- Contact plate - 1 - has two straight edges. Contact plate
can be taken out when these edges are turned in direction
of catches.

- Contact plate can also be unclipped using a screwdriver.

- Now unclip lower battery from holder using a screwdriver.

Installing

Note polarity and installation position of batteries when
installing.

- Place battery - 4 - in transmitter with positive terminal
downward (positive terminal is marked in housing).

- Now set contact plate - 3 - onto battery - 4 - .

- Now position battery - 2 - onto contact plate with positive
terminal downward and lock.

- Connect upper part of radio-frequency unit - 1 - with lower

Central locking system

13/2/2005

part of radio-frequency unit - 5 - and clip.

- Then engage radio-frequency unit on key.

Batteries for key with radio remote control
(foldable), removing and installing 04.01

1. Radio-frequency unit - upper part
2. Key with variable code transponder
3. Radio-frequency unit - lower part
4. Battery

Removing

- Insert screwdriver in slot between radio-frequency unit - 1
- and key - 2 - .

- Rotate screwdriver in direction of - arrow - and detach
radio frequency unit from key.

Central locking system

13/2/2005

- Press radio-frequency apart unit in direction of - arrow - .

- Use a screwdriver to pry batteries out of holders in
direction of - arrow - .

Installing

Note polarity and installation position of batteries when
installing.

- Place batteries in radio-frequency unit with positive
terminal downward (positive terminal is marked in housing).

- Press on battery with light pressure to engage it in radio-
frequency unit.

- Reattach cover to radio-frequency unit (do not damage
seal).

Central locking system

13/2/2005

- Then engage radio-frequency unit on key.

Batteries for key with radio remote control
(foldable) removing and installing 05.01

1. Key with alternating code

transponder

2. Radio remote container - upper
