Monitor-ID $A3: Misfire Cylinder 2 Data nents that are not continuously monitored”. Select “Monitor-ID $A3”. Test-ID DTC Component or System Min. Max. Additional Information $0B P0302 Misfire Cylinder 2, Average Value Over 10 Driving Cycles. 0.0 counts 65,535. 0 counts Refer to DTC P0302 in the DTC summary table. $0C P0302 Misfire Cylinder 2, In This Driving Cy‐ cle. 0.0 counts 65,535. 0 counts Refer to DTC P0302 in the DTC summary table. – If any of components or systems fail to meet the specified val‐ ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐ ory” to check for stored DTC's or the corresponding diagnostic repair procedure ⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”, – Switch the ignition OFF. nents that are not continuously monitored”. Select “Monitor-ID $A4”. Test-ID DTC Component or System Min. Max. Additional Information $0B P0303 Misfire Cylinder 3, Average Value Over 10 Driving Cycles. 0.0 counts 65,535. 0 counts Refer to DTC P0303 in the DTC summary table. $0C P0303 Misfire Cylinder 3, In This Driving Cy‐ cle. 0.0 counts 65,535. 0 counts Refer to DTC P0303 in the DTC summary table. – If any of components or systems fail to meet the specified val‐ ues. Refer to Diagnostic “Mode 03: Interrogating Fault Mem‐ ory” to check for stored DTC's or the corresponding diagnostic repair procedure ⇒ “3.3.3 Diagnostic Mode 03 - Read DTC Memory”, – Switch the ignition OFF. GTI 2014 ➤ Generic Scan Tool - Edition 04.2015 3. Diagnosis and Testing 33 |
