Toyota Prius (2023 year). Manual in english - page 36

595

7-2. Steps to take in an emergency

hen
trou

e ari

■

If “Maintenance Required for Traction Battery Cooling Parts See Owner's
Manual” is shown

The filter may be clogged, the air intake vent may be blocked or there may be
a gap in the duct.

●

If the air intake vent is dirty, refer to P. 545 for information on how to clean
the air intake vent.

●

If the message is shown when the air intake vent is not dirty, have the vehi-
cle inspected by any authorized Toyota retailer or Toyota authorized
repairer, or any reliable repairer.

■

If “Traction Battery Needs to be Protected Refrain From the Use of
Position” is shown

This message may be displayed when the shift position is in N.
As the hybrid battery (traction battery) can not be charged when the shift
position is in N, shift the shift position to P when the vehicle is stopped.

■

If “Traction Battery Needs to be Protected Shift into

to Restart” is

shown

This message is displayed when the hybrid battery (traction battery) charge
has become extremely low because the vehicle has been left with the N shift
position selected for a certain amount of time.
When operating the vehicle, shift to P and restart the hybrid system.

■

If “Shifted into

Shift Again to Start Vehicle” is shown

Message is displayed when the automatic P position selection function oper-
ates. (



P. 256)

To start off the vehicle after the shift position is changed to P, operate the shift
lever again.

■

If “Shift to

Before Exiting Vehicle” is shown

Message is displayed when the driver’s door is opened without turning the
power switch to off with the shift position in any position other than P.
Shift the shift position to P.

■

If “Shift is in

Release Accelerator Before Shifting” is shown

Message is displayed when the accelerator pedal has been depressed and
the shift position is in N.
Release the accelerator pedal and shift the shift position to D or R.

■

If “Depress Brake When Vehicle is Stopped. Hybrid System may Over-
heat.” is shown

The message may be shown when the accelerator pedal is depressed to hold
the vehicle while the vehicle is stopped on an uphill, etc.
The hybrid system may overheat. Release the accelerator pedal and depress
the brake pedal.

■

If “Shifted to

Stop Vehicle to Shift to

” is shown

If the P position switch is pressed while driving, the shift position is changed
to N and the message is shown. (



P. 255)

596

7-2. Steps to take in an emergency

■

If “Auto Power OFF to Conserve Battery” is shown

The power switch has been turned off by the automatic power off function.
When starting the hybrid system next time, operate the hybrid system for
approximately 5 minutes to recharge the 12-volt battery.

■

If “Engine Oil Level Low Add or Replace” is displayed

The engine oil level may be low. Check the level of the engine oil, and add
engine oil if necessary. This message may be displayed if the vehicle is
stopped on a slope. Move the vehicle to a level surface and check if the mes-
sage disappears.

■

If “Accelerator and Brake Pedals Pressed Simultaneously” is shown

The accelerator and brake pedals are being depressed simultaneously.
(



P. 221)

Release the accelerator pedal and depress the brake pedal.

■

If a message that indicates the malfunction of front camera is displayed

The following systems may be suspended until the problem shown in the
message is resolved. (



P. 294, 580)

●

PCS (Pre-Collision System) (if equipped)

●

LTA (Lane Tracing Assist) (if equipped)

●

AHB (Automatic High Beam)

(if equipped)

●

RSA (Road Sign Assist)

(if equipped)

●

Dynamic radar cruise control with full-speed range (if equipped)

■

If a message that indicates the malfunction of radar sensor is displayed

The following systems may be suspended until the problem shown in the
message is resolved. (



P. 294, 580)

●

PCS (Pre-Collision System) (if equipped)

●

LTA (Lane Tracing Assist) (if equipped)

●

Dynamic radar cruise control with full-speed range (if equipped)

■

If “Radar Cruise Control Unavailable See Owner’s Manual” is shown

The dynamic radar cruise control with full-speed range system is suspended
temporarily or until the problem shown in the message is resolved. (causes
and coping methods:



P. 294)

■

If “Radar Cruise Control Unavailable” is shown

The dynamic radar cruise control with full-speed range system cannot be
used temporarily. Use the system when it becomes available again.

597

7-2. Steps to take in an emergency

hen
trou

e ari

■

If the shift position cannot be changed or the power switch is turned to
ACCESSORY mode even if trying to turn the power switch off when a
warning message is shown

If the 12-volt battery is discharged or the shift control system is malfunction-
ing, the followings may occur.

●

The shift position may not be changed to P.
When parking, stop the vehicle on level ground and apply the parking brake
firmly.

●

The hybrid system may not start.

●

The power switch may be turned to ACCESSORY mode even if trying to
turn the power switch off.
In this case, the power switch may be turned off after applying the parking
brake.

●

The automatic P position selection function (



P. 256) may not operate.

Before turning the power switch off, be sure to press the P position switch
and check that the shift position is in P by the shift position indicator or P
position switch indicator.

■

Warning buzzer



P. 587

NOTICE

■

If “Maintenance Required for Traction Battery at Your Dealer” is shown

The hybrid battery (traction battery) is scheduled to be inspected or
replaced. Have the vehicle inspected by any authorized Toyota retailer or
Toyota authorized repairer, or any reliable repairer immediately.

●

Continuing to drive the vehicle without having the hybrid battery (traction
battery) inspected will cause the hybrid system not to start.

●

If the hybrid system does not start, contact any authorized Toyota retailer
or Toyota authorized repairer, or any reliable repairer immediately.

598

7-2. Steps to take in an emergency

If you have a flat tire (vehicles without

spare tire)

Your vehicle is not equipped with a spare tire, but instead is
equipped with an emergency tire puncture repair kit.
A puncture caused by a nail or screw passing through the tire
tread can be repaired temporarily using the emergency tire
puncture repair kit. (The kit contains a bottle of sealant. The
sealant can be used only once to temporarily repair one tire
without removing the nail or screw from the tire.) After temporar-
ily repairing the tire with the kit, have the tire repaired or
replaced by any authorized Toyota retailer or Toyota authorized
repairer, or any reliable repairer.

WARNING

■

If you have a flat tire

Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the
wheel beyond repair, which could result in an accident.

599

7-2. Steps to take in an emergency

hen
trou

e ari

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift position to P.

●

Stop the hybrid system.

●

Turn on the emergency flashers.

●

Check the degree of the tire damage.

A tire should only be repaired
with the emergency tire punc-
ture repair kit if the damage is
caused by a nail or screw pass-
ing through the tire tread.

• Do not remove the nail or

screw from the tire. Remov-
ing the object may widen the
opening and make emer-
gency repair with the repair
kit impossible.

• To avoid sealant leakage, move the vehicle until the area of the

puncture, if known, is positioned at the top of the tire.

■

A flat tire that cannot be repaired with the emergency tire puncture repair
kit

In the following cases, the tire cannot be repaired with the emergency tire
puncture repair kit. Contact any authorized Toyota retailer or Toyota autho-
rized repairer, or any reliable repairer.

●

When the tire is damaged due to driving without sufficient air pressure

●

When there are any cracks or damage at any location on the tire, such as on
the side wall, except the tread

●

When the tire is visibly separated from the wheel

●

When the cut or damage to the tread is 4 mm (0.16 in.) long or more

●

When the wheel is damaged

●

When two or more tires have been punctured

●

When more than one sharp objects such as nails or screws have passed
through the tread on a single tire

●

When the sealant has expired

Before repairing the tire

600

7-2. Steps to take in an emergency



2WD models

Location of the emergency tire puncture repair kit and tools

Jack handle
Jack
(Use of the jack:



P. 604)

Wheel nut wrench

Emergency tire puncture
repair kit
Towing eyelet

1
2

601

7-2. Steps to take in an emergency

hen
trou

e ari



AWD models

Towing eyelet
Jack handle
Wheel nut wrench

Jack
(Use of the jack:



P. 604)

Emergency tire puncture
repair kit

1
2
3

602

7-2. Steps to take in an emergency

Emergency tire puncture repair kit components

Bottle
Sticker
Compressor
Air pressure gauge

Compressor switch
Power plug
Hose
Air release cap

1
2
3
4

5
6
7
8

603

7-2. Steps to take in an emergency

hen
trou

e ari

Pull up the handle to open the
deck board.

Secure the deck board using
the grocery bag hooks.
(



P. 481)

Take out the emergency tire puncture repair kit.

If the luggage cover is stowed, turn over the luggage cover to take out the
emergency tire puncture repair kit.

Taking out the emergency tire puncture repair kit



2WD models



AWD models

604

7-2. Steps to take in an emergency

■

Taking out the jack

Unhook the tightening strap and take out the jack.

■

Storing the jack

Place the jack in the same direction as the mark next to the storage

space.

2WD models

AWD models

2WD models

AWD models

WARNING

■

After using the tools and jack

Before driving, make sure all the tools and jack are securely in place in their
storage location to reduce the possibility of personal injury during a collision
or sudden braking.

605

7-2. Steps to take in an emergency

hen
trou

e ari

Take out the repair kit from the plastic bag.

Attach the sticker enclosed with the bottle on the specified locations. (See
step .)

Remove the hose and take out
the power plug from the com-
pressor.

Connect the bottle to the com-
pressor.

Insert and connect the bottle
straight into the compressor as
shown in the illustration, and check
that the claws of the bottle are con-
cealed in the holes.

Emergency repair method

606

7-2. Steps to take in an emergency

Connect the hose to the bottle.

As shown in the illustration, make
sure the hose is connected
securely to the bottle.

Remove the valve cap from the
valve of the punctured tire.

Extend the hose. Remove the
air release cap from the hose.

You will use the air release cap
again. Therefore keep it in a safe
place.

607

7-2. Steps to take in an emergency

hen
trou

e ari

Connect the hose to the valve.

Screw the end of the hose clock-
wise as far as possible.

Make sure that the compressor
switch is off.

Connect the power plug to the power outlet socket. (



P. 486)

Attach the sticker provided with
the tire puncture repair kit to a
position easily seen from the
driver’s seat.



Front



Rear

608

7-2. Steps to take in an emergency

Check the specified tire inflation pressure.

Tire inflation pressure is specified on the label as shown. (



P. 665)

Start the hybrid system. (



P. 244)

To inject the sealant and inflate
the tire, turn the compressor
switch on.



Left-hand drive vehicles



Right-hand drive vehicles

609

7-2. Steps to take in an emergency

hen
trou

e ari

Inflate the tire until the specified air pressure is reached.

The sealant will be injected
and the pressure will spike to
300 kPa (3.0 kgf/cm

or bar, 44

psi) or 400 kPa (4.0 kgf/cm

bar, 58 psi), then gradually
decrease.
The air pressure gauge will
display the actual tire infla-
tion pressure about 1 to 5
minutes after the switch is
turned on.

Turn the compressor switch off
and then check the tire inflation
pressure.
Being careful not to over inflate,
check and repeat the inflation
procedure until the specified tire
inflation pressure is reached.
The tire can be inflated for about 5 to 20 minutes (depending on the out-
side temperature). If the tire inflation pressure is still lower than the
specified point after inflation for 25 minutes, the tire is too damaged to
be repaired. Turn the compressor switch off and contact any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer.
If the tire inflation pressure exceeds the specified air pressure, let out
some air to adjust the tire inflation pressure. (



P. 612, 665)

With the compressor switch off, pull out the power plug from the
power outlet socket and then disconnect the hose from the valve on
the tire.

Some sealant may leak when the hose is removed.

Install the valve cap onto the valve of the emergency repaired tire.

Attach the air release cap to the
end of the hose.

If the air release cap is not
attached, the sealant may leak and
the vehicle may get dirty.

610

7-2. Steps to take in an emergency

Temporarily store the bottle in the luggage compartment while it is
connected to the compressor.
To spread the liquid sealant evenly within the tire, immediately drive
safely for about 5 km (3 miles) below 80 km/h (50 mph).

After driving, stop your vehicle
in a safe place on a hard, flat
surface and reconnect the
repair kit.

Remove the air release cap from
the hose before reconnecting the
hose.

Turn the compressor switch on and wait for several seconds, then
turn it off. Check the tire inflation pressure.

If the tire inflation pressure is
under 130 kPa (1.3 kgf/cm

or bar, 19 psi): The puncture
cannot be repaired. Contact
any authorized Toyota
retailer or Toyota authorized
repairer, or any reliable
repairer.
If the tire inflation pressure is
130 kPa (1.3 kgf/cm

or bar,

19 psi) or higher, but less
than the specified air pres-
sure: Proceed to step

If the tire inflation pressure is the specified air pressure (



P. 665):

Proceed to step

Turn the compressor switch on to inflate the tire until the specified
air pressure is reached. Drive for about 5 km (3 miles) and then
perform step

Content .. 34 35 36 37 ..
