– Remove the automatic belt retractor -3- from the mount. WARNING ♦ Observe the safety precautions for pyrotechnical compo‐ nents. Refer to ⇒ “1.2 Safety Precautions for Pyrotechnic Components”, . ♦ Before handling pyrotechnic components (for example, connecting the connector), the person handling it must “discharge static electricity”. This can be done by touching the door striker pin, for example. Install in reverse order of removal while paying attention to the following: replace the belt system bolts. Note Make sure the connectors are pushed in all the way and that they engage audibly. WARNING The ignition must be on when connecting the battery. If pyro‐ technic components (for example, airbag, belt tensioner) are not repaired correctly, they may deploy unintentionally after connecting battery. There must not be anyone inside the ve‐ hicle when connecting the battery. – Connect the battery ground cable with the ignition turned on. Refer to ⇒ Electrical Equipment; Rep. Gr. 27 ; Battery; Bat‐ tery, Disconnecting and Connecting . WARNING If the ignition is not switched on after the battery is reconnected - “indicator lamps in the instrument cluster do not light up” - the ignition (key/button) may only be switched on when the driver seat is positioned all the way back. Tightening Specifications ⇒ “1.3.2 Overview - Three-Point Seat Belt, 2-Door Sedan, with 1.8.3 Rear Three-Point Seat Belt, Removing and Installing, 4-Door Sedan, without Belt Tensioner Removing |
