451

8

n

8-1. Specifications

Vehi

cle s
pec
ifi

cati

ons

Preferred

Temperature range anticipated

before next oil change

SAE 0W-16 is filled into your Toyota
vehicle at manufacturing, and the
best choice for good fuel economy
and good starting in cold weather. If
SAE 0W-16 oil is not available,
SAE 0W-20 oil may be used. How-
ever, it should be replaced with
SAE 0W-16 at the next oil change.
Oil viscosity (0W-16 is explained
here as an example):
• The 0W in 0W-16 indicates the

characteristic of the oil which
allows cold startability. Oils with a
lower value before the W allow
for easier starting of the engine
in cold weather.

• The 16 in 0W-16 indicates the

viscosity characteristic of the oil
when the oil is at high tempera-
ture. An oil with a higher viscos-
ity (one with a higher value) may
be better suited if the vehicle is

operated at high speeds, or
under extreme load conditions.

How to read oil container labels:
Either or both API registered marks
are added to some oil containers to
help you select the oil you should
use.

API Service Symbol

Top portion: “API SERVICE SP” means
the oil quality designation by American
Petroleum Institute (API).
Center portion: “SAE 0W-16” means
the SAE viscosity grade.
Lower portion: “Resource-Conserving”
means that the oil has fuel-saving and
environmental protection capabilities.

ILSAC Certification Mark

The International Lubricant Specifica-
tion Advisory Committee (ILSAC) Certi-
fication Mark is displayed on the front of
the container.

452

n

8-1. Specifications

*

: The fluid capacity is a reference quantity.

If replacement is necessary, contact any authorized Toyota retailer or Toyota
authorized repairer, or any reliable repairer.

Cooling system

Capacity (Reference)

4.7 L (5.0 qt., 4.1 Imp. qt.)

Coolant type

Use either of the following:



“Toyota Super Long Life Coolant”



Similar high-quality ethylene glycol-based non-sili-
cate, non-amine, non-nitrite, and non-borate coolant
with long-life hybrid organic acid technology

Do not use plain water alone.

Ignition system (spark plug)

Make

DENSO FC16HR-Q8
NGK DILKAR6T8

Gap

0.8 mm (0.031 in.)

NOTICE

■

Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

Electrical system (battery)

Open voltage at 20°C (68°F):

12.3 V or higher
(Turn the engine switch off and turn on the high
beam headlights for 30 seconds.)

Charging rates
Quick charge
Slow charge

15 A max.
5 A max.

Multidrive

Fluid capacity

*

8.43 L (8.9 qt., 7.4 Imp. qt.)

Fluid type

“Toyota Genuine CVT Fluid FE”

453

8

n

8-1. Specifications

Vehi

cle s
pec
ifi

cati

ons

NOTICE

■

Multidrive fluid type

Using Multidrive fluid other than the above type may cause abnormal noise or
vibration, or damage the Multidrive of your vehicle.

Manual transmission

Gear oil capacity (Reference)

2.1 L (2.2 qt., 1.8 Imp. qt.)

Gear oil type

“TOYOTA Genuine Manual Transmission Gear
Oil LV GL-4 75W” or equivalent

NOTICE

■

Manual transmission gear oil type

●

Please be aware that depending on the particular characteristics of the gear oil

used or the operating conditions, idle sound, shift feeling and/or fuel efficiency

may be different or affected and, in the worst case, damage to the vehicle’s
transmission.

Toyota recommends to use “TOYOTA Genuine Manual Transmission Gear Oil

LV GL-4 75W” to achieve optimal performance.

●

Your Toyota vehicle is filled with “TOYOTA Genuine Manual Transmission Gear

Oil LV GL-4 75W” at the factory.
Use Toyota approved “TOYOTA Genuine Manual Transmission Gear Oil LV GL-

4 75W” or an equivalent oil of matching quality that satisfies the above specifica-
tions.

Please contact any authorized Toyota retailer or Toyota authorized repairer, or

any reliable repairer for further details.

Clutch (Manual transmission)

Pedal free play

3



 15 mm (0.1



 0.6 in.)

Fluid type

SAE J1704 or FMVSS No.116 DOT 4

Brakes

Pedal clearance

*1

87 mm (3.4 in.) Min.

Pedal free play

1



 6 mm (0.04



 0.24 in.)

454

n

8-1. Specifications

*1

: Minimum pedal clearance when depressed with a force of 300 N (31.0 kgf, 67.4

lbf) while the engine is running.

*2

: Make sure to confirm that the brake warning light (yellow) does not illuminate. (If

the brake warning light illuminates, refer to P.81, 410)



16-inch tires



17-inch tires

Parking brake indicator

*2

When pulling the parking brake switch for 1 to 2
seconds: comes on
When pushing the parking brake switch for 1 to
2 seconds: turns off

Fluid type

SAE J1704 or FMVSS No.116 DOT 4

Steering

Free play

Less than 30 mm (1.2 in.)

Tires and wheels

Tire size

205/65R16 95H

Tire inflation pressure
(Recommended cold tire
inflation pressure)



Front tire

230 kPa (2.3 kgf/cm

2

 or bar, 33 psi)



Rear tire

220 kPa (2.2 kgf/cm

2

 or bar, 32 psi)

Wheel size

16



 6 1/2J

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Tire size

215/55R17 94V

Tire inflation pressure
(Recommended cold tire
inflation pressure)



Front tire

220 kPa (2.2 kgf/cm

2

 or bar, 32 psi)



Rear tire

200 kPa (2.0 kgf/cm

2

 or bar, 29 psi)

Wheel size

17



 7J

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

455

8

n

8-1. Specifications

Vehi

cle s
pec
ifi

cati

ons



18-inch tires



Compact spare tire (if equipped)

*

: If equipped

A: HIR2 halogen bulbs
B: Wedge base bulbs (amber)
C: Wedge base bulbs (clear)

Tire size

215/50R18 92V

Tire inflation pressure
(Recommended cold tire
inflation pressure)



Front tire

220 kPa (2.2 kgf/cm

2

 or bar, 32 psi)



Rear tire

200 kPa (2.0 kgf/cm

2

 or bar, 29 psi)

Wheel size

18



 7J

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Tire size

T145/90D16 106M

Tire inflation pressure
(Recommended cold tire
inflation pressure)

420 kPa (4.2 kgf/cm

2

 or bar, 60 psi)

Wheel size

16



 4T

Wheel nut torque

103 N•m (10.5 kgf•m, 76 ft•lbf)

Light bulbs

Light bulbs

W

Type

Exterior

Halogen headlights (bulb type)

55

A

Front turn signal lights (bulb type)

21

B

Rear turn signal lights (bulb type)

21

B

Back up light (bulb type)

16

C

License plate light

5

C

Interior

Vanity lights

*

8

C

Interior lights/personal lights

5

C

Luggage compartment light

5

C

456

n

8-1. Specifications

■

Use of ethanol blended gasoline in

a gasoline engine

Toyota allows the use of ethanol
blended gasoline where the ethanol

content is up to 10%. Make sure that the

ethanol blended gasoline to be used has
a Research Octane Number that follows

the above.

■

If your engine knocks

●

Consult any authorized Toyota retailer

or Toyota authorized repairer, or any

reliable repairer.

●

You may occasionally notice light
knocking for a short time while accel-

erating or driving uphill. This is normal
and there is no need for concern.

Fuel information

When you find these types of
fuel label at the gas station,
use only the fuel with one of
the following labels.



EU area

You must only use unleaded
gasoline conforming to Euro-
pean standard EN228.
Select unleaded gasoline with
a Research Octane Number of
95 or higher for optimum
engine performance.



Except EU area

You must only use unleaded
gasoline.
Select unleaded gasoline with
a Research Octane Number of
95 or higher for optimum
engine performance.

NOTICE

■

Notice on fuel quality

●

Do not use improper fuels. If
improper fuels are used, the engine

will be damaged.

●

Do not use gasoline with metallic

additives, for example manganese,

iron or lead, otherwise it may cause
damage on your engine or emission

control system.

●

Do not add aftermarket fuel addi-

tives which contain metallic addi-

tives.

●

EU area: Bioethanol fuel sold under

names such as “E50” or “E85” and
fuel containing a large amount of

ethanol should not be used. The

use of these fuels will damage the
vehicle’s fuel system. In case of any

doubt, ask any authorized Toyota

retailer or Toyota authorized
repairer, or any reliable repairer.

●

Except EU area: Bioethanol fuel
sold under names such as “E50” or

“E85” and fuel containing a large

amount of ethanol should not be
used. Your vehicle can use gasoline

mixed with 10% max ethanol. The

use of fuel with more than 10% eth-
anol content (E10) will damage the

vehicle’s fuel system. You must

ensure that refueling is carried out
only from a source where fuel spec-

ification and quality can be guaran-

teed. In case of any doubt, ask any
authorized Toyota retailer or Toyota

authorized repairer, or any reliable

repairer.

●

Do not use the methanol blended

gasoline such as M15, M85, M100.
The use of gasoline containing

methanol may cause engine dam-

age or failure.

457

8

n

8-2. Customization

Vehi

cle s
pec
ifi

cati

ons

8-2.Customization

■

Changing by using the naviga-
tion/multimedia system screen
(vehicles with 7-inch/8-inch
display multimedia system)

1

Press the “MENU” button.

2

Select “Setup” on the “Menu”
screen.

3

Select “Vehicle” on the “Setup”
screen.

4

4 Select “Vehicle customiza-
tion”.

Various setting can be changed. Refer

to the list of settings that can be
changed for details.

■

Changing by using the meter
control switches

1

Press

 /

 (4.2-inch display)

or

 /

 (7-inch display) of

the meter control switch to

select

.

2

Press

 /

 (4.2-inch display)

or

 /

 (7-inch display) of

the meter control switch to
select the desired item to be
customized.

3

Press or press and hold

.

The available settings will differ

depending on if

 is pressed or

pressed and held. Follow the instruc-
tions on the display.

Customizable features

Your vehicle includes a variety
of electronic features that can
be personalized to suit your
preferences. The settings of
these features can be changed
using the multi-information
display, the navigation/multi-
media system or at any autho-
rized Toyota retailer or Toyota
authorized repairer, or any reli-
able repairer.

Customizing vehicle fea-
tures

WARNING

■

During customization

As the engine needs to be running

during customization, ensure that the
vehicle is parked in a place with ade-

quate ventilation. In a closed area

such as a garage, exhaust gases
including harmful carbon monoxide

(CO) may collect and enter the vehi-

cle. This may lead to death or a seri-
ous health hazard.

NOTICE

■

During customization

To prevent battery discharge, ensure

that the engine is running while cus-

tomizing features.

458

n

8-2. Customization

Some function settings are changed simultaneously with other functions
being customized. Contact any authorized Toyota retailer or Toyota autho-
rized repairer, or any reliable repairer for further details.

 Settings that can be changed using the 7-inch/8-inch display multimedia

system

 Settings that can be changed using the multi-information display

 Settings that can be changed by any authorized Toyota retailer or Toyota

authorized repairer, or any reliable repairer

Definition of symbols: O = Available, — = Not available

■

Alarm

*

 (



P.77)

*

: If equipped

■

Gauges, meters and multi-information display (



P.85, 89, 94, 100)

Customizable features

Function

Default setting

Customized setting

Deactivates the alarm
when the doors are
unlocked using the key or
mechanical key

Off

On

—

—

O

Function

*1

Default setting

Customized setting

Language

*2

English

Except English

*3

—

O

—

Units

*2

L/100 km

km/L

—

O

—

miles (MPG)

*4

Speedometer display

*5

Analog

Digital

—

O

—

Eco Driving Indicator
Light

*4

On

Off

—

O

—

Fuel economy display

Total average

(Average fuel

consumption

[after reset])

Trip average (Aver-

age fuel consump-

tion [after start])

—

O

—

Tank average (Aver-

age fuel consump-

tion [after refuel])

459

8

n

8-2. Customization

Vehi

cle s
pec
ifi

cati

ons

*1

: For details about each function:



P.98, 104

*2

: The default setting varies according to country.

*3

: Available languages may differ depending on the target region.

*4

: If equipped

*5

: Vehicles with 7-inch display only

■

Head-up display

*

 (



P.106)

*

: If equipped

Audio system linked dis-
play

*4

On

Off

—

O

—

Drive information type

Trip (after start)

Total (after reset)

—

O

—

Drive information items
(First item)

Distance

Average vehicle

speed

—

O

—

Elapsed time

Drive information items
(Second item)

Elapsed time

Average vehicle

speed

—

O

—

Distance

Pop-up display

On

Off

—

O

—

Function

Default setting

Customized setting

Head-up display

On

Off

—

O

—

Gauge information

Tachometer

Eco Driving Indicator

*

—

O

—

No content

Route guidance to destina-
tion/street name

*

On

Off

—

O

—

Driving support system dis-
play

*

On

Off

—

O

—

Compass

*

On

Off

—

O

—

Audio system operation
status

*

On

Off

—

O

—

Function

*1

Default setting

Customized setting

460

n

8-2. Customization

■

Smart entry & start system

*

 and wireless remote control (



P.119,

136)

*

: If equipped

■

Smart entry & start system

*

 (



P.119, 125, 136)

*

: If equipped

■

Wireless remote control (



P.116, 119)

■

Power back door

*

 (



P.126)

Function

Default setting

Customized setting

Operation signal (Emer-
gency flashers)

On

Off

O

—

O

Time elapsed before auto-
matic door lock function is
activated if door is not
opened after being
unlocked

30 seconds

60 seconds

—

—

O

120 seconds

Open door warning buzzer

On

Off

—

—

O

Function

Default setting

Customized setting

Smart entry & start system

On

Off

O

—

O

Number of consecutive
door lock operations

2 times

As many as desired

—

—

O

Function

Default setting

Customized setting

Wireless remote control

On

Off

—

—

O

Function

Default setting

Customized setting

Power back door

On

Off

—

O

—

Power back door opening
position

5

1 to 4

—

O

—

User optional setting —

O

—

Buzzer volume

Level 3

Level 1

—

O

—

Level 2

Kick sensor

On

Off

—

O

—

461

8

n

8-2. Customization

Vehi

cle s
pec
ifi

cati

ons

*

: If equipped

■

Outside rear view mirrors (



P.150)

*

: If equipped

■

Power windows (



P.153)

*

: If equipped

■

Automatic light control system (



P.192)

■

Lights (



P.193)

Kick sensor sensitivity

+2

+0

—

—

O

+1

Function

Default setting

Customized setting

Automatic mirror folding
and extending operation

*

Linked to the

locking/ unlock-
ing of the doors

Off

—

—

O

Linked to operation of

the engine switch

Function

Default setting

Customized setting

Key (include mechanical
key

*

) linked operation

Off

On

—

—

O

Wireless remote control
linked operation

Off

On

—

—

O

Wireless remote control
linked operation signal
(buzzer)

On

Off

—

—

O

Function

Default setting

Customized setting

Light sensor sensitivity

Standard

-2 to 2

O

—

O

Extended headlight light-
ing function (Time elapsed
before headlights automati-
cally turn off)

30 seconds

60 seconds

—

—

O

90 seconds

120 seconds

Function

Default setting

Customized setting

Welcome lamp

On

Off

—

—

O

Function

Default setting

Customized setting

462

n

8-2. Customization

■

AHS (Adaptive High-beam System)

*1

 (



P.197)

*1

: If equipped

*2

: The headlights will operate under Automatic High Beam control. (



P.201)

■

Rear window wiper (



P.208)

Function

Default setting

Customized setting

Adaptive High-beam Sys-
tem

On

Off

*2

—

—

O

Vehicle speed at which the
brightness and illuminated
area adjustment of the high
beams changes mode

Approximately

15 km/h (10

mph) or more

Approximately 30

km/h (18 mph) or

more

—

—

O

Approximately 60

km/h (37 mph) or

more

Intensity adjustment of the
high beams when driving
around a curve (illuminates
the area in the direction
vehicle is turning more
brightly)

On

Off

—

—

O

Projection distance adjust-
ment of the low beams
according to the distance to
a preceding vehicle

On

Off

—

—

O

Function

Default setting

Customized setting

Rear window wiper opera-
tion when the back door is
opened

Off

On

—

—

O

Washer linked rear window
wiper operation

On

Off

—

—

O

Shift position linked rear
window wiper operation

Once

Off

—

—

O

Continuous

463

8

n

8-2. Customization

Vehi

cle s
pec
ifi

cati

ons

■

PCS (Pre-Collision System)

*

 (



P.217)

*

: If equipped

■

LTA (Lane Tracing Assist)

*

 (



P.228)

*

: If equipped

■

RSA (Road Sign Assist)

*1

 (



P.263)

*1

: If equipped

*2

: RSA function becomes On when the engine switch is turned to ON.

Function

Default setting

Customized setting

PCS (Pre-Collision Sys-
tem)

On

Off

—

O

—

Adjust alert timing

Middle

Early

—

O

—

Late

Function

Customized setting

Lane centering function

On / Off

—

O

—

Alert types

Buzzer / Steering

wheel vibration

—

O

—

Alert sensitivity

High / Standard

—

O

—

Vehicle sway warning function

On / Off

—

O

—

Vehicle sway warning sensitivity

High / Standard / Low —

O

—

Function

Default setting

Customized setting

RSA (Road Sign Assist)

*2

On

Off

—

O

—

Excess speed notification
method

*3

Display only

No notification

—

O

—

Display and buzzer

Excess speed notification
level

2 km/h (1 mph)

5 km/h (3 mph)

—

O

—

10 km/h (5 mph)

No overtaking notification
method

Display only

No notification

—

O

—

Display and buzzer

Other notifications method
(No-entry notification)

*4

Display only

No notification

—

O

—

Display and buzzer

464

n

8-2. Customization

*3

: If a speed limit with supplemental mark is exceeded, the notification buzzer does

not operate.

*4

: Vehicles with 7-inch/8-inch display navigation system

■

Dynamic radar cruise control

*

 (



P.238, 250)

*

: If equipped

■

Stop & Start system

*

 (



P.267)

*

: If equipped

■

BSM (Blind Spot Monitor)

*

 (



P.272)

*

: If equipped

■

Toyota parking assist-sensor

*

 (



P.277)

Function

Default setting

Customized setting

Radar Cruise Control with
Road Sign Assist

Off

On

—

O

—

Function

Default setting

Customized setting

Change the Stop & Start
system duration when the
A/C is on

Standard

Extended

—

O

—

Function

Default setting

Customized setting

BSM (Blind Spot Monitor)
function

On

Off

—

O

—

Outside rear view mirror
indicator brightness

Bright

Dim

—

O

—

Alert timing for presence of
approaching vehicle (sensi-
tivity)

Intermediate

Early

—

O

—

Late

Only when vehicle

detected in blind spot

Function

Default setting

Customized setting

Toyota parking assist-sen-
sor

On

Off

—

O

—

Buzzer volume

Level 2

Level 1

—

O

—

Level 3

465

8

n

8-2. Customization

Vehi

cle s
pec
ifi

cati

ons

*

: If equipped

■

RCTA (Rear Crossing Traffic Alert)

*

 (



P.284)

*

: If equipped

■

PKSB (Parking Support Brake)

*

 (



P.289)

*

: If equipped

■

Automatic air conditioning system

*

 (



P.316)

*

: If equipped

■

Rear seat reminder (



P.121)

■

Illumination (



P.324)

Function

Default setting

Customized setting

RCTA (Rear Crossing Traf-
fic Alert) function

On

Off

—

O

—

Buzzer volume

Level 2

Level 1

—

O

—

Level 3

Function

Default setting

Customized setting

PKSB (Parking Support
Brake) function

On

Off

—

O

—

Function

Default setting

Customized setting

Switching between outside
air and recirculated air
mode linked to automatic
mode switch operation

On

Off

O

—

O

Function

Default setting

Customized setting

Indication to prevent mis-
placement in the rear seat

On

Off

—

O

—

Function

Default setting

Customized setting

Time elapsed before the
interior lights turn off

15 seconds

Off

O

—

O

7.5 seconds

30 seconds

466

n

8-2. Customization

*

: If equipped

■

Vehicle customization

When the smart entry & start system is

off, Smart door unlocking cannot be cus-

tomized.

■

In the following situations, custom-
ize mode in which the settings can

be changed through the multi-infor-

mation display will automatically
be turned off

●

A warning message appears after the
customize mode screen is displayed

●

The engine switch is turned off.

●

The vehicle begins to move while the

customize mode screen is displayed.

Operation after the engine
switch is turned off

On

Off

—

—

O

Operation when the doors
are unlocked

On

Off

—

—

O

Operation when you
approach the vehicle with
the electronic key on your
person

*

On

Off

—

—

O

Footwell lights

*

, front con-

sole light and door trim
lights

*

On

Off

—

—

O

Function

Default setting

Customized setting
