Toyota Tacoma (2023 year). Manual in english - page 6

106

●

Accent color
Select to change the accent colors on the screen, such as the
cursor color.

●

Speed limit display

Select to set the display of speed limit information stored in the
navigation system (if equipped) to on with the speed limit caution
indicator (yellow) enabled, on with the speed limit caution not
enabled, or off. If enabled, the speed limit caution indicator will
come on if the vehicle speed exceeds the displayed speed limit.

●

Programming
It is possible to set up a screen desired to be displayed as the

Top Screen by pressing and holding

There are also screens that cannot be setup as the Top Screen.

●

Maintenance system (U.S.A.)
Select to reset the message after the required maintenance is
performed. (



P. 410)

●

Default settings
Registered or changed meter settings will be deleted or returned
to their default setting.

: Speed limit display may not be available for some regions.

107

2. Instrument cluster

Instrument cluster

■

Setting items

●

Setting items are not selectable during driving and cannot be operated.
Also, the settings screen is temporarily canceled in the following situations.
• A warning message is displayed.
• The vehicle starts off.

●

Settings for functions not equipped to the vehicle are not displayed.

●

When a function is turned off, the related settings for that function are not
selectable.

■

Pop-up display

In some situations, such as when a switch operation is performed, a pop-up
display will be temporarily displayed on the multi-information display.

■

When disconnecting and reconnecting battery terminals

The drive information will be reset.

■

Ending display

When the engine switch is turned off, each of the following will be displayed
on the multi-information display, and will extinguish after approximately
30 seconds.

●

Distance traveled

●

Average fuel economy

●

Distance to empty

■

Tire inflation pressure (vehicles with tire pressure warning system)

●

It may take a few minutes to display the tire inflation pressure after the
engine switch is turned to the “ON” position (vehicles without a smart key
system) or IGNITION ON mode (vehicles with a smart key system). It may
also take a few minutes to display the tire inflation pressure after inflation
pressure has been adjusted.

●

“---” may be displayed if the tire position information cannot be determined
due to unfavorable radio wave conditions.

●

Tire inflation pressure changes with temperature. The displayed values may
also be different from the values measured using a tire pressure gauge.

■

Liquid crystal display



P. 100

108

2. Instrument cluster

WARNING

■

Caution for use while driving

●

When operating the multi-information display while driving, pay extra
attention to the safety of the area around the vehicle.

●

Do not look continuously at the multi-information display while driving as
you may fail to see pedestrians, objects on the road, etc. ahead of the
vehicle.

■

Cautions during setting up the display

As the engine needs to be running during setting up the display, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area
such as a garage, exhaust gases including harmful carbon monoxide (CO)
may collect and enter the vehicle. This may lead to death or a serious
health hazard.

NOTICE

■

During setting up the display

To prevent battery discharge, ensure that the engine is running while setting
up the display features.

109

2. Instrument cluster

Instrument cluster

Fuel consumption information



Press the “APPS” button, and then select “Eco” on the screen.

■

Trip information

If the “Past Record” screen is displayed, select “Trip Information”.

Resetting the consumption
data
Average vehicle speed since
the engine was started
Elapsed time since the
engine was started
Fuel consumption in the past
15 minutes
Cruising range (



P. 110)

Current fuel consumption

Average  fuel  consumption  for  the  past  15  minutes  is  divided  by
color  into  past  averages  and  averages  attained  since  the  engine
switch  was  last  turned  to  the  “ON”  position  (vehicles  without  a
smart  key  system)  or  IGNITION  ON  mode  (vehicles  with  a  smart
key system). Use the displayed average fuel consumption as a ref-
erence.

These images are examples only.



: If equipped

The fuel consumption information can be displayed on the navi-
gation system or multimedia system.

Display the trip information or past record screen

Fuel consumption

110

2. Instrument cluster

■

Past record

If the “Trip Information” screen is displayed, select “Past Record”.

Resetting the past record
data
Best recorded fuel consump-
tion
Average fuel consumption (if
equipped)
Previous fuel consumption
record
Update the average fuel consumption data

The average fuel consumption history is divided by color into past
averages and the average fuel consumption since the last updated.
Use the displayed average fuel consumption as a reference.

These images are examples only.

■

Resetting the data

The fuel consumption data can be deleted by selecting “Clear”.

■

Updating the past record data

Update the average fuel consumption by selecting “Update” to measure the
current fuel consumption again.

■

Cruising range

Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
This distance is computed based on your average fuel consumption. As a
result, the actual distance that can be driven may differ from that displayed.

111

Operation of

each component

3-1. Key information

Keys .................................. 112

3-2. Opening, closing and

locking the doors

Doors ................................ 119
Tailgate ............................. 126
Smart key system.............. 131

3-3. Adjusting the seats

Front seats ........................ 139
Rear seats......................... 142
Head restraints.................. 145

3-4. Adjusting the steering

wheel and mirrors

Steering wheel .................. 149
Inside rear view mirror....... 151
Outside rear view

mirrors............................. 154

3-5. Opening, closing the

windows and moon roof

Power windows ................. 156
Back window (vehicles

with sliding type) ............. 159

Power back window .......... 160
Moon roof.......................... 162

112

3-1. Key information

Keys

The following keys are provided with the vehicle.



Type A

Keys
Key number plate



Type B

Keys
Key number plate



Type C

Keys

Operating the wireless remote con-
trol function

Key number plate

The keys

113

3-1. Key information

Opera

tion of e

ach compon

ent



Type D

Electronic keys

• Operating the smart key sys-

tem

(



P. 131)

• Operating

the

wireless

remote control function

Mechanical keys
Key
Key number plate



Type C

Locks all the doors (



P. 119)

Unlocks all the doors (



P. 119)

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.

Sounds the alarm (press and
hold) (



P. 114)



Type D

Locks all the doors (



P. 120)

Unlocks all the doors (



P. 120)

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.

Sounds the alarm (press and
hold) (



P. 114)

Wireless remote control (type C or type D)

114

3-1. Key information

To take out the mechanical key,
push the release button and take
the key out.

The  mechanical  key  can  only  be
inserted  in  one  direction,  as  the
key only has grooves on one side.
If  the  key  cannot  be  inserted  in  a
lock cylinder, turn it over and reat-
tempt to insert it.

After using the mechanical key, store it in the electronic key. Carry the
mechanical key together with the electronic key. If the electronic key
battery is depleted or the entry function does not operate properly, you
will need the mechanical key. (



P. 528)

■

Panic mode (type C or type D)



Type C



Type D

Using the mechanical key (type D)

When

is pressed for longer than

about 1 second, an alarm will sound inter-
mittently and the vehicle lights will flash to
deter any person from trying to break into
or damage your vehicle.
To stop the alarm, press any button on the
wireless remote control.

When

is pressed for longer than

115

3-1. Key information

Opera

tion of e

ach compon

ent

■

When required to leave the vehicle’s key with a parking attendant (type
D)

Lock the glove box as circumstances demand. (



P. 357)

Remove the mechanical key for your own use and provide the attendant with
the electronic key only.

■

If you lose your keys



Type A, B and C

New genuine key can be made by your Toyota dealer using the other key and
the key number stamped on your key number plate.
Keep the plate in a safe place such as your wallet, not in the vehicle.



Type D

New genuine key can be made by your Toyota dealer.
The following are necessary when making new keys.
Mechanical key:
The key number for the mechanical key stamped on the number plate and the
other key.
Key:
The key number for key stamped on the key number plate.
Keep the plates in a safe place such as your wallet, not in the vehicle.
There are key number plates for the mechanical key and key respectively.
When storing them, keep them in a safe place in a manner to distinguish one
from the other (such as markings, etc.).

■

When riding in an aircraft (type C or type D)

When bringing an wireless remote control function onto an aircraft, make sure
you do not press any button on the key while inside the aircraft cabin. If you
are carrying the key in your bag, etc., ensure that the buttons are not likely to
be pressed accidentally. Pressing a button may cause the key to emit radio
waves that could interfere with the operation of the aircraft.

■

Conditions affecting operation (type C or type D)



Type C

The wireless remote control function may not operate normally in the follow-
ing situations:

●

Near a TV tower, radio station, electric power plant, airport or other facility
that generates strong radio waves

●

When carrying a portable radio, cellular phone or other wireless communi-
cation devices

●

When multiple wireless keys are in the vicinity

●

When the wireless key is in contact with, or is covered by a metallic object

●

When a wireless key (that emits radio waves) is being used nearby

●

When the wireless key has been left near an electrical appliance such as a
personal computer



Type D



P. 134

116

3-1. Key information

■

Key battery depletion (type C or type D)



Type C

If the wireless remote control function does not operate, the battery may be
depleted. Replace the battery when necessary. (



P. 451)



Type D

●

The standard battery life is 1 to 2 years.

●

If the battery becomes low, an alarm will sound in the cabin when the engine
stops. (



P. 508)

●

As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate that the electronic key battery may be depleted. Replace the battery
when necessary. (



P. 451)

• The smart key system or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.

●

To avoid serious deterioration, do not leave the electronic key within 1 m
(3 ft.) of the following electrical appliances that produce a magnetic field:
• TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Table lamps
• Induction cookers

■

Replacing the battery (type C or type D)



P. 451

■

Confirmation of the registered key number

The number of keys already registered to the vehicle can be confirmed. Ask
your Toyota dealer for details.

■

Customization (type C or type D)

Settings (e.g. wireless remote control system) can be changed.
(Customizable features:



P. 568)

117

3-1. Key information

Opera

tion of e

ach compon

ent

■

Certification for wireless remote control (type C)



For vehicles sold in U.S.A. and New Caledonia

FCC ID: HYQ23AAH
FCC ID: HYQ23AAN
FCC ID: HYQ12BEL
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
<For 12BEL>
The FCC ID/IC Certification number is affixed inside the equipment. You can
find the ID/number when replacing the battery.



For vehicles sold in Canada

NOTE:
This device  complies with Industry Canada’s  licence-exempt RSSs. Opera-
tion is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
<For 12BEL>
The FCC ID/IC Certification number is affixed inside the equipment. You can
find the ID/number when replacing the battery.
NOTE:
Le  présent  appareil  est  conforme  aux  CNR  d’Industrie  Canada  applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
<Pour 12BEL>
L’identification  FCC/Ie  numéro  d’accréditation  IC  est  apposé(e)  à  l’intérieur
de l’appareil. Cette identification/ce numéro est visible au remplacement de la
pile.

■

Certification for wireless remote control (type D)



P. 137

118

3-1. Key information

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to strong shocks or bend them.

●

Do not expose the keys to high temperatures for long periods of time.

●

Do not get the keys wet or wash them in an ultrasonic washer, etc.

●

Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else to the surface of the electronic key.

●

Do not place the keys near objects that produce magnetic fields, such as
TVs, audio systems and induction cookers, or medical electrical equip-
ment, such as low-frequency therapy equipment.

■

Carrying the electronic key on your person (type D)

Carry the electronic key 10 cm (3.9 in.) or more away from electric appli-
ances that are turned on. Radio waves emitted from electric appliances
within 10 cm (3.9 in.) of the electronic key may interfere with the key, caus-
ing the key to not function properly.

■

In case of a smart entry & start system malfunction or other key-related
problems (type D)

Take your vehicle with all the electronic keys provided with your vehicle to
your Toyota dealer.

■

When an electronic key is lost (type D)

If the electronic key remains lost, the risk of vehicle theft increases signifi-
cantly. Visit your Toyota dealer immediately with all remaining electronic
keys that was provided with your vehicle.

119

3-2. Opening, closing and locking the doors

Opera

tion of e

ach compon

ent

Doors

◆

Key



Vehicles without a smart key system

Locks all the doors
Unlocks all the doors

Turning the key unlocks the
driver’s door. Turning the key
again unlocks the other doors.



Vehicles with a smart key system
The doors can also be locked and unlocked with the mechanical
key. (



P. 528)

◆

Wireless remote control (if equipped)

Locks all the doors

Check that the door is securely locked.

Unlocks all the doors

Pressing the button unlocks the driver’s door. Pressing the button again
within 3 seconds unlocks the other doors.

Unlocking and locking the doors from the outside



Vehicles without a smart key
system



Vehicles with a smart key sys-
tem

120

3-2. Opening, closing and locking the doors

◆

Smart key system (if equipped)

Carry the electronic key to enable this function.

Grip the driver’s door handle
to unlock the door. Grip the
passenger’s door handle to
unlock all the doors.

Make sure to touch the sensor
on the back of the handle.
The doors cannot be unlocked
for 3 seconds after the doors are
locked.

Touch the lock sensor (the indentation on the upper part or lower
part of the front door handle) to lock the doors.

Check that the door is securely locked.

■

Operation signals (vehicles with a wireless remote control or smart key
system)

A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: once; Unlocked: twice)

■

Security feature (vehicles with a wireless remote control or smart key
system)

If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.

■

When the door cannot be locked by the lock sensor on the upper part of
the door handle (vehicles with a smart key system)

■

Door lock buzzer (vehicles with a smart key system)

If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds continuously for 5 seconds. Fully close the door to stop the
buzzer, and lock the vehicle once more.

■

Alarm (if equipped)

Locking the doors will set the alarm system. (



P. 88)

If the door will not lock even when the top-
side sensor area is touched, try touching
both the topside and underside sensor
areas at the same time.
