Installing Note ♦ Check all the fasteners for damage and replace if necessary. ♦ Remove any remaining clips in the body mounting points -2- using the Omega Clip Tool - T40280- . To install, insert into the C-pillar trim panel. ♦ Make sure that the C-pillar trim panel is inside the door seal molding after installing. Install in reverse order of removal. 5.15 D-Pillar Trim Panel, Removing and In‐ stalling Note The following describes the removing and installing on the left side of the vehicle. Removing and installing on the right side is identical. Special tools and workshop equipment required ⇒ “7.2 Roof End Strip, Removing and Installing”, page 299 – Loosen the D-pillar trim panel -1- near the clips -2- from the body mounts using the Pry Lever - 80-200- . – Loosen the D-pillar trim panel -1- from the luggage compart‐ ment side trim panel. – Unclip the D-pillar trim panel from the clips -3-. in direction of -arrow- and remove it. Installing Note ♦ Check all the fasteners for damage and replace if necessary. ♦ Remove any remaining clips in the body mounting points -2- using the Omega Clip Tool - T40280- . To install, insert into the D-pillar trim panel. ♦ Make sure that the D-pillar trim panel is inside the rear lid seal molding after it is installed. Install in reverse order of removal. |
