Toyota Corolla Hybrid (2022 year). Manual in english - page 3

1-1. For safe use

Exhaust gas precau-

tions

Harmful substance to the
human body is included in
exhaust gases if inhaled.

WARNING

Exhaust gases include harmful

carbon monoxide (CO), which is

colorless and odorless. Observe

the following precautions.

Failure to do so may cause

exhaust gases enter the vehicle

and may lead to an accident

caused by light-headedness, or

may lead to death or a serious

health hazard.

■

Important points while driving

●

Keep the trunk lid closed.

●

If you smell exhaust gases in

the vehicle even when the trunk

lid is closed, open the windows

and have the vehicle inspected

at your Toyota dealer as soon

as possible.

■

When parking

●

If the vehicle is in a poorly venti-

lated area or a closed area,

such as a garage, stop the

hybrid system.

●

Do not leave the vehicle with

the hybrid system on for a long

time.

If such a situation cannot be

avoided, park the vehicle in an

open space and ensure that

exhaust fumes do not enter the

vehicle interior.

●

Do not leave the hybrid system

operating in an area with snow

build-up, or where it is snowing.

If snowbanks build up around

the vehicle while the hybrid sys-

tem is operating, exhaust gases

may collect and enter the vehi-

cle.

■

Exhaust pipe

The exhaust system needs to be

checked periodically. If there is a

hole or crack caused by corro-

sion, damage to a joint or abnor-

mal exhaust noise, be sure to

have the vehicle inspected and

repaired by your Toyota dealer.

1-2. Child safety

For safety and secu

rity

1-2.Child safety

Riding with children

Observe the following pre-
cautions when children are
in the vehicle.
Use a child restraint system
appropriate for the child,
until the child becomes
large enough to properly
wear the vehicle’s seat belt.



It is recommended that chil-
dren sit in the rear seats to
avoid accidental contact
with the shift lever, wiper
switch, etc.



Use the rear door child-pro-
tector lock or the window
lock switch to avoid children
opening the door while driv-
ing or operating the power
window accidentally.
(



P.120, 140)



Do not let small children
operate equipment which
may catch or pinch body
parts, such as the power
window, hood, trunk, seats,
etc.

WARNING

■

When children are in the vehi-

cle

Never leave children unattended

in the vehicle, and never allow

children to have or use the key.
Children may be able to start the

vehicle or shift the vehicle into

neutral. There is also a danger

that children may injure them-

selves by playing with the win-

dows or other features of the

vehicle. In addition, heat build-up

or extremely cold temperatures

inside the vehicle can be fatal to

children.

1-2. Child safety

Points to remember: P.48
Child restraint system: P.50
When using a child restraint sys-
tem: P.52
Child restraint system compati-
bility for each seating position
(for Puerto Rico): P.54
Child restraint system installa-
tion method
• Fixed with a seat belt: P.59
• Fixed with a child restraint

LATCH anchor (except for
Puerto Rico): P.64

• Fixed with an ISOFIX lower

anchorage (for Puerto Rico):
P.66

• Using an anchor bracket (for

top tether strap) (except for
Puerto Rico): P.68

• Using a top tether anchorage

(for Puerto Rico): P.70

The laws of all 50 states of the
U.S.A. as well as Canada now
require the use of child restraint
systems.



Prioritize and observe the
warnings, as well as the laws
and regulations for child
restraint systems.



Use a child restraint system
until the child becomes large
enough to properly wear the
vehicle’s seat belt.



Choose a child restraint sys-
tem that suits your vehicle
and is appropriate to the age
and size of the child.

Child restraint sys-

tems

Before installing a child
restraint system in the vehi-
cle, there are precautions
that need to be observed,
different types of child
restraint systems, as well as
installation methods, etc.,
written in this manual.

Use a child restraint system
when riding with a small child
that cannot properly use a
seat belt. For the child’s
safety, install the child
restraint system to a rear seat.
Be sure to follow the installa-
tion method that is in the oper-
ation manual enclosed with
the restraint system.

Table of contents

Points to remember

WARNING

■

When a child is riding

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

1-2. Child safety

For safety and secu

rity

WARNING

●

For effective protection in auto-

mobile accidents and sudden

stops, a child must be properly

restrained, using a seat belt or

child restraint system which is

correctly installed. For installa-

tion details, refer to the opera-

tion manual enclosed with the

child restraint system. General

installation instruction is pro-

vided in this manual.

●

Toyota strongly urges the use of

a proper child restraint system

that conforms to the weight and

size of the child, installed on the

rear seat. According to accident

statistics, the child is safer when

properly restrained in the rear

seat than in the front seat.

●

Holding a child in your or some-

one else’s arms is not a substi-

tute for a child restraint system.

In an accident, the child can be

crushed against the windshield

or between the holder and the

interior of the vehicle.

■

Handling the child restraint

system

If the child restraint system is not

properly fixed in place, the child or

other passengers may be seri-

ously injured or even killed in the

event of sudden braking, sudden

swerving, or an accident.

●

If the vehicle were to receive a

strong impact from an accident,

etc., it is possible that the child

restraint system has damage

that is not readily visible. In

such cases, do not reuse the

restraint system.

●

For Puerto Rico: Depending on

the child restraint system, instal-

lation may be difficult or impos-

sible. In those cases, check

whether the child restraint sys-

tem is suitable for installment in

the vehicle. (



P.54) Be sure to

install and observe the usage

rules after carefully reading the

child restraint system fixing

method in this manual, as well

as the operation manual

enclosed with the child restraint

system.

●

Except for Puerto Rico: Make

sure you have complied with all

installation instructions provided

with the child restraint system

manufacturer and that the sys-

tem is properly secured.

●

Keep the child restraint system

properly secured on the seat

even if it is not in use. Do not

store the child restraint system

unsecured in the passenger

compartment.

●

If it is necessary to detach the

child restraint system, remove it

from the vehicle or store it

securely in the trunk.

1-2. Child safety

■

Types of child restraint system installation methods

Confirm with the operation manual enclosed with the child restraint
system about the installation of the child restraint system.

Child restraint system

Installation method

Page

Seat belt attachment

P.59

1-2. Child safety

For safety and secu

rity

Except for Puerto Rico:

Child restraint LATCH

anchors attachment

For Puerto Rico:

ISOFIX lower anchor-

age attachment

Except for Puerto Rico
For Puerto Rico

P.64, 66

Installation method

Page

1-2. Child safety

■

When installing a child
restraint system to a front
passenger seat

For the safety of a child, install a
child restraint system to a rear
seat. When installing a child
restraint system to a front pas-
senger seat is unavoidable,
adjust the seat as follows and

install the child restraint system:



Move the front seat fully rear-
ward.



If the passenger seat height
can be adjusted, Adjust the
seat height to the upper most
position.



Adjust the seatback angle to
the most upright position.

If there is a gap between the child
seat and the seatback, adjust the

Except for Puerto Rico:

Anchor brackets (for

top tether strap) attach-

ment

For Puerto Rico:

Top tether anchorage

attachment

Seats with an adjustable type head
restraint:

Except for Puerto Rico
For Puerto Rico

Seats with an integrated type head
restraint:

Except for Puerto Rico
For Puerto Rico

P.68, 70

Installation method

Page

When using a child
restraint system

1-2. Child safety

For safety and secu

rity

seatback angle until good contact is
achieved.



If the head restraint interferes
with the child restraint system
installation and the head
restraint can be removed,
remove the head restraint.

Otherwise, put the head restraint in
the upper most position.

WARNING

■

When using a child restraint

system

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

●

Never install a rear-facing child

restraint system on the front

passenger seat even if the “AIR

BAG OFF” indicator light is illu-

minated. In the event of an acci-

dent, the force of the rapid

inflation of the front passenger

airbag can cause death or seri-

ous injury to the child if the

rear-facing child restraint sys-

tem is installed on the front pas-

senger seat.

●

A forward-facing child restraint

system may be installed on the

front passenger seat only when

it is unavoidable. A child

restraint system that requires a

top tether strap should not be

used in the front passenger seat

since there is no top tether strap

anchor for the front passenger

seat.

●

A forward-facing child restraint

system may be installed on the

front passenger seat only when

it is unavoidable. When install-

ing a forward-facing child

restraint system on the front

passenger seat, adjust the seat-

back angle to the most upright

position, move the seat to the

rearmost position, and raise the

seat to the upper most position,

even if the “AIR BAG OFF” indi-

cator light is illuminated. If the

head restraint interferes with the

child restraint system installa-

tion and the head restraint can

be removed, remove the head

restraint.

1-2. Child safety

■

Child restraint system com-
patibility for each seating
position

Compatibility of each seating
position with child restraint sys-
tems (



P.56) displays the type

of child restraint systems that
can be used and possible seat-
ing positions for installation
using symbols.
Also, the recommended child
restraint system that is suitable
for your child can be selected.
Otherwise, check [Recom-
mended child restraint systems
and Compatibility table] for rec-
ommended child restraint sys-
tems. (



P.58)

Check the selected child

WARNING

●

Do not allow the child to lean

his/her head or any part of

his/her body against the door or

the area of the seat, front or rear

pillars, or roof side rails from

which the SRS side airbags or

SRS curtain shield airbags

deploy even if the child is

seated in the child restraint sys-

tem. It is dangerous if the SRS

side and curtain shield airbags

inflate, and the impact could

cause death or serious injury to

the child.

●

When a booster seat is

installed, always ensure that the

shoulder belt is positioned

across the center of the child’s

shoulder. The belt should be

kept away from the child’s neck,

but not so that it could fall off the

child’s shoulder.

●

Use child restraint system suit-

able to the age and size of the

child and install it to the rear

seat.

●

If the driver’s seat interferes

with the child restraint system

and prevents it from being

attached correctly, attach the

child restraint system to the

right-hand rear seat.

●

Adjust the front passenger seat

so that it does not interfere with

the child restraint system.

Child restraint system
compatibility for each
seating position (for
Puerto Rico)

1-2. Child safety

For safety and secu

rity

restraint system together with
the following [Before confirming
the compatibility of each seating
position with child restraint sys-
tems].

■

Before confirming the com-
patibility of each seating
position with child restraint
systems

Checking the child restraint
system standards.
Use a child restraint system
that conforms to UN(ECE)
R44

or UN(ECE) R129

*1, 2

The following approval mark
is displayed on child restraint
systems which are con-
formed.
Check for an approval mark
attached to the child restraint
system.

Example of the displayed regulation
number

UN(ECE) R44 approval
mark

The weight range of the child

who is applicable for an
UN(ECE) R44 approval mark
is indicated.
UN(ECE) R129 approval
mark

The height range of the child
who is applicable as well as
available weights for an
UN(ECE) R129 approval
mark is indicated.

Checking the category of the
child restraint system.
Check the approval mark of
the child restraint system for
which of the following catego-
ries the child restraint system
is suitable.
Also, if there are any uncer-
tainties, check the user’s
guide included with the child
restraint system or contact
the retailer of the child
restraint system.

• “universal”
• “semi-universal”
• “restricted”
• “vehicle specific”

:UN(ECE) R44 and UN(ECE)

R129 are U.N. regulations for
child restraint systems.

:The child restraint systems men-

1-2. Child safety

tioned in the table may not be
available outside of the EU area.

:The displayed mark may differ

depending on the product.

■

Compatibility of each seat-
ing position with child
restraint systems

:Move the front seat fully rear-

ward. If the passenger seat
height can be adjusted, move it
to the upper most position.

:Adjust the seatback angle to the

most upright position. When
installing a forward-facing child
seat, if there is a gap between
the child seat and the seatback,
adjust the seatback angle until
good contact is achieved.

:If the head restraint interferes

with your child restraint system,
and the head restraint can be
removed, remove the head
restraint.
Otherwise, put the head restraint
in the upper most position.

*1, 2, 3

Suitable for “universal” cate-
gory child restraint system
fixed with the seat belt.
Suitable for child restraint
systems given on recom-
mended child restraint sys-
tems and compatibility table
(



P.58).

Suitable for i-Size and ISO-
FIX child restraint system.

Includes a top tether anchor-
age point.

1-2. Child safety

For safety and secu

rity

■

Detail information for child restraint systems installation

: When it is unavoidable to install a rear-facing child restraint system on the

front passenger seat, a child restraint system can be installed it the PAS-
SENGER AIR BAG OFF indicator lamp is lit.

ISOFIX child restraint systems are divided into different “fixture”. The
child restraint system can be used in the seating positions for “fix-
ture” mentioned in the table above. For kind of “fixture” relation, con-
firm the following table.
If your child restraint system has no kind of “fixture” (or if you cannot
find information in the table below), please refer to the child restraint
system “vehicle list” for compatibility information or ask the retailer of
your child seat.

Seating position

Seat position number

Vehicle with front pas-

senger occupant

detection system

Passenger airbag indi-

cator light

OFF

Seating position suitable for

universal belted (Yes/No)

Yes

Forward fac-

ing only

Yes

i-Size seating position

(Yes/No)

Yes

Seating position suitable for

lateral fixture (L1/L2/No)

Suitable rearward facing fix-

ture (R1/R2X/R2/R3/No)

R1,

R2X,

R1,

R2X,

Suitable forward facing fix-

ture (F2X/F2/F3/No)

F2X,

F2, F3

F2X,

F2, F3

Suitable junior seat fixture

(B2/B3/No)

B2, B3

1-2. Child safety

■

Recommended child restraint systems and Compatibility
table

: When it is unavoidable to install a rear-facing child restraint system on the

front passenger seat, a child restraint system can be installed it the PAS-
SENGER AIR BAG OFF indicator lamp is lit.

The child restraint systems mentioned in the table may not be avail-

Fixture

Description

Full-height, forward-facing child restraint systems

Reduced-height forward-facing child restraint systems

F2X

Reduced-height forward-facing child restraint systems

Full-size, rearward-facing child restraint systems

Reduced-size, rearward-facing child restraint systems

R2X

Reduced-size, rearward-facing child restraint systems

Rearward-facing infant seat

Left lateral-facing (carrycot) infant seat

Right lateral-facing (carrycot) infant seat

Junior seat

Mass groups

Recom-

mended

Child

Restraint

System

Seating position

Vehicle with front pas-

senger occupant

detection system

Passenger airbag indi-

cator light

OFF

0, 0+
Up to 28 lb.
(13 kg)

MIDI 2
(Yes/No)

Yes

I
20 to 39 lb.
(9 to 18 kg)

MIDI 2
(Yes/No)

Yes

1-2. Child safety

For safety and secu

rity

able outside the LATIN area.
When securing some types of
child restraint systems in rear
seat, it may not be possible to
properly use the seat belts in
positions next to the child
restraint without interfering with
it or affecting seat belt effective-
ness. Be sure your seat belt fits
snugly across your shoulder and
low on your hips. If it does not,
or if it interferes with the child
restraint, move to a different
position. Failure to do so may
result in death or serious injury.



When installing a child
restraint in the rear seats,
adjust the front seat so that it
does not interfere with the
child or child restraint system.



When installing a child seat
with support base, if the child
seat interferes with the seat-
back when latching it into the
support base, adjust the seat-
back rearward until there is no
interference.



If the seat belt shoulder
anchor is ahead of the child
seat belt guide, move the seat
cushion forward.



When installing a junior seat,
if the child in your child
restraint system is in a very
upright position, adjust the
seatback angle to the most
comfortable position. And if
the seat belt shoulder anchor
is ahead of the child seat belt
guide, move the seat cushion
forward.

A child restraint system for a
small child or baby must itself be
properly restrained on the seat
with the lap portion of the
lap/shoulder belt.

■

Installing child restraint
system using a seat belt
(child restraint lock func-
tion belt)

Install the child restraint system
in accordance to the operation
manual enclosed with the child
restraint system.
For Puerto Rico: If the child
restraint system on hand is not
within the “universal” category

Child restraint system
fixed with a seat belt

1-2. Child safety

(or the necessary information is
not in the table), refer to the
“Vehicle List” provided by the
child restraint system maker for
various possible installation
positions, or check the compati-
bility after asking the retailer of
the child seat. (



P.55, 56)

■

Rear-facing



Infant

seat/convertible seat

Place the child restraint sys-
tem on the rear seat facing
the rear of the vehicle.

Run the seat belt through the
child restraint system and
insert the plate into the
buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt
and allow it to retract to put it

in lock mode. In lock mode,
the belt cannot be extended.

While pushing the child
restraint system down into
the rear seat, allow the shoul-
der belt to retract until the
child restraint system is
securely in place.

After the shoulder belt has

retracted to a point where there is

no slack in the belt, pull the belt to

check that it cannot be extended.

After installing the child
restraint system, rock it back
and forth to ensure that it is
installed securely. (



P.63)

■

Forward-facing



Convert-

ible seat

If installing the child restraint
system to the front passen-
ger seat is unavoidable, refer
to P.52for the front passenger
seat adjustment.

1-2. Child safety

For safety and secu

rity

If the head restraint interferes
with your child restraint sys-
tem, and the head restraint
can be removed, remove the
head restraint.
Otherwise, put the head
restraint in the upper most
position. (



P.132)

Place the child restraint sys-
tem on the seat facing the
front of the vehicle.

Run the seat belt through the
child restraint system and
insert the plate into the

buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt
and allow it to retract to put it
in lock mode. In lock mode,
the belt cannot be extended.

While pushing the child
restraint system into the rear
seat, allow the shoulder belt
to retract until the child
restraint system is securely in
place.

After the shoulder belt has

retracted to a point where there is

no slack in the belt, pull the belt to

Content .. 1 2 3 4 ..
