Volkswagen Golf Variant, Jetta. Manual - part 1

Gearbox identification

KHN - Gearbox code letters

⇒ page 2

01.06.06 - Production date:

1 June 2006
14 - Factory code
14 15 - Time
0026 - Serial number

Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤ , Jetta 2011 ➤

1. Gearbox identification

1



Allocation: gearbox codes for petrol engines

KHN, LKG, LKM

KUT, LPL

LSU

1.4 l/90 kW TSFI

1.4 l/118 kW TSI

1.6 l/75 kW MPI

Allocation: gearbox codes for diesel engines

KHM, LKL, LKF

LQN, LST



1.9 l/77 kW TDI PD 1.6 l/77 kW TDI CR



Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤ , Jetta 2011 ➤

2



Dual clutch gearbox 0AM

Mechatronic unit for dual clutch

gearbox -J743-

1.7 l gear oil -G 052 171- 1 l central hydraulic oil and power

steering oil -G 004 000-

Further information in the part number designates the container

size.

Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤ , Jetta 2011 ➤

3. Capacities

3



4.1

Tools

Uncertainty often occurs with smaller bolts having low tightening

forces. Torque wrench 2...10 Nm -V.A.G 1783- can be used with

these bolts.

4.2

Gearbox

The gearbox has a hole in the housing.

Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤ , Jetta 2011 ➤

4
