2.16 Left/Right Seat Heating Button -E653- / -E654- , Removing and Installing The seat heating buttons are integrated in the Heater Control Module - J65- / A/C Control Module - J301- / Climatronic Control Module - J255- display control head. Components cannot be re‐ placed separately if faulty. Climatronic Control Module - J255- removing and installing. Refer to ⇒ Heating, Ventilation, and Air Conditioning; Rep. Gr. 87 ; Component Location Overview - Display And Control Unit . 2.17 Glove Compartment Lamp Switch - E26- , Removing and Installing Removing ward direction of the -arrow-. – Open the glove compartment lid -2-. the -arrow B- so that the steering rack -2- is removed from the damper -1-. – Remove the Glove Compartment Lamp Switch - E26- in the damper -1- from the mount in the direction of the -arrow A-. Installing 2.18 Exterior Rearview Mirror Adjuster - EX11- , Removing and Installing Caution Risk of damaging the component surfaces. ♦ When positioning a prying tool, put commercially available adhesive tape over the component in the visible area. |
