Toyota Corolla (2023 year). Manual in english - page 2

Pictorial index

■

Switches

Instrument panel light control dial ............................... P.88, 91

Automatic High Beam switch ........................................... P.175

Heated steering wheel switch

.......................................... P.269

Windshield wiper de-icer switch

..................................... P.267

Outside rear view mirror switch ....................................... P.132

Door lock switches ............................................................ P.115

Power window switches.................................................... P.134

Window lock switch ........................................................... P.136

: If equipped

Pictorial index

Meter control switches ........................................................ P.92

Paddle shift switches

...................................................... P.164

Cruise control switches

Dynamic radar cruise control ............................................... P.219
Cruise control....................................................................... P.227

Audio remote control switches

LTA (Lane Tracing Assist) switch ..................................... P.201

Phone switch

Talk switch

:If equipped

:Refer to “MULTIMEDIA OWNER’S MANUAL”.

Pictorial index

Seat heater switches

........................................................ P.269

Wireless charger switch

................................................... P.278

Brake hold switch .............................................................. P.171

Parking brake switch ......................................................... P.168

Applying/releasing................................................................ P.168
Precautions against winter season ...................................... P.254
Warning buzzer/message ............................................ P.356, 366

VSC OFF switch ................................................................. P.249

Driving mode select switch

.............................................. P.247

: If equipped

Pictorial index

■

Interior

SRS airbags.......................................................................... P.31

Floor mats............................................................................. P.24

Front seats.......................................................................... P.125

Head restraints................................................................... P.128

Seat belts .............................................................................. P.27

Console box ....................................................................... P.275

Inside lock buttons ............................................................ P.115

Cup holders ........................................................................ P.274

Rear seats........................................................................... P.126

Rear seat heater switches

................................................ P.269

: If equipped

Pictorial index

■

Ceiling

Inside rear view mirror ...................................................... P.131

Sun visors........................................................................... P.284

Vanity mirrors..................................................................... P.284

Vanity lights

....................................................................... P.284

Interior lights/personal lights ........................................... P.271

Moon roof switches

.......................................................... P.137

“SOS” button

....................................................................... P.72

Assist grips ........................................................................ P.285

: If equipped

Pictorial index

For safety and secu

rity

For safety and security

1-1. For safe use

Before driving.................

For safe driving ..............

Seat belts .......................

SRS airbags...................

Front passenger occupant

classification system ....

Exhaust gas precautions

.....................................

1-2. Child safety

Riding with children........

Child restraint systems...

1-3. Emergency assistance

Safety Connect ..............

1-4. Theft deterrent system

Engine immobilizer system

.....................................

Alarm..............................

1-1. For safe use

1-1.For safe use

Use only floor mats designed
specifically for vehicles of the
same model and model year as
your vehicle. Fix them securely
in place onto the carpet.

Insert the retaining hooks
(clips) into the floor mat eye-
lets.

Turn the upper knob of each
retaining hook (clip) to secure
the floor mats in place.

Always align the

marks

The shape of the retaining hooks
(clips) may differ from that shown in
the illustration.

Before driving

Observe the following
before starting off in the
vehicle to ensure safety of
driving.

Floor mat

WARNING

Observe the following precau-

tions.

Failure to do so may cause the

driver’s floor mat to slip, possibly

interfering with the pedals while

driving. An unexpectedly high

speed may result or it may

become difficult to stop the vehi-

cle. This could lead to an acci-

dent, resulting in death or serious

injury.

■

When installing the driver’s

floor mat

●

Do not use floor mats designed

for other models or different

model year vehicles, even if

they are Toyota Genuine floor

mats.

●

Only use floor mats designed

for the driver’s seat.

●

Always install the floor mat

securely using the retaining

hooks (clips) provided.

●

Do not use two or more floor

mats on top of each other.

●

Do not place the floor mat bot-

tom-side up or upside-down.

1-1. For safe use

For safety and secu

rity

Adjust the angle of the seat-
back so that you are sitting
straight up and so that you do
not have to lean forward to
steer. (



P.125)

Adjust the seat so that you
can depress the pedals fully
and so that your arms bend
slightly at the elbow when
gripping the steering wheel.
(



P.125)

Lock the head restraint in
place with the center of the
head restraint closest to the
top of your ears. (



P.128)

Wear the seat belt correctly.
(



P.27)

WARNING

■

Before driving

●

Check that the floor mat is

securely fixed in the correct

place with all the provided

retaining hooks (clips). Be espe-

cially careful to perform this

check after cleaning the floor.

●

With the engine stopped and

the shift lever in P, fully depress

each pedal to the floor to make

sure it does not interfere with

the floor mat.

For safe driving

For safe driving, adjust the
seat and mirror to an appro-
priate position before driv-
ing.

Correct driving posture

1-1. For safe use

Make sure that all occupants are
wearing their seat belts before
driving the vehicle. (



P.27)

Use a child restraint system
appropriate for the child until the
child becomes large enough to
properly wear the vehicle’s seat
belt. (



P.48)

Make sure that you can see
backward clearly by adjusting
the inside and outside rear view
mirrors properly. (



P.131, 132)

WARNING

■

For safe driving

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

●

Do not adjust the position of the

driver’s seat while driving.

Doing so could cause the driver

to lose control of the vehicle.

●

Do not place a cushion between

the driver or passenger and the

seatback.

A cushion may prevent correct

posture from being achieved,

and reduce the effectiveness of

the seat belt and head restraint.

●

Do not place anything under the

front seats.

Objects placed under the front

seats may become jammed in

the seat tracks and stop the

seat from locking in place. This

may lead to an accident and the

adjustment mechanism may

also be damaged.

●

Always observe the legal speed

limit when driving on public

roads.

●

When driving over long dis-

tances, take regular breaks

before you start to feel tired.

Also, if you feel tired or sleepy

while driving, do not force your-

self to continue driving and take

a break immediately.

●

Take care when adjusting the

seat position to ensure that

other passengers are not

injured by the moving seat.

●

When adjusting the seat posi-

tion, do not put your hands

under the seat or near the mov-

ing parts to avoid injury. Fingers

or hands may become jammed

in the seat mechanism.

Correct use of the seat
belts

Adjusting the mirrors

1-1. For safe use

For safety and secu

rity

Seat belts

Make sure that all occu-
pants are wearing their seat
belts before driving the
vehicle.

WARNING

Observe the following precautions

to reduce the risk of injury in the

event of sudden braking, sudden

swerving or an accident.

Failure to do so may cause death

or serious injury.

■

Wearing a seat belt

●

Ensure that all passengers wear

a seat belt.

●

Always wear a seat belt prop-

erly.

●

Each seat belt should be used

by one person only. Do not use

a seat belt for more than one

person at once, including chil-

dren.

●

Toyota recommends that chil-

dren be seated in the rear seat

and always use a seat belt

and/or an appropriate child

restraint system.

●

To achieve a proper seating

position, do not recline the seat

more than necessary. The seat

belt is most effective when the

occupants are sitting up straight

and well back in the seats.

●

Do not wear the shoulder belt

under your arm.

●

Always wear your seat belt low

and snug across your hips.

■

Pregnant women

Obtain medical advice and wear

the seat belt in the proper way.

(



P.28)

Women who are pregnant should

position the lap belt as low as

possible over the hips in the same

manner as other occupants,

extending the shoulder belt com-

pletely over the shoulder and

avoiding belt contact with the

rounding of the abdominal area.
If the seat belt is not worn prop-

erly, not only the pregnant

woman, but also the fetus could

suffer death or serious injury as a

result of sudden braking or a colli-

sion.

■

People suffering illness

Obtain medical advice and wear

the seat belt in the proper way.

(



P.28)

■

When children are in the vehi-

cle



P.64

■

Seat belt damage and wear

●

Do not damage the seat belts

by allowing the belt, plate, or

buckle to be jammed in the

door.

1-1. For safe use



Extend the shoulder belt so
that it comes fully over the
shoulder, but does not come
into contact with the neck or
slide off the shoulder.



Position the lap belt as low as
possible over the hips.



Adjust the position of the
seatback. Sit up straight and
well back in the seat.



Do not twist the seat belt.

■

Child seat belt usage

The seat belts of your vehicle were

principally designed for persons of

adult size.

●

Use a child restraint system

appropriate for the child, until the

child becomes large enough to

properly wear the vehicle’s seat

belt. (



P.48)

●

When the child becomes large

enough to properly wear the vehi-

cle’s seat belt, follow the instruc-

tions regarding seat belt usage.

(



P.27)

■

Seat belt extender

If your seat belts cannot be fastened

securely because they are not long

enough, a personalized seat belt

extender is available from your Toy-

ota dealer free of charge.

WARNING

●

Inspect the seat belt system

periodically. Check for cuts,

fraying, and loose parts. Do not

use a damaged seat belt until it

is replaced. Damaged seat belts

cannot protect an occupant

from death or serious injury.

●

Ensure that the belt and plate

are locked and the belt is not

twisted.

If the seat belt does not function

correctly, immediately contact

your Toyota dealer.

●

Replace the seat assembly,

including the belts, if your vehi-

cle has been involved in a seri-

ous accident, even if there is no

obvious damage.

●

Do not attempt to install,

remove, modify, disassemble or

dispose of the seat belts. Have

any necessary repairs carried

out by your Toyota dealer. Inap-

propriate handling may lead to

incorrect operation.

Correct use of the seat
belts

WARNING

■

Using a seat belt extender

●

Do not wear the seat belt

extender if you can fasten the

seat belt without the extender.

1-1. For safe use

For safety and secu

rity

To fasten the seat belt, push
the plate into the buckle until
a click sound is heard.

To release the seat belt,
press the release button .

■

Emergency locking retractor

(ELR)

The retractor will lock the belt during

a sudden stop or on impact. It may

also lock if you lean forward too

quickly. A slow, easy motion will

allow the belt to extend so that you

can move around fully.

■

Automatic locking retractor

(ALR)

When a passenger’s shoulder belt is

completely extended and then

retracted even slightly, the belt is

locked in that position and cannot

be extended. This feature is used to

hold the child restraint system

(CRS) firmly. To free the belt again,

fully retract the belt and then pull the

belt out once more. (



P.48)

■

Rear seat belt

Use the seat belt after passing it

through the guide if the seat belt

comes free from the guide.

Push the seat belt shoulder

WARNING

●

Do not use the seat belt

extender when installing a child

restraint system because the

belt will not securely hold the

child restraint system, increas-

ing the risk of death or serious

injury in the event of an acci-

dent.

●

The personalized extender may

not be safe on another vehicle,

when used by another person,

or at a different seating position

other than the one originally

intended.

NOTICE

■

When using a seat belt

extender

When releasing the seat belt,

press on the buckle release but-

ton on the extender, not on the

seat belt.

This helps prevent damage to the

vehicle interior and the extender

itself.

Fastening and releasing
the seat belt

Adjusting the seat belt
shoulder anchor height
(front seats)

1-1. For safe use

anchor down while pressing
the release button .

Push the seat belt shoulder
anchor up while pressing the
release button .

Move the height adjuster up and
down as needed until you hear a
click.

The pretensioners help the seat
belts to quickly restrain the
occupants by retracting the seat
belts when the vehicle is sub-
jected to certain types of severe
frontal or side collision or a vehi-

cle rollover.

The pretensioners do not activate
in the event of a minor frontal
impact, a minor side impact or a
rear impact.

■

Replacing the belt after the pre-

tensioner has been activated

If the vehicle is involved in multiple

collisions, the pretensioner will acti-

vate for the first collision, but will not

activate for the second or subse-

quent collisions.

■

PCS-linked seat belt preten-

sioner control

If the PCS (Pre-Collision System)

determines that the possibility of a

collision with a vehicle is high, the

seat belt pretensioners will be pre-

pared to operate.

WARNING

■

Adjustable shoulder anchor

Always make sure the shoulder

belt is positioned across the cen-

ter of your shoulder. The belt

should be kept away from your

neck, but not falling off your shoul-

der. Failure to do so could reduce

the amount of protection in an

accident and cause death or seri-

ous injuries in the event of a sud-

den stop, sudden swerve or

accident.

Seat belt pretensioners
(front seats and outboard-
rear seats)

WARNING

■

Seat belt pretensioners

Observe the following precautions

to reduce the risk of injury in the

event of sudden braking, sudden

swerving or an accident.

Failure to do so may result in

death or serious injury.

●

Do not place anything, such as

a cushion, on the front passen-

ger’s seat. Doing so will

disperse the passenger’s

weight, which prevents the sen-

sor from detecting the passen-

ger’s weight properly. As a

result, the seat belt pretensioner

for the front passenger’s seat

may not operate in the event of

a collision.

●

If a pretensioner has operated,

the SRS warning light will illumi-

nate. In this situation, the seat

belt cannot be used and must

be replaced by your Toyota

dealer.

1-1. For safe use

For safety and secu

rity

■

Location of the SRS airbags



SRS front airbags

SRS driver airbag/front passenger airbag

Can help protect the head and chest of the driver and front passenger from
impact with interior components

SRS knee airbag

Can help provide driver protection

SRS seat cushion airbag

Can help restrain the front passenger



SRS side and curtain shield airbags

SRS front side airbags

Can help protect the torso of the front seat occupants

SRS airbags

The SRS airbags inflate when the vehicle is subjected to cer-
tain types of severe impacts that may cause significant injury
to the occupants. They work together with the seat belts to
help reduce the risk of death or serious injury.

SRS airbag system

1-1. For safe use

SRS rear side airbags

Can help protect the torso of occupants in the rear outer seats

SRS curtain shield airbags

• Can help protect primarily the head of occupants in the outer seats
• Can help prevent the occupants from being thrown from the vehicle in the

event of vehicle rollover

■

SRS airbag system components

Seat cushion airbag
Front passenger's seat belt buckle switch
Front passenger airbag
Curtain shield airbags
Side impact sensors (front doors)
Front side airbags
“AIR BAG ON” and “AIR BAG OFF” indicator lights
Seat belt pretensioners and force limiters
Rear side airbags
Side impact sensors (front)
Driver airbag
Driver’s seat belt buckle switch
Driver’s seat position sensor
Driver’s knee airbag
SRS warning light

Content .. 1 2 3 ..
