337

WARNING

■

When starting the hybrid system

Always start the hybrid system while sitting in the driver’s seat. Do not
depress the accelerator pedal while starting the hybrid system under any
circumstances.
Doing so may cause an accident resulting in death or serious injury.

■

Stopping the hybrid system in an emergency

●

If you want to stop the hybrid system in an emergency while driving the
vehicle, press and hold the power switch for more than 2 seconds, or
press it briefly 3 times or more in succession. (



P. 661)

However, do not touch the power switch while driving except in an emer-
gency. Turning the hybrid system off while driving will not cause loss of
steering or braking control, however, power assist to the steering will be
lost. This will make it more difficult to steer smoothly, so you should pull
over and stop the vehicle as soon as it is safe to do so.

●

If the power switch is operated while the vehicle is running, a warning
message will be shown on the multi-information display and a buzzer
sounds.

●

When restarting the hybrid system after an emergency shutdown while
driving, press the power switch. When restarting the hybrid system after
stopping the vehicle, change the shift position to P and then press the
power switch.

■

When parking

Exhaust gases include harmful carbon monoxide (CO), which is colorless
and odorless. Observe the following precautions.
Failure to do so may cause exhaust gases to enter the vehicle and may
lead to an accident caused by light-headedness, or may lead to death or a
serious health hazard.

●

If the vehicle is in a poorly ventilated area or a closed area, such as a
garage, stop the hybrid system.

●

Do not leave the vehicle with the hybrid system operating for a long time. If
such a situation cannot be avoided, park the vehicle in an open space and
ensure that exhaust fumes do not enter the vehicle interior.

●

Do not leave the hybrid system operating in an area with snow build-up, or
where it is snowing. If snowbanks build up around the vehicle while the
hybrid system is operating, exhaust gases may collect and enter the vehi-
cle.

338

5-2. Driving procedures

NOTICE

■

To prevent 12-volt battery discharge

●

Do not leave the power switch in ACCESSORY or ON mode for long peri-
ods of time without the hybrid system on.

●

If “Accessory”, “Ignition ON” or mileage display (



P. 213) is displayed on

the main display while the hybrid system is not operating, the power switch
is not off. Exit the vehicle after turning the power switch off.

■

When starting the hybrid system

If the hybrid system becomes difficult to start, have your vehicle checked by
your Toyota dealer immediately.

■

Symptoms indicating a malfunction with the power switch

If the power switch seems to be operating somewhat differently than usual,
such as the switch sticking slightly, there may be a malfunction. Contact
your Toyota dealer immediately.

339

5-2. Driving procedures

Drivin

Hybrid transmission

Shift lever

Operate the shift lever gently and ensure correct shifting operation.
Release the shift lever after each shifting operation to allow it to return to
the

position.

When shifting from P to N, D or R, from D to R, or from R to D, ensure that
the brake pedal is being depressed and the vehicle is stationary.

Shift position indicator

The current shift position is highlighted.
When any shift position other than D or B is selected, the arrow toward B
and B position indicator disappear from the shift position indicator.

When selecting the shift position, make sure that the shift position has
been changed to the desired position by checking the shift position
indicator provided on the instrument cluster.

Shifting the shift lever

When shifting to the D or R, move the shift lever along the shift
gate.

To shift to the N, slide the shift lever to the left and hold it. The shift
position will change to N.

To shift to the B, pull the shift lever down. Shifting to B is only pos-
sible when shift position D is selected.

340

5-2. Driving procedures

: For good fuel economy and noise reduction, the D position should usually

be used.



P. 425

■

When shifting the shift position to P

Fully stop the vehicle and set
the parking brake, and then
press the P position switch.

When  the  shift  position  is
changed to P, the switch indica-
tor comes on.
Check  that  the  P  position  is
highlighted  on  the  shift  position
indicator.

■

Shifting the shift position from P to other positions

●

While depressing the brake pedal firmly, operate the shift lever. If
the shift lever is operated without depressing the brake pedal, the
buzzer will sound and the shifting operation will be disabled.

●

When selecting the shift position, make sure that the shift posi-
tion has been changed to the desired position by checking the
shift position indicator provided on the instrument cluster.

●

The shift position cannot be changed from P to B directly.

Shift position purpose

Shift position

Objective or function

Parking the vehicle/starting the hybrid system

Reversing

Neutral

(Condition in which the power is not transmitted)

Normal driving

Applying engine braking or strong braking when the

accelerator pedal has been released on steep down-

ward slopes etc.

Selecting a driving mode

P position switch

341

5-2. Driving procedures

Drivin

■

For the shift positions

●

When the power switch is off, the shift position cannot be changed.

●

When the power switch is in ON mode (the hybrid system is not operating),
the shift position can only be changed to N. The shift position will be
changed to N even if the shift lever is shifted to D or R and held in that posi-
tion.

●

When the “READY” indicator is on, the shift position can be changed from P
to D, N or R.

●

When the “READY” indicator is flashing, the shift position cannot be
changed from P to another position even if the shift lever is operated. Wait
until the “READY” indicator changes from a flashing to a solid light, and then
operate the shift lever again.

●

The shift position can only be changed to B directly from D.

In addition, if an attempt is made to change the shift position by moving the
shift lever or by pressing the P position switch in any of the following situa-
tions, the buzzer will sound and the shifting operation will be disabled or the
shift position will automatically change to N. When this happens, select an
appropriate shift position.

●

Situations where the shifting operation will be disabled:
• When an attempt is made to change the shift position from P to another

position by moving the shift lever without depressing the brake pedal.

• When the shift lever is moved to attempt to change the shift position from

P or N with the accelerator pedal depressed and the vehicle stopped.

• When an attempt is made to change the shift position from P or N to B by

moving the shift lever.

• When an attempt is made to change the shift position from P to another

position by moving the shift lever while the charging cable is connected to
the vehicle.

●

Situations where the shift position will automatically change to N:
• When the P position switch is pressed while the vehicle is running.

• When an attempt is made to select the R position by moving the shift

lever when the vehicle is moving forward.

• When an attempt is made to select the D position by moving the shift

lever when the vehicle is moving in reverse.

• When an attempt is made to change the shift position from R to B by

moving the shift lever.

: Shift position may be changed to P when driving at extremely low

speeds.

: Shift position may be changed to R when driving at low speeds.

: Shift position may be changed to D when driving at low speeds.

342

5-2. Driving procedures

●

If N is selected while driving at a certain speed, even if the shift lever is not
held in the N position, the shift position changes to N. In this situation, the
buzzer sounds and a confirmation message is displayed on the multi-infor-
mation display to inform the driver that the shift position has changed to N.

■

Restraining sudden start (Drive-Start Control)



P. 316

■

Automatic P position selection function

In the following situations, the shift position is automatically changed to P.

●

When pressing the power switch with the vehicle stopped while the power
switch is in ON mode and the shift position is in a position other than P (after
the shift position has changed to P, the power switch will turn off)

●

If the driver’s door is opened and all of the following conditions are met,
while the shift position is in a position other than P
• The power switch is in ON mode.
• The driver is not wearing the seat belt.
• The brake pedal is not depressed.
To start off the vehicle after the shift position is changed to P, operate the
shift lever again.

: When the power switch is pressed while driving at extremely slow speeds,

such as immediately before stopping the vehicle, the shift position may
automatically change to P. Make sure that the vehicle is completely stopped
before pressing the power switch.

The shift position may also automatically switch to P if one of the following
conditions is detected while the vehicle is stopped by dynamic radar cruise
control with full-speed range.

●

Driver’s seat belt is not fastened

●

Driver’s door is opened

●

Approximately 3 minutes elapse after the vehicle stopped

■

If the shift position cannot be shifted from P

There is a possibility that the 12-volt battery is discharged. Check the 12-volt
battery in this situation. (



P. 712)

■

About engine braking

When shift position B is selected, releasing the accelerator pedal will apply
engine braking.

●

When the vehicle is driven at high speeds, compared to ordinary gasoline-
fueled vehicles, the engine braking deceleration is felt less than that of other
vehicles.

●

The vehicle can be accelerated even when shift position B is selected.

If the vehicle is driven continuously in the B position, fuel efficiency will
become low. Usually, select the D position.

■

After recharging/reconnecting the 12-volt battery



P. 606

343

5-2. Driving procedures

riv

■

When a message related to shift operations is displayed on the multi-
information display

When the shift position does not switch due to a mistaken operation, system
conditions, etc., or when the attempted shift operation is invalid, a message
indicating the correct operation or the reason why switching cannot be per-
formed is shown on the multi-information display. In these cases, follow the
instructions and retry the operation.

■

Customization

Settings (e.g. reverse warning buzzer) can be changed.
(Customizable features:



P. 749)

WARNING

■

When driving on slippery road surfaces

Do not accelerate or shift the shift position suddenly.
Sudden changes in engine braking may cause the vehicle to spin or skid,
resulting in an accident.

■

Shift lever and P position switch

●

Do not remove the shift lever knob or use anything but a genuine Toyota
shift lever knob. Also, do not hang anything on the shift lever.
Doing so could prevent the shift lever from returning to position, causing
unexpected accidents to occur when the vehicle is in motion.

●

Do not press the P position switch while the vehicle is moving.
If the P position switch is pressed when driving at very low speeds (for
example, just before the vehicle stops), the vehicle may stop suddenly
when the shift position switches to P, which could lead to an accident.

●

In order to prevent the shift position from accidentally being changed, do
not touch the shift lever or P position switch when not using them.

344

5-2. Driving procedures

NOTICE

■

Hybrid battery (traction battery) charge

If the shift position is in N, the hybrid battery (traction battery) will not be
charged. To help prevent the battery from discharging, avoid leaving the N
position selected for an extended period of time.

■

Situations where shift control system malfunctions are possible

If any of the following situations occurs, shift control system malfunctions
are possible.
Immediately stop the vehicle in a safe place on level ground, apply the park-
ing brake, and then contact your Toyota dealer.

●

When the warning message indicating the shift control system appears on
the multi-information display.

●

The display indicates that no shift position is selected for more than a few
seconds.

■

Notes regarding shift lever and P position switch operation

Avoid repeatedly operating the shift lever and P position switch in quick suc-
cession.
The system protection function may activate and it will not be temporarily
possible to shift the shift position other than P. If this happens, please wait
for approximately 20 seconds before attempting to change the shift position
again.

■

When exiting the vehicle (driver’s seat only)

Check that the shift position indicator shows P and that the parking brake is
set before opening the door and exiting the vehicle.

345

5-2. Driving procedures

Drivin

Turn signal lever

Right turn
Lane change to the right (move
the lever partway and release
it)

The right hand signals will flash 3
times.

Lane change to the left (move
the lever partway and release
it)

The left hand signals will flash 3
times.

Left turn

■

Turn signals can be operated when

The power switch is in ON mode.

■

If the indicator flashes faster than usual

Check that each turn signal light flashes correctly.

■

If the turn signals stop flashing before a lane change has been per-
formed

Operate the lever again.

■

Customization

The number of times the turn signals flash during a lane change can be
changed. (Customizable features:



P. 749)

Operating instructions

1
2

346

5-2. Driving procedures

Parking brake

To  set  the  parking  brake,  fully
depress  the  parking  brake  pedal
with  your  left  foot  while  depress-
ing the brake pedal with your right
foot.
(Depressing  the  pedal  again
releases the parking brake.)

■

Parking the vehicle



P. 315

■

Parking brake engaged warning buzzer

A buzzer will sound if the vehicle is driven with the parking brake engaged.
“Release Parking Brake” is displayed on the multi-information display (with
the vehicle reached a speed of 3 mph [5 km/h]).

■

Usage in winter time



P. 503

Operating instructions

(U.S.A.)

(Canada)

NOTICE

■

Before driving

Fully release the parking brake.
Driving the vehicle with the parking brake set will lead to brake components
overheating, which may affect braking performance and increase brake
wear.

347

5-3. Operating the lights and wipers

Drivin

Headlight switch

Operating the

switch turns on the lights as follows:



U.S.A. (type A)

The daytime running
lights turn on. (



P. 350)

The  side  marker,  park-
ing,  tail,  license  plate,
instrument  panel  lights,
and  daytime  running
lights (



P. 350) turn on.

The  headlights  and  all
the  lights  listed  above
(except daytime running
lights) turn on.
The  daytime  running
lights turn off.

The headlights can be operated manually or automatically.

Operating instructions

348

5-3. Operating the lights and wipers



U.S.A. (type B)

The headlights and all the lights listed above (except day-
time running lights) turn on.
The daytime running lights turn off.

The  headlights,  side
marker,  parking,  LED
accent  (if  equipped),
daytime  running  lights
(



P. 350) and so on

turn on and off automat-
ically  (when  the  power
switch is in ON mode).
The  side  marker,  park-
ing,  LED  accent  (if
equipped),  tail,  license
plate,  instrument  panel
lights, and daytime run-
ning  lights  (



P. 350)

turn on.

(if equipped)

349

5-3. Operating the lights and wipers

Drivin



Canada

The  headlights,  side
marker,  parking,  LED
accent  (if  equipped),
daytime  running  lights
(



P. 350) and so on



P. 350)

turn on.
The headlights and all the lights listed above (except day-
time running lights) turn on.

With the headlights on, push
the lever away from you to turn
on the high beams.

Pull the lever toward you to the
center position to turn the high
beams off.

Pull the lever toward you and
release it to flash the high
beams once.

You can flash the high beams with the headlights on or off.

Turning on the high beam headlights

IO53PH019

350

5-3. Operating the lights and wipers

■

Daytime running light system

●

The daytime running lights illuminate using the same lights as the head-
lights, and illuminate dimmer than the headlights.

●

To make your vehicle more visible to other drivers during daytime driving,
the daytime running lights turn on automatically when all of the following
conditions are met. (The daytime running lights are not designed for use at
night.)
• The hybrid system is operating
• The parking brake is released

• The headlight switch is in the

position

: When the surroundings are bright

The daytime running lights remain on after they illuminate, even if the park-
ing brake is set again.

●

For the U.S.A.: Daytime running lights can be turned off by operating the
switch.

●

Compared to turning on the headlights, the daytime running light system
offers greater durability and consumes less electricity, so it can help improve
fuel economy.

■

Headlight control sensor (if equipped)

The sensor may not function properly if an
object is placed on the sensor, or anything
that  blocks  the  sensor  is  affixed  to  the
windshield.
Doing  so  interferes  with  the  sensor
detecting  the  level  of  ambient  light  and
may  cause  the  automatic  headlight  sys-
tem to malfunction.
Air  conditioning  operation  may  also  be
interrupted.

351

5-3. Operating the lights and wipers

riv

■

Automatic light off system

●

When the headlights come on: The headlights and tail lights turn off 30 sec-
onds after the driver’s door is opened and closed if the power switch is
turned to ACCESSORY mode or turned off. (The lights turn off immediately
if

on the key is pressed after all the doors are locked.)

●

When only the tail lights come on: The tail lights turn off automatically if the
power switch is turned to ACCESSORY mode or turned off and the driver’s
door is opened.

To turn the lights on again, turn the power switch to ON mode, or turn the light

switch to the

position once and then back to the

position.

■

12-volt battery-saving function

In order to prevent the 12-volt battery of the vehicle from discharging, if the
headlights and/or tail lights are on when the power switch is turned off, the
12-volt battery saving function will operate and automatically turn off all the
lights after approximately 20 minutes.
When any of the following are performed, the 12-volt battery-saving function
is canceled once and then reactivated. All the lights will turn off automatically
20 minutes after the 12-volt battery-saving function has been reactivated:

●

When the headlight switch is operated

●

When a door is opened or closed

■

If “Headlight System Malfunction Visit Your Dealer” is displayed on the
multi-information display

The system may be malfunctioning. Have the vehicle inspected by your Toy-
ota dealer.

■

Customization

Settings (e.g. light sensor sensitivity) can be changed.
(Customizable features:



P. 749)

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the lights on longer than necessary when the hybrid system is
off.

352

5-3. Operating the lights and wipers

AHB (Automatic High Beam)

Push the lever away from you
with the headlight switch in the

position.

Press the Automatic High
Beam switch.

The Automatic  High  Beam  indica-
tor  will  come  on  when  the  head-
lights  are  turned  on  automatically
to  indicate  that  the  system  is
active.

The Automatic High Beam uses an in-vehicle front camera to
assess the brightness of streetlights, the lights of vehicles
ahead etc., and automatically turns the high beam on or off as
necessary.

WARNING

■

Limitations of the Automatic High Beam

Do not rely on the Automatic High Beam. Always drive safely, taking care to
observe your surroundings and turning the high beam on or off manually if
necessary.

■

To prevent incorrect operation of the Automatic High Beam system

Do not overload the vehicle.

Activating the Automatic High Beam system

Content .. 19 20 21 22 ..
