380

5-4. Other interior features

NOTICE

■

To avoid damaging the power outlet and the plug

●

Close the power outlet lid when not in use.

●

Do not allow foreign objects or liquids to enter the power outlet, as this
may cause a short circuit.

●

Do not use plug adaptors to connect too many plugs to the power outlet.

●

After removing a plug, gently close the power outlet lid.

■

To prevent the fuse from being blown

Do not use a 120 V AC appliance that requires more than the maximum
capacity of the power outlet. If a 120 V AC appliance that consumes more
than the maximum capacity is used, the protection circuit will cut the power
supply.

■

Appliances that may not operate properly (120 V AC)

The following 120 V AC appliances may not operate even if their power con-
sumption is under maximum capacity.

●

Appliances with high initial peak wattage

●

Measuring devices that process precise data.

●

Other appliances that require an extremely stable power supply

■

To prevent battery discharge

Turn off all the vehicle’s electronic equipment and accessories, such as the
headlights and air conditioning, when electrical appliances that consume in
excess of 100 W are used continuously for long periods of time.

■

To prevent any damage caused by heat

●

Do not use any electrical appliances that give off intense heat, such as
toasters, in any locations including the internal or external trim, seats and
deck.

●

Do not use any electrical appliances that are easily affected by vibration or
heat inside the vehicle. Vibration while driving, or the heat of the sun while
parking, may result in damage to those electrical appliances.

■

If any electrical appliances are to be used while driving

Securely fasten both the appliances and their cables to prevent them from
falling or getting caught in any of the power train components.

■

If the power outlet is loose when an electrical appliance plug is con-
nected

Replace the outlet. Contact your Toyota dealer for any necessary replace-
ments.

■

If the power outlet gets dirty

Turn the main switch off and use a soft, clean cloth to wipe it gently. Do not
use any cleansing materials, such as organic solvents, wax, or compound
cleaners, as these may damage the power outlet or cause it to malfunction.

381

5-4. Other interior features

Interio

r features

The USB charging ports are used to supply 2.5 A (Type A) and 3.0 A
(Type C) of electricity at 5 V to external devices. The USB charging
ports are for charging only. They are not designed for data transfer or
other purposes. Depending on the external device, it may not charge
properly. Refer to the manual included with the device before using a
USB charging port.

■

Using the USB charging ports

Open the console box lid.

■

The USB charging ports can be used when



Vehicles without a smart key system

The engine switch is in the “ACC” or “ON” position.



Vehicles with a smart key system

The engine switch is in ACCESSORY or IGNITION ON mode.

■

Situations in which the USB charging ports may not operate correctly

●

Type A USB charging port: If a device which consumes more than 2.5 A at 5
V is connected

●

Type C USB charging port: If a device which consumes more than 3.0 A at 5
V is connected

●

If a device designed to communicate with a personal computer, such as a
USB memory device, is connected

●

If the connected external device is turned off (depending on device)

●

If the temperature inside the vehicle is high, such as after the vehicle has
been parked in the sun

■

About connected external devices

Depending on the connected external device, charging may occasionally be
suspended and then start again. This is not a malfunction.

USB charging ports

382

5-4. Other interior features

NOTICE

■

To prevent damage to the USB charging ports

●

Do not insert foreign objects into the ports.

●

Do not spill water or other liquids into the ports.

●

When the USB charging ports are not in use, close the lids. If a foreign
object or liquid enters a port may cause a short circuit.

●

Do not apply excessive force to or impact the USB charging ports.

●

Do not disassemble or modify the USB charging ports.

■

To prevent damage to external devices

●

Do not leave external devices in the vehicle. The temperature inside the
vehicle may become high, resulting in damage to an external device.

●

Do not push down on or apply unnecessary force to an external device or
the cable of an external device while it is connected.

■

To prevent battery discharge

●

Do not use the USB charging ports for a long period of time with the
engine stopped.

383

5-4. Other interior features

Interio

r features

A mobile device can be charged wirelessly on the tray.



Vehicles without a smart key system
Charging can only be performed with the engine switch in the
“ACC” or “ON” position and only on mobile devices with the “

”

logo.



Vehicles with a smart key system
Charging can only be performed with the engine switch in ACCES-
SORY or IGNITION ON mode and only on mobile devices with the
“

” logo.

Press the wireless charger
switch.

Place a mobile device on the
tray as shown in the illustration.

An  amber  indicator  is  illuminated
while  charging  is  in  progress.
When  charging  is  complete,  a
green  indicator  will  also  be  illumi-
nated.  Some  phones,  cases  or
cover  type  wireless  chargers  may
not  cause  the  green  indicator  to
illuminate  even  though  it  is  fully
charged.

When placing the mobile device on the wireless charging surface of
the tray, make sure that there are no objects in-between the mobile
device and the tray. They may interfere with charging.

Wireless charger (if equipped)

384

5-4. Other interior features

■

If the wireless charger LED indicators flash

If the wireless charging surface of the tray becomes too hot, the LED indica-
tors will flash and charging is canceled. The LED indicators will be illuminated
if the surface of the tray cools down.
If the LED indicators flash even though the surface of the tray is not hot, the
wireless charger may be malfunctioning. Consult your Toyota dealer.

■

When charging of the wireless charger stops temporarily

If any of the following operations are performed with the wireless key or elec-
tronic key present, charging may stop temporarily. Charging will start again
after a while.
• Locking/unlocking the doors by touching the door handle

(vehicles with a smart key system)

• Opening/closing the doors
• Starting the engine
• Locking the doors by pressing the lock button on the wireless key or elec-

tronic key

• When the electronic key is out of the detection area

(vehicles with a smart key system)

■

Certification for the wireless charger



For vehicles sold in the U.S.A.

This device complies with Part 18 of the FCC Rules.
Toyota Motor Sales, U.S.A., Inc.
19001 S. Western Avenue
Torrance, CA 90501



For vehicles sold in Canada

This ISM device complies with Canadian ICES-001.
Cet appareil ISM est conforme à la norme NMB-001 du Canada.

386

5-4. Other interior features

WARNING

■

Caution regarding interference with electronic devices

●

People with implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should main-
tain a reasonable distance between themselves and the wireless charger.
The radio waves may affect the operation of such devices.

●

Before using the wireless charger, users of any electrical medical device
other than implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should con-
sult the manufacturer of the device for information about its operation
under the influence of radio waves. Radio waves could have unexpected
effects on the operation of such medical devices.

●

To avoid interference with other electrical devices, turn the wireless char-
ger off by turning off the wireless charger switch.

■

To prevent damage or fire

Observe the following precautions.
Failure to do so may result in the possibility of equipment failure or damage,
vehicle fire, burns due to heat, or even electrical shock.

●

Do not put any metallic objects between the charging area and the porta-
ble device.

●

Do not place anything but a device to be charged on the wireless charger.
It is not designed for use as an auxiliary box.

●

Do not apply force or impact to the wireless charger.

●

Do not disassemble or modify the wireless charger.

●

Do not attempt to charge portable devices which are not compatible with
the Qi wireless charging standard.

●

Do not bring magnetized objects close to the wireless charger.

●

Do not perform charging if the charging area is dusty.

●

Keep foreign objects away from the wireless charger, and do not spill liquid
on the wireless charger.

●

Do not cover the wireless charger with a cloth or other object while
charging.

●

Do not attach metallic objects, such as aluminum stickers, to the charging
area.

387

5-4. Other interior features

Interio

r features

NOTICE

■

Conditions in which the wireless charger may not operate correctly

In the following situations, the wireless charger may not operate correctly:

●

When a portable device is fully charged

●

When there is a foreign object between the charging area and portable
device

●

When a portable device becomes hot while charging

●

When a portable device is placed on the wireless area with its charging
surface facing up

●

When a portable device is not centered on the charging area

●

When the vehicle is near a TV tower, electric power plant, gas station,
radio station, large display, airport or other facility that generates strong
radio waves or electrical noise

●

When the portable device is in contact with, or is covered by any of the fol-
lowing metallic objects

• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Metal hand warmers
• Media such as CDs and DVDs

●

When wireless keys (that emit radio waves) other than those of your vehi-
cle are being used nearby.

If in situations other than above the wireless charger does not operate prop-
erly or the operation indicator light is blinking, the wireless charger may be
malfunctioning. Contact your Toyota dealer.

■

To prevent failure or damage to data

●

Do not bring magnetic cards, such as a credit card, or magnetic recording
media, close to the wireless charger. Otherwise, data may be erased due
to the influence of magnetism.
Additionally, do not bring precision instruments such as wrist watches,
close to the wireless charger, as such objects may malfunction.

●

Do not leave portable devices in the cabin. The temperature inside the
cabin may become high when parked in the sun, and cause damage to the
device.

■

To prevent battery discharge

Do not use the wireless charger for a long period of time with the engine is
stopped.

388

5-4. Other interior features

An assist grip (type A) installed on the pillar can be used when getting
in or out of the vehicle and others.
An assist grip (type B) installed on the ceiling can be used to support
your body while sitting on the seat.

Assist grip (type A)
Assist grip (type B)

Assist grips

WARNING

■

Assist grip (type B)

Do not use the assist grip when getting in or out of the vehicle or rising from
your seat.
Doing so could damage the assist grip, or could cause you to injure yourself
by falling over.

NOTICE

Do not hang any heavy object or put a heavy load on the assist grip.

389

5-4. Other interior features

Interio

r features

Garage door opener



The HomeLink

wireless control system in your vehicle has 3 buttons

which can be programmed to operate 3 different devices. Refer to the
programming methods on the following pages to determine the
method which is appropriate for the device.

HomeLink

indicator light

Garage door operation indica-
tors
Buttons

■

Before programming the HomeLink

●

During programming, it is possible that garage doors, gates, or
other devices may operate. For this reason, make sure that peo-
ple and objects are clear of the garage door or other devices to
prevent injury or other potential harm.

●

It is recommended that a new battery be placed in the remote
control transmitter for more accurate programming.

●

Garage door opener motors manufactured after 1995 may be
equipped with rolling code protection. If this is the case, you may
need a stepladder or other sturdy, safe device to reach the
“learn” or “smart” button on the garage door opener motor.



: If equipped

The garage door opener can be programmed to operate garage
doors, gates, entry doors, door locks, home lighting systems,
security systems, and other devices.

HomeLink

1
2

390

5-4. Other interior features

■

HomeLink

programming procedure

The programming procedures can
also be found at the following
URL.
Website:
www.homelink.com/toyota

For support, contact customer support at the following.
Help Line: 1-800-355-3515

■

Programming the HomeLink

Steps

through

must be performed within 60 seconds, other-

wise the indicator light will stop flashing and programming will not
be able to be completed.

Press and release the HomeLink

button you want to program

and check that the HomeLink

indicator light flashes orange.

Point  the  remote  control
transmitter  for  the  device  at
the rear view mirror, 1 to 3 in.
(25  to  75  mm)  from  the
HomeLink

buttons.

Keep the HomeLink

indicator

light in view while programming.

Program a device.

391

5-4. Other interior features

Interio

r features



Programming a device other than an entry gate (for U.S.A.
owners)

Press and hold the handheld transmitter button until the Home-
Link

indicator light changes from slowly flashing orange to rap-

idly flashing green (rolling code) or continuously lit green (fixed
code), then release the button.



Programming an entry gate (for U.S.A. owners)/Programming
a device in the Canadian market

Press and release the remote control transmitter button at 2 sec-
ond intervals, repeatedly, until the HomeLink

indicator light

changes from slowly flashing orange to rapidly flashing green
(rolling code) or continuously lit green (fixed code).
Test the HomeLink

operation by pressing the newly pro-

grammed button and observing the indicator light:

●

Indicator light illuminates: Programming of a fixed code device
has completed. The garage door or other device should oper-
ate when a HomeLink

button is pressed and released.

●

Indicator light flashes rapidly: The garage door opener motor
or other device is equipped with a rolling code. To complete
programming, firmly press and hold the HomeLink

button for

2 seconds then release it.

●

If the garage door or other device does not operate, proceed
to “Programming a rolling code system”.

Repeat the steps above to program another device for any of the
remaining HomeLink

buttons.

392

5-4. Other interior features

■

Programming a rolling code system

2 or more people may be necessary to complete rolling code pro-
gramming.

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

This button can usually be found
where the hanging antenna wire
is  attached  to  the  unit.  The
name  and  color  of  the  button
may  vary  by  manufacturer.
Refer  to  the  Owner’s  manual
supplied  with  the  garage  door
opener motor for details.

Press and release the
“Learn” or “Smart” button.
Perform

within 30 sec-

onds after performing

393

5-4. Other interior features

Interio

r features

Press and hold the desired
HomeLink

button (inside the

vehicle) for 2 seconds and
release it. Repeat this
sequence

(press/hold/

release)  up  to  3  times  to
complete programming.
If  the  garage  door  opener
motor  operates  when  the
HomeLink

button

pressed, the garage door
opener motor recognizes the
HomeLink

signal.

■

Enabling 2-way communication with a garage door (only avail-
able for compatible devices)

When enabled, 2-way communication allows you to check the sta-
tus of the opening and closing of a garage door through indicators
in your vehicle.
2-way communication is only available if the garage door opener
motor used is a compatible device. (To check device compatibility,
refer to www.HomeLink.com.)

Within 5 seconds after programming the garage door opener has
been completed, if the garage door opener motor is trained to
HomeLink

, both garage door operation indicators will flash rap-

idly green and the light on the garage door opener motor will
blink twice, indicating that 2-way communication is enabled.

If the indicators do not flash, perform

and

within the first 10

presses of the HomeLink

button after programming has been

completed.

Press a programmed HomeLink

button to operate a garage

door.
Within 1 minute of pressing the HomeLink

button, after the

garage door operation has stopped, press the “Learn” or “Smart”
button on the garage door opener motor. Within 5 seconds of the
establishment of 2-way communication with the garage door
opener, both garage door operation indicators in the vehicle will
flash rapidly green and the light on the garage door opener motor
will blink twice, indicating that 2-way communication is enabled.

394

5-4. Other interior features

■

Reprogramming a single HomeLink

button

When the following procedure is performed, buttons which already
have devices registered to them can be overwritten:

With one hand, press and hold the desired HomeLink

button.

When the HomeLink

indicator starts flashing orange, release

the HomeLink

button and perform “Programming the Home-

Link

”

(it takes 20 seconds for the HomeLink

indicator to

start flashing).

Press the appropriate HomeLink

button. The HomeLink

indicator

light should turn on.

The status of the opening and
closing of a garage door is shown
by the indicators.

Opening
Closing

This function is only available if the
garage door opener motor used is
a compatible device. (To check
device compatibility, refer to
www.HomeLink.com.)

The indicators can operate within approximately 820 ft. (250 m) of
the garage door. However, if there are obstructions between the
garage door and the vehicle, such as houses and trees, feedback
signals from the garage door may not be received.
To recall the previous door operation status, press and release

either HomeLink

buttons

and

simultaneously. The last recorded status will be displayed for 3 sec-
onds.

Operating the HomeLink

Garage door operation indicators

1
2

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

395

5-4. Other interior features

Interio

r features

Press and hold the 2 outside but-
tons for 10 seconds until the
HomeLink

indicator

light

changes from continuously lit
orange to rapidly flashing green.

If you sell your vehicle, be sure to
erase the programs stored in the
HomeLink

memory.

■

Codes stored in the HomeLink

memory

●

The registered codes are not erased even if the battery cable is discon-
nected.

●

If learning failed when registering a different code to a HomeLink

button

that already has a code registered to it, the already registered code will not
be erased.

■

Before programming

●

Install a new battery in the transmitter.

●

The battery side of the transmitter must be pointed away from the Home-
Link

Erasing the entire HomeLink

memory (all three codes)

396

5-4. Other interior features

■

Certification for the garage door opener



For vehicles sold in the U.S.A.

FCC ID: NZLAECHL5
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.



For vehicles sold in Canada

NOTE:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.
REMARQUE:
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.

■

About HomeLink

HomeLink and the HomeLink house icon are registered trademarks of Gen-
tex Corporation.

WARNING

■

When programming a garage door or other remote control device

The garage door or other device may operate, so ensure people and
objects are out of danger to prevent potential harm.

■

Conforming to federal safety standards

Do not use the HomeLink

compatible transceiver with any garage door

opener or device that lacks safety stop and reverse features as required by
federal safety standards.
This includes any garage door that cannot detect an interfering object. A
door or device without these features increases the risk of death or serious
injury.

■

When operating or programming HomeLink

Never allow a child to operate or play with the HomeLink

buttons.

Content .. 21 22 23 24 ..
