Toyota Mirai (2023 year). Manual in english - page 28

454

8-2. Steps to take in an emergency

■

Hydrogen leak warning light (warning buzzer)

■

Brake system warning light (warning buzzer)

■

Brake system warning light (warning buzzer)

If a warning light turns on or a warning buzzer

sounds

Calmly perform the following actions if any of the warning
lights comes on or flashes. If a light comes on or flashes, but
then goes off, this does not necessarily indicate a malfunc-
tion in the system. However, if this continues to occur, have
the vehicle inspected by your Toyota dealer.

Actions to the warning lights or warning buzzers

Warning light

Details/Actions

When a hydrogen gas leak is detected, a buzzer sounds, a
light comes on, and a warning message is displayed on the
multi-information display.



P.90

Warning light

Details/Actions

(U.S.A.)

(Red)

(Canada)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer. Continuing to drive the vehi-
cle may be dangerous.

Warning light

Details/Actions

(Yellow)

Indicates a malfunction in:



The regenerative braking system;



The electronically controlled brake system; or



The parking brake system



Have the vehicle inspected by your Toyota dealer
immediately.

455

8-2. Steps to take in an emergency

Whe

n tr

ouble

rises

■

High coolant temperature warning light

■

Fuel cell system overheat warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

■

Charging system warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

■

SRS warning light

■

Pop Up Hood warning light

Warning light

Details/Actions

(Red)

Indicates that the coolant temperature is too high



Immediately stop the vehicle in a safe place.
Handling method (



P.490)

Warning light

Details/Actions

Indicates the fuel cell system has overheated



Stop the vehicle in a safe place.
Handling method (



P.490)

Warning light

Details/Actions

Indicates a malfunction in the vehicle’s charging system



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer.

Warning light

Details/Actions

Indicates a malfunction in:



The SRS airbag system;



The front passenger occupant classification system; or



The seat belt pretensioner system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

Indicates that the Pop Up Hood system has operated



The Pop Up Hood system cannot be reused once it
has operated. Have it replaced by your Toyota dealer.

Indicates a malfunction in the Pop Up Hood system



Have the vehicle inspected by your Toyota dealer
immediately.

456

8-2. Steps to take in an emergency

■

ABS warning light

■

Electric power steering system warning light (warning
buzzer)

■

PCS warning light

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The ABS; or



The brake assist system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

(Red)

(Yellow)

Indicates a malfunction in the EPS (Electric Power Steer-
ing) system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

(Flashes or illu-

minates)

When a buzzer sounds simultaneously:
Indicates a malfunction has occurred in the PCS (Pre-Colli-
sion System).



Have the vehicle inspected by your Toyota dealer
immediately.

When a buzzer does not sound:
The PCS (Pre-Collision System) has become temporarily
unavailable, corrective action may be necessary.



Follow the instructions displayed on the multi-infor-
mation display. (



P.217, 464)

If the PCS (Pre-Collision System) or VSC (Vehicle Stability
Control) system is disabled, the PCS warning light will illu-
minate.



P.323

457

8-2. Steps to take in an emergency

Whe

n tr

ouble

rises

■

LTA indicator (warning buzzer)

■

Intuitive parking assist OFF indicator (warning buzzer)

■

PKSB OFF indicator (warning buzzer)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the LTA (Lane Tracing Assist)



Follow the instructions displayed on the multi-infor-
mation display. (



P.240)

Warning light

Details/Actions

(If equipped)

Indicates a malfunction in the intuitive parking assist func-
tion



Have the vehicle inspected by your Toyota dealer
immediately.

Indicates that the system is temporarily unavailable, possi-
bly due to a sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-infor-
mation display. (



P.263)

Warning light

Details/Actions

(If equipped)

When a buzzer sounds:
Indicates a malfunction in the PKSB (Parking Support
Brake) system



Have the vehicle inspected by your Toyota dealer
immediately.

When a buzzer does not sound:
Indicates that the system is temporarily unavailable, possi-
bly due to a sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-infor-
mation display. (



P.286)

458

8-2. Steps to take in an emergency

■

RCTA OFF indicator (warning buzzer)

■

RCD OFF indicator (warning buzzer)

■

Slip indicator light

Warning light

Details/Actions

(Flashes)

(If equipped)

Indicates a malfunction in the RCTA (Rear Cross Traffic
Alert) function



Have the vehicle inspected by your Toyota dealer
immediately.

Indicates that the rear bumper around the radar sensor is
covered with dirt, etc. (



P.258)



Follow the instructions displayed on the multi-infor-
mation display. (



P.273)

Warning light

Details/Actions

(Flashes or illu-

minates)

(If equipped)

When a buzzer sounds:
Indicates a malfunction in the RCD (Rear Camera Detec-
tion) function



Have the vehicle inspected by your Toyota dealer
immediately.

When a buzzer does not sound:
Indicates that the function temporarily cannot be used due
to the camera being dirty, etc.



Follow the instructions displayed on the multi-infor-
mation display. (



P.279)

Warning light

Details/Actions

Indicates a malfunction in:



The VSC system;



The TRAC system; or



The hill-start assist control system



Have the vehicle inspected by your Toyota dealer
immediately.

459

8-2. Steps to take in an emergency

Whe

n tr

ouble

rises

■

Inappropriate pedal operation warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

■

Brake hold operated indicator (warning buzzer)

■

Parking brake indicator (warning buzzer)

Warning light

Details/Actions

When a buzzer sounds:



Brake Override System is malfunctioning



Drive-Start Control is malfunctioning



Drive-Start Control is operating



PKSB (Parking Support Brake) is operating



Follow the instructions displayed on the multi-infor-
mation display.

When a buzzer does not sound:
Brake Override System is operating.



Release the accelerator pedal and depress the brake
pedal.

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

(Flashes)

(U.S.A.)

(Flashes)
(Canada)

It is possible that the parking brake is not fully engaged or
released.



Operate the parking brake switch once again.

This light comes on when the parking brake is not released.
If the light turns off after the parking brake is fully released,
the system is operating normally.

460

8-2. Steps to take in an emergency

■

Tire pressure warning light

■

Low fuel level warning light

■

Driver’s and front passenger’s seat belt reminder light (warn-
ing buzzer)

: Driver’s seat belt warning buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or
her seat belt is not fastened. Once the power switch is turned to ON, the
buzzer sounds. If the seat belt is still unfastened, the buzzer sounds inter-
mittently for a certain period of time after the vehicle reaches a certain
speed.
Front passenger’s seat belt warning buzzer:
The front passenger’s seat belt warning buzzer sounds to alert the front
passenger that his or her seat belt is not fastened. If the seat belt is
unfastened, the buzzer sounds intermittently for a certain period of time
after the vehicle reaches a certain speed.

Warning light

Details/Actions

When the light comes on after blinking for approximately 1
minute:
Malfunction in the tire pressure warning system



Have the system checked by your Toyota dealer.

When the light comes on:
Low tire inflation pressure such as



Natural causes



Flat tire



Immediately stop the vehicle in a safe place.
Handling method (



P.461)

Warning light

Details/Actions

Indicated the remain fuel is approximately 12% or less



Refuel the vehicle.

Warning light

Details/Actions

Warns the driver and/or front passenger to fasten their seat
belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front
passenger’s seat belt also needs to be fastened to
make the warning light (warning buzzer) turn off.

461

8-2. Steps to take in an emergency

Whe

n tr

ouble

rises

■

Rear passengers’ seat belt reminder lights (warning buzzer)

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear
passenger that his or her seat belt is not fastened. If the seat belt is
unfastened, the buzzer sounds intermittently for a certain period of time,
after the seat belt is fastened and unfastened and the vehicle reaches a
certain speed.

■

Warning buzzer

In some cases, the buzzer may not

be heard due to being in a noisy

location or audio sound.

■

Front passenger detection sen-

sor, seat belt reminder and

warning buzzer

●

If luggage is placed on the front

passenger seat, the front passen-

ger detection sensor may cause

the warning light to flash and the

warning buzzer to sound even if a

passenger is not sitting in the

seat.

●

If a cushion is placed on the seat,

the sensor may not detect a pas-

senger, and the warning light may

not operate properly.

■

SRS warning light

This warning light system monitors

the airbag sensor assembly, front

impact sensors, side impact sensors

(front door), side impact sensors

(front), side impact sensors (rear),

driver’s seat position sensor,

driver’s seat belt buckle switch, front

passenger occupant classification

system (ECU and sensors), “AIR-

BAG ON” indicator light, “AIRBAG

OFF” indicator light, front passen-

ger’s seat belt buckle switch, seat

belt pretensioners, airbags, inter-

connecting wiring and power

sources. (



P.34)

■

Electric power steering system

warning light (warning buzzer)

When the 12-volt battery charge

becomes insufficient or the voltage

temporarily drops, the electric power

steering system warning light may

come on and the warning buzzer

may sound.

■

When the tire pressure warning

light comes on

Inspect the tires to check if a tire is

punctured.
If a tire is punctured:



P.467

If none of the tires are punctured:

Turn the power switch off then turn it

to ON. Check if the tire pressure

warning light comes on or blinks.



If the tire pressure warning light

blinks for approximately 1 minute

then stays on

There may be a malfunction in the

tire pressure warning system. Have

the vehicle inspected by your Toyota

dealer immediately.



If the tire pressure warning light

comes on

After the temperature of the tires

has lowered sufficiently, check

the inflation pressure of each tire

and adjust them to the specified

level.

If the warning light does not turn

off even after several minutes

have elapsed, check that the

inflation pressure of each tire is

Warning light

Details/Actions

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

462

8-2. Steps to take in an emergency

at the specified level and perform

initialization. (



P.420)

■

The tire pressure warning light

may come on due to natural

causes

The tire pressure warning light may

come on due to natural causes such

as natural air leaks and tire inflation

pressure changes caused by tem-

perature. In this case, adjusting the

tire inflation pressure will turn off the

warning light (after a few minutes).

■

Conditions that the tire pres-

sure warning system may not

function properly



P.419

WARNING

■

If both the ABS and the brake

system warning lights remain

Stop your vehicle in a safe place

immediately and contact your Toy-

ota dealer.

The vehicle will become

extremely unstable during brak-

ing, and the ABS system may fail,

which could cause an accident

resulting in death or serious injury.

■

When the electric power

steering system warning light

comes on

When the light comes on yellow,

the assist to the power steering is

restricted. When the light comes

on red, the assist to the power

steering is lost and handling oper-

ations of the steering wheel

become extremely heavy.

When steering wheel operations

are heavier than usual, grip the

steering wheel firmly and operate

it using more force than usual.

■

If the tire pressure warning

light comes on

Be sure to observe the following

precautions.

Failure to do so could cause a

loss of vehicle control and result

in death or serious injury.

●

Check and adjust the tire infla-

tion pressure immediately.

●

If the tire pressure warning light

comes on even after tire infla-

tion pressure adjustment, it is

probable that you have a flat

tire. Have the flat tire replaced

by the nearest Toyota dealer.

●

Avoid abrupt maneuvering and

braking.

If the vehicle tires deteriorate,

you could lose control of the

steering wheel or the brakes.

■

If a blowout or sudden air

leakage should occur

The tire pressure warning system

may not activate immediately.

■

Maintenance of the tires

Each tire, including the spare (if

provided), should be checked

monthly when cold and inflated to

the inflation pressure recom-

mended by the vehicle manufac-

turer on the vehicle placard or tire

inflation pressure label (tire and

load information label). (If your

vehicle has tires of a different size

than the size indicated on the

vehicle placard or tire inflation

pressure label [tire and load infor-

mation label], you should deter-

mine the proper tire inflation

pressure for those tires.)

463

8-2. Steps to take in an emergency

Whe

n tr

ouble

rises

WARNING

As an added safety feature, your

vehicle has been equipped with a

tire pressure monitoring system

(TPMS-tire pressure warning sys-

tem) that illuminates a low tire

pressure telltale (tire pressure

warning light) when one or more

of your tires is significantly under-

inflated. Accordingly, when the

low tire pressure telltale (tire pres-

sure warning light) illuminates,

you should stop and check your

tires as soon as possible, and

inflate them to the proper pres-

sure. Driving on a significantly

under-inflated tire causes the tire

to overheat and can lead to tire

failure. Under-inflation also

reduces fuel efficiency and tire

tread life, and may affect the vehi-

cle’s handling and stopping ability.

Please note that the TPMS (tire

pressure warning system) is not a

substitute for proper tire mainte-

nance, and it is the driver’s

responsibility to maintain correct

tire pressure, even if under-infla-

tion has not reached the level to

trigger illumination of the TPMS

low tire pressure telltale (tire pres-

sure warning light).

Your vehicle has also been

equipped with a TPMS (tire pres-

sure warning system) malfunc-

tion indicator to indicate when the

system is not operating properly.

The TPMS (tire pressure warning

system) malfunction indicator is

combined with the low tire pres-

sure telltale (tire pressure warning

light). When the system detects a

malfunction, the telltale will flash

for approximately one minute and

then remain continuously illumi-

nated. This sequence will con-

tinue upon subsequent vehicle

start-ups as long as the malfunc-

tion exists. When the malfunction

indicator is illuminated, the sys-

tem may not be able to detect or

signal low tire pressure as

intended.

TPMS (tire pressure warning sys-

tem) malfunctions may occur for a

variety of reasons, including the

installation of replacement or

alternate tires or wheels on the

vehicle that prevent the TPMS

(tire pressure warning system)

from functioning properly. Always

check the TPMS (tire pressure

warning system) malfunction tell-

tale after replacing one or more

tires or wheels on your vehicle to

ensure that the replacement or

alternate tires and wheels allow

the TPMS (tire pressure warning

system) to continue to function

properly.

NOTICE

■

To ensure the tire pressure

warning system operates

properly

Do not install tires with different

specifications or makers, as the

tire pressure warning system may

not operate properly.

464

8-2. Steps to take in an emergency

■

Warning messages

The warning messages explained

below may differ from the actual

messages according to operation

conditions and vehicle specifica-

tions.

■

Warning buzzer

A buzzer may sound when a mes-

sage is displayed.
In some cases, the buzzer may not

be heard due to being in a noisy

location or audio sound.

■

If “FCV System Stopped Steer-

ing Power Low” is displayed

This message is displayed if the fuel

cell system is stopped while driving.
When steering wheel operations are

heavier than usual, grip the steering

wheel firmly and operate it using

more force than usual.

■

If “FCV System High Temp. FCV

Power Reduced” or “FCV

Power Reduced Due to Exces-

sive Acceleration” is displayed

Lower the speed while check the

safety, and run the vehicle like

this for several minutes.

If the message goes off, the vehi-

cle can be driven as is, since it

temporarily overheated.

This message may be displayed

when driving under severe operat-

ing conditions. (For example, when

driving up a long steep hill.)

■

If “FCV Power Significantly

Reduced” is displayed

The output power of the fuel cell

system is greatly restrained. If it is

displayed frequently, contact your

Toyota dealer.

■

If “Stop Vehicle in a Safe Place

Push P Switch” is displayed

There may be a malfunction in the

fuel cell system or the shift position

may be shifted to N for a long time.

Immediately stop the vehicle and

contact your Toyota dealer.

■

If “Shift is in N Release Acceler-

ator Before Shifting” is dis-

played

The accelerator pedal has been

depressed when the shift position is

in N.
Release the accelerator pedal and

shift the shift position to D or R.

■

If “Press brake when vehicle is

stopped FCV system may over-

heat” is displayed

The message may be displayed

when the accelerator pedal is

If a warning message

is displayed

The multi-information dis-
play shows warnings for
system malfunctions and
incorrectly performed oper-
ations, and messages that
indicate a need for mainte-
nance. When a message is
displayed, perform the
appropriate corrective
action for the message.

If a warning message is dis-
played again after the
appropriate actions have
been performed, contact
your Toyota dealer.

Additionally, if a warning
light comes on or flashes at
the same time that a warn-
ing message is displayed,
take the appropriate correc-
tive action for the warning
light. (



P.454)

465

8-2. Steps to take in an emergency

Whe

n tr

ouble

rises

depressed to hold the vehicle while

the vehicle is stopped on an incline,

etc. The fuel cell system may over-

heat. Release the accelerator pedal

and depress the brake pedal.

■

If “Auto Power OFF to Conserve

Battery” is displayed

Power was turned off due to the

automatic power off function. Next

time when starting the fuel cell sys-

tem, operate the fuel cell system for

approximately 5 minutes to

recharge the 12-volt battery.

■

If “Headlight System Malfunc-

tion Visit Your Dealer” is dis-

played

The following systems may be mal-

functioning. Have the vehicle

inspected by your Toyota dealer

immediately.

●

The LED headlight system

●

The automatic headlight leveling

system (if equipped)

●

AHB (Automatic High Beam)

■

If “Radar Cruise Control

Unavailable See Owner’s Man-

ual” is displayed

The dynamic radar cruise control

with full-speed range system is sus-

pended temporarily or until the prob-

lem shown in the message is

resolved. (Causes and coping meth-

ods:



P.217)

■

If “Radar Cruise Control

Unavailable” is displayed

The dynamic radar cruise control

with full-speed range system cannot

be used temporarily. Use the system

when it becomes available again.

■

If a message that indicates the

malfunction of front camera is

displayed

The following systems may be sus-

pended until the problem shown in

the message is resolved. (



P.217,

454)

●

PCS (Pre-Collision system)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

RSA (Road Sign Assist) (if

equipped)

●

Dynamic radar cruise control with

full-speed range

■

If a message that indicates the

malfunction of radar sensor is

displayed

The following systems may be sus-

pended until the problem shown in

the message is resolved. (



P.217,

454)

●

PCS (Pre-Collision system)

●

LTA (Lane Tracing Assist)

●

Dynamic radar cruise control with

full-speed range

■

If “Shift System Malfunction

Shifting Unavailable Drive to a

Safe Place and Stop” or “Shift

System Malfunction Driving

Unavailable” is displayed

There is a malfunction in the shift

control system. Have the vehicle

inspected by your Toyota dealer

immediately.

■

If a message that indicates the

need for the shift lever opera-

tion is displayed

To prevent the shift lever from being

operated incorrectly or the vehicle

from moving unexpectedly, a mes-

sage that requires shifting the shift

position may be displayed on the

multi-information display. In that

case, follow the instruction of the

message and shift the shift position.

■

If a message regarding

Advanced Drive is displayed

Refer to “Toyota Teammate

Advanced Drive OWNER’S MAN-

UAL” at Toyota.com for details.

466

8-2. Steps to take in an emergency

■

If a message that indicates the

need for visiting your Toyota

dealer is displayed

The system or part shown on the

multi-information display is malfunc-

tioning. Have the vehicle inspected

by your Toyota dealer immediately.

■

If a message that indicates the

need for referring to Owner’s

Manual is displayed

●

If any of the following messages

are shown on the multi-informa-

tion display, it may indicate a mal-

function. Have the vehicle

inspected by your Toyota dealer

immediately.

• “Smart Key System Malfunction

See Owner’s Manual”

• “P Switch Malfunction Apply Park-

ing Brake Securely When Parking

See Owner’s Manual”

• “Shift System Malfunction Apply

Parking Brake Securely When

Parking See Owner’s Manual”

• “Shift System Unavailable Apply

Parking Brake Securely When

Parking See Owner’s Manual”

• “Shift System Malfunction See

Owner’s Manual”

• “Shift System Malfunction Stop in

a Safe Place See Owner’s Man-

ual”

• “Battery Low Shifting Unavailable

See Owner’s Manual”

• “FCV system malfunction”

• “Traction battery system malfunc-

tion”

• “Accelerator System Malfunction”

●

If any of the following messages

are shown on the multi-informa-

tion display, it may indicate a mal-

function. Immediately stop the

vehicle and contact your Toyota

dealer.

• “Braking Power Low Stop in a

Safe Place See Owner’s Manual”

• “FCV System Shutdown Due to

Hydrogen Leakage Stop in a Safe

Place See Owner’s Manual”

●

If “FCV system stopped” is shown

on the multi-information display,

the vehicle may have run out of

fuel. Stop the vehicle in a safe

place and, if the fuel level is low,

refuel the vehicle. (



P.83)

●

If “Low Auxiliary Battery See

Owner’s Manual” is shown,

• When the display goes off after

several seconds (displays for

about 6 seconds): Maintain the

fuel cell system operation for more

than 15 minutes and charge the

12-volt battery.

• When the display does not go off:

Start up the fuel cell system using

the procedures:



P.485

●

If “Maintenance Required for Trac-

tion Battery Cooling Parts See

Owner’s Manual” is shown, the fil-

ters may be clogged, the air intake

vents may be blocked, or there

may be a gap in the duct. There-

fore, perform the following correc-

tion procedure.

• Cleaning the traction battery air

intake vents (



P.433)

If the warning message is shown

even if the vents are cleaned,

have the vehicle inspected by

your Toyota dealer.

■

If “Ion Filter Maintenance

Required Visit Your Dealer” is

displayed

Ion filter replacement is necessary.

Contact your Toyota dealer.

NOTICE

■

If “Low Auxiliary Battery See

Owner’s Manual” is displayed

frequently

The 12-volt battery may have

deteriorated. As the battery may

discharge in this state when left

unattended, have the battery

inspected by your Toyota dealer.

467

8-2. Steps to take in an emergency

Whe

n tr

ouble

rises

NOTICE

■

If “Maintenance Required For

Traction Battery At Your

Dealer” is displayed

This message indicates that the

traction battery may require

inspection or replacement. Have

the vehicle inspected by your Toy-

ota dealer immediately.

Do not continue driving the vehi-

cle, as the fuel cell system may

become not able to be started

again.

If you have a flat tire

Your vehicle is not equipped
with a spare tire, but instead
is equipped with an emer-
gency tire puncture repair
kit.

A puncture caused by a nail
or screw passing through
the tire tread can be
repaired temporarily using
the emergency tire puncture
repair kit. (The kit contains a
bottle of sealant. The seal-
ant can be used only once
to temporarily repair one
tire without removing the
nail or screw from the tire.)
Depending on the damage,
this kit cannot be used to
repair the tire. (



P.468)

After temporarily repairing
the tire with the kit, have the
tire repaired or replaced by
your Toyota dealer. Repairs
conducted using the emer-
gency tire puncture repair
kit are only a temporary
measure. Have the tire
repaired and replaced as
soon as possible.

WARNING

■

If you have a flat tire

Do not continue driving with a flat

tire.

Driving even a short distance with

a flat tire can damage the tire and

the wheel beyond repair, which

could result in an accident.

468

8-2. Steps to take in an emergency



Stop the vehicle in a safe
place on a hard, flat surface.



Set the parking brake.



Shift the shift position to P.



Stop the fuel cell system.



Turn on the emergency flash-
ers. (



P.446)



Check the degree of the tire
damage.

Do not remove the nail or screw
from the tire. Removing the
object may widen the opening
and make emergency repair
with the repair kit impossible.

■

A flat tire that cannot be

repaired with the emergency

tire puncture repair kit

In the following cases, the tire can-

not be repaired with the emergency

tire puncture repair kit. Contact your

Toyota dealer.

●

When the tire is damaged due to

driving without sufficient air pres-

sure

●

When there are any cracks or

damage at any location on the

tire, such as on the side wall,

except the tread

●

When the tire is visibly separated

from the wheel

●

When the cut or damage to the

tread is 0.16 in. (4 mm) long or

●

When the wheel is damaged

●

When two or more tires have been

punctured

●

When more than 2 sharp objects

such as nails or screws have

passed through the tread on a sin-

gle tire

●

When the sealant has expired

Before repairing the tire

469

8-2. Steps to take in an emergency

Whe

n tr

ouble

rises



Type A

Emergency tire puncture repair kit

Towing eyelet

Location of the emergency tire puncture repair kit and
tools

Content .. 26 27 28 29 ..
