4-2. Driving procedures

when the accelerator pedal is

depressed, release the parking

brake manually.
When the shift lever is shifted from

P, the parking brake will be released

automatically.

■

Parking brake automatic lock

function

The parking brake will be set auto-

matically under the following condi-

tions:

●

The brake pedal is not depressed

●

The driver’s door is open

●

The driver’s seat belt is not fas-

tened

●

The shift lever is in a position

other than P or N

●

The malfunction indicator lamp

and brake system warning light

are not illuminated

■

If “Parking Brake Temporarily

Unavailable” is displayed on

the multi-information display

If the parking brake is operated

repeatedly over a short period of

time, the system may restrict opera-

tion to prevent overheating. If this

happens, refrain from operating the

parking brake. Normal operation will

return after about 1 minute.

■

If “Parking Brake Unavailable”

is displayed on the multi-infor-

mation display

Operate the parking brake switch. If

the message does not disappear

after operating the switch several

times, the system may be malfunc-

tioning. Have the vehicle inspected

by your Toyota dealer.

■

Parking brake operation sound

When the parking brake operates, a

motor sound (whirring sound) may

be heard. This does not indicate a

malfunction.

■

Parking brake indicator light

●

Depending on the engine switch

position/mode, the parking brake

indicator light will turn on and stay

on as described below:

ON: Comes on until the parking

brake is released.

Not in ON: Stays on for approxi-

mately 15 seconds.

●

When the engine switch is turned

off with the parking brake set, the

parking brake indicator light will

stay on for about 15 seconds. This

does not indicate a malfunction.

■

When the parking brake switch

malfunctions

Automatic mode (automatic brake

setting and releasing) will be turned

on automatically.

■

Parking the vehicle



P.122

■

Parking brake engaged warning

buzzer

A buzzer will sound if the vehicle is

driven with the parking brake

engaged. “Parking Brake ON” is dis-

played on the multi-information dis-

play (with the vehicle reaching a

speed of 3 mph [5 km/h]).

■

If the brake system warning

light comes on



P.320

■

Usage in winter time



P.230

WARNING

■

When parking the vehicle

Do not leave a child in the vehicle

alone. The parking brake may be

released unintentionally by a child

and there is the danger of the

vehicle moving that may lead to

an accident resulting in death or

serious injury.

145

4-2. Driving procedures

ing

WARNING

■

Parking brake switch

Do not set any objects near the

parking brake switch.

Objects may interfere with the

switch and may lead the parking

brake to unexpectedly operate.

■

Parking brake automatic lock

function

Never use the automatic parking

brake engagement function in

place of normal parking brake

operation. This function is

designed to reduce the risk of a

collision due to the driver forget-

ting to engage the parking brake.

Over-reliance on this function to

park the vehicle safely may lead

to an accident resulting in death

or serious injury.

NOTICE

■

When parking the vehicle

Before you leave the vehicle, shift

the shift lever to P, set the parking

brake and make sure that the

vehicle does not move.

■

When the system malfunc-

tions

Stop the vehicle in a safe place

and check the warning messages.

■

When the vehicle battery is

discharged

The parking brake system cannot

be activated. (



P.358)

■

When the parking brake can-

not be released due to a mal-

function

Driving the vehicle with the park-

ing brake set will lead to brake

components overheating, which

may affect braking performance

and increase brake wear.
Have the vehicle inspected by

your Toyota dealer immediately if

this occurs.

146

4-2. Driving procedures

Turns the brake hold system on

The brake hold standby indicator
(green)

comes on. While the

system is holding the brake, the
brake hold operated indicator (yel-
low)

comes on.

■

Brake hold system operating

conditions

The brake hold system cannot be

turned on in the following condi-

tions:

●

The driver’s door is not closed.

●

The driver is not wearing the seat

belt.

●

The parking brake is engaged.

If any of the conditions above are

detected when the brake hold sys-

tem is enabled, the system will turn

off and the brake hold standby indi-

cator light will go off. In addition, if

any of the conditions are detected

while the system is holding the

brake, a warning buzzer will sound

and a message will be shown on the

multi-information display. The park-

ing brake will then be set automati-

cally.

■

Brake hold function

●

If the brake pedal is left released

for a period of about 3 minutes

after the system has started hold-

ing the brake, the parking brake

will be set automatically. In this

case, a warning buzzer sounds

and a message is shown on the

multi-information display.

●

To turn the system off while the

system is holding the brake, firmly

depress the brake pedal and

press the button again.

●

The brake hold function may not

hold the vehicle when the vehicle

is on a steep incline. In this situa-

tion, it may be necessary for the

driver to apply the brakes. A warn-

ing buzzer will sound and the

multi-information display will

inform the driver of this situation. If

a warning message is shown on

the multi-information display, read

the message and follow the

instructions.

●

When do not wish for the parking

brake to operate automatically,

press and hold the brake hold

switch until the standby indicator

(green) turns off, and then turn the

engine switch off.

■

When the parking brake is set

automatically while the system

is holding the brakes

Perform any of the following opera-

tions to release the parking brake:

●

Depress the accelerator pedal.

Brake Hold

The brake hold system
keeps the brake applied
when the shift lever is in D,
M or N with the system on
and the brake pedal has
been depressed to stop the
vehicle. The system
releases the brake when the
accelerator pedal is
depressed with the shift
lever in D or M to allow
smooth start off.

Enabling the system

147

4-2. Driving procedures

ing

(The parking brake will not be

released automatically if the seat

belt is not fastened.)

●

Operate the parking brake switch

with the brake pedal depressed.

Make sure that the parking brake

indicator light goes off. (



P.142)

■

When an inspection at your

Toyota dealer is necessary

When the brake hold standby indi-

cator (green) does not illuminate

even when the brake hold switch is

pressed with the brake hold system

operating conditions met, the sys-

tem may be malfunctioning. Have

the vehicle inspected at your Toyota

dealer.

■

If “Brake Hold Malfunction

Press Brake to Deactivate Visit

Your Dealer” or “Brake Hold

Malfunction Visit Your Dealer”

is displayed on the multi-infor-

mation display

The system may be malfunctioning.

Have the vehicle inspected by your

Toyota dealer.

■

Warning messages and buzzers

Warning messages and buzzers are

used to indicate a system malfunc-

tion or to inform the driver of the

need for caution. If a warning mes-

sage is shown on the multi-informa-

tion display, read the message and

follow the instructions.

■

If the brake hold operated indi-

cator flashes



P.327

WARNING

■

When the vehicle is on a

steep incline

Take care when using the brake

hold system on a steep incline,

exercise caution. The brake hold

function may not hold brakes in

such situations.
Also, the system may not activate

depending on the angle of the

slope.

■

When stopped on a slippery

road

The system cannot stop the vehi-

cle when the gripping ability of the

tires has been exceeded. Do not

use the system when stopped on

a slippery road.

NOTICE

■

When parking the vehicle

The brake hold system is not

designed for use when parking

the vehicle for a long period of

time. Turning the engine switch off

while the system is holding the

brake may release the brake,

which would cause the vehicle to

move. When operating the engine

switch, depress the brake pedal,

shift the shift lever to P and set

the parking brake.

148

4-3. Operating the lights and wipers

4-3.Operating the lights and wipers

Operating the

switch

turns on the lights as follows:

U.S.A.
Canada

The headlights, daytime

running lights (



P.148) and

all the lights listed above turn
on and off automatically.

The side marker, park-

ing, tail, license plate, instru-
ment panel lights, and
daytime running lights
(



P.148) turn on.

The headlights and all

lights listed above (except
daytime running lights) turn

on.

(U.S.A.) Off

■

AUTO mode can be used when

The engine switch is in ON.

■

Daytime running light system

●

The daytime running lights illumi-

nate using the same lights as the

headlights and illuminate darker

than the headlights.

●

To make your vehicle more visible

to other drivers during daytime

driving, the daytime running lights

turn on automatically when all of

the following conditions are met.

(The daytime running lights are

not designed for use at night.)

• The engine is running

• The parking brake is released
• The headlight switch is in the,

position

: When the surroundings are bright

The daytime running lights remain

on after they illuminate, even if the

parking brake is set again.

●

For the U.S.A.: Daytime running

lights can be turned off by operat-

ing the switch.

●

Compared to turning on the head-

lights, the daytime running light

system offers greater durability

and consumes less electricity, so

it can help improve fuel economy.

■

Headlight control sensor

The sensor may not function prop-

erly if an object is placed on the sen-

sor, or anything that blocks the

Headlight switch

The headlights can be oper-
ated manually or automati-
cally.

Operating instructions

149

4-3. Operating the lights and wipers

ing

sensor is affixed to the windshield.

Doing so interferes with the sensor

detecting the level of ambient light

and may cause the automatic head-

light system to malfunction.

■

Automatic light off system

●

When the headlights are on: The

headlights and tail lights turn off

30 seconds after the driver’s door

is opened and closed if the engine

switch is turned to ACC or OFF.

(The lights turn off immediately if

on the key is pressed after all

the doors are closed.)

●

When only the tail lights are on:

The tail lights turn off automati-

cally if the engine switch is turned

to ACC or OFF and the driver’s

door is opened.

To turn the lights on again, turn the

engine switch to ON, or turn the light

switch off once and then back to

■

Light reminder buzzer

A buzzer sounds when the engine

switch is turned to OFF or ACC and

the driver’s door is opened while the

lights are turned on.

■

Automatic headlight leveling

system (if equipped)

The level of the headlights is auto-

matically adjusted according to the

number of passengers and the load-

ing condition of the vehicle to

ensure that the headlights do not

interfere with other road users.

■

Windshield wiper linked head-

light illumination

When driving during daytime with
the headlight switch turned to

, if

the windshield wipers are used, the

headlights will turn on automatically

after several seconds to help

enhance the visibility of your vehi-

cle.

■

Battery-saving function

In order to prevent the battery of the

vehicle from discharging, if the

headlights and/or tail lights are on

when the engine switch is turned off

the battery saving function will oper-

ate and automatically turn off all the

lights after approximately 20 min-

utes. When the engine switch is

turned to ON, the battery-saving

function will be disabled.

When any of the following are per-

formed, the battery-saving function

is canceled once and then reacti-

vated. All the lights will turn off auto-

matically 20 minutes after the

Battery- saving function has been

reactivated:

●

When the headlight switch is oper-

ated

●

When a door is opened or closed

■

Customization

Some functions can be customized.

(



P.386)

With the headlights on, push
the lever away from you to
turn on the high beams.

Pull the lever toward you to the

NOTICE

■

To prevent battery discharge

Do not leave the lights on longer

than necessary when the engine

is not running.

Turning on the high beam
headlights

150

4-3. Operating the lights and wipers

center position to turn the high
beams off.

Pull the lever toward you and
release it to flash the high
beams once.

You can flash the high beams with
the headlights on or off.

Press the Automatic High
Beam switch.

AHB (Automatic High

Beam)

The Automatic High Beam
uses a front camera located
on the upper portion of the
windshield to detect the
brightness of the lights of
vehicles ahead, street-
lights, etc., and automati-
cally changes the head
lights between the high
beams and low beams.

WARNING

■

For safe use

Do not overly rely on the Auto-

matic High Beam. Always drive

safely, taking care to observe your

surroundings and turning the high

beams on or off manually if nec-

essary.

■

To prevent unintentional

operation of the Automatic

High Beam System

●

When it is necessary to disable

the system:



P.161

Using the Automatic High
Beam system

151

4-3. Operating the lights and wipers

ing

Turn the headlight switch to

the

position.

When the headlight switch lever is

in the low beam position, the AHB

system will be enabled and the

AHB indicator will illuminate.

■

Automatic operating condi-

tions of the high beams

●

When all of the following condi-

tions are met, the high beams will

illuminate automatically:

• The vehicle speed is approxi-

mately 21 mph (34 km/h) or more.

• The area ahead of the vehicle is

dark.

• There are no vehicles ahead with

lights on.

• There are few streetlights or other

lights on the road ahead.

●

If any of the following conditions

are met, the headlights will

change to the low beams:

• Vehicle speed drops below

approximately 17 mph (27 km/h).

• The area ahead of the vehicle is

not dark.

• There is a vehicle ahead with

lights on.

• There are many streetlights or

other lights on the road ahead.

■

Front camera detection

●

In the following situations, the high

beams may not be automatically

changed to the low beams:

• When a vehicle cuts in front of

your vehicle

• When another vehicle crosses in

front of the vehicle

• When vehicles ahead are repeat-

edly detected and then hidden

due to repeated curves, road

dividers or roadside trees

• When a vehicle ahead

approaches from a far lane

• When a vehicle ahead is far away

• When a vehicle ahead has no

lights

• When the lights of a vehicle ahead

are dim

• When a vehicle ahead is reflecting

strong light, such as own head-

lights

• Situations in which the sensors

may not operate properly:



P.165

●

The headlights may change to the

low beams if a vehicle ahead that

is using fog lights without its head-

lights turned on is detected.

●

House lights, street lights, traffic

signals, and illuminated billboards

or signs may cause the high

beams to change to the low

beams, or the low beams to

remain on.

●

The following may change the tim-

ing at which the headlights

change to the low beams:

• The brightness of lights of vehi-

cles ahead

• The movement and direction of

vehicles ahead

• The distance between the vehicle

and a vehicle ahead

• When a vehicle ahead only has

lights illuminated on one side

• When a vehicle ahead is a

two-wheeled vehicle

• The condition of the road (gradi-

ent, curve, condition of the road

surface, etc.)

• The number of passengers and

amount of luggage

●

The headlights may change

between the high beams and low

beams unexpectedly.

●

Bicycles and other small vehicles

may not be detected.

●

In the following situations, the sys-

tem may not be able to correctly

detect the brightness of the sur-

152

4-3. Operating the lights and wipers

roundings. This may cause the

low beams to remain on or the

high beams to flash or dazzle

pedestrians or vehicles ahead. In

such a case, it is necessary to

manually change between the

high beams and low beams.

• When there are lights similar to

headlights or tail lights in the sur-

rounding area

• When headlights or tail lights of

vehicles ahead are turned off,

dirty, changing color, or not aimed

properly

• When the headlights are repeat-

edly changing between the high

beams and low beams.

• When use of the high beams is

inappropriate or when the high

beams may be flashing or daz-

zling pedestrians or other drivers.

• When the vehicle is used in an

area in which vehicles travel on

the opposite side of the road of

the country for which the vehicle

was designed, for example using

a vehicle designed for right-hand

traffic in a left-hand traffic area, or

vice versa

• When it is necessary to disable

the system:



P.161

• Situations in which the sensors

may not operate properly:



P.165

■

Temporarily reducing front

camera sensitivity (for the

U.S.A.)

The sensitivity of the front camera

can be temporarily reduced.

Turn the engine switch off with

the following conditions met.

• The headlight switch is in the

position.

• The headlight switch lever is in the

low beam position.

• The automatic High Beam switch

is on.

Press the engine switch to ON.

Within 60 seconds after perform-

ing step 2, push the headlight

switch lever to the high beam

position then pull it to the original

position quickly 10 times, then

leave the lever in its original posi-

tion.

■

Changing to the high
beams

Push the lever forward.

The Automatic High Beam indicator
will turn off and the high beam indi-
cator will turn on.
Pull the lever to its original position
to enable the Automatic High Beam
system again.

■

Changing to the low beams

Press the Automatic High Beam
switch.

The Automatic High Beam indicator
will turn off.
Press the switch to enable the
Automatic High Beam system
again.

Turning the high beams
on/off manually

153

4-3. Operating the lights and wipers

ing

■

Temporarily changing to
the low beams

It is recommended to switch to
the low beams when use of the
high beams is inappropriate or
when the high beams may
cause problems or distress to
other drivers or pedestrians
nearby.
Pull the lever rearward and then
return it to its original position.

The high beams will illuminate
while the lever is pulled, however,
after the lever is returned to its orig-
inal position, the low beams will
remain on for a certain amount of
time. After this, the Automatic High
Beam system will operate.

: If equipped

(U.S.A) or

(Canada)

Turns the front fog lights off

Turns the front fog lights

■

Fog lights can be used when

The headlights are on in low beam.

Fog light switch

The fog lights secure excel-
lent visibility in difficult driv-
ing conditions, such as in
rain and fog.

Operating instructions

154

4-3. Operating the lights and wipers

Operating the

lever oper-

ates the wipers or washer as fol-
lows.

(U.S.A.) or

(Canada)

Intermittent windshield wiper
operation

(U.S.A.) or

(Canada)

Low speed windshield wiper

operation

(U.S.A.) or

(Canada)

High speed windshield wiper
operation

(U.S.A.) or

(Canada)

Temporary operation

Wiper intervals can be adjusted
when intermittent operation is
selected.

Increases the intermittent
windshield wiper frequency

Decreases the intermittent
windshield wiper frequency

Washer/wiper dual

operation

Pulling the lever operates the wip-
ers and washer.
Wipers will automatically operate a
couple of times after the washer
squirts.

Windshield wipers and

washer

Operating the lever can use
the windshield wipers or the
washer.

NOTICE

■

When the windshield is dry

Do not use the wipers, as they

may damage the windshield.

Operating the wiper lever

155

4-3. Operating the lights and wipers

ing

■

The windshield wiper and

washer can be operated when

The engine switch is in ON.

■

If no windshield washer fluid

sprays

Check that the washer nozzles are

not blocked if there is washer fluid in

the windshield washer fluid reser-

voir.

■

When stopping the engine in an

emergency while driving

If the windshield wipers are operat-

ing when the engine is stopped, the

windshield wipers will operate in

high speed operation. After the vehi-

cle is stopped, operation will return

to normal when the engine switch is

turned to ON, or operation will stop

when the driver’s door is opened.

Operating the

switch

operates the rear wiper as fol-
lows:

(U.S.A.) or

(Canada)

Intermittent window wiper
operation

(U.S.A.) or

(Canada)

Normal window wiper opera-
tion

WARNING

■

Caution regarding the use of

washer fluid

When it is cold, do not use the

washer fluid until the windshield

becomes warm. The fluid may

freeze on the windshield and

cause low visibility. This may lead

to an accident, resulting in death

or serious injury.

NOTICE

■

When the washer fluid tank is

empty

Do not operate the switch continu-

ally as the washer fluid pump may

overheat.

■

When a nozzle becomes

blocked

In this case, contact your Toyota

dealer. Do not try to clear it with a

pin or other object. The nozzle will

be damaged.

Rear window wiper

and washer

Operating the lever can use
the rear window wiper or the
washer.

NOTICE

■

When the rear window is dry

Do not use the wiper, as it may

damage the rear window.

Operating instructions

156

4-3. Operating the lights and wipers

Washer/wiper dual

operation

Pushing the lever operates the
wiper and washer.
The wiper will automatically operate
a couple of times after the washer
squirts.

■

The rear window wiper and

washer can be operated when

The engine switch is in ON.

■

If no windshield washer fluid

sprays

Check that the washer nozzle is not

blocked if there is washer fluid in the

windshield washer fluid reservoir.

■

Back door opening linked rear

window wiper stop function

When the rear window wiper are

operating, if a back door is opened

while the vehicle is stopped, opera-

tion of the rear window wiper will be

stopped to prevent anyone near the

vehicle from being sprayed by water

from the wiper. When the back door

is closed, wiper operation will

resume.

NOTICE

■

When the washer fluid tank is

empty

Do not operate the switch continu-

ally as the washer fluid pump may

overheat.

■

When a nozzle becomes

blocked

In this case, contact your Toyota

dealer.

Do not try to clear it with a pin or

other object. The nozzle will be

damaged.

157

4-4. Refueling

ing

4-4.Refueling



Turn the engine switch off and
ensure that all the doors and
windows are closed.



Confirm the type of fuel.

■

Fuel types



P.373

■

Fuel tank opening for unleaded

gasoline

To help prevent incorrect fueling,

your vehicle has a fuel tank opening

that only accommodates the spe-

cial nozzle on unleaded fuel pumps.

■

If the malfunction indicator

lamp illuminates

The malfunction indicator lamp may

illuminate erroneously if refueling is

performed repeatedly when the fuel

tank is nearly full.

Opening the fuel tank

cap

Perform the following steps
to open the fuel tank cap:

Before refueling the vehi-
cle

WARNING

■

When refueling the vehicle

Observe the following precautions

while refueling the vehicle. Failure

to do so may result in death or

serious injury.

●

After exiting the vehicle and

before opening the fuel door,

touch an unpainted metal sur-

face to discharge any static

electricity. It is important to dis-

charge static electricity before

refueling because sparks result-

ing from static electricity can

cause fuel vapors to ignite while

refueling.

●

Always hold the grips on the

fuel tank cap and turn it slowly

to remove it.

A whooshing sound may be

heard when the fuel tank cap is

loosened. Wait until the sound

cannot be heard before fully

removing the cap. In hot

weather, pressurized fuel may

spray out the filler neck and

cause injury.

●

Do not allow anyone that has

not discharged static electricity

from their body to come close to

an open fuel tank.

●

Do not inhale vaporized fuel.

Fuel contains substances that

are harmful if inhaled.

●

Do not smoke while refueling

the vehicle.

Doing so may cause the fuel to

ignite and cause a fire.

●

Do not return to the vehicle or

touch any person or object that

is statically charged.

This may cause static electricity

to build up, resulting in a possi-

ble ignition hazard.

■

When refueling

Observe the following precautions

to prevent fuel overflowing from

the fuel tank:

●

Securely insert the fuel nozzle

into the fuel filler neck.

●

Stop filling the tank after the fuel

nozzle automatically clicks off.

158

4-4. Refueling

Pull up the opener to open
the fuel filler door.

Turn the fuel tank cap slowly
and remove it, then hang it
on the back of the fuel filler
door.

After refueling, turn the fuel tank
cap until you hear a click. Once
the cap is released, it will turn
slightly in the opposite direction.

WARNING

●

Do not top off the fuel tank.

NOTICE

■

Refueling

Do not spill fuel during refueling.

Doing so may damage the vehi-

cle, such as causing the emission

control system to operate abnor-

mally or damaging fuel system

components or the vehicle’s

painted surface.

Opening the fuel tank cap

Closing the fuel tank cap

WARNING

■

When replacing the fuel tank

cap

Do not use anything but a genu-

ine Toyota fuel tank cap designed

for your vehicle. Doing so may

cause a fire or other incident

which may result in death or seri-

ous injury.

159

4-5. Using the driving support systems

ing

4-5.Using the driving support systems

: If equipped

This Owner's Manual contains
information for Ver. 1. For the
latest information about the con-
trols, use, warnings/precautions,
etc. of each function of Toyota
Safety Sense, refer to the Digital
Owner's Manual at the Owner's
Manual website.
If the software of this system
has been updated after initial

purchase of the vehicle, before
using this system, be sure to
read the Owner's Manual which
corresponds to the software ver-
sion of the system.

■

Precautions for use

●

Be aware that some functions

may temporarily be disabled if a

legal or safety related issue

occurs.

●

If a connected services contract

has not been entered or has

expired, software updates will not

be able to be performed wire-

lessly.

If the software of this system
has been updated after initial
purchase of the vehicle, to
access the appropriate Owner’s
Manual, it is necessary to check
the software version of the sys-
tem and then visit the Owner's
Manual website.

The software version of the sys-
tem can be checked using One-
App.

Toyota Safety Sense
3.0 software update

It is necessary to enter a
connected services con-
tract, provided by Toyota, to
use these functions. For
details, contact your Toyota
dealer.

WARNING

■

For safe use

When the Toyota Safety Sense

3.0 software is updated, the oper-

ating methods of functions may

change. Using this system without

knowing the correct operating

methods may lead to an accident

resulting in death or serious injury.

●

Make sure to read the Digital

Owner's Manual which corre-

sponds to the software version

of the system, available at the

Owner's Manual website, before

using this system.

Content of the Toyota
Safety Sense Owner's
Manual

Checking your vehicle’s
Toyota Safety Sense ver-
sion

Checking the version
using OneApp

Toyota Corolla Hatchback (2023 year). Manual in english - page 9
