159

3-4. Adjusting the steering wheel and mirrors

Before

driving

■

Recommended mirror angle

when towing a trailer (vehicles

with extending mirrors)

Power adjust the upper part of
the mirror until an appropriate
view is obtained. It is recom-
mended that the outer 2/3 of the
upper mirror be filled with images
other than the vehicle and trailer.

Manually adjust the lower part of
the mirror until an appropriate
view of the towed object is
obtained. It is recommended that
the outer 2/3 of the lower mirror
be filled with images other than
the trailer.

When either “L” or “R” of the mir-
ror select switch is selected, the
outside rear view mirrors will
automatically angle downwards
when the vehicle is reversing in
order to give a better view of the
ground.

To disable this function, select
neither “L” nor “R”.

■

Adjusting the mirror angle
when the vehicle is revers-
ing

With the shift lever in R, adjust
the mirror angle at a desired
position.
The adjusted angle will be mem-
orized and the mirror will auto-
matically tilt to the memorized
angle whenever the shift lever is
shifted to R from next time.

The memorized downward tilt posi-
tion of the mirror is linked to the
normal position (angle adjusted
with the shift position in other than
R). Therefore, if the normal position
is changed after adjustment, the tilt
position will also change.
When the normal position is
changed, readjust the angle in
reversing.

Improves reverse operation for
trailer parking by turning on the
outer mirror lights at night.
These lights can be used as
work lights.
When the shift lever is in P or R,
press the switch.

Linked mirror function
when reversing (if
equipped)

Trailering light (if
equipped)

160

3-4. Adjusting the steering wheel and mirrors

■

Automatic light off system

The lights will automatically turn off

when any of the following conditions

are satisfied:

●

When the shift lever is in N or D

●

When the outer mirror is folded

(



P.157)

161

3-5. Opening, closing the windows and moon roof

Before

driving

3-5.Opening, closing the windows and moon roof

The power windows can be
opened and closed using the
switches.
Operating the switch moves the
windows as follows:

Closing

One-touch closing

Opening

One-touch opening

: To stop the window partway,

operate the switch in the opposite
direction.

■

The power windows can be

operated when

The engine switch is in ON

■

Operating the power windows

after turning the engine off

The power windows can be oper-

ated for approximately 45 seconds

even after the engine switch is

turned to ACC or turned off. They

cannot, however, be operated once

either front door is opened.

■

Jam protection function

If an object becomes jammed

between the window and the win-

dow frame while the window is clos-

ing, window movement is stopped

and the window is opened slightly.

■

Catch protection function

If an object becomes caught

between the door and window while

the window is opening, window

movement is stopped.

■

When the side window cannot

be opened or closed

When the jam protection function or

catch protection function operates

unusually and the side window can-

not be opened or closed, perform

the following operations with the

power window switch of that door.

●

Stop the vehicle. With the engine

switch in ON, within 4 seconds of

the jam protection function or

catch protection function activat-

ing, continuously operate the

power window switch in the one-

touch closing direction or one-

touch opening direction so that the

side window can be opened and

closed.

●

If the side window cannot be

opened and closed even when

performing the above operations,

perform the following procedure

for function initialization.

Turn the engine switch to ON.

Pull and hold the power window

switch in the one-touch closing

direction and completely close

the side window.

Release the power window

switch for a moment, resume

pulling the switch in the one-

touch closing direction, and hold

it there for approximately 6 sec-

onds or more.

Press and hold the power win-

dow switch in the one-touch

opening direction. After the side

window is completely opened,

continue holding the switch for

an additional 1 second or more.

Release the power window

switch for a moment, resume

Power windows

Opening and closing the
power windows

162

3-5. Opening, closing the windows and moon roof

pushing the switch in the one-

touch opening direction, and

hold it there for approximately 4

seconds or more.

Pull and hold the power window

switch in the one-touch closing

direction again. After the side

window is completely closed,

continue holding the switch for a

further 1 second or more.

If you release the switch while the

window is moving, start again from

the beginning.

If the window reverses and cannot

be fully closed or opened, have the

vehicle inspected by your Toyota

dealer.

■

Door lock linked window opera-

tion

●

The power windows can be

opened and closed using the
mechanical key.

(



P.535)

●

The power windows can be

opened using the wireless remote
control.

(



P.111)

: These settings must be custom-

ized at your Toyota dealer.

■

Power windows open warning

buzzer

A buzzer sounds and a message is

shown on the multi-information dis-

play in the instrument cluster when

the engine switch is turned off and

the driver’s door is opened with the

power windows open.

■

Customization

Some functions can be customized.

(



P.567)

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Closing the windows

●

The driver is responsible for all

the power window operations,

including the operation for the

passengers. In order to prevent

accidental operation, especially

by a child, do not let a child

operate the power windows. It is

possible for children and other

passengers to have body parts

caught in the power window.

Also, when riding with a child, it

is recommended to use the win-

dow lock switch. (



P.163)

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when a window

is being operated.

●

When using the wireless remote

control or mechanical key and

operating the power windows,

operate the power window after

checking to make sure that

there is no possibility of any

passenger having any of their

body parts caught in the win-

dow. Also do not let a child

operate window by the wireless

remote control or mechanical

key. It is possible for children

and other passengers to get

caught in the power window.

●

When exiting the vehicle, turn

the engine switch off, carry the

key and exit the vehicle along

with the child. There may be

accidental operation, due to

mischief, etc., that may possibly

lead to an accident.

163

3-5. Opening, closing the windows and moon roof

Before

driving

This function can be used to
prevent children from acciden-
tally opening or closing a pas-
senger window.
Press the switch.

The indicator

will come on and

the passenger windows will be
locked.
The passenger windows can still be
opened and closed using the
driver’s switch even if the lock
switch is on.

■

The power windows can be

operated when

The engine switch is in ON.

■

When the battery is discon-

nected

The window lock switch is disabled.

If necessary, press the window lock

switch after reconnecting the bat-

tery.

WARNING

■

Jam protection function

●

Never use any part of your body

to intentionally activate the jam

protection function.

●

The jam protection function may

not work if something gets

jammed just before the window

is fully closed. Be careful not to

get any part of your body

jammed in the window.

■

Catch protection function

●

Never use any part of your body

or clothing to intentionally acti-

vate the catch protection func-

tion.

●

The catch protection function

may not work if something gets

caught just before the window is

fully opened. Be careful not to

get any part of your body or

clothing caught in the window.

Preventing accidental
operation (window lock
switch)

164

3-5. Opening, closing the windows and moon roof

: If equipped



Type A

Opening

Closing



Type B

Opening

Closing

■

The power back window can be

operated when

The engine switch is in ON.

■

Operating the power back win-

dows after turning the engine

off

The power back windows can be

operated for approximately 43 sec-

onds after the engine switch is

turned to ACC or off. They cannot,

however, be operated once either

front door is opened.

Power back window

WARNING

■

Caution while driving

Keep the back window closed.
This not only keeps personal

belongings from being thrown out,

but also prevents exhaust gases

from entering the vehicle.

Opening and closing the
power back windows

WARNING

■

Closing the back window

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

165

3-5. Opening, closing the windows and moon roof

Before

driving

: If equipped

■

Opening and closing

Opens the moon roof

The moon roof tilts up and then
opens.
The moon roof stops slightly before
the fully open position to reduce
wind noise. Press the switch again
to fully open the moon roof.

Closes the moon roof

: Lightly press either side of the

moon roof switch to stop the
moon roof partway.

■

Tilting up and down

WARNING

●

The driver is responsible for all

the power back window opera-

tions, including the operation for

the passengers. In order to pre-

vent accidental operation, espe-

cially by a child, do not let a

child operate the power back

window. It is possible for chil-

dren and other passengers to

have body parts caught in the

power back window.

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when a window

is being operated.

●

When exiting the vehicle, turn

the engine switch off, carry the

key and exit the vehicle along

with the child. There may be

accidental operation, due to

mischief, etc., that may possibly

lead to an accident.

Moon roof

Use the overhead switches
to open and close the moon
roof and tilt it up and down.

Operating the moon roof

166

3-5. Opening, closing the windows and moon roof

Tilts the moon roof up

Tilts the moon roof down

: Lightly press either side of the

moon roof switch to stop the
moon roof partway.

■

The moon roof can be operated

when

The engine switch is in ON.

■

Operating the moon roof after

turning the engine off

The moon roof can be operated for

approximately 45 seconds after the

engine switch is turned to ACC or

OFF. It cannot, however, be oper-

ated once either front door is

opened.

■

Jam protection function

If an object is detected between the

moon roof and the frame while the

moon roof is closing or tilting down,

travel is stopped and the moon roof

opens slightly.

■

Sunshade

The sunshade can be opened and

closed manually. However, the sun-

shade will open automatically when

the moon roof is opened.

■

Door lock linked moon roof

operation

●

The moon roof can be opened

and closed using the mechanical
key.

(



P.535)

●

The moon roof can be opened

and closed using the wireless
remote control.

(



P.109)

●

The alarm may be triggered if the

alarm is set and the moon roof is

closed using the door lock linked

moon roof operation function.

(



P.74)

: These settings must be custom-

ized at your Toyota dealer.

■

When the moon roof does not

close normally

Perform the following procedure:

●

If the moon roof closes but then

re-opens slightly

Stop the vehicle.

Press and hold the “CLOSE”
switch.

The moon roof will close, reopen

and pause for approximately 10 sec-
onds.

Then it will close again, tilt

up and pause for approximately 1

second. Finally, it will tilt down, open

and close.

Check to make sure that the

moon roof is completely closed

and then release the switch.

●

If the moon roof tilts down but then

tilts back up

Stop the vehicle.

Press and hold the “UP” switch

until the moon roof moves into

the tilt up position and stops.

Release the “UP” switch once

and then press and hold the “UP”
switch again.

The moon roof will pause for

approximately 10 seconds in the tilt
up position.

Then it will adjust

slightly and pause for approximately

1 second. Finally, it will tilt down,

open and close.

Check to make sure that the

moon roof is completely closed

and then release the switch.

:If the switch is released at the

incorrect time, the procedure will
have to be performed again from
the beginning.

:If the switch is released after the

above mentioned 10 seconds
pause, automatic operation will
be disabled. In that case, press
and hold the “CLOSE” or “UP”
switch, and the moon roof will tilt
up and pause for approximately 1

167

3-5. Opening, closing the windows and moon roof

Before

driving

second. Then it will tilt down,
open and close. Check to make
sure that the moon roof is com-
pletely closed and then release
the switch.

If the moon roof does not fully close

even after performing the above

procedure correctly, have the vehi-

cle inspected by your Toyota dealer.

■

Moon roof open reminder func-

tion

The buzzer sounds and a message

is shown on the multi-information

display when the engine switch is

turned to OFF and the driver’s door

is opened with the moon roof open.

■

Customization

Some functions can be customized.

(



P.567)

WARNING

Observe the following precau-

tions.

Failure to do so may cause death

or serious injury.

■

Opening the moon roof

●

Do not allow any passengers to

put their hands or head outside

the vehicle while it is moving.

●

Do not sit on top of the moon

roof.

■

Opening and closing the

moon roof

●

The driver is responsible for

moon roof opening and closing

operations.

In order to prevent accidental

operation, especially by a child,

do not let a child operate the

moon roof. It is possible for chil-

dren and other passengers to

have body parts caught in the

moon roof.

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when the moon

roof is being operated.

●

When using the wireless remote

control or mechanical key and

operating the moon roof, oper-

ate the moon roof after checking

to make sure that there is no

possibility of any passenger

having any of their body parts

caught in the moon roof. Also,

do not let a child operate moon

roof by the wireless remote con-

trol or mechanical key. It is pos-

sible for children and other

passengers to get caught in the

moon roof.

WARNING

●

When exiting the vehicle, turn

the engine switch off, carry the

key and exit the vehicle along

with the child. There may be

accidental operation, due to

mischief, etc., that may possibly

lead to an accident.

■

Jam protection function

●

Never use any part of your body

to intentionally activate the jam

protection function.

168

3-5. Opening, closing the windows and moon roof

: If equipped

■

Opening and closing the
electronic sunshade

Opens the electronic sun-
shade

Slide and hold the

switch back-

ward momentary and the sunshade
will automatically open. The elec-
tronic sunshade will fully open auto-
matically.

Closes the electronic sun-
shade

Slide and hold the

switch for-

ward. The electronic sunshade will
fully close automatically.
If the panoramic moon roof is not
fully closed, it will close fully before
the electronic sunshade closes.

●

The jam protection function may

not work if something gets

caught just before the moon

roof is fully closed. Also, the jam

protection function is not

designed to operate while the

switch is being pressed. Take

care so that your fingers, etc. do

not get caught.

Panoramic moon roof

Use the overhead switches
to operate the panoramic
moon roof and electronic
sunshade.

Operating the electronic
sunshade and panoramic
moon roof

169

3-5. Opening, closing the windows and moon roof

Before

driving

: Quickly slide and release the

switch in either direction to stop
the electronic sunshade partway.

■

Tilting the panoramic moon
roof up and down

Press the

switch to tilt the

panoramic moon roof up.

When the panoramic moon roof is
tilted up, the electronic sunshade
will open to the half-open position
of the roof.

: Lightly press the

switch again

to stop the panoramic moon roof
partway.

Press and hold the

switch to

tilt the panoramic moon roof
down.

The panoramic moon roof can be
tilted down only when it is in the til-
tup position.

■

Opening and closing the
panoramic moon roof

Opens the panoramic moon
roof

Slide and hold the

switch back-

ward. The panoramic moon roof
and electronic sunshade will open

automatically.
The panoramic moon roof can be
opened from the tilt-up position.

: Quickly slide and release the

switch in either direction to stop
the panoramic moon roof part-
way.

Closes the panoramic moon
roof

Slide and hold the

switch for-

ward. The panoramic moon roof will
fully close automatically.

■

The panoramic moon roof can

be operated when

The engine switch is in ON.

■

Operating the panoramic moon

roof after turning the engine off

The panoramic moon roof and elec-

tronic sunshade can be operated for

approximately 45 seconds after the

engine switch is turned to ACC or

OFF. They cannot, however, be

170

3-5. Opening, closing the windows and moon roof

operated once either front door is

opened.

■

Jam protection function

If an object is detected between the

panoramic moon roof and the frame

in the following situations, travel is

stopped and the panoramic moon

roof opens slightly.

●

The panoramic moon roof is clos-

ing or tilting down.

●

The electronic sunshade is clos-

ing.

■

Closing both the panoramic

moon roof and electronic sun-

shade

Slide the

switch forward.

The electronic sunshade will close

to the half-open position and pause.

The panoramic moon roof will then

fully close. Then the electronic sun-

shade will fully close.

■

Door lock linked panoramic

moon roof operation

●

The panoramic moon roof can be

opened and closed using the
mechanical key.

(



P.535)

●

The panoramic moon roof can be

opened using the wireless remote
control.

(



P.109)

●

The alarm may be triggered if the

alarm is set and the panoramic

moon roof is closed using the door

lock linked panoramic moon roof

operation function. (



P.74)

: These settings must be custom-

ized at your Toyota dealer.

■

When the panoramic moon roof

does not close normally

Perform the following procedure:

Stop the vehicle.

Operate the

switch forward

to close the panoramic moon
roof.

Slide the

switch forward and

hold it for 15 seconds. After
about 10 seconds the glass
should move forward toward the
hard stops and stall, then
reverse to close position.

Within 5 seconds, Slide and hold
the

switch forward again.

The sunshade will go to fully
open position and stop. The
moon roof will then follow, to fully
open then close. The sunshade
will then close.

If the panoramic moon roof does not
fully close even after performing the
above procedure correctly, have the
vehicle inspected by your Toyota
dealer.

■

Panoramic moon roof open

reminder function

A buzzer sounds and a message is

shown on the multi-information dis-

play when the engine switch is

turned to OFF and the driver’s door

is opened with the panoramic moon

roof open.

■

Customization

Some functions can be customized.

(



P.567)

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

171

3-5. Opening, closing the windows and moon roof

Before

driving

WARNING

■

Opening and closing the elec-

tronic sunshade

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when the elec-

tronic sunshade is being oper-

ated.

●

Do not let a child operate the

electronic sunshade. Closing

the electronic sunshade on

someone can cause death or

serious injury.

■

Opening the panoramic moon

roof

●

Do not allow any passengers to

put their hands or head outside

the vehicle while it is moving.

●

Do not sit on top of the pan-

oramic moon roof.

■

Opening and closing the pan-

oramic moon roof

●

The driver is responsible for

panoramic moon roof opening

and closing operations.

In order to prevent accidental

operation, especially by a child,

do not let a child operate the

panoramic moon roof. It is pos-

sible for children and other pas-

sengers to have body parts

caught in the panoramic moon

roof.

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when the pan-

oramic moon roof is being oper-

ated.

●

When using the wireless remote

control or mechanical key and

operating the panoramic moon

roof, operate the panoramic

moon roof after checking to

make sure that there is no pos-

sibility of any passenger having

any of their body parts caught in

the panoramic moon roof. Also,

do not let a child operate pan-

oramic moon roof by the wire-

less remote control or

mechanical key. It is possible for

children and other passengers

to get caught in the panoramic

moon roof.

●

When exiting the vehicle, turn

the engine switch to OFF, carry

the key and exit the vehicle

along with the child. There may

be accidental operation, due to

mischief, etc., that may possibly

lead to an accident.

■

Jam protection function

●

Never use any part of your body

to intentionally activate the jam

protection function.

172

3-5. Opening, closing the windows and moon roof

WARNING

●

The jam protection function may

not work if something gets

caught just before the pan-

oramic moon roof or electronic

sunshade is fully closed. Also,

the jam protection function is

not designed to operate while

the switch is being pressed.

Take care so that your fingers,

etc. do not get caught.

■

To prevent burns or injuries

Do not touch the area between

the underside of the panoramic

moon roof and the electronic sun-

shade. Your hand may get caught

and you could injure yourself.

Also, if the vehicle is left in direct

sunlight for a long time, the under-

side of the panoramic moon roof

could become very hot and could

cause burns.

NOTICE

■

To prevent damage to the

panoramic moon roof

●

Before opening the panoramic

moon roof, make sure that there

are no foreign objects, such as

stones or ice, around the open-

ing.

●

Do not hit the surface or edge of

the panoramic moon roof with

hard objects.

●

The panoramic moon roof

opens outside the vehicle,

thereby increasing the height of

the vehicle. Please use caution

when opening or driving with the

panoramic moon roof open

(pulling into low garages, etc.)

■

After the vehicle has been

washed or rained on

Before opening the panoramic

moon roof, wipe any water off the

panoramic moon roof. Otherwise,

water may enter the cabin when

the panoramic moon roof is

opened.

173

ing

Driving

4-1. Before driving

Driving the vehicle.......

175

Cargo and luggage .....

182

Vehicle load limits .......

185

Trailer towing...............

186

Dinghy towing .............

201

4-2. Driving procedures

Engine (ignition) switch

202

Automatic transmission

206

Turn signal lever..........

210

Parking brake..............

211

Brake Hold ..................

214

4-3. Operating the lights and

wipers

Headlight switch..........

217

Fog light switch ...........

220

AHB (Automatic High

Beam)........................

220

Windshield wipers and

washer.......................

224

4-4. Refueling

Opening the fuel tank cap

..................................

228

4-5. Using the driving support

systems

Toyota Safety Sense 2.5

..................................

230

PCS (Pre-Collision System)

..................................

235

LTA (Lane Tracing Assist)

..................................

247

RSA (Road Sign Assist)

..................................

258

Dynamic radar cruise con-

trol with full-speed range

..................................

261

Cruise control ..............

272

Stop & Start system ....

275

BSM (Blind Spot Monitor)

..................................

282

Intuitive parking assist.

289

RCTA (Rear Cross Traffic

Alert)..........................

296

PKSB (Parking Support

Brake)........................

302

Parking Support Brake func-

tion (static objects) ....

307

Parking Support Brake func-

tion (rear-crossing vehi-
cles)...........................

310

Toyota parking assist moni-

tor ..............................

312

Panoramic view monitor

..................................

325

Multi-terrain Monitor ....

360

174

Electronically modulated air

suspension ................

371

Driving mode select switch

..................................

374

Four-wheel drive system

..................................

377

AUTO LSD system......

379

Rear differential lock system

..................................

380

Crawl Control ..............

381

Multi-terrain Select ......

385

Downhill assist control sys-

tem ............................

388

Driving assist systems

390

Trailer brake controller

395

Trailer Backup Guide ..

398

Active front spoiler ......

403

4-6. Driving tips

Off-road precautions ...

405

Winter driving tips .......

408

Content .. 8 9 10 11 ..
