Toyota Corolla Hatchback (2023 year). Manual in english - page 6

3-2. Opening, closing and locking the doors

For vehicles with an alarm: To pre-

vent unintended triggering of the

alarm, unlock the doors using the

wireless remote control and open

and close a door once after the set-

tings have been changed. (If a door

is not opened within 60 seconds
after

is pressed, the doors will

be locked again and the alarm will

automatically be set.)

In case that the alarm is triggered,

immediately stop the alarm. (



P.65)

■

Operation signals

A buzzer sounds and the emer-

gency flashers flash to indicate that

the doors have been

locked/unlocked using the entry

function or wireless remote control.

(Locked: Once; Unlocked: Twice)
A buzzer sounds to indicate that the

windows are operating.

■

Security feature

If a door is not opened within

approximately 60 seconds after the

vehicle is unlocked using the entry

function or wireless remote control,

the security feature automatically

locks the vehicle again.

■

When the door cannot be

locked by the lock sensor on

the surface of the front door

handle

If the doors cannot be locked by

touching the lock sensor with a fin-

ger, touch the lock sensor with the

palm of your hand.
If you are wearing gloves, remove

them.

■

Door lock buzzer

If an attempt to lock the doors using

the entry function or wireless remote

control is made when a door is not

fully closed, a buzzer will sound

continuously for 5 seconds. Fully

close the door to stop the buzzer,

and lock the doors again.

■

Alarm (if equipped)

Locking the doors will set the alarm

system. (



P.65)

■

Conditions affecting the opera-

tion of the smart key system or

wireless remote control



P.104

■

If the smart key system or the

wireless remote control does

not operate properly

Use the mechanical key to lock and

unlock the doors. (



P.356)

Replace the key battery with a new

one if it is depleted. (



P.304)

■

If the battery is discharged

The doors cannot be locked and

unlocked using the smart key sys-

Multi-informa-

tion display/Beep

Unlocking func-

tion

Exterior: Beeps 3

times

Interior: Pings

once

Holding the
driver’s door
handle unlocks
only the driver’s
door.

Holding the front
passenger’s
door handle
unlocks all the
doors.

Exterior: Beeps

twice

Interior: Pings

once

Holding either
front door handle
unlocks all the
doors.

3-2. Opening, closing and locking the doors

Before driv

ing

tem or wireless remote control. Lock

or unlock the doors using the

mechanical key. (



P.356)

■

Rear seat reminder function

In order to remind you not to forget

luggage, etc. in the rear seat, when

the engine switch is turned off after

any of the following conditions are

met, a buzzer will sound and a mes-

sage will be displayed on the

multi-information display for approx-

imately 6 seconds.

●

The engine is started within

approximately 10 minutes after

opening and closing a rear door.

●

A rear door has been opened and

closed after the engine was

started.

However, if a rear door is opened

and then closed within approxi-

mately 2 seconds, the rear seat

reminder function may not operate.
The rear seat reminder function

determines that luggage, etc. has

been placed in a rear seat based on

opening and closing of a rear door.

Therefore, depending on the situa-

tion, the rear seat reminder function

may not operate and you may still

forget luggage, etc. in the rear seat,

or it may operate unnecessarily.

■

Customization

Some functions can be customized.

(



P.386)

WARNING

■

To prevent an accident

Observe the following precautions

while driving the vehicle.

Failure to do so may result in a

door opening and an occupant

being thrown out of the vehicle,

resulting in death or serious injury.

●

Ensure that all doors are prop-

erly closed and locked.

●

Do not pull the inside door han-

dle while driving.

Be especially careful of the front

doors, as the doors may be

opened even if the inside lock

buttons are in the locked posi-

tion.

●

Set the rear door child-protector

locks when children are seated

in the rear seats.

■

When opening or closing a

door

Check the surroundings of the

vehicle such as whether the vehi-

cle is on an incline, whether there

is enough space for a door to

open and whether a strong wind

is blowing. When opening or clos-

ing the door, hold the door handle

tightly to prepare for any unpre-

dictable movement.

■

When using the wireless

remote control and operating

the power windows

Operate the power windows after

checking to make sure that there

is no possibility of any passenger

having any of their body parts

caught in the windows. Also, do

not allow children to operate the

wireless remote control. It is pos-

sible for children and other pas-

sengers to get caught in the

power windows.

3-2. Opening, closing and locking the doors

■

Door lock switches (to
lock/unlock)



For driver’s side



For passenger’s side

Locks all the doors

Unlocks all the doors

■

Inside lock buttons

Locks the door

Unlocks the door

The front doors can be opened by

pulling the inside handle even if the
lock buttons are in the lock position.

■

Locking the front doors from

the outside without a key

Move the inside lock button to

the lock position.

Close the door.

The door cannot be locked if the

engine switch is in ACC or ON, or

the electronic key is left inside the

vehicle.
The key may not be detected cor-

rectly and the door may be locked.

■

Open door warning buzzer

If a door or the back door is not fully

closed, a buzzer will sound when

the vehicle speed reaches 3 mph (5

km/h).
The open door(s) or back door is

indicated on the multi-information

display.

The door cannot be opened
from inside the vehicle when
lock is set.

Unlock

Lock

These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear doors.

Unlocking and locking the
doors from the inside

Rear door child-protector
lock

3-2. Opening, closing and locking the doors

Before driv

ing

The following functions can be
set or canceled:

For instructions on customizing,
refer to P.386.

Automatic door locking
and unlocking systems

Function

Operation

Speed linked
door locking
function

All doors are auto-
matically locked
when vehicle
speed is approxi-
mately 12 mph (20
km/h) or higher.

Shift position
linked door
locking func-
tion

All doors are auto-
matically locked
when shifting the
shift lever out of P.

Shift position
linked door
unlocking
function

All doors are auto-
matically unlocked
when shifting the
shift lever to P.

Driver’s door
linked door
unlocking
function

All doors are auto-
matically unlocked
when driver’s door
is opened.

Back door

The back door can be
locked/unlocked and
opened by the following
procedures.

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Caution while driving

●

Keep the back door closed

while driving. If the back door is

left open, it may hit near-by

objects while driving or luggage

may be unexpectedly thrown

out, causing an accident.

In addition, exhaust gases may

enter the vehicle, causing death

or a serious health hazard.

Make sure to close the back

door before driving.

●

Before driving the vehicle, make

sure that the back door is fully

closed. If the back door is not

fully closed, it may open unex-

pectedly while driving, causing

an accident.

●

Never let anyone sit in the lug-

gage compartment. In the event

of sudden braking or a collision,

they are susceptible to death or

serious injury.

■

When children are in the vehi-

cle

●

Do not allow children to play in

the luggage compartment.

If a child is accidentally locked

in the luggage compartment,

they could have heat exhaus-

tion or other injuries.

100

3-2. Opening, closing and locking the doors

WARNING

●

Do not allow a child to open or

close the back door.

Doing so may cause the back

door to move unexpectedly, or

cause the child’s hands, head,

or neck to be caught by the

closing back door.

■

Operating the back door

●

Remove any heavy loads, such

as snow and ice, from the back

door before opening it. Failure

to do so may cause the back

door to suddenly shut again

after it is opened.

●

When opening or closing the

back door, thoroughly check to

make sure the surrounding area

is safe.

●

If anyone is in the vicinity, make

sure they are safe and let them

know that the back door is

about to open or close.

●

Use caution when opening or

closing the back door in windy

weather as it may move

abruptly in strong wind.

●

The back door may suddenly

shut if it is not opened fully. It is

more difficult to open or close

the back door on an incline than

on a level surface, so beware of

the back door unexpectedly

opening or closing by itself.

Make sure that the back door is

fully open and secure before

using the luggage compartment.

●

When closing the back door,

take extra care to prevent your

fingers etc. from being caught.

●

When closing the back door,

make sure to press it lightly on

its outer surface. If the back

door handle is used to fully

close the back door, it may

result in hands or arms being

caught.

●

Do not pull on the back door

damper stay to close the back

door, and do not hang on the

back door damper stay. Doing

so may cause hands to be

caught or the back door damper

stay to break, causing an acci-

dent.

●

If a bicycle carrier or similar

heavy object is attached to the

back door, it may suddenly shut

again after being opened, caus-

ing someone’s hands, head or

neck to be caught and injured.

When installing an accessory

part to the back door, using a

genuine Toyota part is recom-

mended.

101

3-2. Opening, closing and locking the doors

Before driv

ing

■

Entry function

Press the button to unlock
the back door.

The door cannot be unlocked for 3
seconds after the door is locked.

Press the button to lock the
back door.

Check that the door is securely
locked.

■

Wireless remote control



P.95

■

Operation signals



P.96

■

Door lock switches



P.98

■

Open

Raise the back door while push-

ing up the back door opener
switch.

The back door cannot be closed
immediately after the back door
opener switch is pushed.

■

Close

Lower the back door using the
back door handle, and make
sure to push the back door
down from the outside to close
it.
Be careful not to pull the back
door sideways when closing the
back door with the handle.

■

Open door warning buzzer



P.98

■

Luggage compartment light

The luggage compartment light

turns on when the back door is

opened.

Unlocking and locking the
back door from the out-
side

Unlocking and locking the
back door from the inside

Opening/closing the back
door

102

3-2. Opening, closing and locking the doors

■

Antenna location

Antennas outside the cabin
Antennas inside the cabin
Antenna inside the luggage
compartment
Antenna outside the luggage
compartment

NOTICE

■

Back door damper stays

The back door is equipped with

damper stays that hold the back

door in place.

Observe the following precau-

tions.

Failure to do so may cause dam-

age to the back door damper stay,

resulting in malfunction.

●

Do not attach any foreign

objects, such as stickers, plastic

sheets, or adhesives to the

damper stay rod.

●

Do not touch the damper stay

rod with gloves or other fabric

items.

●

Do not attach any accessories

other than genuine Toyota parts

to the back door.

●

Do not place your hand on the

damper stay or apply lateral

forces to it.

Smart key system

The following operations
can be performed simply by
carrying the electronic key
on your person, for example
in your pocket. The driver
should always carry the
electronic key.



Locks and unlocks the
doors (



P.95)



Locks and unlocks the back
door (



P.101)



Starts the engine (



P.133)

103

3-2. Opening, closing and locking the doors

Before driv

ing

■

Effective range (areas within

which the electronic key is

detected)

When locking or unlocking the
doors

The system can be operated when
the electronic key is within about 2.3
ft. (0.7 m) of an outside front door
handle and back door. (Only the
doors detecting the key can be
operated.)

When starting the engine or
changing engine switch modes

The system can be operated when
the electronic key is inside the vehi-
cle.

■

Alarms and warning messages

A combination of exterior and inte-

rior buzzers as well as warning mes-

sages shown on the

multi-information display are used to

prevent theft of the vehicle and acci-

dents resulting from erroneous

operation. Take appropriate mea-

sures based on the displayed mes-

sage. (



P.330)

When only an alarm sounds, cir-

cumstances and correction proce-

dures are as follows.

●

Exterior buzzer sounds once for 5

seconds

●

Interior buzzer sounds continu-

ously

■

Battery-saving function

The battery-saving function will be

activated in order to prevent the

electronic key battery and the vehi-

cle battery from being discharged

while the vehicle is not operated for

a long time.

●

In the following situations, the

smart key system may take some

time to unlock the doors.

• The electronic key has been left

within approximately 11 ft. (3.5 m)

of the outside of the vehicle for 2

minutes or longer.

• The smart key system has not

been used for 5 days or longer.

●

If the smart key system has not

been used for 14 days or longer,

the doors cannot be unlocked

from any door except the driver’s

door. In this case, hold the driver’s

door handle, or use the wireless

Situation

Correction

procedure

An attempt was
made to lock the
vehicle while a door
was open.

Close all of
the doors
and lock the
doors again.

Situation

Correction

procedure

The engine switch
was turned to ACC
while the driver’s
door was open (or
the driver’s door was
opened while the
engine switch was in
ACC).

Turn the
engine
switch off
and close
the driver’s
door.

The engine switch
was turned to off
while the driver’s
door was open.

Close the
driver’s door

104

3-2. Opening, closing and locking the doors

remote control or mechanical key

to unlock the doors.

■

Electronic key battery-saving

function

●

When battery-saving mode is set,

battery depletion is minimized by

stopping the electronic key from

receiving radio waves.

Press

twice while pressing and

holding

. Confirm that the elec-

tronic key indicator flashes 4 times.
While the battery-saving mode is

set, the smart key system cannot be

used. To cancel the function, press

any of the electronic key buttons.

●

Electronic keys that will not be

used for long periods of time can

be set to the battery-saving mode

in advance.

■

Conditions affecting operation

The smart key system uses weak

radio waves. In the following situa-

tions, the communication between

the electronic key and the vehicle

may be affected, preventing the

smart key system, wireless remote

control and engine immobilizer sys-

tem from operating properly.

●

When the electronic key battery is

depleted

●

Near a TV tower, electric power

plant, gas station, radio station,

large display, airport or other facil-

ity that generates strong radio

waves or electrical noise

●

When carrying a portable radio,

cellular phone, cordless phone or

other wireless communication

device

●

When the electronic key is in con-

tact with, or is covered by the fol-

lowing metallic objects

• Cards to which aluminum foil is

attached

• Cigarette boxes that have alumi-

num foil inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless keys (that

emit radio waves) are being used

nearby

●

When carrying the electronic key

together with the following devices

that emit radio waves

• Another vehicle’s electronic key or

a wireless key that emits radio

waves

• Personal computers or personal

digital assistants (PDAs)

• Digital audio players

• Portable game systems

●

If window tint with a metallic con-

tent or metallic objects are

attached to the rear window

●

When the electronic key is placed

near a battery charger or elec-

tronic devices

●

When the vehicle is parked in a

pay parking spot where radio

waves are emitted

If the doors cannot be

locked/unlocked using the smart key

system, lock/unlock the doors by

performing any of the following:

●

Bring the electronic key close to

either front door handle and oper-

ate the entry function.

●

Operate the wireless remote con-

trol.

If the doors cannot be

locked/unlocked using the above

methods, use the mechanical key.

(



P.356)

If the engine cannot be started using

the smart key system, refer to

P.357.

105

3-2. Opening, closing and locking the doors

Before driv

ing

■

Note for the entry function

●

Even when the electronic key is

within the effective range (detec-

tion areas), the system may not

operate properly in the following

cases:

• The electronic key is too close to

the window or outside door han-

dle, near the ground, or in a high

place when the doors are locked

or unlocked.

• The electronic key is on the instru-

ment panel, luggage cover or

floor, or in the door pockets or

glove box when the engine is

started or engine switch modes

are changed.

●

Do not leave the electronic key on

top of the instrument panel or near

the door pockets when exiting the

vehicle. Depending on the radio

wave reception conditions, it may

be detected by the antenna out-

side the cabin and the door will

become lockable from the outside,

possibly trapping the electronic

key inside the vehicle.

●

As long as the electronic key is

within the effective range, the

doors may be locked or unlocked

by anyone. However, only the

doors detecting the electronic key

can be used to unlock the vehicle.

●

Even if the electronic key is not

inside the vehicle, it may be possi-

ble to start the engine if the elec-

tronic key is near the window.

●

The doors may unlock or lock if a

large amount of water splashes on

the door handle, such as in the

rain or in a car wash when the

electronic key is within the effec-

tive range. (The doors will auto-

matically be locked after

approximately 60 seconds if the

doors are not opened and closed.)

●

If the wireless remote control is

used to lock the doors when the

electronic key is near the vehicle,

there is a possibility that the door

may not be unlocked by the entry

function. (Use the wireless remote

control to unlock the doors.)

●

Touching the door lock or unlock

sensor while wearing gloves may

prevent lock or unlock operation.

●

When the lock operation is per-

formed using the lock sensor, rec-

ognition signals will be shown up

to two consecutive times. After

this, no recognition signals will be

given.

●

If the door handle becomes wet

while the electronic key is within

the effective range, the door may

lock and unlock repeatedly. In that

case, follow the following correc-

tion procedures to wash the vehi-

cle:

• Place the electronic key in a loca-

tion 6 ft. (2 m) or more away from

the vehicle. (Take care to ensure

that the key is not stolen.)

• Set the electronic key to bat-

tery-saving mode to disable the

smart key system. (



P.104)

●

If the electronic key is inside the

vehicle and a door handle

becomes wet during a car wash, a

message may be shown on the

multi-information display and a

buzzer will sound outside the vehi-

cle. To turn off the alarm, lock all

the doors.

●

The lock sensor may not work

properly if it comes into contact

with ice, snow, mud, etc. Clean

the lock sensor and attempt to

operate it again.

●

A sudden handle operation or a

handle operation immediately

after entering the effective range

may prevent the doors from being

unlocked. Touch the door unlock

sensor and check that the doors

are unlocked before pulling the

door handle again.

●

If there is another electronic key in

the detection area, it may take

slightly longer to unlock the doors

after the door handle is gripped.

106

3-2. Opening, closing and locking the doors

■

When the vehicle is not driven

for extended periods

●

To prevent theft of the vehicle, do

not leave the electronic key within

6 ft. (2 m) of the vehicle.

●

The smart key system can be

deactivated in advance. (



P.386)

●

Setting the electronic key to bat-

tery-saving mode helps to reduce

key battery depletion. (



P.104)

■

To operate the system properly

Make sure to carry the electronic

key when operating the system. Do

not get the electronic key too close

to the vehicle when operating the

system from the outside of the vehi-

cle.

Depending on the position and hold-

ing condition of the electronic key,

the key may not be detected cor-

rectly and the system may not oper-

ate properly. (The alarm may go off

accidentally, or the door lock pre-

vention function may not operate.)

■

If the smart key system does

not operate properly

●

Locking and unlocking the doors:



P.356

●

Starting the engine:



P.357

■

Customization

Some functions can be customized.

(



P.386)

■

If the smart key system has

been deactivated in a custom-

ized setting

●

Locking and unlocking the doors:

Use the wireless remote control or

mechanical key. (



P.95, 356)

●

Starting the engine and changing

engine switch modes:



P.357

●

Stopping the engine:



P.134

WARNING

■

Caution regarding interfer-

ence with electronic devices

●

People with implantable car-

diac pacemakers, cardiac

resynchronization ther-

apy-pacemakers or implantable

cardioverter defibrillators should

keep away from the smart key

system antennas. (



P.102)

The radio waves may affect the

operation of such devices. If

necessary, the entry function

can be disabled. Ask your Toy-

ota dealer for details, such as

the frequency of radio waves

and timing of the emitted radio

waves. Then, consult your doc-

tor to see if you should disable

the entry function.

●

Users of any electrical medical

device other than implantable

cardiac pacemakers, cardiac

resynchronization ther-

apy-pacemakers or implantable

cardioverter defibrillators should

consult the manufacturer of the

device for information about its

operation under the influence of

radio waves.

Radio waves could have unex-

pected effects on the operation

of such medical devices.

Ask your Toyota dealer for details

on disabling the entry function.

107

3-3. Adjusting the seats

Before driv

ing

3-3.Adjusting the seats



Manual seat

Seat position adjustment
lever
Seatback angle adjustment
lever
Vertical height adjustment
lever (driver’s side only)
Lumbar support adjustment
switch

(driver’s side only)

: If equipped



Power seat (driver’s side
only)

Seat position adjustment
switch
Seatback angle adjustment
switch
Seat cushion (front) angle
adjustment switch
Vertical height adjustment
switch
Lumbar support adjustment
switch

Front seats

Adjustment procedure

WARNING

■

When adjusting the seat posi-

tion

●

Take care when adjusting the

seat position to ensure that

other passengers are not

injured by the moving seat.

●

Do not put your hands under the

seat or near the moving parts to

avoid injury.

Fingers or hands may become

jammed in the seat mechanism.

●

Make sure to leave enough

space around the feet so they

do not get stuck.

108

3-3. Adjusting the seats

Move the front seats forward.
(



P.107)

Stow the rear armrest.
(



P.257)

Lower the rear center seat
head restraint to the lowest
position. (



P.110)

Fold the rear outside seat
head restraints. (



P.110)

Pull the seatback lock
release lever and fold the
seatback down.

Each seatback may be folded sep-

arately.

WARNING

■

Seat adjustment

●

Be careful that the seat does

not hit passengers or luggage.

●

To reduce the risk of sliding

under the lap belt during a colli-

sion, do not recline the seat

more than necessary.

If the seat is too reclined, the lap

belt may slide past the hips and

apply restraint forces directly to

the abdomen, or your neck may

contact the shoulder belt,

increasing the risk of death or

serious injury in the event of an

accident.

Adjustments should not be

made while driving as the seat

may unexpectedly move and

cause the driver to lose control

of the vehicle.

●

Manual seat only: After adjust-

ing the seat, make sure that the

seat is locked in position.

NOTICE

■

When adjusting a front seat

When adjusting a front seat, make

sure that the head restraint does

not contact the headliner. Other-

wise, the head restraint and head-

liner may be damaged.

Rear seats

The seatbacks of the rear
seats can be folded down.

Folding down the rear
seatbacks

WARNING

Observe the following precau-

tions. Failure to do so may result

in death or serious injury.

109

3-3. Adjusting the seats

Before driv

ing

WARNING

■

When folding the rear seat-

backs down

●

Do not fold the seatbacks down

while driving.

●

Stop the vehicle on level

ground, set the parking brake

and shift the shift lever to P.

●

Do not allow anyone to sit on a

folded seatback or in the lug-

gage compartment while driv-

ing.

●

Do not allow children to enter

the luggage compartment.

●

Do not allow anyone to sit on

the rear center seat if the rear

right seat is folded down, as the

seat belt buckle for the rear cen-

ter seat belt is then concealed

under the folded seat and can-

not be used.

●

Be careful not to get your hand

caught when folding the rear

seatbacks.

●

Adjust the position of the front

seats before folding down the

rear seatbacks so that the front

seats do not interfere with the

rear seatbacks when folding

down the rear seatbacks.

■

After returning the rear seat-

back to the upright position

●

Make sure that the seatback is

securely locked in position by

lightly pushing it back and forth.

If the seatback is not securely

locked, the red marking will be

visible on the seatback lock

release lever. Make sure that the

red marking is not visible.

●

Check that the seat belts are

not twisted or caught in the

seatback.

If the seat belt gets caught

between the seatback’s securing

hook and latch, it may damage

the seat belt.

110

3-3. Adjusting the seats

■

Front seats

Pull the head restraints up.

Down

Push the head restraint down while
pressing the lock release button

■

Rear outside seats

Folding the rear outside seat
head restraints

Pull the head restraint up while
pressing only the right-side lock
release button

and then fold it

forward.

Setting up the rear outside
seat head restraints

Fold back the head restraint and
then push it down to the lock posi-
tion.

■

Rear center seat

Pull the head restraint up.

Down

Push the head restraint down while
pressing the lock release button

■

Adjusting the height of the head

restraints (front seats)

Make sure that the head restraints

are adjusted so that the center of

Head restraints

Head restraints are provided
for all seats.

WARNING

■

Head restraint precautions

Observe the following precautions

regarding the head restraints.

Failure to do so may result in

death or serious injury.

●

Use the head restraints

designed for each respective

seat.

●

Adjust the head restraints to the

correct position at all times.

●

After adjusting the head

restraints, push down on them

and make sure they are locked

in position.

●

Do not drive with the head

restraints removed.

Adjusting a head restraint

111

3-3. Adjusting the seats

Before driv

ing

the head restraint is closest to the

top of your ears.

■

Adjusting the rear center seat

head restraint

Always raise the head restraint one

level from the stowed position when

using.

■

Front seats

Pull the head restraint up while
pressing the lock release button

■

Rear outside seats

Pull the head restraint up while
pressing the lock release but-
tons .

■

Rear center seat

Pull the head restraint up while
pressing the lock release button

■

Front seats

Align the head restraint with the
installation holes and push it
down to the lock position.

Press and hold the lock release
button

when lowering the head

restraint.

Removing the head
restraints

Installing the head
restraints

Content .. 4 5 6 7 ..
