Volkswagen Jetta GLI (2014 year). Instruction

In order to:

You must:

⇒

fig. 130

Result:

Switch on cruise control.

Move switch

(2)

position.

System is switched on, but does not
regulate vehicle speed until a speed

is set.

Set cruise control to

current vehicle speed.

Press button

(3)

Current vehicle speed is set; cruise

control helps to maintain this speed.

Temporarily deactivate

cruise control.

Move switch

(2)

to the

CANCEL

position.

OR: depress the brake or clutch

pedal.

Cruise control is temporarily

deactivated. The speed is still

stored in the memory.

Resume speed stored in

cruise control.

Press button

(1)

Cruise control resumes speed

previously set.

Increase set speed

(while cruise control is

actively controlling

vehicle speed).

Press button

(1)

briefly to

increase the set speed in small

steps of 1 mph (1 km/h) each.

The vehicle will accelerate until the

new higher speed is reached and

saves the new higher speed in the

memory.

Press and hold button

(1)

increase the set speed until the

higher desired speed is reached

and button is released.

Reduce set speed (while

cruise control is actively

controlling vehicle

speed).

Press button

(3)

. briefly to

reduce the set speed in small steps

of 1 mph (1 km/h) each.

Cruise control will slow the vehicle

down without braking by reducing

the flow of fuel to the engine until

the new lower speed is reached and

saves the new lower speed in the

memory.

Press and hold button

(3)

.to

reduce the set speed until the lower

desired speed is reached and the

button is released.

Switch off cruise control.

Move switch

(2)

OFF

position.

System is switched off. The set

speed is deleted.

Driving downhill with cruise control

If cruise control cannot maintain constant speed while driving downhill, slow the vehicle with the foot
brake and downshift if necessary.

Automatic deactivation

Cruise control speed regulation is automatically deactivated or temporarily interrupted:

  If the system detects an error that could affect the function of the cruise control.
  If the vehicle has accelerated and goes faster than the stored speed for a longer time.
  If the brake or clutch pedal is depressed.
  If the vehicle shifts gear (manual transmission).
  If an airbag deploys.

Rear Assist

Introduction

In this section you’ll find information about:

Operation

Parking

Depending on equipment, the vehicle may be equipped with a Rear Assist rearview camera.

There is a camera in the luggage compartment lid to assist the driver while backing up or
maneuvering. The camera image is shown together with the orientation lines projected by the system
on the screen of the factory-installed radio or navigation system.

Rear Assist may take a few seconds to bring up the camera image.

More information:

Exterior views
Parts, accessories, repairs, and modifications

⇒ booklet

Radio or ⇒ booklet Navigation system

WARNING

Rear Assist is not able to give you a clear and undistorted view of all areas behind the
vehicle.

The camera has blind spots in which it cannot detect people and objects.
Always be careful and look around you when parking. The camera cannot show people,

animals, and objects in certain situations. Watch out for small children and animals in
particular.

Due to the screen resolution or in low-light conditions, the camera may not pick up thin

posts, chain-link fences and similar fences, and other objects, or it may not show them
clearly.

The camera lens enlarges and distorts the field of vision and causes objects on the screen

to appear altered and imprecise.

Always keep the camera lens clean and free of snow and ice; do not cover the lens.

WARNING

Rear Assist technology cannot overcome the laws of physics and the limits of the system.
Careless or unintentional use of Rear Assist may result in accidents and severe injuries.

Always adjust your speed and driving style to road, traffic, weather, and visibility

conditions.

Always keep an eye on the parking direction and the vehicle surroundings. The front of

the vehicle swings out more than the rear of the vehicle.

Never pay so much attention to the graphics shown on the screen that you fail to notice

what is going on around you.

Always watch for people, especially small children, animals, and objects, because the

camera may not always be able to detect them.

The system may not be able to clearly show everything behind the vehicle.
Use Rear Assist only when the luggage compartment lid is completely closed.

NOTICE

The camera shows only two-dimensional images on the screen. Due to the lack of depth of

field, it may be difficult or impossible to identify protruding objects or recesses in the road, for
example.

Things like thin rods, fences, posts, and trees may not be detected by the camera and could

damage the vehicle.

Operation

Fig. 131 In the luggage compartment lid: Location of the Rear Assist camera.

Fig. 132 Rear Assist display.

Please first read and note the introductory information and heed the WARNINGS

In order to

Operation

Automatically activate display:

Shift into Reverse when the ignition is switched on or the

engine is running.

Manually deactivate display:

Press a function selection button on the radio or the

navigation system

⇒ booklet

Radio or

⇒ booklet

Navigation system.

OR: Switch off the ignition. The Rear Assist display turns off

after a few seconds.

Switch off display by shifting out of

Reverse:

The camera display switches off.

In order to

Operation

Deactivate display by driving

forward:

Drive forward faster than about 10 mph (15 km/h).

Press the Options function button at the bottom of the screen to adjust the display brightness,
contrast, and color.

Special considerations

1) Do not use Rear Assist in the following situations:

– When an incorrect or unclear image is displayed, such as when there is poor visibility or the lens is

dirty.

– If the area behind the vehicle cannot be seen clearly or completely.

– If the rear of the vehicle is heavily loaded.

– When the luggage compartment lid is open.

– If the driver is not familiar with the system.

– If the position or angle of the camera has changed, such as after a rear-end collision. Have the

system checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.

2) Examples of optical distortion by the camera:

The Rear Assist camera displays only two-dimensional images. Recesses and protruding objects on

the ground or protruding parts on other vehicles are difficult or impossible to identify due to the lack

of depth of field.

Objects or another vehicle may seem closer or farther away on the screen than they really are:

– When driving from a level surface onto an upward or downward slope.

– When driving up or down a slope onto a level surface.

– If the rear of the vehicle is heavily loaded.

– When approaching protruding objects. These objects can disappear from the field of view when

backing up.

Cleaning the camera lens

Keep the camera lens clean and free of snow and ice:

Engage the parking brake.
Wet the camera lens with a commercially available alcohol-based glass cleaner and clean with a

dry cloth

⇒

Remove snow with a brush.

Remove ice with deicer spray

⇒

NOTICE

Never use abrasive cleaning agents to clean the camera lens.
Never remove snow or ice on the camera lens with warm or hot water. This can damage the

camera lens.

Volkswagen recommends practicing parking with Rear Assist in a safe place with little or no

traffic or in a parking lot under good visibility and weather conditions in order to familiarize yourself
with the system, the orientation lines and the way they work.

Rear Assist does not work when the luggage compartment lid is open.

Parking

Fig. 133 On the screen: Static orientation lines for the parking space behind the vehicle.

Please first read and note the introductory information and heed the WARNINGS

Orientation lines overview

The yellow area displayed stops about 2 yards (meters) behind the vehicle on the road.

Meaning of the orientation lines on the screen

⇒

fig. 133

(1)

Safety distance: area up to about 16 inches (40 cm) behind the vehicle on the road.

(2)

Projection of the vehicle (widened somewhat) toward the rear. The middle markers are about
40 inches (1 meter) behind the vehicle on the road.

Parking

Position the vehicle in front of a parking space and shift into Reverse.
Slowly back up and steer so that the yellow orientation lines lead into the parking space

(2)

Align the vehicle in the parking place so that the yellow orientation lines are parallel with the

parking space.

All distances of the orientation lines refer to a vehicle that is on a level surface.

Heating and air conditioning

Introduction

In this section you’ll find information about:

Manual controls

Climatronic controls

Operation

Air vents

Air recirculation

Manual air conditioning (A/C) and Climatronic

Your vehicle is equipped with either a manual A/C climate control system or a Climatronic
climate control system.

On vehicles with Climatronic climate control, Climatronic information appears in the Climatronic display
and/or on the screen of the factory-installed Radio system or Radio & Navigation system.

The temperature units (Fahrenheit or Celsius) in the factory-installed Radio system or Radio &
Navigation system screen can be changed in the Settings menu in the instrument cluster display on
appropriately equipped vehicles.

The dust and pollen filter

The dust and pollen filter with an activated carbon insert reduces the entry of pollutants into the
passenger compartment.

The dust and pollen filter must be replaced at the intervals recommended in

⇒ booklet

Warranty and

Maintenance so that the air conditioner can work properly.
If the effectiveness of the filter decreases prematurely due to operating the vehicle where the outside
air is heavily polluted, the dust and pollen filter should be replaced more frequently than indicated.

More information:

  Exterior views
  Passenger compartment
  Volkswagen Information System
  Seat functions
  Windshield wipers and washer
  Starting and stopping the engine
  Exterior care and cleaning

WARNING

Poor visibility increases the risk of collisions and other accidents that cause serious
personal injuries.

Always make sure all windows are clear of ice, snow and condensation for good visibility

to the front, sides, and rear.

Maximum heating output and defrosting performance are not possible until the engine has

reached operating temperature. Wait until you have good visibility before driving off.

Always make sure you know how to properly use the climate control system as well as the

rear window defroster that you will need for good visibility.

Never use air recirculation for long periods of time. When the air conditioner is off and

recirculation mode is on, condensation can quickly form on the windows and greatly reduce
visibility.

Always switch off recirculation mode when it is not needed.

WARNING

Stale air causes driver fatigue and reduces driver alertness, which can cause accidents,
collisions and serious personal injury.

Never switch off the fan for a long period of time and never use air recirculation for a long

period of time because no fresh air will enter the passenger compartment.

NOTICE

If you think the air conditioner is not working properly or may be damaged, switch it off to

help prevent more damage. Have the air conditioner checked by an authorized Volkswagen
dealer or an authorized Volkswagen Service Facility.

Air conditioner repair requires specialized knowledge and special tools. Volkswagen

recommends that you see an authorized Volkswagen dealer or an authorized Volkswagen
Service Facility.

Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation

system can leave residue on the evaporator and on the dust and pollen active carbon filter,
resulting in permanent odors whenever the air conditioner is switched on.

If the air conditioner is switched off, the fresh outside air will not be dehumidified. To help keep

the windows from fogging over, Volkswagen recommends leaving the air conditioner (compressor)
switched on. Press the

button. The indicator light in the button must come on.

When it is very hot and humid outside, water condensation can drip from the air conditioner

evaporator and form a puddle under the vehicle. This is normal and does not indicate a leak.

Keep the air intake slots in front of the windshield free of ice, snow, and leaves in order to

maintain proper functioning of the heating and ventilation systems.

Maximum heating output and defrosting performance are not possible until the engine has

reached operating temperature.

Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle

battery has been replaced may change or delete system settings (including time, date, personal
convenience settings, and programming). Check the settings and correct as necessary once the
vehicle battery has built up a sufficient charge.

Manual controls

Fig. 134 In the center console: Manual A/C controls.

Please first read and note the introductory information and heed the WARNINGS

Press the corresponding button to switch a function on or off. If a function is switched on, an indicator
light in the button comes on. To switch off a function, press the button again.

Button/Knob

More information: Manual A/C

⇒

fig. 134

Temperature

(1)

...

Turn knob to set the desired temperature. The

MAX

position provides maximum

cooling output. Recirculation mode and the cooling system switch on

automatically.

Fan

(2)

...

Setting 0: the fan and manual A/C are switched off.

Setting 4: highest fan speed.

Air distribution

(3)

Direct airflow by turning knob to any setting (continuously adjustable).

Defog/defrost: Airflow is directed to the windshield. Recirculation mode switches

off automatically in this position. Increases the fan speed to clear the windshield

as quickly as possible. The cooling system switches on automatically to

dehumidify the air.

Air distribution to the upper instrument panel outlets.

Air distribution to the footwells.

Air distribution to the windshield and footwells.

Rear window defroster: Works only when the engine is running and switches off

automatically after 10 minutes or less.

Button/Knob

More information: Manual A/C

⇒

fig. 134

Air recirculation mode

Buttons for seat heating

Press the button to switch the air conditioner on or off.

Switching off

Turn the fan switch to position 0.

WARNING

Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions,
and serious personal injury.

Never switch off the fan for a long time because no fresh air will enter the passenger

compartment.

Climatronic controls

Fig. 135 In the center console: Climatronic controls.

Please first read and note the introductory information and heed the WARNINGS

Press the corresponding button to switch a function on or off. If a function is switched on, an indicator
light in or under the button comes on. To switch off a function, press the button again.

Button/Knob

More information: Climatronic

⇒

fig. 135

Temperature

(1)

...

Left and right sides of the vehicle can be set to different temperatures. Turn the

knob to set the temperature.

Fan

(2)

The fan speed is automatically controlled depending on the vehicle speed in

order to help prevent unnecessary noise. The fan can also be adjusted manually.

Air distribution

(3)

Air flow is automatically adjusted to a comfortable level. It can also be manually

adjusted with buttons

(3)

Displays

(4)

Left-side and right-side digital temperature displays.

Button/Knob

More information: Climatronic

⇒

fig. 135

Defog/defrost button. The incoming outside air is directed to the windshield, and

air recirculation automatically switches off. To defrost the windshield as quickly as

possible, humidity is removed from the air at temperatures above about +35 °F

(+1.5 °C), and the blower is set to a high speed.

Air distribution to the upper instrument panel outlets.

Air distribution to the footwells.

Air is directed upward.

Rear window defroster: Works only when the engine is running and switches off

automatically after 10 minutes or less.

Manual and automatic air recirculation

Buttons for seat heating

Press the button to switch the air conditioner on or off.

Press the button for maximum air conditioner cooling. The air recirculation and

cooling system are switched on automatically and the air distribution is

automatically set to position

SYNC

Applies the temperature settings for the driver side to the passenger side: If the

indicator light in the

SYNC

button comes on, the temperature settings for the driver

side also apply to the passenger side.

Press the button or turn the temperature knob for the passenger side to set a

different temperature for the passenger side. The indicator light in the button goes

out.

AUTO

Automatic temperature control, fan speed, and air distribution.

Press the

AUTO

button to switch on the feature. The indicator light in the button

comes on.

OFF

Press the

OFF

button. If the system is switched off, the indicator light in the

OFF

button lights up.

WARNING

Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions,
and serious personal injury.

Never switch off the fan for a long time because no fresh air will enter the passenger

compartment.

Operation

Please first read and note the introductory information and heed the WARNINGS

The air conditioner works only when the ignition is switched on. The cooling system for the passenger
compartment works only when the engine is running and the fan is on.

The air conditioner is most efficient when the windows and the power sunroof are closed. If the vehicle
is stationary and the passenger compartment becomes very hot due to sunlight, briefly opening the
windows and the power sunroof may speed up the cooling process.

Keep the air intake slots in front of the windshield free of ice, snow, and leaves so that the heating and
ventilation systems can work properly.

Settings for optimum visibility

When you switch on the cooling system, both the temperature and humidity in the vehicle are reduced.
This will help make passengers feel more comfortable and help keep the windows from fogging up.

For manual A/C

  Switch off the air recirculation, Air recirculation.
  Set the fan to the desired speed.
  Turn the temperature knob to the center position.

Open and adjust all air vents in the instrument panel

⇒ page 297, Air vents.

Turn the air distribution knob to the desired setting.
Push the button to turn on the air conditioner. The indicator light in the button lights up.

For Climatronic

Press the

AUTO

button.

Set the temperature to +72 °F (+22 °C).
Open and adjust all air vents in the instrument panel, Air vents.

Climatronic: Changing the temperature unit on the factory-installed Radio or Radio &
Navigation system display

The inside and outside temperatures can be displayed in either Fahrenheit (F) or Celsius (C).

Select Units in the instrument cluster display in the Settings main menu, Volkswagen Information
System.

You can also press and hold the and

AUTO

buttons to switch the Climatronic temperature display

from Celsius to Fahrenheit and vice versa.

Heating

Maximum heating output and defrosting performance are not possible until the engine has reached
operating temperature.

Air conditioner does not work

The air conditioner may not switch on for one of the following reasons:

  The engine is not running.
  The fan is switched off.
  The air conditioner fuse has blown.
  The outside air temperature is colder than about +38 °F (+3 °C).
  The air conditioner compressor has been temporarily switched off due to excessive engine coolant

temperature.

There is another malfunction in the vehicle. Have the air conditioner checked by an authorized

Volkswagen dealer or authorized Volkswagen Service Facility.

Special considerations

When it is very hot and humid outside, water condensation can drip from the air conditioner
evaporator and form a puddle under the vehicle. This is normal and does not indicate a leak.

The climate control system adjusts the passenger compartment temperature as fast as possible

considering the outside temperature.

Due to residual moisture in the air conditioner, the windshield may fog up after the engine is

started. Switch on the windshield defroster to help evaporate the condensation as quickly as possible.

Air vents

Fig. 136 In the instrument panel: Air vents.

Please first read and note the introductory information and heed the WARNINGS

Air vents

To help ensure sufficient heating, cooling and ventilation in the passenger compartment, never close

the air vents completely

⇒

fig. 136

(1)

To open and close the air vents, turn the respective thumbwheel (magnified view) in the desired

direction. When the thumbwheel is in the

position, the air vent is closed.

Use the lever on the vent grille to adjust the airflow direction.

Additional, non-adjustable air vents are located in the instrument panel

(2)

, in the footwells, as well as

in the rear area of the passenger compartment.

NOTICE

Do not place food, medications, or other heat-sensitive things in front of the air vents. Food,
medications, and other things that are sensitive to heat or cold can be damaged or made
unusable by the air flow from the vents.

Air recirculation

Please first read and note the introductory information and heed the WARNINGS

General information

There are different types of air recirculation:

Manual air recirculation (manual A/C).

The left indicator light under the button comes on: manual air recirculation is switched
on (Climatronic).

The right indicator light under the button comes on: automatic air recirculation is
switched on (Climatronic).

The air recirculation mode helps prevent outside air from entering the vehicle interior.

In very hot outside temperatures, temporarily switch to manual air recirculation in order to cool the
vehicle interior faster.

For safety reasons, air recirculation is switched off if you push the

button or the air distribution

switch is turned to

⇒

Switching manual air recirculation on and off: manual A/C

Switching on: Press the button. The indicator light in the button comes on.

Switching off: Press the button. The indicator light in the button goes out.

Switching manual air recirculation on and off: Climatronic

Switching on: Press the

button repeatedly until the left indicator light under the button comes on.

Switching off: Press the

button repeatedly until the indicator light under the button goes out.

Automatic air recirculation

In the

setting, fresh air enters the passenger compartment. If the system detects an increased

concentration of pollutants in the outside air, it automatically switches to air recirculation. As soon as
the pollutant level is back in the normal range, air recirculation is switched off.

Unpleasant odors cannot be detected by the system.

Air recirculation is not automatically activated under the following outside temperatures and
conditions:

The air conditioning is on (indicated by the light in the button) and the outside air temperature is

colder than about +38 °F (+3 °C).

The cooling system and the windshield wiper are switched off and the outside air temperature is

cooler than about +50 °F (+10 °C).

The cooling system is switched off, the outside air temperature is cooler than about +59 °F

(+15 °C), and the windshield wiper is switched on.

Switching automatic air recirculation on and off

Switching on: Press the

button repeatedly until the right indicator light under the button comes on.

Switching off: Press the

button repeatedly until no indicator light under the button is on.

It is not possible to activate automatic air recirculation when the outside air temperature is colder than
about +38 °F (+3 °C).

Temporarily deactivating the automatic air recirculation

Press the

button once to switch to air recirculation temporarily in the event of unpleasant odors.

The left indicator light comes on.

Press the

button again after more than 2 seconds to resume automatic air recirculation. The

right indicator light comes on.

WARNING

Stale air causes driver fatigue and reduces driver alertness, which can cause accidents,
collisions and serious personal injury.

Never use air recirculation mode over an extended period of time, since no fresh air will

enter the passenger compartment.

When the air conditioner is off and recirculation mode is on, condensation can quickly

form on the windows and greatly reduce visibility.

Always switch off recirculation mode when it is not needed.

NOTICE

Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation system
can leave residue on the evaporator and on the dust and pollen active carbon filter, resulting in
permanent odors whenever the air conditioner is switched on.

Climatronic: When backing up and while the automatic wiper/washer is operating, air

recirculation is briefly activated to help keep exhaust fumes from getting into the passenger
compartment.

Refueling

Introduction

In this section you’ll find information about:

Indicator lights and fuel gauge

Refueling

Fuel capacities

Refueling checklist

The fuel filler flap is located on the rear right side of the vehicle.

More information:

  Exterior views
  Fuel
  Working in the engine compartment

WARNING

Improper refueling or handling of fuel is dangerous and can cause fire, explosion, and severe
burns.

Always make sure that the fuel filler cap is screwed on all the way. This helps keep fuel

from spilling out or evaporating.

Fuel is highly flammable and explosive; it can cause severe burns and other severe

injuries.

Failure to shut the engine off while refueling and/or to insert the pump nozzle all the way

into the fuel filler neck can cause fuel to overflow and to spray out. Fuel spray and
overflowing fuel are dangerous because they can cause fire and serious personal injury.

During refueling, the engine and the ignition must be switched off for safety reasons.
Never use a mobile telephone, CB radio, or other radio equipment while refueling. The

electromagnetic radiation can cause sparks that can ignite fuel vapors and cause a fire.

Never get back into your vehicle while refueling. If in exceptional circumstances you must

get back in your vehicle while refueling, make certain that you close the door and touch metal
to discharge static electricity before touching the filler nozzle again. This helps avoid the
buildup of static electricity, which can cause sparks that can ignite fuel vapors released
during refueling.

Never smoke or have an open flame (or sparks, cigarettes, or other smoldering objects)

anywhere in or near your vehicle when refueling or filling a portable fuel container.

Follow all safety instructions and procedures that apply at the service station where you

refuel.

Never spill fuel in the vehicle or the luggage compartment.

WARNING

Even if empty, portable fuel containers can leak and cause a fire and serious personal
injuries, especially in a crash.

For your safety, we strongly recommend that you do not travel with a portable fuel

container in your vehicle.

If, under exceptional circumstances, you must transport a portable fuel container, please

observe the following:

– Never fill a portable fuel container while it is anywhere in or on the vehicle (for
example, in the luggage compartment or on top of the luggage compartment lid). Static
electricity can build up while filling and can ignite fuel vapors, causing a fire.

– Always place a portable fuel container on the ground before filling. Never spill fuel
inside the vehicle or luggage compartment. Fuel vapors are highly flammable.

– Always keep the filler nozzle completely inside the portable container before and
during filling.

– If filling a portable container made of metal, the filler nozzle must always be in contact
with the container. This will help prevent static electricity from discharging and causing a
fire.

– Always observe local and state or provincial laws about the use, storage, and
transportation of portable fuel containers.

– Make certain that the portable fuel container meets industry standards, such as
ANSI/ASTM F852-86.

NOTICE

Remove fuel spills from the vehicle immediately to help prevent damage to the paint, tires,

and wheel housings.

Refueling with gasoline when your vehicle has a diesel engine or refueling with diesel fuel

when your vehicle has a gasoline engine can cause very serious and expensive engine and
fuel system damage that is not covered by any Volkswagen Limited Warranty.

If you put any amount of incorrect fuel in the fuel tank, do not start the engine under any

circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized
Volkswagen Service Facility for assistance. These fuels contain substances that can severely
damage the fuel system and the engine if the engine is started.

Fuels can pollute the environment. Spilled fuel must be collected and disposed of properly,

following all applicable environmental regulations.

There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer

or an authorized Volkswagen Service Facility for assistance.

Volkswagen Jetta GLI (2014 year). Instruction - part 15
