1-1. For safe use

1-1.For safe use

Use only floor mats designed spe-
cifically for vehicles of the same
model and model year as your vehi-
cle. Fix them securely in place onto
the carpet.

Insert the retaining hooks (clips)
into the floor mat eyelets.

Turn the upper knob of each
retaining hook (clip) to secure
the floor mats in place.

Always align the

marks

The shape of the retaining hooks (clips)

may differ from that shown in the illus-
tration.

Before driving

Observe the following before
starting off in the vehicle to
ensure safety of driving.

Floor mat

WARNING

Observe the following precautions.
Failure to do so may cause the

driver’s floor mat to slip, possibly

interfering with the pedals while driv-
ing. An unexpectedly high speed may

result or it may become difficult to

stop the vehicle. This could lead to an
accident, resulting in death or serious

injury.

■

When installing the driver’s floor

mat

●

Do not use floor mats designed for
other models or different model

year vehicles, even if they are

Toyota Genuine floor mats.

●

Only use floor mats designed for

the driver’s seat.

●

Always install the floor mat securely

using the retaining hooks (clips)
provided.

●

Do not use two or more floor mats
on top of each other.

●

Do not place the floor mat bottom-
side up or upside-down.

■

Before driving

●

Check that the floor mat is securely

fixed in the correct place with all the

provided retaining hooks (clips). Be
especially careful to perform this

check after cleaning the floor.

1-1. For safe use

For s

afety
and s

ity

Adjust the angle of the seatback

so that you are sitting straight up
and so that you do not have to
lean forward to steer. (



P.141)

Adjust the seat so that you can

depress the pedals fully and so
that your arms bend slightly at
the elbow when gripping the
steering wheel. (



P.141)

Lock the head restraint in place

with the center of the head
restraint closest to the top of
your ears. (



P.144)

Wear the seat belt correctly.

(



P.35)

WARNING

●

With the engine stopped and the

shift lever in P (Multidrive) or N
(manual transmission), fully

depress each pedal to the floor to

make sure it does not interfere with
the floor mat.

For safe driving

For safe driving, adjust the
seat and mirror to an appropri-
ate position before driving.

Correct driving posture

1-1. For safe use

Make sure that all occupants are
wearing their seat belts before driv-
ing the vehicle. (



P.35)

Use a child restraint system appro-
priate for the child until the child
becomes large enough to properly
wear the vehicle’s seat belt.
(



P.49)

Make sure that you can see back-
ward clearly by adjusting the inside
and outside rear view mirrors prop-
erly. (



P.149, 150)

WARNING

■

For safe driving

Observe the following precautions.
Failure to do so may result in death or

serious injury.

●

Do not adjust the position of the

driver’s seat while driving.

Doing so could cause the driver to
lose control of the vehicle.

●

Do not place a cushion between the
driver or passenger and the

seatback.

A cushion may prevent correct pos-
ture from being achieved, and

reduce the effectiveness of the seat

belt and head restraint.

●

Do not place anything under the

front seats.
Objects placed under the front

seats may become jammed in the

seat tracks and stop the seat from
locking in place. This may lead to

an accident and the adjustment

mechanism may also be damaged.

●

Always observe the legal speed

limit when driving on public roads.

●

When driving over long distances,

take regular breaks before you start
to feel tired.

Also, if you feel tired or sleepy while

driving, do not force yourself to con-
tinue driving and take a break

immediately.

Correct use of the seat belts

Adjusting the mirrors

1-1. For safe use

For s

afety
and s

ity

Seat belts

Make sure that all occupants
are wearing their seat belts
before driving the vehicle.

WARNING

Observe the following precautions to
reduce the risk of injury in the event of

sudden braking, sudden swerving or

an accident.
Failure to do so may cause death or

serious injury.

■

Wearing a seat belt

●

Ensure that all passengers wear a

seat belt.

●

Always wear a seat belt properly.

●

Each seat belt should be used by

one person only. Do not use a seat

belt for more than one person at
once, including children.

●

Toyota recommends that children
be seated in the rear seat and

always use a seat belt and/or an

appropriate child restraint system.

●

To achieve a proper seating posi-

tion, do not recline the seat more
than necessary. The seat belt is

most effective when the occupants

are sitting up straight and well back
in the seats.

●

Do not wear the shoulder belt under
your arm.

●

Always wear your seat belt low and
snug across your hips.

■

Pregnant women

Obtain medical advice and wear the

seat belt in the proper way. (



P.36)

Women who are pregnant should

position the lap belt as low as possi-

ble over the hips in the same manner
as other occupants, extending the

shoulder belt completely over the

shoulder and avoiding belt contact
with the rounding of the abdominal

area.
If the seat belt is not worn properly,
not only the pregnant woman, but

also the fetus could suffer death or

serious injury as a result of sudden
braking or a collision.

■

People suffering illness

Obtain medical advice and wear the

seat belt in the proper way. (



P.36)

■

When children are in the vehicle



P.62

■

Seat belt damage and wear

●

Do not damage the seat belts by

allowing the belt, plate, or buckle to
be jammed in the door.

1-1. For safe use



Extend the shoulder belt so that
it comes fully over the shoulder,
but does not come into contact
with the neck or slide off the
shoulder.



Position the lap belt as low as
possible over the hips.



Adjust the position of the
seatback. Sit up straight and well
back in the seat.



Do not twist the seat belt.

■

Child seat belt usage

The seat belts of your vehicle were prin-

cipally designed for persons of adult
size.

●

Use a child restraint system appropri-
ate for the child, until the child

becomes large enough to properly

wear the vehicle’s seat belt. (



P.49)

●

When the child becomes large

enough to properly wear the vehicle’s
seat belt, follow the instructions

regarding seat belt usage. (



P.35)

■

Seat belt regulations

If seat belt regulations exist in the coun-
try where you reside, please contact any

authorized Toyota retailer or Toyota

authorized repairer, or any reliable
repairer for seat belt replacement or

installation.

To fasten the seat belt, push the
plate into the buckle until a click
sound is heard.

WARNING

●

Inspect the seat belt system period-

ically. Check for cuts, fraying, and
loose parts. Do not use a damaged

seat belt until it is replaced. Dam-

aged seat belts cannot protect an
occupant from death or serious

injury.

●

Ensure that the belt and plate are

locked and the belt is not twisted.

If the seat belt does not function
correctly, immediately contact any

authorized Toyota retailer or Toyota

authorized repairer, or any reliable
repairer.

●

Replace the seat assembly, includ-
ing the belts, if your vehicle has

been involved in a serious accident,

even if there is no obvious damage.

●

Do not attempt to install, remove,

modify, disassemble or dispose of
the seat belts. Have any necessary

repairs carried out by any autho-

rized Toyota retailer or Toyota
authorized repairer, or any reliable

repairer. Inappropriate handling

may lead to incorrect operation.

Correct use of the seat belts

Fastening and releasing the
seat belt

1-1. For safe use

For s

afety
and s

ity

To release the seat belt, press

the release button

■

Emergency locking retractor (ELR)

The retractor will lock the belt during a

sudden stop or on impact. It may also

lock if you lean forward too quickly.
When the seat belt locks, pull the belt

strongly and then release the belt, then

a slow and easy pulling will allow the
belt to extend.

■

After using the rear center seat belt

Stow seat belt buckle in the pocket.

The pretensioners help the seat
belts to quickly restrain the occu-
pants by retracting the seat belts
when the vehicle is subjected to
certain types of severe frontal or
side collision.

The pretensioners do not activate in the

event of a minor frontal impact, a minor
side impact, a rear impact or a vehicle
rollover.

■

Replacing the belt after the

pretensioner has been activated

If the vehicle is involved in multiple colli-
sions, the pretensioner will activate for

the first collision, but will not activate for

the second or subsequent collisions.

■

PCS-linked seat belt pretensioner
control (vehicles with Toyota Safety

Sense)

If the PCS (Pre-Collision System) deter-
mines that the possibility of a collision

with a vehicle is high, the seat belt

pretensioners will be prepared to oper-
ate.

Seat belt pretensioners
(front and outboard rear
seats)

WARNING

■

Seat belt pretensioners

If the pretensioner has activated, the

SRS warning light will come on. In

that case, the seat belt cannot be
used again and must be replaced at

any authorized Toyota retailer or

Toyota authorized repairer, or any reli-
able repairer.

Failure to do so may cause death or

serious injury.

1-1. For safe use

■

Location of the SRS airbags



SRS front airbags

SRS driver airbag/front passenger airbag

Can help protect the head and chest of the driver and front passenger from impact
with interior components



SRS side and curtain shield airbags

SRS front side airbags

Can help protect the torso of the front seat occupants

SRS curtain shield airbags

Can help protect primarily the head of occupants in the outer seats

SRS airbags

The SRS airbags inflate when the vehicle is subjected to certain
types of severe impacts that may cause significant injury to the
occupants. They work together with the seat belts to help reduce the
risk of death or serious injury.

SRS airbag system

1-1. For safe use

For s

afety
and s

ity



Other SRS airbag

SRS front seat center airbags

Can help protect the side head and neck of the front seat occupants

■

SRS airbag system components

Front impact sensors

Airbag manual on-off switch

Front passenger airbag

Side impact sensors (front door)

Side impact sensors (front)

Seat belt pretensioners and force limiters

Side airbags

Curtain shield airbags

Front seat center airbags

Driver airbag

SRS warning light

1-1. For safe use

“PASSENGER AIR BAG” indicator

Airbag sensor assembly

The main SRS airbag system components are shown above. The SRS air-
bag system is controlled by the airbag sensor assembly. As the airbags
deploy, a chemical reaction in the inflators quickly fills the airbags with non-
toxic gas to help restrain the motion of the occupants.

■

If the SRS airbags deploy (inflate)

●

Slight abrasions, burns, bruising etc.,

may be sustained from SRS airbags,
due to the extremely high speed

deployment (inflation) by hot gases.

●

A loud noise and white powder will be

emitted.

●

Parts of the airbag module (steering

wheel hub, airbag cover and inflator)

as well as the front seats, parts of the
front and rear pillars, and roof side

rails, may be hot for several minutes.
The airbag itself may also be hot.

●

The windshield may crack.

●

The brakes and stop lights will be con-

trolled automatically. (



P.301)

●

The interior lights will turn on automat-

ically. (



P.325)

●

The emergency flashers will turn on

automatically. (



P.394)

●

Fuel supply to the engine will be

stopped. (



P.402)

●

Vehicles with eCall: If any of the fol-
lowing situations occur, the system is
designed to send an emergency call

to the eCall control center, notifying

them of the vehicle’s location (without
needing to push the “SOS” button)

and an agent will attempt to speak

with the occupants to ascertain the
level of emergency and assistance

required. If the occupants are unable

to communicate, the agent automati-
cally treats the call as an emergency

and helps to dispatch the necessary

emergency services. (



P.65)

• An SRS airbag is deployed.

• A seat belt pretensioner is activated.

• The vehicle is involved in a severe

rear-end collision.

: In some cases, the call cannot be

made. (



P.66)

■

SRS airbag deployment conditions

(SRS front airbags)

●

The SRS front airbags will deploy in

the event of an impact that exceeds
the set threshold level (the level of

force corresponding to an approxi-

mately 20 - 30 km/h [12 - 18 mph]
frontal collision with a fixed wall that

does not move or deform).

However, this threshold velocity will be

considerably higher in the following situ-

ations:
• If the vehicle strikes an object, such

as a parked vehicle or sign pole,

which can move or deform on impact

• If the vehicle is involved in an under-

ride collision, such as a collision in

which the front of the vehicle “under-
rides”, or goes under, the bed of a

truck

●

Depending on the type of collision, it is

possible that only the seat belt

pretensioners will activate.

■

SRS airbag deployment conditions
(SRS side and curtain shield air-

bags and SRS front seat center air-

bags)

●

The SRS side and curtain shield air-

bags and SRS front seat center air-
bags will deploy in the event of an

impact that exceeds the set threshold

level (the level of force corresponding
to the impact force produced by an

approximately 1500 kg [3300 lb.] vehi-

cle colliding with the vehicle cabin

1-1. For safe use

For s

afety
and s

ity

from a direction perpendicular to the
vehicle orientation at an approximate

speed of 20 - 30 km/h [12 - 18 mph]).

●

Both SRS curtain shield airbags may

deploy in the event of a severe side

collision.

●

Both SRS curtain shield airbags may

also deploy in the event of a severe
frontal collision.

■

Conditions under which the SRS

airbags may deploy (inflate), other

than a collision

The SRS front airbags and SRS side

and curtain shield airbags may also

deploy if a serious impact occurs to the
underside of your vehicle. Some exam-

ples are shown in the illustration.

●

Hitting a curb, edge of pavement or

hard surface

●

Falling into or jumping over a deep

hole

●

Landing hard or falling

■

Types of collisions that may not
deploy the SRS airbags (SRS front

airbags)

The SRS front airbags do not generally
inflate if the vehicle is involved in a side

or rear collision, if it rolls over, or if it is

involved in a low-speed frontal collision.
But, whenever a collision of any type

causes sufficient forward deceleration of

the vehicle, deployment of the SRS front
airbags may occur.

●

Collision from the side

●

Collision from the rear

●

Vehicle rollover

■

Types of collisions that may not
deploy the SRS airbags (SRS side

and curtain shield airbags and SRS

front seat center airbags)

The SRS side and curtain shield airbags

and SRS front seat center airbags may

not activate if the vehicle is subjected to
a collision from the side at certain

angles, or a collision to the side of the

vehicle body other than the passenger
compartment.

●

Collision from the side to the vehicle
body other than the passenger com-

partment

●

Collision from the side at an angle

The SRS side airbags and SRS front
seat center airbags do not generally

inflate if the vehicle is involved in a fron-

tal or rear collision, if it rolls over, or if it
is involved in a low-speed side collision.

●

Collision from the front

●

Collision from the rear

●

Vehicle rollover

1-1. For safe use

The SRS curtain shield airbags do not
generally inflate if the vehicle is involved

in a rear collision, if it rolls over, or if it is

involved in a low-speed side or low-
speed frontal collision.

●

Collision from the rear

●

Vehicle rollover

■

When to contact any authorized

Toyota retailer or Toyota authorized

repairer, or any reliable repairer

In the following cases, the vehicle will

require inspection and/or repair. Contact

any authorized Toyota retailer or Toyota
authorized repairer, or any reliable

repairer as soon as possible.

●

Any of the SRS airbags have been

inflated.

●

The front of the vehicle is damaged or

deformed, or was involved in an acci-

dent that was not severe enough to
cause the SRS front airbags to inflate.

●

A portion of a door or its surrounding

area is damaged, deformed or has
had a hole made in it, or the vehicle

was involved in an accident that was

not severe enough to cause the SRS
side and curtain shield airbags and

SRS front seat center airbags to

inflate.

●

The pad section of the steering wheel

or dashboard near the front passen-
ger airbag is scratched, cracked, or

otherwise damaged.

●

The surface of the seats with the SRS

side airbag and SRS front seat center

airbag is scratched, cracked, or other-
wise damaged.

●

The portion of the front pillars, rear pil-
lars or roof side rail garnishes (pad-

ding) containing the SRS curtain

shield airbags inside is scratched,
cracked, or otherwise damaged.

1-1. For safe use

For s

afety
and s

ity

WARNING

■

SRS airbag precautions

Observe the following precautions
regarding the SRS airbags.

Failure to do so may cause death or

serious injury.

●

The driver and all passengers in the

vehicle must wear their seat belts
properly.

The SRS airbags are supplemental

devices to be used with the seat
belts.

●

The SRS driver airbag deploys with
considerable force, and can cause

death or serious injury especially if

the driver is very close to the air-
bag.

Since the risk zone for the driver’s air-
bag is the first 50 - 75 mm (2 - 3 in.) of
inflation, placing yourself 250 mm (10
in.) from your driver airbag provides
you with a clear margin of safety. This
distance is measured from the center
of the steering wheel to your breast-
bone. If you sit less than 250 mm (10
in.) away now, you can change your
driving position in several ways:

• Move your seat to the rear as far as

you can while still reaching the ped-

als comfortably.

• Slightly recline the back of the seat.

Although vehicle designs vary,

many drivers can achieve the 250
mm (10 in.) distance, even with the

driver seat all the way forward, sim-

ply by reclining the back of the seat
somewhat. If reclining the back of

your seat makes it hard to see the

road, raise yourself by using a firm,
non-slippery cushion, or raise the

seat if your vehicle has that feature.

• If your steering wheel is adjustable,

tilt it downward. This points the air-

bag toward your chest instead of
your head and neck.

The seat should be adjusted as rec-
ommended above, while still main-

taining control of the foot pedals,

steering wheel, and your view of the
instrument panel controls.

●

The SRS front passenger airbag
also deploys with considerable

force, and can cause death or seri-

ous injury especially if the front pas-
senger is very close to the airbag.

The front passenger seat should be

as far from the airbag as possible
with the seatback adjusted, so the

front passenger sits upright.

●

Improperly seated and/or restrained

infants and children can be killed or

seriously injured by a deploying air-
bag. An infant or child who is too

small to use a seat belt should be

properly secured using a child
restraint system. Toyota strongly

recommends that all infants and

children be placed in the rear seats
of the vehicle and properly

restrained. The rear seats are safer

for infants and children than the
front passenger seat. (



P.49)

1-1. For safe use

WARNING

●

Do not sit on the edge of the seat or

lean against the dashboard.

●

Do not allow a child to stand in front

of the SRS front passenger airbag
unit or sit on the knees of a front

passenger.

●

Do not allow the front seat occu-

pants to hold items on their knees.

●

Do not lean against the door, the

roof side rail or the front, side and

rear pillars.

●

Do not allow anyone to kneel on the

passenger seat toward the door or

put their head or hands outside the
vehicle.

●

Do not attach anything to or lean
anything against areas such as the

dashboard or steering wheel pad.

These items can become projec-
tiles when the SRS driver and front

passenger airbags deploy.

●

Do not attach anything to areas

such as a door, windshield, side

windows, front or rear pillar, roof
side rail and assist grip. (Except for

the speed limit label



P.419)

●

Do not hang coat hangers or other

hard objects on the coat hooks. All

of these items could become pro-
jectiles and may cause death or

serious injury, should the SRS cur-

tain shield airbags deploy.

1-1. For safe use

For s

afety
and s

ity

WARNING

●

Do not use seat accessories which

cover the parts where the SRS side
airbags and SRS front seat center

airbags inflate as they may interfere

with inflation of the SRS airbags.
Such accessories may prevent the

SRS side airbags and SRS front

seat center airbags from activating
correctly, disable the system or

cause the SRS side airbags and

SRS front seat center airbags to
inflate accidentally, resulting in

death or serious injury.

●

Do not strike or apply significant

levels of force to the area of the

SRS airbag components or the
front doors.

Doing so can cause the SRS air-

bags to malfunction.

●

Do not touch any of the component

parts immediately after the SRS air-
bags have deployed (inflated) as

they may be hot.

●

If breathing becomes difficult after

the SRS airbags have deployed,

open a door or window to allow
fresh air in, or leave the vehicle if it

is safe to do so. Wash off any resi-

due as soon as possible to prevent
skin irritation.

●

If the areas where the SRS airbags
are stored, such as the steering

wheel pad and front and rear pillar

garnishes, are damaged or
cracked, have them replaced by

any authorized Toyota retailer or

Toyota authorized repairer, or any
reliable repairer.

■

Modification and disposal of SRS

airbag system components

Do not dispose of your vehicle or per-
form any of the following modifica-

tions without consulting your Toyota

retailer or Toyota authorized repairer,
or any reliable repairer. The SRS air-

bags may malfunction or deploy

(inflate) accidentally, causing death or
serious injury.

●

Installation, removal, disassembly
and repair of the SRS airbags

●

Repairs, modifications, removal or
replacement of the steering wheel,

instrument panel, dashboard, seats

or seat upholstery, front, side and
rear pillars, roof side rails, front

door panels, front door trims or front

door speakers

●

Modifications to the front door panel

(such as making a hole in it)

●

Repairs or modifications of the front

fender, front bumper, or side of the
occupant compartment

●

Installation of a grille guard (bull
bars, kangaroo bar, etc.), snow

plows or winches

●

Modifications to the vehicle’s sus-

pension system

●

Installation of electronic devices

such as mobile two-way radios (RF-

transmitter) and CD players

1-1. For safe use

Exhaust gas precautions

Harmful substance to the
human body is included in
exhaust gases if inhaled.

WARNING

Exhaust gases include harmful car-
bon monoxide (CO), which is color-

less and odorless. Observe the

following precautions.
Failure to do so may cause exhaust

gases enter the vehicle and may lead

to an accident caused by light-
headedness, or may lead to death or

a serious health hazard.

■

Important points while driving

●

Keep the back door closed.

●

If you smell exhaust gases in the

vehicle even when the back door is

closed, open the windows and have
the vehicle inspected at any autho-

rized Toyota retailer or Toyota

authorized repairer, or any reliable
repairer as soon as possible.

■

When parking

●

If the vehicle is in a poorly venti-

lated area or a closed area, such as

a garage, stop the engine.

●

Do not leave the vehicle with the

engine on for a long time.
If such a situation cannot be

avoided, park the vehicle in an

open space and ensure that
exhaust fumes do not enter the

vehicle interior.

●

Do not leave the engine running in

an area with snow build-up, or

where it is snowing. If snowbanks
build up around the vehicle while

the engine is running, exhaust

gases may collect and enter the
vehicle.

■

Exhaust pipe

The exhaust system needs to be

checked periodically. If there is a hole
or crack caused by corrosion, dam-

age to a joint or abnormal exhaust

noise, be sure to have the vehicle
inspected and repaired by any autho-

rized Toyota retailer or Toyota autho-

rized repairer, or any reliable repairer.

1-2. Child safety

For s

afety
and s

ity

1-2.Child safety

“PASSENGER AIR BAG” indica-

tor

“PASSENGER AIR BAG” and “ON”
indicator light turns on when the airbag
system is on, and about after 60 sec-
onds they go off. (only when the engine
switch is in ON)

Airbag manual on-off switch

Vehicles without a smart entry &
start system: Insert the key into the
cylinder and turn to the “OFF” posi-
tion.

The “OFF” indicator light turns on (only
when the engine switch is in ON).

Vehicles with a smart entry & start
system: Insert the mechanical key
into the cylinder and turn to the
“OFF” position.

The “OFF” indicator light turns on (only
when the engine switch is in ON).

■

“PASSENGER AIR BAG” indicator

information

If any of the following problems occur, it
is possible that there is a malfunction in

the system. Have the vehicle inspected

by any authorized Toyota retailer or
Toyota authorized repairer, or any reli-

able repairer.

●

The “OFF” indicator does not illumi-

nate when the airbag manual on-off

switch is set to “OFF”.

●

The indicator light does not change

when the airbag manual on-off switch
is switched to “ON” or “OFF”.

Airbag manual on-off

system

This system deactivates the
front passenger airbag.
Only deactivate the airbag
when using a child restraint
system on the front passenger
seat.

System components

Deactivating the front seat
passenger airbag

Content .. 1 2 3 ..
