to the left.

– Take the holder with the bulb out of the reading light.

– Pull glas base bulb carefully out of the holder.
– Renew glas base bulb (12 V, 5 W).
Installing:
Install in reverse order of removal.

6.2

Removing and installing front interior

light and reading light (vehicles with slid‐

ing sunroof)

The following components are integrated in the interior light and

reading light:
♦ Front interior light -W1-
♦ Left centre reading light -W39-
♦ Left centre reading light -W40-
♦ Sunroof switch -E8-

Note

The interior light and reading light as well as the switches for the

interior light and reading light are connected together and can not

be separated. When repairing, renew the complete component.

6.2.1

Removing and installing front interior

light and reading light

Special tools and workshop equipment required

Jetta 2005 ➤ , Bora 2006 ➤

6. Lights and switches in roof trim

261

Note

When removing and installing components in visual area (con‐

nectors, covers, trims etc.) apply a commercial adhesive tape

where a lever tool is applied ( removal wedge -VAS 3409- , srew‐

driver).

Removing:
– Switch off the ignition and all electrical consumers.
– Carefully lever trim out of interior light using removal wedge -

VAS 3409- or screwdriver -arrow-.

– Unbolt securing bolts -arrow-.
– Take the interior light out of the headliner console.

Jetta 2005 ➤ , Bora 2006 ➤

262

6.2.2

Removing and installing sunroof switch

-E8-

Removing:
– Remove interior light

⇒ page 261

 .

– Disconnect connector -arrow-.

– Release locking lugs -arrows- and remove switch from the in‐

stallation frame.

Installing:
Install in reverse order of removal.

6.2.3

Replace front interior light -W1-

Special tools and workshop equipment required

Jetta 2005 ➤ , Bora 2006 ➤

6. Lights and switches in roof trim

263

Note

When removing and installing components in visual area (con‐

nectors, covers, trims etc.) apply a commercial adhesive tape

where a lever tool is applied ( removal wedge -VAS 3409- , srew‐

driver).

Removing:
– Switch off the ignition and all electrical consumers.
– Carefully lever lens for interior light out using removal wedge

-VAS 3409- or screwdriver -arrow-.

– Press contact -1- of light to side -arrow- and remove festoon

bulb -2- with the contact from the interior light.
