Toyota Venza Hybrid (2023 year). Manual in english - page 22

353

5-4. Using the other interior features

Interior

featur

To set the visor in the forward
position, flip it down.

To set the visor in the side
position, flip down, unhook,
and swing it to the side.

To use the side extender,
place the visor in the side
position, then slide it back-
ward.

Slide the cover to open.

The light turns on when the cover is
opened.

■

Automatic light off to prevent

12-volt battery discharge

If the vanity lights remain on when

the power switch is turned to OFF,

the lights will go off automatically

after 20 minutes.

Please use a power supply for
electronic goods that use less
than 12 VDC /10 A (power con-
sumption of 120 W).
Open the console box and open
the lid.

■

The power outlet can be used

when

The power switch is in ACC or ON.

■

When stopping the hybrid sys-

tem

Disconnect electrical devices with

charging functions, such as mobile

battery packs.

If such devices are left connected,

the hybrid system may not stop nor-

mally.

Other interior features

Sun visors

Vanity mirrors

NOTICE

■

To prevent 12-volt battery dis-

charge

Do not leave the vanity lights on

for extended periods while the

hybrid system is off.

Power outlet

354

5-4. Using the other interior features

The USB Type-C charging ports
are used to supply 3 A of elec-
tricity at 5 V to external devices.
The USB Type-C charging ports
are for charging only. They are
not designed for data transfer or
other purposes.
Depending on the external
device, it may not charge prop-
erly. Refer to the manual
included with the device before
using a USB Type-C charging
port.

■

Using the USB Type-C
charging ports



On the instrument panel



Rear of console box

Open the lid.

■

The USB Type-C charging ports

can be used when

The power switch is in ACC or ON.

■

Situations in which the USB

Type-C charging ports may not

operate correctly

●

If a device which consumes more

than 3 A at 5 V is connected

●

If a device designed to communi-

cate with a personal computer,

such as a USB memory device, is

connected

●

If the connected external device is

turned off (depending on device)

●

If the temperature inside the vehi-

cle is high, such as after the vehi-

cle has been parked in the sun

NOTICE

■

When power outlet is not in

use

To avoid damaging the power out-

let, close the power outlet lid

when the power outlet is not in

use.
Foreign objects or liquids that

enter the power outlet may cause

a short circuit.

■

To prevent blown fuse

Do not use an accessory that

uses more than 12 V 10 A.

■

To prevent 12-volt battery dis-

charge

Do not use the power outlet lon-

ger than necessary when the

hybrid system is off.

USB Type-C charging
ports

355

5-4. Using the other interior features

Interior

featur

■

About connected external

devices

Depending on the connected exter-

nal device, charging may occasion-

ally be suspended and then start

again. This is not a malfunction.

A portable device can be
charged by just placing Qi stan-
dard wireless charge compatible
portable devices according to
the Wireless Power Consortium,
such as smartphones and
mobile batteries, etc., on the
charge area.
This function cannot be used
with portable devices that are
larger than the charging tray.
Also, depending on the portable
device, it may not operate as
normal. Please read the opera-
tion manual for portable devices
to be used.

■

The “Qi” logo

The “Qi” logo is a trademark of
the Wireless Power Consortium.

■

Name for all parts

NOTICE

■

To prevent damage to the

USB Type-C charging ports

●

Do not insert foreign objects into

the ports.

●

Do not spill water or other liq-

uids into the ports.

●

USB Type-C charging ports

(rear of console box): When the

USB Type-C charging ports are

not in use, close the lids. If a for-

eign object or liquid enters a

port may cause a short circuit.

●

Do not apply excessive force to

or impact the USB Type-C

charging ports.

●

Do not disassemble or modify

the USB Type-C charging ports.

■

To prevent damage to exter-

nal devices

●

Do not leave external devices in

the vehicle. The temperature

inside the vehicle may become

high, resulting in damage to an

external device.

●

Do not push down on or apply

unnecessary force to an exter-

nal device or the cable of an

external device while it is con-

nected.

■

To prevent 12-volt battery dis-

charge

Do not use the USB Type-C

charging ports for a long period of

time when the hybrid system is

off.

Wireless charger

356

5-4. Using the other interior features

Power supply switch

Operation indicator light

Charge area

Charging tray

: Portable devices and wireless

chargers contain charging coils.
The charging coil in the wireless
charger can be moved within the
charge area near the center of
the charging tray. If the charging
coil inside a portable device is
detected in the charge area, the
charging coil inside the wireless
charger will move toward it and
start charging. If the charging coil
inside a portable device moves
outside of the charge area,
charging will automatically stop.
If 2 or more portable devices are
placed on the charging tray, their
charging coils may not be prop-
erly detected and they may not
be charged.

■

Using the wireless charger

Press the power supply
switch of the wireless char-
ger.

Switches on and off with each

press of the power supply switch.
When turned on, the operation indi-

cator light (green) comes on.
Even with the hybrid system off, the

on/off state of the power supply

switch is memorized.

Place the portable device on
the charging tray

Place the charging side of the por-

table device down with the center of

the device in the center of the

charge area.
Depending on the portable device,

its charging coil may not be in the

center of the device. In this case,

place the portable device so that its

charging coil is centered in the

charging area.
When charging, the operation indi-

cator light (orange) comes on.
If charging is not occurring, try plac-

ing the portable device as close to

the center of the charging area as

possible.
If charging is not performed, the

operation indicator light will slowly

illuminate in green and orange

alternatively and a sound of

charging coil operation may be

heard repeatedly.
When charging is complete, the

operation indicator light (green)

comes on.

357

5-4. Using the other interior features

Interior

featur

■

Recharging function



When charging is complete
and after a fixed time in the
charge suspension state,
charging restarts.



If a portable device is moved
significantly within the
charging area, the charging
coil may disconnect and
charging may temporarily be
stopped. However, if a
charging coil is detected
within the charging area, the
charging coil inside the wire-
less charger will move near
the other coil and charging
will resume.

■

Rapid charging function



The following portable
devices support rapid
charging.

• Portable devices compliant with

WPC Ver1.2.4 and compatible
with rapid charging

• iPhone’s with an iOS version that

supports 7.5 W charging (iPhone
8 and later models)



To switch to the rapid
charging function, press the
power supply switch 3 times
while charging. When rapid
charging is possible, the oper-
ation indicator light will switch
from orange to flashing
between green and orange.



When charging is complete,
the rapid charging function
will stop. Switch again to the

rapid charging function to use
rapid charging again.

■

Lighting conditions of oper-
ation indicator light

:Charging power will not be out-

put during standby. A metallic
object will not be heated, if it is
placed on the charging tray in
this state.

:Depending on the portable

device, there are cases where

Operation

indicator

light

Conditions

Turning off

When the Wireless
charger power supply
is off

Green
(comes
on)

On Standby (charging
possible state)

When charging is com-
plete

Orange
(comes
on)

When placing the por-
table device on the
charging area (detect-
ing the portable device)

Charging

Flashing
between
green and
orange

When any of the follow-
ing portable devices is
using rapid charging
• Portable devices

compliant with WPC
Ver1.2.4 and compat-
ible with rapid
charging

• iPhone’s with an iOS

version that supports
7.5 W charging
(iPhone 8 and later
models)

358

5-4. Using the other interior features

the operation indicator light will
continue being lit up orange even
after the charging is complete.

■

When the operation indica-
tor light flashes

When an error occurs, the oper-
ation indicator light flashes an
orange color.
Handle the error based on the
following tables.



Flashing repeatedly once
every second (Orange)



Repeatedly flashes 3 times
continuously (Orange)

Suspected

causes

Handling method

Vehicle to char-
ger communica-
tion failure.

If the hybrid sys-
tem is running,
stop and then
restart the hybrid
system. If the
power switch is
in ACC, start the
hybrid system.
(



P.201)

Suspected

causes

Handling method

Foreign sub-
stance detection:
A metallic for-
eign substance
is in the charge
area, and so the
abnormal heat-
ing prevention
function oper-
ated

Remove the for-
eign substance
from the charge
area.

Portable device
misaligned:
The charging coil
in the portable
device moved
outside of the
charge area, and
so the abnormal
heating preven-
tion function
operated

Remove the por-
table device from
the charging
tray, check that
the operation
indicator light
switches back to
green, and then
once again place
the device near
the center of the
charging tray. If
there is a case or
cover attached
to the portable
device, remove
it.

359

5-4. Using the other interior features

Interior

featur



Repeatedly flashes 4 times
continuously (Orange)

■

The wireless charger can be

operated when

The power switch is in ACC or ON.

■

Usable portable devices

●

Qi standard wireless charge stan-

dard can be used on compatible

devices. However, not all Qi stan-

dard devices and compatibility are

guaranteed.

●

Starting with mobile phones and

smartphones, it is aimed for low

power electrically supplied porta-

ble devices of no more than 5W.

●

However, charging exceeding 5 W

is supported by the following por-

table devices.

• Charging at 7.5 W or less is sup-

ported by iPhone’s that support

7.5 W charging.

• Charging at 10 W or less is sup-

ported by portable devices compli-

ant with EPP output as defined by

WPC standard Ver1.2.4.

■

Using the smart key system

If the smart key system detects the

key while a device is being charged,

charging will be temporarily

stopped.

■

When covers and accessories

are attached to portable devices

Do not charge in situations where

cover and accessories not able to

handle Qi are attached to the porta-

ble device. Depending on the type

of cover (including the certain genu-

ine manufacture parts) and acces-

sory, it may not be possible to

charge. When charging is not per-

formed even with the portable

device placed on the charge area,

remove the cover and accessories.

■

While charging, noise enters

the AM radio

●

Turn off the wireless charger and

confirm that the noise has

decreased. If the noise

decreases, continuously pushing

the power supply switch of the

wireless charger for 2 seconds,

the frequency of the charger can

be changed and the noise can be

reduced. Also, on that occasion,

the operation indicator light will

flash orange 2 times.

●

iPhone’s use a particular fre-

quency for rapid charging.

Depending on the iOS version,

rapid charging may not be per-

formed while switching frequen-

cies.

■

Important points of the wireless

charger

●

If the electronic key cannot be

detected within the vehicle inte-

rior, charging cannot be done.

When the door is opened and

closed, charging may be tempo-

rarily suspended.

●

When charging, the wireless

charging device and portable

device will get warmer, however

this is not a malfunction.

When a portable device gets

warm while charging, charging

may stop due to the protection

function on the portable device

side. In this case, when the tem-

perature of the portable device

drops significantly, charge again.

The fan may start operating to lower

the temperature inside the wireless

charger, however this is not a mal-

Suspected

causes

Handling method

Safety shut-
down resulting
when the tem-
perature within
the wireless
charger
exceeded the set
value

Stop charging,
remove the por-
table device from
the charging
tray, wait for the
temperature to
drop, and then
start charging
again.

360

5-4. Using the other interior features

function.

■

Operation sounds

A buzzing noise may be heard when

pressing the power supply switch to

turn the power supply on, when

turning the power switch to ACC or

ON while the wireless charger

power supply is on, or when detect-

ing a portable device. However, this

is not a malfunction.

■

If the smartphone OS has been

updated

If the smartphone OS has been

updated to a newer version, its

charging specifications may have

changed significantly. For details,

check the information on the manu-

facturer’s website.

■

Trademark information

iPhone is a trademark of Apple Inc.,

registered in the U.S. and other

countries.

WARNING

■

Caution while driving

When charging a portable device,

for safety reasons, the driver

should not operate the main part

of the portable device while driv-

ing.

■

Caution while in motion

Do not charge lightweight devices

such as wireless headphones

while in motion. These devices

are very light and may be ejected

from the charging tray, which may

lead to unforeseen accidents.

■

Caution regarding interfer-

ence with electronic devices

People with implantable cardiac

pacemakers, cardiac resynchroni-

zation therapy-pacemakers or

implantable cardioverters, as well

as any other electrical medical

device, should consult their physi-

cian about the usage of the wire-

less charger.

■

To prevent malfunctions or

burns

Observe the following precau-

tions. Failure to do so may result

in a equipment failure and dam-

age, catch fire, burns due to over-

heat or electric shock.

●

Do not insert any metallic

objects between the charge

area and the portable device

while charging

●

Do not attach an aluminum

sticker or other metallic object to

the charge area

●

Do not attach an aluminum

sticker or other metallic object to

the side of the portable device

(or to its case or cover) that

touches the charge area

●

Do not use the charging tray as

a small storage space

●

Do not subject to a strong force

or impact

●

Do not disassemble, modify or

remove

●

Do not charge devices other

than specified portable devices

●

Keep away from magnetic items

●

Do not charge devices if the

charge area is covered in dust

●

Do not cover with a cloth or sim-

ilar material

NOTICE

■

Situations in which the func-

tion may not operate normally

Devices may not be charged nor-

mally in the following situations.

●

The portable device is fully

charged

361

5-4. Using the other interior features

Interior

featur

NOTICE

●

The portable device is being

charged with a cable connected

●

There is foreign matter between

the charge area and portable

device

●

Charging has caused the porta-

ble device to heat up

●

The temperature around the

charging tray is 95°F (35°C) or

higher, such as in extreme heat

●

The portable device is placed

with its charging side facing up

●

When the charging coil for the

portable device is misaligned

from the charge area (In particu-

lar, small portable devices such

as foldable devices may be mis-

aligned from the charging area

while driving)

●

The portable device is larger

than the charging tray

●

The camera lens protrudes 0.12

in. (3mm) or more from the sur-

face of the portable device

●

The vehicle is in an area where

strong electrical waves or noise

are emitted, such as near a tele-

vision tower, power plant, gaso-

line station, broadcasting

station, large display, airport,

etc.

●

Any of the following objects that

is 0.08 in (2mm) or thicker is

between the charging side of

the portable device and the

charge area

• Thick cases or covers

• Thick decorations

• Accessories, such as finger

rings, straps, etc.

• A case or cover with a protrud-

ing shape for the lens

●

When the portable device is in

contact with, or is covered by

any of the following metallic

objects:

• A card that has metal on it, such

as aluminum foil, etc.

• A pack of cigarettes that

includes aluminum foil

• A wallet or bag that is made of

metal

• Coins

• A heating pad

• CDs, DVDs or other media

• A metal accessory

• A case or cover made of metal

• Casing which has magnet in it

on the charging side of the por-

table device

●

Electric wave type wireless

remote controls are being used

nearby

●

The electronic key is not inside

the vehicle

●

2 or more portable devices are

placed on the charging tray at

the same time

If charging is abnormal or the

operation indicator light contin-

ues to flash for any other reason,

the wireless charger may be mal-

functioning. Contact your Toyota

dealer.

362

5-4. Using the other interior features

■

Front

Slide the console box lid while
pulling up the knob to release
the lock.

■

Rear

Fold down the armrest for use.

An assist grip installed on the
ceiling can be used to support
your body while sitting on the
seat.

NOTICE

■

To prevent malfunctions and

data corruptions

●

When charging, bringing a

credit, or other magnetic card,

or magnetic storage media

close to the charge area may

clear any stored data due to

magnetic influence. Also, do not

bring a wristwatch or other pre-

cision instrument close to the

charge area since doing so may

cause it to malfunction.

●

Do not charge with a non-con-

tact IC card such as a transpor-

tation system IC card inserted

between the charging side of a

portable device and the charge

area. The IC chip may become

extremely hot and damage the

portable device or IC card. Be

especially careful not to charge

a portable device inside a case

or cover with a non-contact IC

card attached.

●

Do not leave portable devices

inside the vehicle. The inside of

the vehicle can become hot in

extreme heat, which could

cause a malfunction.

■

To prevent 12-volt battery dis-

charge

Do not use the wireless charger

for a long period of time when the

hybrid system is stopped.

Armrests

WARNING

■

When sliding the front arm-

rest

Slide until secured in place when

a click sound is heard.
If not secured in place, the front

armrest may suddenly move,

resulting in injury.

NOTICE

■

To prevent damage to the

armrest

Do not apply too much load on the

armrest.

Assist grips

363

5-4. Using the other interior features

Interior

featur

The coat hooks are provided
with the rear assist grips.

WARNING

■

Assist grips

Do not use the assist grip when

getting in or out of the vehicle or

rising from your seat.

NOTICE

■

To prevent damage to the

assist grip

Do not hang any heavy object or

put a heavy load on the assist

grip.

Coat hooks

WARNING

■

Items that must not be

hanged on the hook

Do not hang coat hangers or

other hard or sharp objects on the

hook. If the SRS curtain shield air-

bags deploy, these items may

become projectiles, causing death

or serious injury.

364

5-4. Using the other interior features

: If equipped

■

HomeLink

programming pro-

cedure

The programming procedures can

also be found at the following URL.
Website: www.homelink.com/toyota

For support, contact customer sup-

port at the following.
Help Line: 1-800-355-3515

The HomeLink

wireless control

system in your vehicle has 3
buttons which can be pro-
grammed to operate 3 different
devices. Refer to the program-
ming methods on the following
pages to determine the method
which is appropriate for the

device.



Vehicles with auto anti-glare
inside rear view mirror

HomeLink

indicator light

Garage door operation indi-
cators

HomeLink

icon

Illuminates while HomeLink

operating.

Buttons



Vehicles with Digital Rear-
view Mirror

HomeLink

indicator light

Illuminates above each button
selected.

HomeLink

icon

Garage door opener

The garage door opener can
be programmed using the
HomeLink

to operate

garage doors, gates, entry
doors, door locks, home
lighting systems, security
systems, and other devices.

System components

365

5-4. Using the other interior features

Interior

featur

Garage door operation indi-
cators

HomeLink

logo

Appears while HomeLink

is oper-

ating.
When the HomeLink

button is

pressed, the logo disappears even
while the HomeLink

is operating.

Setting icon

Press the menu button to change
the setting.

Menu buttons

HomeLink

buttons

■

Codes stored in the HomeLink

memory

●

The registered codes are not

erased even if the 12-volt battery

cable is disconnected.

●

If learning failed when registering
a different code to a HomeLink

button that already has a code

registered to it, the already regis-

tered code will not be erased.

■

Before programming
HomeLink



During programming, it is pos-
sible that garage doors,
gates, or other devices may
operate. For this reason,
make sure that people and
objects are clear of the
garage door or other devices
to prevent injury or other
potential harm.



It is recommended that a new
battery be placed in the
remote control transmitter for
successful programming.



Garage door opener motors
manufactured after 1995 may
be equipped with rolling code
protection. If this is the case,
you may need a stepladder or

WARNING

■

When programming a garage

door or other remote control

device

The garage door or other device

may operate, so ensure people

and objects are out of danger to

prevent potential harm.

■

Conforming to federal safety

standards

Do not use the HomeLink

com-

patible transceiver with any

garage door opener or device that

lacks safety stop and reverse fea-

tures as required by federal safety

standards.
This includes any garage door

that cannot detect an interfering

object. A door or device without

these features increases the risk

of death or serious injury.

■

When operating or program-
ming HomeLink

Never allow a child to operate or
play with the HomeLink

buttons.

Programming HomeLink

366

5-4. Using the other interior features

other sturdy, safe device to
reach the “Learn” or “Smart”
button on the garage door
opener motor.

■

Programming HomeLink

Steps

through

must be per-

formed within 60 seconds, oth-
erwise the HomeLink

indicator

light will stop flashing and pro-
gramming will not be success-
fully completed.

Vehicles with Digital Rear-
view Mirror: Press the
HomeLink

button or menu

button

When the HomeLink

button is

pressed: Homelink

Training Tuto-

rial will be displayed to assist you

programming the HomeLink

When Homelink

Training Tutorial

is displayed, follow the instructions

displayed.
When the menu button is pressed:

Press the menu button

and

select the “Set Up >”. Homelink

Training Tutorial will be displayed

to assist you programming the

HomeLink

When Homelink

Training Tutorial

is displayed, follow the instructions

displayed.

Press and release the
HomeLink

button you want

to program and check that
the HomeLink

indicator light

flashes (orange).

Point the remote control
transmitter for the device at
the rear view mirror, 1 to 3 in.

(25 to 75 mm) from the
HomeLink

buttons.

Keep the HomeLink

indicator light

in view while programming.

Program a device.



Programming a device other
than an entry gate (for U.S.A.
owners)

Press and hold the remote con-
trol transmitter button until the
HomeLink

indicator light

changes from slowly flashing
orange to rapidly flashing green
(rolling code) or continuously lit
green (fixed code), then release
the button.



Programming an entry gate
(for U.S.A. owners)/Program-
ming a device in the Cana-
dian market

Press and release the remote

367

5-4. Using the other interior features

Interior

featur

control transmitter button at 2
second intervals, repeatedly,
until the HomeLink

indicator

light changes from slowly flash-
ing orange to rapidly flashing
(green) (rolling code) or continu-
ously lit (green) (fixed code).

Test the HomeLink

opera-

tion by pressing the newly
programmed button and
observing the HomeLink

indicator light:



HomeLink

indicator light illu-

minates: Programming of a
fixed code device has com-
pleted. The garage door or
other device should operate
when a HomeLink

button is

pressed and released.



HomeLink

indicator light

flashes rapidly: The garage
door opener or other device is
equipped with a rolling code.
To complete programming,
firmly press and hold the
HomeLink

button for 2 sec-

onds then release it.



If the garage door or other
device does not operate, pro-
ceed to “Programming a roll-
ing code system”.

Repeat the steps above to
program another device for
any of the remaining
HomeLink

buttons.

■

Programming a rolling code
system

Two or more people may be
needed to complete rolling code
programming.

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

This button can usually be found

where the hanging antenna wire is

attached to the unit. The name and

color of the button may vary by

manufacturer. Refer to the owner’s

manual supplied with the garage

door opener motor for details.

Press and release the
“Learn” or “Smart” button.

Perform

within 30 seconds after

performing

Press and hold the desired
HomeLink

button (inside the

vehicle) for 2 seconds and
release it. Repeat this

368

5-4. Using the other interior features

sequence
(press/hold/release) up to 3
times to complete program-
ming.
If the garage door opener
motor operates when the
HomeLink

button is

pressed, the garage door
opener motor recognizes the
HomeLink

signal.

■

Enabling 2-way communi-
cation with a garage door
(only available for compati-
ble devices)

When enabled, 2-way communi-
cation allows you to check the
status of the opening and clos-
ing of a garage door through
indicators in your vehicle.
2-way communication is only
available if the garage door
opener motor used is a compati-
ble device. (To check device
compatibility, refer to
www.homelink.com.)

Within 5 seconds after pro-
gramming the garage door
opener has been completed,
if the garage door opener
motor is trained to

HomeLink

, both garage

door operation indicators will
flash rapidly (green) and the
light on the garage door
opener motor will blink twice,
indicating that 2-way commu-
nication is enabled.

If the indicators do not flash, per-

form

and

within the first 10

presses of the HomeLink

button

after programming has been com-

pleted.

Press a programmed
HomeLink

button to oper-

ate a garage door.

Within 1 minute of pressing
the HomeLink

button, after

the garage door operation
has stopped, press the
“Learn” or “Smart” button on
the garage door opener
motor. Within 5 seconds of
the establishment of 2-way
communication with the
garage door opener, both
garage door operation indica-
tors in the vehicle will flash
rapidly (green) and the light
on the garage door opener
motor will blink twice, indicat-
ing that 2-way communica-
tion is enabled.

■

Reprogramming a single
HomeLink

button

When the following procedure is
performed, buttons which
already have devices registered
to them can be overwritten:

Content .. 20 21 22 23 ..
