Volkswagen Golf SportWagen (2015 year). Instruction

Cleaning and changing the windshield wiper blades

Fig. 173 Changing the windshield wiper blades.

Fig. 174 Changing the rear window wiper blades.

Please first read and note the introductory information and heed the WARNINGS

Factory-installed wiper blades have a graphite coating. The graphite coating lets the wiper blades glide
smoothly over the windshield. If this coating is worn or damaged, the wipers may grab or squeak.

Check all wiper blades regularly. Wiper blades that grab and squeak must be replaced if worn or

damaged and cleaned if dirty

⇒ .

Replace worn or damaged wiper blades immediately. Replacement blades may be purchased from
any authorized Volkswagen dealer or authorized Volkswagen Service Facility.

Lifting and tilting windshield wiper arms

Move the wiper arms to the service position before lifting them away from the windshield

⇒ Wind-

shield wipers and washer.

It is not possible to lift the wiper arms away from the windshield when they are not in the service
position.

When lifting or replacing a wiper blade on a window, grip it only by its mounting and not by the blade
itself.

Cleaning the wiper blades

Lift the wiper arm(s) away from the windshield.
Using a soft cloth, carefully remove dust and dirt from the wiper blades.

If the blades are very dirty, carefully clean them with a sponge or cloth

⇒ .

Carefully fold the wiper arm back down onto the windshield.

Changing the wiper blades on the windshield

Lift the wiper arm(s) away from the windshield.

Press and hold the release button

⇒

fig. 173

(1)

While lifting the wiper blade in the direction of the wiper arm, pull off the wiper blade in the direction

of the arrow. This may require moderate force.

Install a new wiper blade of same length and type onto the wiper arm by pushing in the opposite

direction of the arrow until it latches.

Carefully fold the wiper arm back down onto the windshield.

Changing the rear window wiper blade

Lift the wiper arm away from the window.

Press and hold the release button

⇒

fig. 174

(1)

While lifting the wiper blade in the direction of the wiper arm

⇒

fig. 174

(arrow

(A)

), pull off the

wiper blade in the direction of the arrow

(B)

. This may require moderate force.

Install a new wiper blade of the same length and type onto the wiper arm by pushing in the oppo-

site direction of the arrow

(B)

until it latches.

Carefully fold the wiper arm back down onto the window.

WARNING

Worn or dirty wiper blades reduce visibility and increase the risk of accidents and severe
injuries.

Always change wiper blades if they are damaged or worn, and if they cannot clean the

windows sufficiently.

NOTICE

Damaged or dirty wiper blades can scratch the windshield.
Solvents, abrasive sponges and sharp-edged objects will damage the graphite coating on

the wiper blades.

Do not clean the windows with gasoline, nail polish remover, paint thinner or similar fluids.
To help prevent damage to the engine hood and the windshield wiper arms, lift the wiper

arms away from the windshield only when they are in the service position.

Waxing and polishing vehicle paint

Please first read and note the introductory information and heed the WARNINGS

Waxing

A good coat of wax helps to protect the vehicle paint. When water no longer forms small drops and
runs off when the paint is clean, apply a new coat of good hard wax to protect the vehicle again.

Even if a wax solution is used regularly at the car wash, Volkswagen recommends applying a coat of
hard wax at least twice a year to protect the paint.

Polishing

Polish your vehicle if the paint has lost its shine and the gloss cannot be brought back with wax.

The vehicle must be waxed after polishing if the polish used does not contain wax compounds to seal
the paint.

NOTICE

To help prevent damage, do not use hard wax or polish on matte-finished parts, plastic

parts, headlights or rear lights.

Do not wax or polish your vehicle if it is dirty, or in a sandy or dusty place.

Caring for and cleaning chrome and aluminum parts

Please first read and note the introductory information and heed the WARNINGS

Clean the surface using a clean, soft, lint-free cloth dampened with water.
If the surface is especially dirty, use a special solvent-free cleaning material.

Then polish chrome and aluminum parts with a soft, dry cloth.

NOTICE

To help prevent damage to chrome and aluminum parts:

  Do not clean or polish in direct sunlight.
  Do not clean or polish in sandy or dusty places.
  Do not use abrasive cleaners or abrasive sponges.
  Do not polish dirty surfaces.
  Do not use cleaning materials that contain solvents.
  Do not use hard wax.

NOTICE

Chrome wheel covers and hubcaps can have an extra coating. Do not treat them with chrome
care or polishing products. Use regular paint care and polishing products.

Cleaning wheel rims

Please first read and note the introductory information and heed the WARNINGS

Cleaning steel wheels

Stubborn brake dust can be removed with an industrial cleaner. Clean steel wheels regularly with a
separate sponge.

Repair any paint damage on steel wheels before rust begins to form.

Cleaning alloy wheels

Every 2 weeks: Wash road salt and brake dust off alloy wheels, and clean the wheels with an acid-
free detergent. Every 3 months: Volkswagen recommends applying a hard wax compound to the
wheels.

If road salt and brake dust are not removed regularly, they can corrode the metal.

Use an acid-free detergent specifically designed for light alloy wheels. Do not use car polish or other
abrasive products.

If the protective coating is damaged, for example by stone impact, repair the damaged area right
away.

Caring for rubber door and window seals

Please first read and note the introductory information and heed the WARNINGS

The rubber seals around the doors and windows will stay soft and flexible, seal better and last longer if
the seals are treated regularly with a suitable rubber care product.

Before applying the treatment, use a soft cloth to remove dust and dirt from the rubber seals.

Do not apply any rubber care products to the rubber seals on the body in the areas around the

windows in the driver and front passenger doors. The product could run down onto the windows and
smudge them.

Deicing door lock cylinders

Please first read and note the introductory information and heed the WARNINGS

Volkswagen recommends using only genuine Volkswagen deicer spray with lubricating and anti-
corrosive properties to deice door lock cylinders.

NOTICE

Lock deicers that contain grease solvents can cause the lock cylinder to rust.

Undercoating

Please first read and note the introductory information and heed the WARNINGS

The vehicle underbody is coated to help protect it from corrosion and damage. The undercoating could
be damaged during normal use. We therefore recommend that you have the protective coatings on the
underbody and suspension inspected regularly, and repaired if necessary.

WARNING

Undercoating and rustproofing products can catch fire on the hot exhaust system or any
other hot engine component.

Never apply additional undercoating or rust proofing on or near the exhaust manifold, the

exhaust pipes, the catalytic converter, the heat shields, or any other hot vehicle component.

Cleaning the engine compartment

Please first read and note the introductory information and heed the WARNINGS

The engine compartment of a vehicle is a dangerous area

⇒ Working in the engine compartment.

If necessary, the engine compartment should be cleaned by an authorized Volkswagen dealer or
authorized Volkswagen Service Facility. Incorrect cleaning procedures could remove corrosion protec-
tion and damage electrical components, among other things. In addition, water could enter directly into

the vehicle interior through the plenum chamber

⇒ .

Never use a power washer to clean the engine compartment

⇒ .

If the engine compartment is extremely dirty, have it cleaned professionally by your authorized
Volkswagen dealer or authorized Volkswagen Service Facility.

Plenum chamber

The plenum chamber is located in the engine compartment between windshield and engine, under a
perforated cover. Outside air is taken into the vehicle interior from the plenum chamber via the climate
control system.

Regularly remove leaves and other loose objects from the plenum chamber cover by hand or with a
vacuum cleaner.

WARNING

Injuries, scalding, electric shock, accidents, and fire hazards can occur while working on the
engine or in the engine compartment!

Before working in the engine compartment, be sure to familiarize yourself with the neces-

sary procedures and generally accepted safety precautions

⇒ page 338, Working in the en-

gine compartment.

Volkswagen recommends having the work performed by an authorized Volkswagen dealer

or authorized Volkswagen Service Facility.

NOTICE

Spraying or pouring water (for example, with a power washer) into the plenum chamber can
cause severe damage to the vehicle.

Wash the engine compartment only in special wash bays so that the oily dirt and fuel residue that

are washed off the vehicle will not enter the sewage system. In some areas it illegal to wash the en-
gine compartment anywhere other than at such specified locations.

Interior care and cleaning

Introduction

In this section you’ll find information about:

Caring for upholstery

Cleaning upholstery, fabric trim and Alcantara

Care and cleaning of leather upholstery

Cleaning leatherette

Cleaning storage compartments and cup holders

Care and cleaning of plastic components, wood trim and instrument panel

Cleaning the safety belts

Modern clothing fabrics such as dark denim may not be completely colorfast. Even with normal use,
dye from these and other fabrics can rub off on seat upholstery and leave visible discolorations (espe-
cially on light-colored seat upholstery). This is caused by a lack of colorfastness in the clothing fabric,
not by any fault in the seat upholstery fabric. To help prevent damage to the seat upholstery, always
make sure your clothing is colorfast. Volkswagen recommends having a qualified specialist remove
any discolorations from the seat upholstery.

The longer stains, dirt and other deposits remain on the surfaces of vehicle components and uphol-
stery, the more difficult it may be to clean them. If stains, dirt and deposits are left untreated for a long
time, they may become impossible to remove.

More information:

Exterior care and cleaning
Parts, accessories, repairs, and modifications

WARNING

Vehicle care products can be dangerous. Improper use can cause accidents, burns, poison-
ing, or other serious personal injuries.

  Always store vehicle care products only in original containers that are securely closed.
  Always read and heed all the instructions and all WARNINGS on the package.
  To reduce the risk of poisoning, never use empty food or beverage containers that might

mislead someone into drinking from them.

Always keep vehicle care products out of the reach of children.
Always use such products outdoors or in well-ventilated areas, because harmful vapors

may be released when these products are used.

Never use fuel, turpentine, engine oil, nail polish remover or other volatile fluids for vehi-

cle care. They are poisonous and highly flammable.

WARNING

Improper care and cleaning of vehicle components can compromise the vehicle's safety fea-
tures and cause serious personal injury.

Always clean and maintain vehicle components according to manufacturer's instructions.

Only use approved or recommended cleaners.

NOTICE

Vehicle care products containing solvents can cause irreparable damage to plastics and

other vehicle materials.

Stains, dirt and other deposits that contain aggressive substances or solvents can corrode

vehicle materials and cause permanent damage, even after brief contact with the surface.

Remove stains, dirt, and other deposits as quickly as possible and do not allow them to dry.
To help prevent damage, have stubborn stains removed by a professional who has the

necessary expertise and experience.

Suitable care products are available from authorized Volkswagen dealers and authorized

Volkswagen Service Facilities.

Caring for upholstery

Please first read and note the introductory information and heed the WARNINGS

Checklist

Please note the following when it comes to the care and preservation of the upholstery

⇒ :

Open Velcro

fasteners can damage upholstery, fabric, and trim. Before you get into the vehicle,

close all Velcro

fasteners that could come into contact with upholstery fabrics and cloth trim.

Sharp-edged objects and items on clothing and belts (such as belt clips, mobile phone cases,

zippers, rivets, and rhinestones) can damage upholstery material and fabric trim. To help prevent
damage, do not let such items come into direct contact with the upholstery and fabric trim.

Dust and dirt particles in pores, folds, and seams can have a “scouring” effect on material and

damage the surface. Remove dust and dirt regularly to help prevent permanent surface damage.

Check clothing for color-fastness to help prevent upholstery discoloration, especially to light-

colored upholstery.

NOTICE

Disregarding the upholstery-related checklist may lead to damage or discoloration of uphol-
stery and fabric trim.

Please note and follow the points listed in the checklist.

Volkswagen recommends having any discoloration removed by an authorized Volkswagen dealer

or authorized Volkswagen Service Facility.

Cleaning upholstery, fabric trim and Alcantara

Please first read and note the introductory information and heed the WARNINGS

Cleaning upholstery on heated seats and power seats or seats with airbag components

Airbag components and electrical connectors may be installed in the driver seat, the front passenger
seat, and in the outer rear seats. Damaging, cleaning and handling incorrectly, or wetting or soaking
these seat surfaces and backrests can damage the vehicle electrical system and prevent the airbag

system from working properly

⇒ .

Electrical components and connectors that could be damaged by incorrect cleaning or handling are

installed in power seats and heated seats

⇒ . This can also result in damage to other parts of the

vehicle electrical system.

For this reason, read and follow these cleaning instructions:

  Do not use power washers, steam cleaners, or cooling spray.
  Do not use detergent pastes or mild detergent solutions.
  Do not wet the surface completely.
  Only use cleaning products approved by Volkswagen.
  If you have questions or concerns, consult a professional cleaner.
  Before using any cleaning agent, familiarize yourself with instructions and warnings on the packag-

ing.

Vacuum upholstery, fabric trim, Alcantara

upholstery, and carpeting regularly with a suitable brush

attachment.

A soft sponge or a commercially available lint-free microfiber cloth may be used for general clean-

ing

⇒ .

Clean Alcantara

surfaces with a damp cotton or wool cloth or a commercially available lint-free

microfiber cloth

⇒ .

Upholstery and fabric trim with light generalized soiling can be cleaned with a commercially available
dry-foam cleaner.

If the upholstery and fabric trim pieces are heavily soiled, see your authorized Volkswagen dealer or
authorized Volkswagen Service Facility before you begin cleaning to learn about suitable cleaning
options. If necessary, have the cleaning done by a professional.

Cleaning upholstery on non-heated seats, manual seats, or seats without airbag
components

Before using any cleaning agent, familiarize yourself with instructions and warnings on the packag-

ing.

Vacuum upholstery, fabric trim, Alcantara

upholstery, and carpeting regularly with a suitable brush

attachment.

Do not use power washers, steam cleaners, or cooling spray.
A soft sponge or a commercially available lint-free microfiber cloth may be used for general clean-

ing

⇒ .

Clean Alcantara

surfaces with a damp cotton or wool cloth or a commercially available lint-free

microfiber cloth

⇒ .

Upholstery and fabric trim with light generalized soiling can be cleaned with a commercially available
dry-foam cleaner.

Treating stains

When treating stains, it may be necessary to clean the entire surface and not just the stain itself. This
is especially true if the entire surface has become dirty from normal use. Otherwise, the area that is
treated may become lighter than the untreated area. If you have questions or concerns, consult a
professional cleaner.

Type of stain

Recommended cleaning for fabric and uphol-

stery

Water-based stains,

such as coffee or

fruit juice.

– Moisten a sponge with water and rub the stain

gently with a circular motion.

– Wipe dry with an absorbent cloth.

Persistent stains,

such as chocolate

or make-up.

– Use only Volkswagen-approved cleaning products.

– If necessary, have the fabric or upholstery profes-

sionally cleaned.

Grease-based

stains, such as oil,

lipstick, etc.

– Use only Volkswagen-approved cleaning products.

– If necessary, have the fabric or upholstery profes-

sionally cleaned.

WARNING

If there is a malfunction in the airbag system, the airbag may not deploy correctly or at all, or
it may deploy unexpectedly. This could cause fatal injuries.

Have the airbag system inspected immediately by your authorized Volkswagen dealer or

authorized Volkswagen Service Facility.

NOTICE

If the upholstery on power seats, heated seats, or seats with airbag components is wet, electri-
cal components and the vehicle electrical system could be damaged.

If the seating surface becomes soaked, have it dried and the system components checked

immediately by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

Do not use steam cleaners because the steam could cause the dirt to penetrate deeper into

the fabric and make it impossible to remove.

Power washers and cooling sprays can damage the upholstery.

NOTICE

Clean only the carpet and floor mats with brushes. Other textile surfaces can be damaged

by brushes.

If detergent pastes or mild detergent solutions are applied with a damp cloth or sponge, the

surfactants in the detergent may cause visible lines to form at the edges of the area where the
detergent was applied. These lines are generally difficult or impossible to remove.

NOTICE

Do not soak Alcantara

Do not treat Alcantara

with leather care products, solvents, floor wax, shoe polish, stain

remover or similar products.

Do not use brushes for damp cleaning, because they can damage upholstery surfaces.
Do not use a steam cleaner, because dirt will penetrate deeper into the fabric.

Care and cleaning of leather upholstery

Please first read and note the introductory information and heed the WARNINGS

If you have questions regarding the care and cleaning of the leather upholstery in the vehicle, please
contact an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

Care and treatment

Natural leather requires special attention and care. Napa leather has a smooth surface. The intensity
of the color application determines the leather's appearance and texture. If you can see the leather
grain and other natural characteristics, this is an untreated napa leather that will provide very comfort-
able seating. Delicate veins, closed scars, insect bites, folds, and a slightly clouded color remain
visible and represent authentic characteristics of the natural material. Untreated napa leather has no
protective coating. It is therefore more susceptible to damage. You should keep this in mind if the
leather is going to be exposed to severe wear from children, animals, or other factors. By contrast,
leather that has a protective coating is more robust. This has a positive effect on the leather's durabil-
ity in daily use. The typical natural characteristics are hardly visible or no longer visible at all, but that
has no impact on the quality of the leather itself. The typical characteristics of untreated leather are
much more distinctive than those of a surface-treated leather.

After each cleaning, apply cream that waterproofs the leather and protects it against the sun. Such

creams also nourish the leather, let it breathe, keep it flexible and moisturized. At the same time it
protects the surface.

Clean leather every 2 to 3 months and remove any new stains.

Treat leather with a suitable leather-care product twice a year

⇒ .

Apply cleaning and conditioning materials sparingly and always with a dry, lint-free cotton or wool

cloth. Do not apply cleaning and conditioning materials directly to the leather.

Remove fresh stains such as ballpoint pen, lipstick, ink, shoe polish, etc. as soon as possible.
Preserve the leather's color. If necessary, refresh fading spots with a specially-colored leather

cream.

Wipe the leather with a soft cloth.

Cleaning

Volkswagen recommends using a slightly moistened cotton or wool cloth for general cleaning.

It is important not to let water soak through the leather or penetrate into seams.

Before cleaning leather surfaces, read and heed the information

⇒ page 381, Cleaning upholstery on

heated seats and power seats or seats with airbag components.

Type of stain

Cleaning

Type of stain

Cleaning

Heavy stains

– Apply a mild soapy solution with a cloth that has

been wrung nearly dry

– Dab dry with an absorbent cloth.

Water-based stains,

such as coffee, tea,

juice, or blood.

– Remove fresh stains with an absorbent cloth.

– If the stains are already dry, use an appropriate

cleaning agent

⇒ .

Grease-based

stains, such as oil,

lipstick, etc.

– Remove fresh stains with an absorbent cloth.

– Use an appropriate cleaning agent on stains that

have not yet penetrated the surface

⇒ .

Special stains, such

as ballpoint pen,

marker, nail polish,

latex paint, or shoe

polish.

– Dab dry with an absorbent cloth.

– Clean with a special stain remover designed for

leather.

NOTICE

Stains that have been left in place too long will penetrate the surface of the leather and

cannot be removed.

Never treat leather with solvents, floor wax, shoe polish, stain remover or similar products.
Wipe up spilled liquids immediately with an absorbent cloth. Liquid can penetrate leather

surfaces and seams within a few seconds.

If the vehicle is left in the sun for a long time, cover the upholstery to protect the leather

from direct sunlight and to help prevent fading and discoloration.

Slight discoloration caused by wear and tear is normal.

Cleaning leatherette

Please first read and note the introductory information and heed the WARNINGS

Clean leatherette upholstery only with water and a mild soap solution.

Before cleaning leatherette surfaces, read and heed the information

⇒ Cleaning upholstery on heat-

ed seats and power seats or seats with airbag components.

Mild soap solution: 2 tablespoons of liquid soap in 1 quart (liter) of water.

NOTICE

Do not clean leatherette with solvents, floor wax, shoe polish, stain remover, or similar

products.

These can cause the material to become brittle and break. Sharp-edged objects and items

on clothing and belts (such as belt clips, mobile phone cases, zippers, rivets, and rhinestones)
can damage upholstery material and fabric trim.

If the vehicle is left in the sun for a long time, cover the upholstery to protect the leatherette

from direct sunlight and to help prevent fading or discoloration.

Cleaning storage compartments and cup holders

Please first read and note the introductory information and heed the WARNINGS

Some storage compartments and cup holders may have a removable rubber or felt insert at the bot-
tom.

Moisten a clean, lint-free cloth with water and clean plastic or rubber parts.
If this is not sufficient, then use a special solvent-free care and cleaning product designed for

plastics.

Clean felt inserts with a vacuum cleaner.

Care and cleaning of plastic components, wood trim and instrument
panel

Please first read and note the introductory information and heed the WARNINGS

Moisten a clean, lint-free cloth with water and clean the parts.
Clean plastic components (inside and outside of the vehicle) and the instrument panel only with a

solvent-free care and cleaning product that is specifically designed for plastics and approved by

Volkswagen

⇒ .

Clean wood trim with a mild soap solution.

WARNING

Using solvents or other improper cleaning products on surfaces where airbags are located
can change the way airbags deploy in a crash.

Products containing solvents will change the properties of the plastics and may cause

plastic parts to break and fly around when the airbag deploys in a crash, causing injury.

Never use solvents or cleaners on the steering wheel horn pad or on the instrument panel

because they can damage the airbag cover or change the stiffness or strength of the material
so that the airbag cannot deploy and protect properly.

When cleaning the horn pad and instrument panel, use only a soft, dry cloth or a cloth

moistened with plain water.

Cleaning the safety belts

Please first read and note the introductory information and heed the WARNINGS

If a safety belt is dirty, this can prevent the belt from working properly. Keep safety belts clean and
regularly check all safety belts for damage.

Safety belts must never be taken apart for cleaning.

Remove coarse dirt with a soft brush

⇒ .

  Carefully pull the dirty safety belt out of the retractor and keep it out.
  Clean the safety belt with a mild soap solution.
  After cleaning, always give the safety belts time to dry thoroughly before letting them retract. This

helps prevent damage to the retractor.

Do not let the safety belts retract until they are completely dry.

WARNING

Damage to safety belts reduces their overall effectiveness and increases the risk of serious
personal injury and death whenever the vehicle is being used.

Check the condition of all safety belts regularly. If you notice that the safety belt webbing,

hardware, retractor, buckle, or any other part of the safety belts is damaged, immediately
have an authorized Volkswagen dealer or authorized Volkswagen Service Facility replace the
safety belt with the correct replacement belt for your vehicle model and model year.

Never use chemical cleaning agents, solvents, or any substance that may damage or

weaken the safety belt webbing or any other parts of the safety belt. Never let the belts come
into contact with corrosive fluids or sharp objects. Otherwise, the safety belt webbing will be
significantly weakened.

After cleaning, always give the safety belts time to dry completely before letting them

retract. The moisture can damage the retractor and keep it from working properly.

Never let foreign objects or liquids get into the safety belt latch. This could prevent the

belt buckles and safety belts from working properly.

Damaged safety belts must be replaced; they cannot be repaired.
Never try to repair a damaged safety belt yourself. Never remove or modify the safety belts

in any way.

Safety belts that were subject to stress in an accident and stretched must be replaced with

a correct, new safety belt, preferably by an authorized Volkswagen dealer or authorized
Volkswagen Service Facility.

Replacement after a crash may be necessary even if a safety belt shows no visible dam-

age. Anchorages that have been loaded must also be inspected.

Parts, accessories, repairs, and modifications

Introduction

In this section you’ll find information about:

Break-in period

Parts and accessories

Operating fluids and equipment

Repairs and technical modifications

Repairs and other things that can affect Advanced Airbag performance

Notice about data recorded by the Event Data Recorder and vehicle control modules

Notice about data recorded by vehicle control modules

Using a mobile phone without a vehicle-integrated antenna - some important things to know

More information:

  Safety belts
  Airbag system
  Roof rack
  Trailer towing
  Tire Pressure Monitoring System (TPMS)
  Power outlets
  Braking and parking
  Starting assistance systems
  Cruise control
  Rear View Camera system
  Selective catalytic reduction (AdBlue

)

  Working in the engine compartment
  Engine oil
  Engine coolant
  Vehicle battery
  Exterior care and cleaning
  Interior care and cleaning
  Consumer information

⇒ Booklet

Radio, Navigation System

⇒ Booklet

Mobile Phone Package

WARNING

Inappropriate spare parts and accessories as well as improperly performed work, modifica-
tions and repairs can cause vehicle damage, accidents and serious personal injuries.

Volkswagen strongly recommends to only use accessories approved by Volkswagen and

Genuine Volkswagen Parts

. These parts and accessories have been evaluated by

Volkswagen for their suitability, reliability and safety.

Have repairs and vehicle modifications performed by an authorized Volkswagen dealer or

authorized Volkswagen Service Facility. Authorized Volkswagen dealers and authorized
Volkswagen Service Facilities have the required tools, diagnostic equipment, repair infor-
mation, and trained personnel to properly replace any airbag in your vehicle and assure sys-
tem effectiveness in a crash.

Only install parts on the vehicle that are consistent with factory-installed parts with re-

spect to design and characteristics.

Never store, mount, or attach objects, such as cup holders or phone cradles, on or next to

the airbag module covers or within the airbags deployment zones.

Only use wheel rim/tire combinations approved by Volkswagen for the respective vehicle

type.

Break-in period

Please first read and note the introductory information and heed the WARNINGS

Note applicable requirements for breaking in new parts.

Breaking in a new engine

A new engine must be carefully broken in during the first 1000 miles (1600 kilometers). During the first
few hours of driving, the engine's internal friction is higher than later when all moving parts have been
broken in.

Engine life is influenced by how you drive the vehicle for the first 1000 miles (1600 km). Even after-
wards, driving at moderate engine speeds, especially when the engine is cold, will tend to reduce
engine wear and help the engine to last longer and go farther. But do not drive at an excessively low
engine speed, either. Always downshift if the engine is not running smoothly. For the first 600 miles
(1000 km):

  Do not use full throttle.
  Don't let the engine speed get above 2/3 of the maximum speed.
  Do not tow a trailer.

From 600 to 1000 miles (1000 to 1600 km): Speed may gradually be increased to maximum permis-
sible road and engine speed.

New tires and brake pads

New tires and replacement tires

⇒ Tires and wheels

Brakes

⇒ About the brakes

Breaking in a new engine gently will increase service life and reduce oil consumption.

Parts and accessories

Please first read and note the introductory information and heed the WARNINGS

Volkswagen recommends that you consult an authorized Volkswagen dealer or authorized
Volkswagen Service Facility before purchasing accessories, spare parts or other equipment. Always
do so if you want to install additional accessories or replace parts. Your authorized Volkswagen dealer
or authorized Volkswagen Service Facility can provide information about legal requirements and
factory-recommended accessories, spare parts, and other equipment.

WARNING

Improper vehicle modifications and repairs affect the performance of the airbag system and
cause malfunctions and severe personal injuries.

Never store, mount, or attach objects, such as cup holders or phone cradles, on or next to

the airbag module covers or within the airbag deployment zones.

Objects on or near the surface where airbags are located can come loose and cause seri-

ous personal injury if the airbag deploys.

Operating fluids and equipment

Please first read and note the introductory information and heed the WARNINGS

Operating fluids and parts that wear out with use (such as timing belts, tires, engine coolants,
engine oils, spark plugs, and vehicle batteries) are constantly being improved. For this reason, it is
important to have operating fluids changed and wearing parts replaced by an authorized Volkswagen
dealer or authorized Volkswagen Service Facility. Authorized Volkswagen dealers and authorized
Volkswagen Service Facilities are always up-to-date regarding new developments and changes.

WARNING

Improper use of operating fluids and equipment can cause accidents, serious personal inju-
ries, burns and/or poisoning.

Always store vehicle care products in a safe place in original containers that are securely

closed.

To reduce the risk of poisoning, never use empty food or beverage containers that might

mislead someone into drinking from them.

Always keep vehicle care products out of the reach of children.
Always read and heed all the instructions and all WARNINGS on the package before using

vehicle care products.

When using products that give off harmful fumes, always work outdoors or in a well venti-

lated area.

Never use fuel, turpentine, engine oil, nail polish remover or other volatile fluids for vehi-

cle care. They are poisonous and highly flammable. They could cause fires and explosions!

NOTICE

Only refill with suitable operating fluids. When changing or topping off fluids, make sure

that you pour the fluids into the correct reservoirs. Adding incorrect fluids will cause serious
malfunctions and engine damage! Under no circumstances should you mix up operating fluids.
Otherwise serious malfunctions and engine damage can occur!

Accessories and other things installed in front of the cooling air intakes impair the efficien-

cy of the engine coolant. The engine can overheat under high outside temperatures or under
high engine loads!

Volkswagen Golf SportWagen (2015 year). Instruction - part 24
