de-
vice initiates a connection to the Volkswagen Car-
Net Response Center. The location of the vehicle
and customer data for identification is sent at the
same time.

Roadside Assis-
tance

Press the

button in the 3-button module: The

vehicle will connect directly to the Volkswagen
Roadside Assistance Call Center. The vehicle’s lo-
cation is also transmitted in order to more quickly
provide assistance.

Stolen Vehicle Lo-
cation Assistance
For use by law en-
forcement authori-
ties only. See
Terms of Service at
www.vw.com/carnet
for details.

After you have reported your vehicle as stolen to law
enforcement, you may provide the case information
to the Volkswagen Car-Net Response Center. Once
the information has been verified, the VW Car-Net
Customer Specialist will be able to provide law en-
forcement with vehicle location data sent by the VW
Car-Net module.

Family Guardian:

Feature

Description

Family Guardian:

Feature

Description

Boundary
Alert

By logging on to your Volkswagen Car-Net account, you
can designate an area on a map as a “virtual fence.” The
vehicle owner can then choose notification channels (text
message or email) for receiving alerts when the vehicle
crosses the defined boundary (texts and data rates apply).

Speed Alert

Volkswagen Car-Net can be configured to inform the vehi-
cle owner whenever the vehicle exceeds a speed set by
the owner. The owner can select to be informed through
multiple channels, including text messages and email (text
and data rates apply).

Remote Vehicle Access:

Feature

Description

Remote Door
Unlock

You can send a request to unlock the vehicle doors
through your Volkswagen Car-Net iPhone

or Android

app, the Volkswagen Car-Net website or by calling the
Volkswagen Car-Net Response Center (text and data rates
apply). If none of the vehicle doors are opened within
about 30 seconds, the car will lock again.

Remote Honk
and Flash

You can send a honk and flash signal to the car using the
Volkswagen Car-Net website or the VW Car-Net iPhone

or Android

app (text and data rates apply). The car will

honk the horn and blink the headlights and emergency
flashers for up to 10 seconds.

Last Parked
Location

You can locate your last parked location using your
Volkswagen Car-Net iPhone

or Android

app (text and

data rates apply).

Remote Vehicle Access:

Feature

Description

Destinations
Only applica-
ble for vehi-
cles
equipped
with a facto-
ry-installed
navigation
system.

Points of Interest (POIs) or other destinations can be im-
ported remotely into the factory-installed navigation system
(if equipped) from a computer or the Volkswagen Car-Net
iPhone

or Android

app (text and data rates apply). These

destinations can be called up and used by the navigation
system.

Destination
Download
Only applica-
ble for vehi-
cles
equipped
with a facto-
ry-installed
navigation
system.

Press the • button in the 3-button module: The vehicle will
connect directly to the Volkswagen Car-Net Response
Center where a Volkswagen Car-Net Customer Specialist
will assist with destinations. The address of a dealer’s loca-
tion can also be sent by the Customer Specialist to your
factory-installed navigation system (if equipped).

Remote Sta-
tus Check

Current information about the vehicle can be viewed
through a computer or your Volkswagen Car-Net iPhone

or Android

app (text and data rates apply). You can find

out if the doors, luggage compartment and engine hood
are open or closed, whether the car lights are on or off, the
level of fuel in the tank, when the vehicle needs to be ser-
viced next and more.

Diagnostics & Maintenance:

Feature

Description

Diagnostics & Maintenance:

Feature

Description

Dealer
Scheduling

Press the • button in the 3-button module: The vehicle will
initiate a call to the Volkswagen Car-Net Response Center
where a Volkswagen Car-Net Customer Specialist will
connect you with an authorized Volkswagen dealer to
schedule your service appointment. The address of the
dealer’s location can also be sent by the Customer Spe-
cialist to your factory-installed navigation system (if
equipped).

Vehicle
Health Re-
port

View a vehicle health report to proactively manage
maintenance and other services and to receive up-to-date
diagnostics in a monthly email report or by immediate re-
quest.

WARNING

Refer to your vehicle's warning and indicator lights for the most current diagnostic infor-
mation. Always consult this manual for maintenance guidelines. Failure to heed warning
lights and instrument cluster text messages can cause the vehicle to break down in traffic
and result in a collision and serious personal injury.

  Never ignore warning lights or text WARNINGS.
  Always stop the vehicle as soon as it is safe to do so.
  Park the vehicle at a safe distance from moving traffic and where no part of the hot cata-

lytic converter and exhaust system can come into contact with flammable materials under the
vehicle, such as dry grass, brush, spilled fuel, etc.

A broken down vehicle presents a high accident risk for itself and others. Switch on

emergency flashers and set up a warning triangle to warn oncoming traffic.

The Volkswagen Car-Net website (http:// www.vw.com/carnet) contains the most up-to-date

information and instructions about Volkswagen Car-Net services.

Please regularly visit the website to learn about changes to services and new features.
Volkswagen Car-Net features can be modified, discontinued, deactivated, reactivated or expanded

without any further notice.

Application software (“apps”)

Please first read and note the introductory information and heed the WARNINGS

Many mobile devices are equipped to load application software (“apps”) into the device. Apps can
make it possible to display additional information on the factory-installed Radio or Navigation system
or activate, control or deactivate specific vehicle features.

Application software, its usage and the wireless connection required to use application software may
be billable services. Apps may be provided by third parties. Therefore you should refer to the terms of
use and privacy statements associated with the apps for information about how the apps collect, use
and share information about you, your vehicle or your mobile device.

The application software provided may be designed to be used for a variety of purposes and be spe-

cific to your vehicle and country

⇒ . The content, range of software provided and application soft-

ware provider can vary. Some application software is also subject to the availability of services provid-
ed by third parties. In order for some application software to work, wireless service reception must be
strong enough to handle the data exchange involved (text and data rates apply).

Application software descriptions may be provided by the service provider.

Due to the multitude of mobile devices and fast pace of software development, the application soft-
ware provided may not run on all mobile devices and their operating systems. This may even apply for
the same model of a mobile device. For example, application software may run on version 2 of the
device's operating system but not on version 3.

Application software can be modified, discontinued, deactivated, reactivated or expanded without any
further notice.

In order for some application software to work, the wireless or cable connection between the factory-
installed Radio or Navigation system and a compatible, functioning mobile device must be strong
enough and uninterrupted.

NOTICE

Volkswagen is not responsible for vehicle damage caused by inferior-quality or malicious
application software, poorly programmed application software, insufficient wireless service
reception, data loss during transmission or misuse of mobile devices.

3-button module

Fig. 14 In the roof console: 3-button module to access Volkswagen Car-Net service operators

Please first read and note the introductory information and heed the WARNINGS

The buttons in the 3-button module provide access to several Volkswagen Car-Net features and
pressing a button will initiate a connection to the Volkswagen Car-Net Response Center. Calls may be
monitored or recorded. In general, the Volkswagen Car-Net Customer Specialist will end the call.

⇒

fig. 14

Function

Content .. 1 2 3 ..
