Toyota 4Runner (2023 year). Manual in english - page 22

354

5-1. Using the air conditioning system and defogger

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high.

Turning

on will dehumidify the air from the outlets and defog the wind-

shield effectively.

●

If you turn

off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

When driving on dusty roads

Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air intake mode be
set to outside air mode and the fan speed to any setting except off.

■

Outside/recirculated air mode

●

Setting to the recirculated air mode temporarily is recommended in prevent-
ing dirty air from entering the vehicle interior and helping to cool the vehicle
when the outside air temperature is high.

●

Outside/recirculated air mode may automatically switch depending on the
temperature setting, outside temperature, pressure, engine coolant tem-
perature or inside temperature.

■

When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on

●

In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.

●

Recirculated air mode is selected as a default mode when the engine switch
is turned to IGNITION ON mode.

●

It is possible to switch to outside air mode at any time by pressing

■

When the outside temperature falls to nearly 32



F (0



The dehumidification function may not operate even when

is pressed.

■

When driving on dusty roads

■

When the indicator light on

flashes

Press

to turn off the cooling and dehumidification function and turn it on

again. There may be a problem in the air conditioning system if the indicator
light continues to flash. Turn the air conditioning system off and have it
inspected by your Toyota dealer.

355

5-1. Using the air conditioning system and defogger

rior

ures

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air

mode prior to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time

immediately after the air conditioning system is started in automatic
mode.

■

Air conditioning filter



P. 445

■

Air conditioning system refrigerant

●

The meaning of each symbol on the label are as follows:

●

A label regarding the refrigerant of the
air conditioning system is attached to the
hood at the location shown in the follow-
ing illustration.

Caution

Air conditioning system

Air conditioning system lubricant type

Requires registered technician to service air conditioning
system

Flammable refrigerant

356

5-1. Using the air conditioning system and defogger

WARNING

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather.

The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on.

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

■

When repairing/replacing parts of the air conditioning system

Have repair/replacement performed by your Toyota dealer.
When a part of the air conditioning system, such as the evaporator, is to be
replaced, it must be replaced with a new one.

●

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

357

5-1. Using the air conditioning system and defogger

rior

ures

Heated steering wheel



/Seat heaters



/seat

ventilators



: If equipped

Heated steering wheel and seat heaters heat the side grips of the
steering wheel and seats, respectively. Seat ventilators maintain
good ventilation by pulling air through the seat upholstery.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

●

Observe the following precautions to prevent minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat

heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is
off.

358

5-1. Using the air conditioning system and defogger

Turns the heated steering wheel
on/off

The indicator light comes on when
the heated steering wheel is oper-
ating.

The heated steering wheel can be used when the engine switch is in IGNI-
TION ON mode.



Vehicles with ventilator

Press the knob to release it,
and turn the knob to the desired
temperature setting.
OFF

Press the knob to lock it when not
in use.

Ventilation
Heat

Heated steering wheel

Seat heaters/ventilators

359

5-1. Using the air conditioning system and defogger

rior

ures



Vehicles without ventilator

The indicator light comes on.

Adjusts the seat temperature

The further you move the dial for-
ward, the warmer the seat
becomes.

Off

Move the dial fully backward. The
indicator light turns off.

■

The seat heaters/seat ventilators can be used when

The engine switch is in IGNITION ON mode.

360

5-2. Using the interior lights

Rear interior light (



P. 361)

Front interior light/front personal lights (



P. 361)

Shift lever light (when the engine switch is in ACCESSORY or IGNI-
TION ON mode)
Inside door handle lights (if equipped)
Outer foot lights (if equipped)
Engine switch light
Footwell lights (if equipped)
Door courtesy lights

Turning the instrument panel light control dial fully downward disables
the inside door handle lights, footwell lights and shift lever light.
(



P. 89)

Interior lights list

361

5-2. Using the interior lights

rior

ures

■

Front

Turns the lights off
Turns the door position on

■

Rear

Turns the door position on
Turns the light off
Turns the light on

Turns the lights on/off

Interior lights

Personal lights

362

5-2. Using the interior lights

■

Illuminated entry system

The lights automatically turn on/off according to engine switch mode, the
presence of the electronic key, whether the doors are locked/unlocked, and
whether the doors are opened/closed.

■

To prevent battery discharge

If the following lights remain on, the lights will go off automatically after 20
minutes:

●

Engine switch light

●

Front interior light

●

Rear interior light

●

Personal lights

●

Footwell lights

●

Inside door handle lights

●

Door courtesy lights

■

Customization

Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features:



P. 549)

NOTICE

■

To prevent battery discharge

Do not leave the lights on longer than necessary when the engine is not
running.

363

rior

ures

5-3. Using the storage features

List of storage features

Auxiliary box (



P. 367)

Glove box (



P. 364)

Bottle holders (



Tissue pocket (

Cup holders (

Pen holder (



P. 368)

Console box (



P. 364)

Coin holder (



P. 368)

WARNING

●

Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact

with other stored items.

• Lighters or spray cans may explode. If they come into contact with other

stored items, the lighter may catch fire or the spray can may release
gas, causing a fire hazard.

●

When driving or when the storage compartments are not in use, keep the
lids closed. In the event of sudden braking or sudden swerving, an acci-
dent may occur due to an occupant being struck by an open lid or the
items stored inside.

364

5-3. Using the storage features

The glove box can be opened by pressing the lock release button and
can be locked and unlocked by using the mechanical key.

Open
Unlock
Lock

Lift the lid while pulling up the
knob to release the lock.

■

The separator can be used in either of the positions shown in the illus-
tration

Glove box

Console box

Change the separator position.

365

5-3. Using the storage features

rior

ures

Cup holders



Front seats



Rear seats (without third row
seats)

Pull down the rear seat center
armrest.



Second row seats (with third
row seats)



Third row seats (if equipped)

Pull down the second row seat
center armrest and press down
the button on the armrest.

366

5-3. Using the storage features

■

Adjusting the size of the cup holders



Front seats



Rear seats (without third row seats)

Remove the adapter.

WARNING

■

Items unsuitable for the cup holders

Do not place anything other than cups or aluminum cans in the cup holders.
Even with the lid is closed, items must not be stored in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.

■

When not in use (second row seat cup holders only)

Keep the cup holders closed. In the event of sudden braking, an accident
may occur due to an occupant being struck by the open cup holders or the
items stored inside.

NOTICE

■

To prevent damage to the rear cup holders (second row seats only)

Stow the cup holders before stowing the armrest.

367

5-3. Using the storage features

rior

ures

Push the lid.

Auxiliary box (if equipped)

WARNING

■

Items unsuitable for storing

Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident.

368

5-3. Using the storage features

Lift the lid while pulling up the knob to release the lock.

Coin holder
Tissue pocket
Pen holder

Coin holder/tissue pocket/pen holder

369

5-3. Using the storage features

rior

ures

■

When using the bottle holder

●

When storing a bottle, close the cap.

●

The bottle may not be stored depending on its size or shape.

Bottle holders



Front seats



Rear seats (without third row
seats)/second row seats (with
third row seats)

WARNING

■

Items unsuitable for the bottle holder

Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.

NOTICE

■

Items that should not be stowed in the bottle holders

Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.

Content .. 20 21 22 23 ..
