1 - Right tail light in rear lid
2 - Designation of engine size
3 - Additional designation
Maß a - 8 mm, from lower edge of engine designation to upper

edge of additional designation
Maß b - 43 mm, from edge of rear lid to outer edge of lettering

6.3.3

“GLI” lettering

1 - Left tail light in rear lid
2 - “GLI” lettering
Maß a - 15 mm, from lower edge of tail light to upper edge of

lettering
Maß b - 77 mm, from edge of tail light to outer edge of lettering

6.3.4

“Hybrid” lettering

Left wing lettering
Dimension -a-: 58 mm, from character line in wing to upper edge

of lettering
Dimension -b-: 32 mm, from edge of wing to rear edge of lettering

Right wing lettering
Dimension -a-: 58 mm, from character line in wing to upper edge

of lettering
Dimension -b-: 35 mm, from edge of wing to rear edge of lettering

Jetta 2011 ➤ , Jetta Hybrid 2013 ➤

6. Lettering

289
