2 Wheel Allocation ⇒ “2.1 6 J x 15”, page 5 2.1 6 J x 15 Note Pay attention to wheels/tires assignments for respective engine versions which are listed in the overview table. Explanatory notes of indications on disc wheels: Refer to ⇒ Wheel and Tire Guide General Information; Rep. Gr. 44 . Tightening specifications for wheel bolts: Refer to ⇒ Suspension, Wheels, Steering; Rep. Gr. 44 ; Wheels and Tires; Wheel Bolt Tightening Specifications . Pitch circle diameter: 112 mm Number of wheel bolt holes: 5 5Q0 601 027 R - Steel Rim Dimension: 6 J x 15 Offset (mm): 43 Wheel load in kg: 615 5G0 601 025 BA - “LYON” Aluminum Rim Dimension: 6 J x 15 Offset (mm): 43 Wheel load in kg: 575 Golf 2015 ➤ Wheel and Tire Guide - Edition 12.2015 2. Wheel Allocation 5 |
