Volkswagen Golf / Golf GTI / Golf Variant. Manual - part 282

WARNING

Only use the adhesive specified in the Parts Catalog, because

it is adapted for elasticity to the trim.
The minimum curing time for safe vehicle operation is three

hours.

– Lightly sand the adhesive surface with fine sandpaper.
– Thoroughly clean around the adhesive surface -2- using the

cleaning solution.

– Apply the glass/paint primer evenly in a single stroke using the

applicator.

– The drying time for the glass/paint primer is 10 minutes.
– Apply one-part adhesive -2-.

Width of the adhesive bead -2-: 8 mm.
Height of the adhesive bead -2-: 12 mm.

– Insert the trim into the roof opening and center it. Secure with

adhesive tape.

– Observe the minimum curing time. Refer to

⇒ page 259

 .

1.13

Power Sunroof Control Module - J245- ,

Removing and Installing

⇒ “1.13.1  Power Sunroof Control Module J245 , Removing and

Installing, Sedan through 02/2015”, page 261
⇒ “1.13.2  Power Sunroof Control Module J245 , Removing and

Installing, Sedan from 03/2015”, page 265
⇒ “1.13.3  Power Sunroof Control Module J245 , Removing and

Installing, Wagon”, page 269

1.13.1

Power Sunroof Control Module - J245- ,

Removing and Installing, Sedan through

02/2015

Special tools and workshop equipment required
♦ Torque Wrench 1783 - 2-10Nm - VAG1783-

Caution

A visual inspection when the sliding sunroof is open on the

vehicle is essential to order the correct replacement part. Refer

to

⇒ “1.1 Characteristics - Sliding Sunroof, Sedan”, page 193

This procedure contains mandatory replaceable parts. Refer

to component overview prior to starting procedure.

Mandatory Replacement Parts
♦ Screws - Drive Motor to Panorama Sunroof
Removing

– Remove the glass panel. Refer to

⇒ “1.6 Glass Panel, Removing and Installing”, page 223

 .

– Remove the glass panel if the drive motor is defective. Refer

to

⇒ “1.6.3 Glass Panel, Removing, Defective Drive Motor, Se‐

dan through 02/2015”, page 232

 .

– Remove the self-adhesive insulation -3-.
– Remove the bolts -2-.
– Remove the cover -1- upward at an angle in direction of

-arrows-.

WARNING

Only  remove  and  install  the  Panorama  sunroof  glass  panel

drive motor when the roof is closed (neutral position).
Requirements for removing and installing the drive motor: the

engine and the ignition must be off, remove the key and open

the door.

– Turn the engine and ignition off, remove the key and open the

door.

– Remove the screws -4- and remove the Panorama sunroof

drive motor -1-.

– Disconnect the connector -5- for the drive motor.
Installing

Note

The screws for the drive motor are micro-encapsulated and must always be replaced.

– Connect the connector -5- to the drive motor -1-.
