Temperature: A, B or C

For example: Treadwear 200, Traction AA, Temperature A.

All passenger car tires must conform to Federal Safety Requirements in addition to these grades.

Treadwear

The treadwear grade is a comparative rating based on the wear rate of the tire when tested under
controlled conditions on a specified government test course.

For example, a tire graded 150 (Treadwear-value 150) would wear one-and-one-half (1 1/2) times as
well on the government course as a tire graded 100.

The relative performance of tires depends upon the actual conditions of their use, however, and may
depart significantly from the norm due to variations in driving habits, service practices and differences
in road characteristics and climate.

Traction

The traction grades, from highest to lowest, are AA, A, B and C. Those grades represent the tire's
ability to stop on wet pavement as measured under controlled conditions on specified government test

surfaces of asphalt and concrete. A tire marked C may have poor traction performance

⇒

Temperature

The temperature grades are A (the highest), B, and C representing the tire's resistance to the
generation of heat, and its ability to dissipate heat when tested under controlled conditions on a
specified indoor laboratory test wheel.

Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and
excessive temperature can lead to sudden tire failure.

The grade C corresponds to a level of performance which all passenger car tires must meet under the
Federal Motor Vehicle Safety Standard No. 109. Grades B and A represent higher levels of

performance on the laboratory test wheel than the minimum required by law

⇒

WARNING

The traction grade assigned to this tire is based on straight-ahead braking traction tests, and
does not include acceleration, cornering, hydroplaning or peak traction characteristics.

WARNING

The temperature grade for this tire is established for a tire that is properly inflated and not
overloaded. Excessive speed, underinflation or excessive loading, either separately or in
combination, can cause heat buildup and possible tire failure.

Tire Pressure Monitoring System (TPMS)

Introduction

In this section you’ll find information about:

Indicator light (telltale)

Tire Pressure Monitoring System (TPMS) and recalibration with the SET button

Your vehicle's Tire Pressure Monitoring System (TPMS) uses the Anti-lock Brake System (ABS)
sensors to indirectly check the tire pressure of all 4 tires while you are driving. The sensors monitor the
tread circumference (rolling circumference) and vibration characteristics of the individual tires. TPMS
warns if there is a significant loss of pressure in one or more tires while the vehicle is moving.
Pressure loss is signaled by the indicator light (described below) as well as by acoustic warnings
and text warnings in the instrument cluster display if your vehicle has this display (Multi-Function
Indicator - MFI).

The original benchmark pressure is the recommended maximum load cold tire inflation pressure for
the tires that come with your vehicle. This pressure is listed on the tire pressure label on the driver
door jamb Tire inflation pressure. After adjusting the tire pressures in all 4 tires, you must confirm and
store the new cold inflation pressures by pressing the SET button, which changes the benchmark
pressure to match the current pressure of the tires on your vehicle, Tire Pressure Monitoring System
(TPMS) and recalibration with the SET button.

Recalibrating the TPMS to reset the benchmark cold tire inflation pressure with proper use of the SET
button is explained below, Tire Pressure Monitoring System (TPMS) and recalibration with the SET
button.

More information:

  Volkswagen Information System
  Transporting
  Tires and wheels
  Braking and parking
  Exterior care and cleaning
  Parts, accessories, repairs and modifications
  Consumer information

WARNING

Incorrect tire pressures and/or underinflation can cause sudden tire failure, loss of control,
collision, serious personal injury or even death.

When the warning symbol appears in the instrument cluster, stop and inspect the tires.
Incorrect tire pressure and/or underinflation can cause increased tire wear and can affect

the handling of the vehicle and stopping ability.

Incorrect tire pressures and/or underinflation can also lead to sudden tire failure,

including a blowout and sudden deflation, causing loss of vehicle control.

The driver is responsible for the correct tire pressures for all tires on the vehicle. The

recommended tire pressure values are listed on a sticker inside the driver door, Tire inflation
pressure.

The TPMS can only work correctly when all tires on the vehicle are filled to the correct

cold tire inflation pressure.

Using incorrect tire pressure values can cause accidents or other damage. Always inflate

the tires to the correct specified cold tire pressure values for the tires installed on the vehicle.

  Always maintain correct cold tire inflation pressure so that TPMS can do its job.
  Always inflate tires to the recommended and correct tire pressure before driving off.
  Driving with underinflated tires causes them to flex (bend) more, letting them get too hot,

resulting in tread separation, sudden tire failure, and loss of control.

Excessive speed and/overloading can cause heat build-up, sudden tire failure and loss of

control.

If the tire pressure is too low or too high, the tires will wear prematurely and the vehicle

will not handle well.

If the tire is not “flat” and you do not have to change a wheel immediately, drive carefully

and at reduced speed to the nearest service station to check the tire pressure and add air as
required.

When replacing tires or wheel rims on vehicles equipped with TPMS always read and heed

the information and all WARNINGS regarding, Tires and wheels.

The Tire Pressure Monitoring System must be recalibrated using the SET button whenever

you remove and remount or change any wheel or tire on the vehicle, even if the reinstalled or
replacement wheels and tires are identical to those that were removed and even if the tire
pressure does not change, Tire inflation pressure.

WARNING

Improper use of the SET button can cause the TPMS to give false warnings or to give no
warning despite dangerously low tire pressure, Tire Pressure Monitoring System (TPMS) and
recalibration with the SET button.

Underinflation increases fuel consumption and tire wear.

Do not rely solely on the Tire Pressure Monitoring System. Check your tires regularly to make

sure they are properly inflated and have no signs of damage, such as punctures, cuts, cracks, and
blisters. Remove any objects that become embedded in the tire tread but have not penetrated into the
body of tire itself.

When you take delivery of the vehicle, the Tire Pressure Monitoring System is calibrated for the

factory-recommended cold tire inflation pressure for the tires on your vehicle, as shown on the label
inside the driver door, Tire inflation pressure.

The system must be recalibrated using the SET button whenever you remove and remount or

change any wheel or tire on the vehicle, even if the reinstalled or replacement wheels and tires are
identical to those that were removed and even if the tire pressure does not change, Tire Pressure
Monitoring System (TPMS) and recalibration with the SET button.

If you have to adjust the tire pressure on a warm tire, fill the tire with 2.0 - 4.35 psi (20 - 30 kPa)

more than the pressure specified on the tire pressure label inside the driver door, Tire inflation
pressure.

If the TPMS determines that the air pressure in at least one tire is too low, carefully check the

pressure in all 4 tires with an accurate tire pressure gauge. Low tire pressure usually cannot be
determined by looking at the tire. This is especially true of low-profile tires.

If you have work done on your wheels or tires, inform the workshop that the vehicle is equipped

with a Tire Pressure Monitoring System (TPMS).

New tires may expand slightly the first time they are driven at high speeds, which can trigger a

tire pressure warning. Remember that tire pressure can only be properly measured when the tire is
“cold”

Only replace old tires with tires that have been approved by Volkswagen for your vehicle type.

Indicator light (telltale)

Please first read and note the introductory information and heed the WARNINGS

Lights up Possible cause or meaning

⇒

Proper response

Lights up and a chime may also sound.
The inflation pressure of one or more
tires is significantly lower than the
benchmark pressure set by the driver or
a tire has structural damage.
Depending on vehicle equipment, a
message may also appear in the
instrument cluster display.

Stop safely as soon as possible!

Reduce speed immediately! Avoid fast
cornering and hard braking!
Check the condition and inflation pressure of
all tires. Have damaged tires replaced.

Flashes

Possible cause or meaning

⇒

Proper response

Flashes for about 70 seconds and then
stays on:
System malfunction.

Check and, if necessary, adjust the tire
inflation pressure in all 4 tires. If the tire
pressure is correct, switch the ignition off
and back on. If the indicator light flashes
again and then stays on or does not go out
after checking and adjusting the air pressure
in all 4 tires and pressing the SET button,
take the vehicle to an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility. Have the
system checked.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.

WARNING

Incorrect tire pressures and/or underinflation can cause sudden tire failure, loss of control,
collision, serious personal injury, or even death.

When the warning symbol appears in the instrument cluster, stop the vehicle as soon

as it is safe to do so and inspect all tires.

Incorrect tire pressure and/or underinflation can cause increased tire wear and can affect

the handling of the vehicle and its stopping ability.

Incorrect tire pressure and/or underinflation can also lead to sudden tire failure, including

a blowout and sudden deflation, causing loss of vehicle control.

The driver is responsible for the correct tire pressures for all tires on the vehicle. The

recommended tire pressure values are listed on a sticker inside the driver door, Tire inflation
pressure.

The TPMS can only work correctly when all tires on the vehicle are filled to the correct

cold tire inflation pressure. Always maintain the correct cold tire inflation pressure so that
TPMS can do its job.

Using incorrect tire pressure values can cause accidents or other damage. Check the

pressure in all 4 tires when the tires are still cold. Never reduce air pressure in warm tires to
match cold tire inflation pressure.

Always inflate the tires to the correct specified cold tire pressure values for the tires

installed on the vehicle; see the tire inflation pressure label on the driver door jamb, Tires and
wheels.

Always inflate tires to the recommended and correct tire pressure before driving off.
Driving with underinflated tires causes them to flex (bend) more, letting them get too hot,

which can result in tread separation, sudden tire failure, and loss of control.

Excessive speed and/or overloading can cause heat build-up, sudden tire failure, and loss

of control.

If the tire pressure is too low or too high, the tires will wear prematurely and the vehicle

will not handle well.

If the tire is not “flat” and you do not have to change the tire or wheel immediately, drive at

reduced speed to the nearest service station to check the tire pressure and add air as
required.

When replacing tires or wheel rims on vehicles equipped with TPMS, always read and

heed the information and all WARNINGS in the section, Tires and wheels.

The Tire Pressure Monitoring System must be recalibrated using the SET button whenever

WARNING

WARNING

Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.

Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.

NOTICE

Failure to heed warning lights or text WARNINGS can result in vehicle damage.

If the ignition is switched on, an acoustic warning sounds when low tire pressure is detected. If a

system malfunction is detected, no acoustic warning sounds.

Driving for a longer period of time on rough roads or with a dynamic and sporty style can make

the TPMS system temporarily unavailable. The indicator light will come on, signaling a malfunction, but
will go out again once the road condition or driving style changes.

Tire Pressure Monitoring System (TPMS) and recalibration with the SET
button

Fig. 97 In the glove compartment: SET button for the Tire Pressure Monitoring System.

Please first read and note the introductory information and heed the WARNINGS

Your vehicle's Tire Pressure Monitoring System (TPMS) indirectly checks the tire pressure of all 4 tires
while you are driving by using the Anti-lock Brake System (ABS) sensors to monitor the tread
circumference (rolling circumference) and vibration characteristics of the individual tires.

The tread circumference of a tire can change:

  If a tire's inflation pressure is too low.
  If the tire's tread is damaged or the tire is structurally damaged.
  If one side of the vehicle is more heavily loaded than the other.
  If there is more weight on one axle than the other (such as when towing a trailer).
  If a compact spare wheel has been mounted.
  If a wheel was replaced on each axle.
  If a tire was changed.
  If the tire pressure was changed, or wheels were rotated or replaced, but the TPMS was not reset.

If there are snow chains on the tires. Using snow chains can cause the system to give false

warnings because snow chains increase tire circumference.

The Tire Pressure Monitoring System may not react at first or may not react at all when you are
driving in a sporty manner, or on snow-covered or unpaved roads, when you are driving with snow
chains, or in certain other situations. A change in the tread circumference of a tire is signaled by the
Tire Pressure Monitoring System indicator in the instrument cluster (telltale).

The tire pressure recommended for the tires originally installed on the vehicle is on a sticker on the
driver door jamb, Tire inflation pressure.

Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the
inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation
pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle
placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those
tires.)

As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System
(TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly
underinflated. Accordingly, when the low tire pressure telltale illuminates, you should stop and check
your tires as soon as possible, and inflate them to the proper pressure. Driving on a significantly
underinflated tire causes the tire to overheat and can lead to tire failure. Underinflation also reduces
fuel efficiency and tire tread life, and may affect the vehicle's handling and stopping ability.

Please note that the TPMS is not a substitute for proper tire maintenance, and it is the driver's
responsibility to maintain correct tire pressure, even if underinflation has not reached the level to
trigger illumination of the TPMS low tire pressure telltale.

Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system
is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure
telltale. When the system detects a malfunction, the telltale will flash for approximately 1 minute and
then remain continuously illuminated. This sequence will continue upon subsequent vehicle start-ups
as long as the malfunction exists.

When the malfunction indicator is illuminated, the system may not be able to detect or signal low tire
pressure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation
of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning
properly. Always check the TPMS malfunction telltale after replacing one or more tires or wheels on
your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue
to function properly.

Resetting and recalibrating the benchmark tire pressure

The SET button for the Tire Pressure Monitoring System is in the glove compartment

⇒

fig. 97

. The

SET button resets the benchmark tire pressure used by the TPMS to the current tire pressure in the
tires based on the circumference of the tires. To reset the TPMS, switch on the ignition and then press
and hold the SET button until you hear a confirmation chime. The chime usually sounds after a couple
of seconds. The SET button must be pressed for at least 2 seconds but no more than 30 seconds
each time the tire pressure in one or more tires has been adjusted or after one or more tires has been
changed, exchanged, or repaired. The new tire pressures are stored in the system only after at least
20 minutes of normal driving.

If you use the SET button to reset the benchmark tire pressure when your tires do not have the correct
tire pressure, this will prevent the TPMS from working properly. It may then give false warnings or may
not give any warning even if the tire pressure is too low.

For this reason, it is vital to make certain that all 4 tires are inflated to the correct pressure
when they are cold before pressing the SET button. Cold tire tires are tires that have not been
driven more than a couple of miles (kilometers) at low speed within the last 3 hours.

Use the SET button to reset the benchmark TPMS pressure in the following situations:

After installing tires on your vehicle that have recommended cold tire inflation pressures that are

different from the tires that were taken off.

After any tire on your vehicle is removed and then remounted, even if the same tire and wheel rim

that were taken off are reinstalled (for instance, after repair).

After any tire on your vehicle is changed and replaced by another tire, even if the replacement tire

is the same type and is inflated to the same pressure as the tire it replaced.

After adjusting the tire pressure of any tire on the vehicle to its correct cold tire inflation pressure,

either by putting air in one or more tires or by letting air out. Do this even though air was only added
(or let out) to bring the tire to the inflation pressure it should have had all along.

After rotating the front and rear wheels, Tires and wheels.
After mounting the compact spare wheel.

WARNING

Improper use of the SET button can cause the TPMS to give false warnings or to give no
warning despite dangerously low tire pressure. Make certain the tire inflation pressure of all
tires is correct before using the SET button.

WARNING

Incorrect tire pressure can cause sudden tire failure, loss of vehicle control and serious
personal injury.

Always check and correct air pressure in all 4 tires, particularly after changing,

exchanging, or repairing tires.

After that, always make sure that all 4 tires are inflated to the correct tire pressure for the

tires installed on the vehicle. Then push the SET button for the Tire Pressure Monitoring
System (TPMS) so that it can properly monitor the pressure in the tires.

Press and hold the SET button until the confirmation chime sounds. Hold the SET button

for at least 2 seconds, but not more than 30 seconds.

See the tire pressure label, Tire inflation pressure and the Owner's Literature for

recommended cold tire inflation pressure and other important information.

When replacing tires or wheel rims, always read and heed all of the information and

WARNINGS, Tires and wheels.

The Tire Pressure Monitoring System must be recalibrated using the SET button whenever

The Tire Pressure Monitoring System stops working if there is an ESC/ABS malfunction, Braking

and parking.

After a low tire pressure warning, the vehicle must stand and must not be driven for at least

1 minute before the SET button can be used to store a new benchmark tire pressure.

Storage areas

Introduction

In this section you’ll find information about:

Storage compartment in the doors

Eyeglass storage compartment in the overhead console

Storage compartment in the front center console

Storage compartment in the front center armrest

Glove compartment

Storage compartment in the rear center console

Store only lightweight or small objects in storage compartments.

Depending on options, there may be a factory-installed AUX-IN jack and a 12 Volt socket in the front
center console storage compartment.

A Media Device Interface (MDI)/(MEDIA-IN) jack may be in the center armrest storage compartment,
Storage compartment in the front center armrest.A Media Device Interface (MDI)/(MEDIA-IN) jack
may be in the glove compartment, Glove compartment.

More information:

  Passenger compartment
  Power locking and closing system
  Driver assistance systems
  Interior care and cleanin

⇒ booklet

Radio or ⇒ booklet Navigation system

WARNING

Loose objects can be thrown around the inside of the vehicle when the vehicle is moving,
especially during sudden maneuvers and hard braking. This can cause serious personal
injuries and even make the driver lose control of the vehicle.

Never let animals ride in the vehicle's open storage compartments, on top of the

instrument panel, or on the shelf behind the rear seat backrests.

Never put hard, heavy or sharp objects in these places or in articles of clothing or bags in

the passenger compartment.

Always keep storage compartments closed while driving.

WARNING

Objects in the driver footwell can prevent the pedals from moving freely. This can cause loss
of vehicle control and increase the risk of serious personal injuries.

  Always make sure that nothing can interfere with the pedals.
  Always fasten floor mats securely to the floor.
  Never put floor mats or other floor coverings on top of already installed floor mats.

Always make sure that nothing can fall into the driver footwell while the vehicle is moving.

WARNING

Some kinds of cigarette lighters can be lit unintentionally, or crushed causing a fire that can
result in serious burns and vehicle damage.

Always make sure that there are no lighters in the seat tracks or near other moving parts

before adjusting the seats.

Before closing a storage compartment, always make sure that no cigarette lighter can be

activated, crushed, or otherwise damaged.

Never leave a cigarette lighter in a storage compartment, on the instrument panel, or in

other places in the vehicle. Heat buildup in the passenger and luggage compartment of a
parked vehicle can result in temperatures in the vehicle that are much higher than the outside
temperatures, particularly in summer. High temperatures could cause the cigarette lighter to
catch fire.

NOTICE

The defroster heating wires or antenna in the rear window can be damaged by hard or sharp

things on the shelf below the rear window.

Do not keep any food, medicine, or other items sensitive to heat or cold in the vehicle. They

can be damaged or made unusable by heat or cold.

Things that are made of transparent materials (such as eyeglasses, magnifying glasses, or

transparent suction cups on the windows) can magnify sunlight and damage the vehicle.

Storage compartment in the doors

Fig. 98 In the driver door: Storage compartment.

Please first read and note the introductory information and heed the WARNINGS

There is a storage compartment in each vehicle door

⇒

fig. 98

Eyeglass storage compartment in the overhead console

Fig. 99 In the overhead console: Storage compartment.

Please first read and note the introductory information and heed the WARNINGS

This storage compartment can be used for storing eyeglasses or other light objects.

To open, briefly press and release the button

⇒

fig. 99

(arrow) on the storage compartment cover.

To close, push the lid up until it latches.

Storage compartment in the front center console

Fig. 100 In the front center console: Storage compartment.

Please first read and note the introductory information and heed the WARNINGS

There may be a 12 Volt socket, 12 Volt sockets in the vehicle or an AUX-IN jack

⇒ booklet

Radio or

⇒booklet

Navigation System in the front center console storage compartment.

Storage compartment in the front center armrest

Fig. 101 In the front center armrest: Storage compartment.

Fig. 102 Inside the front center armrest storage compartment: MDI (MEDIA-IN) jack.

Please first read and note the introductory information and heed the WARNINGS

Depending on equipment, your vehicle may have a storage compartment under the front center
armrest.

To open, push the release button (small arrow) and lift the center armrest up as far as it will go in the

direction of the large arrow

⇒

fig. 101

To close, put the center armrest down.

There may be a factory-installed Media Device Interface (MDI)/(MEDIA-IN) jack in the front center

armrest storage compartment

⇒

fig. 102

⇒ booklet

Radio, or ⇒ booklet Navigation system.

WARNING

The center armrest can restrict the driver's arm movement and cause crashes and serious
personal injury.

Always keep storage compartments in the center armrest closed while driving.

WARNING

Never let a passenger, especially a child, ride on the center armrest.

A phone holder for the mobile phone package may be in the upper section of the center armrest

storage compartment

⇒ booklet

Mobile Phone Package.

Glove compartment

Fig. 104 On the passenger side: Glove compartment.

Fig. 105 Inside the glove compartment.

Please first read and note the introductory information and heed the WARNINGS

Key to

⇒

fig. 105

(1)

Owner's Manual in Owner's Manual slot

(2)

Holders for pen and coins

(3)

SET button for Tire Pressure Monitoring System (TPMS)

Tire Pressure Monitoring

System (TPMS) and recalibration with the SET button

Opening and closing the glove compartment

If necessary, unlock the glove compartment. It is locked when the key slot is vertical.

To open, pull the handle

⇒

fig. 104

To close, push the lid up.

Owner's Manual slot

The slot at the top of the glove compartment is designed to hold the Owner's Manual.

The Owner's Manual is in this glove compartment slot

⇒

fig. 105

(1)

Always keep the Owner's Manual in this slot.

Holders for pen and coins

There are holders for a pen and for coins in the glove compartment cover

(2)

Button in the glove compartment

The Tire Pressure Monitoring System (TPMS) SET button is also located in the glove compartment

(3)

Cooling the glove compartment

There may also be an air vent in the back of the glove compartment. Cool air can be directed into the
glove compartment if the air conditioner is on. Open or close the air vent by turning it.

WARNING

An open glove compartment door can increase the risk of serious injury during sudden
braking or driving maneuvers or in a crash.

Always keep the glove compartment closed while the vehicle is moving.

NOTICE

Vehicles equipped with a Media Device Interface (MDI)/(MEDIA-IN) jack, Storage compartment
in the front center armrest also have an electrical connection in the glove compartment that
connects the MDI to the vehicle electronics. If the cable in the glove compartment is
unplugged, the MDI will not work.

NOTICE

In some vehicle models, design considerations have made it necessary to have openings in the
glove compartment behind the Owner's Manual slot, for example. Small items may fall through
these openings and get behind the instrument panel. This can cause unusual noises and
damage the vehicle. Never put any small objects in the glove compartment for this reason.

Storage compartment in the rear center console

Fig. 108 In the rear center console: Storage compartment.

Please first read and note the introductory information and heed the WARNINGS

There may be storage compartments for stowing small objects

⇒

fig. 108

in the back of the center

console.

Other storage compartments

Please first read and note the introductory information and heed the WARNINGS

Additional storage:

  In the center console.
  Pockets in the backrests of the front seats.
  Shelf behind the rear seat backrest – only for light clothing or similar objects that do not interfere

with visibility to the rear!

Coat hooks on the center door pillars and on the overhead grab handles in the rear.

WARNING

Clothes or other items on the shelf behind the rear seat backrest may limit visibility and
cause accidents and severe personal injuries.

Always hang clothes so that they do not limit visibility.
Always use the built-in coat hooks only for lightweight clothing. Never leave any heavy or

sharp-edged items in the pockets that may interfere with airbag deployment and can cause
personal injury in a collision.

Cup holders

Introduction

In this section you’ll find information about:

Cup holders in the front center console

Cup holders in the rear center armrest

Beverage bottle holders

There is a place for bottles in the open compartments in the driver and passenger doors. The bottle

volume must not exceed 24 oz (0.5 liter)

⇒

More information:

Interior care and cleaning

WARNING

Improper use of beverage holders can cause injuries.

Never put hot drinks in the cup holders. During normal or sudden maneuvers, sudden

braking or in a collision, hot liquid can be spilled and cause burns!

Make certain that bottles or other items cannot fall into the driver's footwell while the

vehicle is moving and interfere with the movement of the pedals.

Never put heavy cups, food or other heavy items in the cup holders. Heavy items can fly

through the passenger compartment in a crash and cause serious injury.

WARNING

Hot or freezing temperatures in the passenger compartment can cause closed bottles to
explode or break.

Never leave closed bottles in a very hot or cold vehicle.

WARNING

Bottles and other things can fall into the driver's footwell and interfere with the pedals while
driving.

Make sure that bottles cannot fall into the driver's footwell during driving to avoid

obstructing the pedals.

Use the bottle holders only for standard beverage bottles holding no more than 24 oz

(0.5 liter).

NOTICE

Never put open drinks in the cup holder when the vehicle is moving. The drinks can spill and
damage the vehicle, including the electrical system.

Some cup holder inserts can be removed for cleaning.

Content .. 9 10 11 12 ..
