❑ Wire routing. Refer to ⇒ “2.3 Wire Routing, Connectors and Bracket on Valve Body”, page 97 ❑ Allocation. Refer to the Parts Catalog. 24 - Seal ❑ If present, replace after removing 25 - ATF Drain Plug ❑ 40 Nm 26 - Selector Lever ❑ For the selector shaft ⇒ “2.2 Valve Body, Removing and Installing”, page 90 27 - Washer ❑ 10 Nm 29 - Spring ❑ Allocation. Refer to the Parts Catalog. 30 - Damper Piston ❑ With 14-pin connector ⇒ “2.3 Wire Routing, Connectors and Bracket on Valve Body”, page 97 . ❑ Removing and installing. Refer to ⇒ “2.3 Wire Routing, Connectors and Bracket on Valve Body”, page 97 . 32 - Bolt ❑ 6 Nm Tightening Specifications |
